User manual: KIT-NFC-LF/HF-EDGE CONNECT Page 1 of 20
User Manual
Elo Touch Solutions
KIT-NFC-LF/HF-EDGE CONNECT
UM600632 Version: B
Copyright © 2021 Elo Touch Solutions, Inc. All Rights Reserved.

User manual: KIT-NFC-LF/HF-EDGE CONNECT Page 2 of 20
No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or
translated into any language or computer language, in any form or by any means, including, but not limited
to, electronic, magnetic, optical, chemical, manual, or otherwise without prior written permission of Elo Touch
Solutions, Inc.
Disclaimer
The information in this document is subject to change without notice. Elo Touch Solutions, Inc. and its
Affiliates (collectively "Elo") makes no representations or warranties with respect to the contents herein, and
specifically disclaims any implied warranties of merchantability or fitness for a particular purpose. Elo
reserves the right to revise this publication and to make changes from time to time in the content hereof
without obligation of Elo to notify any person of such revisions or changes.
Trademark Acknowledgments
AccuTouch, CarrollTouch, Elo, Elo (logo), Elo Touch, Elo Touch Solutions, Elo TouchSystems, IntelliTouch,
iTouch, SecureTouch, TouchTools and VuPoint are trademarks of Elo and its Affiliates. Windows is a
trademark of Microsoft Corporation.

User manual: KIT-NFC-LF/HF-EDGE CONNECT Page 3 of 20
Content
Chapter 1 Introduction.......................................................................................................................4
Chapter 2 Installation Guide ..............................................................................................................5
Chapter 3 Getting Started Guide .......................................................................................................8
Chapter 4Technical Support ...........................................................................................................15
Chapter 5 Safety and Regulatory Information................................................................................16
Chapter 6Warranty Information ......................................................................................................19

User manual: KIT-NFC-LF/HF-EDGE CONNECT Page 4 of 20
Chapter 1 Introduction
Product description
This product, as an add-on to Elo's main products, improves compatibility with Elo products and
applications. This product is easy to install and provides users with a convenient installation method
to reduce the need for external brackets or other accessories.
Product specifications
Basic model
KIT, RFID, LF/HF, USB, EDGE CONNECT
color
black
size
119.6mm x 68.5mm x 29.1mm
power supply
5VDC ± 5%
The host interface
USB2.0
Operating temperature
10°C-40°C (50°F-104°F)
Working humidity
20% - 80%
Storage temperature
0°C-50°C (32°F-122°F)
Store humidity
10% - 90%
buzzer
backing

User manual: KIT-NFC-LF/HF-EDGE CONNECT Page 5 of 20
Chapter 2 Installation Guide
Open the product package
Confirm that the box contains :
•RFID devices
•2 mounting screws
•2 pieces of mela screw cover
•Quick installation guide
Remove all protective materials from the device.
Check the device for signs of damage.
If the device is damaged or missing any of the parts listed above, report them immediately.
Product installation
Note: The following images may vary for different products.
Step 1: Select location to mount the RFID
device.
Step 2: Remove the selected peripheral
interface cover from the side of the main
device.

User manual: KIT-NFC-LF/HF-EDGE CONNECT Page 6 of 20
Step 3: Gently press the RFID device into the
peripheral bracket to ensure that the
connector is properly paired.
Step 4: Install the two screws of the
accessory bag.
(Note: Do not adjust the angle of the NFC reader
without screws, as this may cause damage.)
Step 5: Attach the screws in the accessory
bag to protect the mera and adjust the angle
as needed.

User manual: KIT-NFC-LF/HF-EDGE CONNECT Page 7 of 20
Install Software and Drivers
Windows Platform:
•Download the corresponding driver by visiting the linked website below.
http://www.hidglobal.com/drivers.
oOMNIKEY 5x27 CCID Driver
oOMNIKEY 5x27 EEM Driver
Android platform :
•Download the corresponding installation APK by visiting the link website below.
http://www.hidglobal.com/drivers.
Other platforms:
•Please visit and search for information via the link below.
http://www.hidglobal.com

User manual: KIT-NFC-LF/HF-EDGE CONNECT Page 8 of 20
Chapter 3 Getting Started Guide
Easy Tools to Use
OMNIKEY® Workbench Tool is a stand-alone application that allows you to easily diagnose and
configure RFID devices. The application runs on Windows, macOS, and Linux, using the same
graphical user interface on all platforms.
Here's an example of a Windows platform.
•Find the Workbench Tool tool for the corresponding number of system bits by visiting the linked
website below.
http://www.hidglobal.com/drivers.
Overview
The main window consists of the application menu on the left and the content pane on the right.
The application menu allows you to navigate the application.
List of Available Devices and Diagnostic Options
The RFID devices that PC wants to connect to are shown in the list of card readers below, and
after selecting the devices in the list, you can see all the relevant configuration tabs (blue frame).
The tab contains basic information about the connected smart card reader. All information in this
tab is fixed and cannot be changed. Displays a product image so that you know which device you
are using.

