Models: S450R / S500R / S650R / S700R
EMFI16030756
THIS FILTER OPERATES UNDER HIGH PRESSURE. WHEN ANY PART OF THE CIRCULATING
SYSTEM (e.g., CLAMP, PUMP, FILTER, VALVES, ETC.) IS SERVICED, AIR CAN ENTER THE
SYSTEM AND BECOME PRESSURIZED . PRESSURIZED AIR CAN CAUSE THE LID OR VALVE TO
BE BLOWN OFF WHICH CAN RESULT IN SEVERE INJURY, DEATH, OR PROPERTY DAMAGE
TURN PUMP OFF BEFORE CHANGING VALVE POSITION.
WARNING
!
!
TO PREVENT DAMAGE TO THE PUMP AND FOR PROPER OPERATION OF THE SYSTEM,
CLEAN PUMP STRAINER AND SKIMMER BASKETS REGULARLY.
!
By-passes filter for circulating water to pool
Used after backwash to flush dirt from valve
Cleaning Filter by reversing the flow
By-passes filter, used for vacuuming to waste or lowering water level
CLOSED Shuts off all flow to filter or pool
RECIRCULATE
WASTE
RINSE
BACKWASH
FILTER
Valve Position
Normal Filtration and Vacuuming
Function
DO NOT UNSCREW SCREWS OF FLANGE CLAMP WHILE PUMP IS RUNNING.
!
FUNCTIONS OF VALVE POSITIONS
GENERAL
1) Pipe tap boss provided for optional influent pressure gauge.
2) SERVICING VALVE( Stop pump,close gate valve in suction&discharge before proceeding):
a) Set handle in filter position. b) Remove cover screws. c) Lift cover and key assembly out.
TO ASSEMBLE:
1 Place valve key so that wedge opening is at TOP port (handle in Filter psn.). Flat edge of cover screw lug
should align with flat edge of body screw lug.
2) Position cover O'Ring.
3) Secure assembly to body with cover screws. Tighten cover screws evenly and alternately. Do not over-
tighten.
)
WASTE
FILTER
BACKWASH RINSE
WASTE
RECIRCULATE
CLOSED
WASTE WASTE
WASTE WASTE WASTE
IN FLOW OUT FLOW IN FLOW OUT FLOW IN FLOW OUT FLOW
IN FLOW OUT FLOW IN FLOW OUT FLOW IN FLOW OUT FLOW
FUNCTION
The filter uses special filter sand to remove dirt particles from pool water. The filter sand is loaded into the filter tank
functions as the permanent dirt removing media.When the control valve is in the FILTER position, the pool water which
contains suspended dirt particles, is pumped through your piping system and is automatically directed by the patented
filter control valve to the top of the filter tank.As the pool water is pumped through the filter, dirt particles are trapped by
the sand bed, and filtered out. The cleaned Pool water is returned from the bottom of the filter tank, through the control
valve and back to the pool through the piping system. This entire sequence is continuous and automatic and provides
for total recirculation of pool water through your filter and piping System. After a period of time the accumulated dirt in
the filter causes a resistance to flow, and the flow diminishes. This means it is time to clean your filter. With the control
valve in the BACKWASH position, the water flow is automatically reversed through the filter so that it is directed to the
bottom of the tank, up through the sand, flushing the previously trapped dirt and debris out the waste line. Once the filter
is back-washed of dirt, set control valve to RINSE position and run pump for about 1/2 to 1 minute, and then to filter, to
resume normal filtering.
and
NOTE: Turn pump off before changing valve position.
Pipe sealant for plastic adapters are required to install and service the filter.
1) The filter should be placed on a level concrete slab, very firm ground, or equivalent. Position the filter so that the piping
connections, control valve are convenient and accessible for operation and service.
2) Loading the sand media. Filter sand media is loaded through the top opening of the filter.
a) Place tow O'ring on the side of the filter tank and Connect control valve to the filter using pipes with unions and
glues.(see the fig on page4).
b) Loosen the Ring lock Nut by 2 handles and remove the valve.
c) We recommend filling tank approximately 1/3 way with water to provide a cushion effect when the filter sand is
poured in. This helps protect the under-drain laterals from excessive shock.
d) Carefully pour in correct amount and grade of filter sand. Sand surface should be leveled and should come to about
the middle of the filter tank.
