Quick Installation Guide
Elo Expansion Module
Compatible with following products:
E021201 (15” I-Series Android)
E021388 (22” I-Series Android)
Revision A
P/N E231725
*E231725 REV.A*

M4X32mm LONG,
QTY. 2
M4X7mm LONG,
QTY. 2
M3X8mm LONG,
QTY. 2
100x100mm M4 thread
VESA mount on back of expansion module
1. Remove DC power cover (D) and bottom peripheral cover (E). 3. Assemble micro-USB bracket using screws (C).
2. Assemble expansion module to VESA mount on back of i-Series using screws (A) and
(B). Connect the DC power and micro-USB connections as shown.
4. Connect power supply provided with expansion module to the DC jack on expansion mod-
ule. Continue installation of i-Series Display as desired using stands and mounts available at
www.elotouch.com.
DE
B
A
C
Micro-USB Bracket
DC Jack