User manual: KIT-NFC-LF/HF-EDGE CONNECT Page 9 of 20
Card Diagnostic Options
The Card Diagnostics option contains information about the current smart card, such as ATR,
PACS bits, and card descriptions.

User manual: KIT-NFC-LF/HF-EDGE CONNECT Page 10 of 20
If PACS data is available and PACS data has been successfully obtained from a card, the value of
the PACS data is displayed in the Raw PACS text box. To decode the data, select the encoding
format in the PACS Format area, and then click Resolve. The application allows you to select or
define your own custom formats from popular predefined formats.
Device Settings Options
In the READER SETTINGS option Device mode switching, the device supports keyboard mode
and CCID mode.
The device also supports the Ethernet Emulation Module (EEM) interface feature. The EEM
interface allows USB-connected hosts to access TCP/IP services, such as built-in web servers. All
CCID commands can be pushed to the device via HTTP via the EEM interface. The EEM interface
is turned on by default.

User manual: KIT-NFC-LF/HF-EDGE CONNECT Page 11 of 20
The support card agreement is set in the READER SETTINGS tab below.
However, modifying the configuration of the device does not take effect immediately and requires
the following settings:
•Click APPLY to confirm the change.
•Click RESTORE to restore the RFID device to factory settings.
APPLY and RESTORE settings require a USB reconnection, which causes the reader to disappear
briefly from the list of available readers.

User manual: KIT-NFC-LF/HF-EDGE CONNECT Page 12 of 20
Device Firmware Updates
Workbench Tool supports upgrading and uploading device profiles. Supports uploading firmware,
SE processor firmware, and device configuration information in one operation. Uploads can be
done through WBO or CFG files. WBO files can contain core firmware, SE processor firmware,
and any combination of additional profiles. A CFG file is a snapshot of the reader configuration
generated by the reader's web server. To ensure optimal reader performance, it is recommended
that you always use the latest available WBO files to get the latest firmware from the HID official
link below.
https://www.hidglobal.com/developer-center.
Note: Access to the HID Developer Center requires a license key account, which can be obtained by placing an order.

User manual: KIT-NFC-LF/HF-EDGE CONNECT Page 13 of 20
Update the estimation steps:
•Select the READER UPLOAD option.
•Click LOAD FILE and select the WBO or CFG file that needs to be updated.
Note: The path to place the firmware cannot be too long, and too long a path can easily cause the loading of files to fail.
After loading the WBO file, you can compare the firmware version currently installed on the device
with the version in the file and decide whether to proceed with the upgrade process.
Once you have confirmed the firmware upgrade, click the UPLOAD option and wait for the upgrade.

User manual: KIT-NFC-LF/HF-EDGE CONNECT Page 14 of 20
Note: The path to place the firmware cannot be too long, and too long a path can easily cause the loading of files to fail.
During the upgrade process, do not disconnect the device or close the application, or allow interruptions such as restart,
shutdown, or power outage, as this can seriously damage the device.
More Device Settings
For more detailed settings files for your device, please visit the official HID website
www.hidglobal.com search for the following files:
•OMNIKEY 5x27CK Software Developer Guide
•OMNIKEY® 5X27CK KEYBOARD WEDGE CONFIGURATION AND CUSTOM REPORT USER GUIDE

User manual: KIT-NFC-LF/HF-EDGE CONNECT Page 15 of 20
Chapter 4Technical Support
Technical Assistance
For global technical support phone numbers, see the last page of this user manual.
Technical
specifications
For technical specifications for this
device, visit the website
www.elotouch.com/products
Self-help online
Visit the website for an online self-
service
www.elotouch.com/go/websupport
Technical support
Please visit the website for
technical support
www.elotouch.com/go/contactsuppo
rt

User manual: KIT-NFC-LF/HF-EDGE CONNECT Page 16 of 20
Chapter 5 Safety and Regulatory Information
Electrical Safety Information
The voltage, frequency and current requirements indicated by the manufacturer's label must be
met. If these restrictions are not adhered to, connecting to a non-specified power supply can result
in abnormal operation, equipment damage, or fire.
There are no serviceable parts for the operator inside the equipment. The hazardous voltage
generated by the equipment is a safety hazard. Repairs can only be carried out by qualified service
technicians.
If you have questions about the installation, contact a qualified electrician or manufacturer before
powering the device on.
Emissions and Immunity Information
U.S. Users Note: This device has been tested and meets the limits of Class A digital devices under
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in residential installations. This equipment generates, uses and radiates radio
frequency energy, which, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications.
Canadian Users Note: This equipment complies with the Class A radio noise emission limits for
digital equipment set out in the Canadian Industrial Radio Interference Regulations.
NOTES: Use only the power cords and interconnect cables supplied with the device.
Replacement of wires and cables provided may endanger electrical safety or CE mark certified
emissions or exemptions as required by the following standards:
This Information Technology Equipment (ITE) requires a CE mark on the manufacturer's label,
which means that the device has been tested for the following instructions and standards: This
device has met the European standard EN 55032 Class A EMC Directive 2014/30/EU and
European standard EN 60950-1 Low Voltage Directive 2014/35/EU CE marking requirements.
General information for all users: The device generates, uses, and radiates radio frequency energy.
If not installed and used in accordance with this manual, the equipment may interfere with radio
and television communications. However, there is no guarantee that interference will not occur due
to site-specific factors in any particular installation.
1.In order to meet emission and immunization requirements, users must comply with the following
regulations:
a. Connect the digital device to any computer using only the provided I/O cable.
b. To ensure compliance, use only the manufacturer-approved power cord provided.

User manual: KIT-NFC-LF/HF-EDGE CONNECT Page 17 of 20
c. Remind the user that changes or modifications to the device that are not expressly approved by the compliance
responsible party may invalidate the user's authority to operate the device.
2.If the device appears to be interfering with radio or television reception or any other device.
Confirm as an emission source by turning the device off and on. If you determine that the device is
causing the interference, try one or more of the following measures to correct the interference:
a.Move the digital device away from the affected receiver.
b.Reposition (rotate) the digital device relative to the affected receiver.
c.Relocate the affected receiver antenna.
d.Plug digital devices into different AC sockets so that digital devices and receivers are on different branch circuits.
e.Disconnect and remove any I/O cables that the device does not use. (Untired I/O cables are a potential source of
high RF emission levels.)
f.Plug the digital device into the ground socket. Do not use the AC power adapter plug. (Removing or cutting the
power cord to ground may increase the RF emission level and may pose a deadly risk of electric shock to the user.)
If you need additional help, consult your dealer, manufacturer, or experienced radio or television
technician.
Radio Equipment Instructions
Elo hereby declares that the type of radio device complies with the 2014/53/EU Directive. EU
Declaration of Conformity is available at:www.elotouch.com
This equipment is for indoor use only.
Obtained Certification
This peripheral has been certified and marked as follows:
•UL, FCC (US) –Class B
•cUL, IC (Canada)
•CB (International Safety)
•SRRC(China)
•CE (Europe) –Class B
•VCCI (Japan)
•RCM (Australia)
•China RoHS

User manual: KIT-NFC-LF/HF-EDGE CONNECT Page 18 of 20
Explain the mark
In accordance with the requirements of SJ/T11364, electrical and electronic products
should be marked with the following pollution control signs.
This product has an environmentally friendly life of 10 years. This product will not leak
or mutate under the following operating conditions, and the use of this electronic
product will not cause serious environmental pollution, personal injury or property
damage.
Encourage and recommend that product packaging be recycled and reused in
accordance with local laws.
Waste Electrical & Electronic Equipment Directive (WEEE)
Do not dispose of this product as household waste after it is scrapped. It should be recycled
into the recycling plant.
Elo already has recycling bins in some parts of the world. For information on these activities,
visit:www.elotouch.com/e-waste-recycling-program/
China RoHS
In accordance with Chinese law, the Measures for the Regulation of the Restricted Use of
Hazardous Substances in Electrical and Electronic Products, the following sections list the names
and contents of hazardous substances that may be contained in the
product.

User manual: KIT-NFC-LF/HF-EDGE CONNECT Page 19 of 20
Chapter 6Warranty Information
For warranty information, please visit http://support.elotouch.com/warranty/

User manual: KIT-NFC-LF/HF-EDGE CONNECT Page 20 of 20
www.elotouch.com
Visit our website for the latest
Product information
The instructions
Event preview
Press releases
Software-driven
For more information on the product range of Elo touch solutions, visit our website www.elotouch.com
or call your nearest office.
North America
Tel: [phone]
Fax: [phone]
and[email protected]
Europe
Tel: [phone]
Fax: [phone]
EMEA. [e-mail]
Asia pacific
Tel: [phone]
Fax: [phone]
[email protected]
Latin America
Tel: [phone]
[email protected]