INSTALLATION

REPLACEMENT PARTS OF MULTIPORT VALVE
2-4
MAIN DIMENSION
3-4
DIMENSION TABLE
455
535
635
723
1.5"
1.5"
1.5"
1.5"
Model
A
High
mm
B
Diameter
mm
Valve Port
Size
Inch
Sand
Kg
45
85
145
210
760
825
890
920
S450R
S500R
S650R
S700R
B
A
1
2
3
4
5
6
7
8
9
10
11
12
13 14
15
16 17
18
19
20
21
22
23
24
25
16
16
18
18
REPLACEMENT PARTS OF FILTER
Key No .
Part N o.
Prod uct Des cript ion
Qty
1
0101 3002
Hand le (Sma ll)
1
2
0301 8008
Pin fo r Handl e
1
3
0118 1001
Wash er for Ha ndle
1
4
8928 1203
M6×2 5 Screw w ith Nut f or Camb er Lid
6
8928 0107
M6*30 S crew wi th Nut fo r Stand ard Lid
6
5
0101 3004
1.5"Side M ount Va lve Sta ndard L id (Bla ck)
1
6
0201 1022
O-Ring f or 1.5" Valv e Rotor
2
7
0118 1002
Wash er for Sp ring
1
8
0201 1002
O-Ring f or 1.5" Valv e Lid
1
9
0301 4001
Spri ng for 1.5" Si md Moun t Valve
1
10
0102 1001
1.5" Valv e Rotor
1
11
0231 1002
Spid er Gask et
1
12
0101 3009
1.5" Side M ount Va lve Bot tom Bod y (Blac k)
1
13
0111 1048
Conn ector f or Pres sure Ga uge/Stop per
1
14
8902 1303
Drai n Plug wi th O-ring
1
15
0601 1029
Oil Pr essur e Gauge W ith O-rin g (40ps i)
1
16
0201 1151
O-Ring
5
17
0101 3018
1.5"Unio n Tale (B lack)
1
18
0101 3017
1.5" Unio n Nut (Bl ack)
5
19
8928 0104
Sigh t Glass w ith O-Rin g
1
20
0101 3120
1.5" Side M ount Va lve Plu g (Blac k)
1
21
0101 3117
1.5" Elbo w Tube (B lack) 1 75mm
1
0101 3116
1.5" Elbo w Tube (B lack) 1 20mm
1
22
0117 1002
1.5" Unio n Adapt or (Met ric)
1
23
0101 3015
1.5"Conn ector w ith Ext ernal T hread(Black)
3
24
0201 1003
O-Ring f or Unio n Adapt or
3
25
0117 1153
1.5"Unio n Adapt or
3
3) Tighten the Ring Lock Nut by 2 handles and make sure the nut is “sand free” on its thread.
a)
)
4) Connect pump to control valve opening marked PUMP.
5) Make return to pool pipe connection to control valve opening marked RETURN and complete other
necessary plumbing connections, suction lines to pump, waste, etc.
6) Make electrical connections to pump per pump instructions.
7) To prevent water leakage, be sure all pipe connections are right.
Install the valve.
Carefully screw the T-shape Exhaust Switch onto the filter lid and make sure there do not over-tighten.
b Ensure T-Shape Exhaust switch is tight fit to filter lid and turn it easily.
1) Be sure correct amount of filter media sand is in tank and that all connections have been made and are secure.
2) Depress control valve handle and rotate to BACKWASH position. (To prevent damage to control valve seal,
always depress handle before turning.)
3) Prime and start pump according to pump instructions (be sure all suction and return lines are open), allowing the
filter tank to fill with water. Once water is flowing out of the waste line, run the pump for at least 1 minute. The
initial back-washing of the filter is recommended to remove any impurities or fine sand particles in the sand
media.
4) Turn pump off and set valve to RINSE position. Start pump and operate until water in sight glass is clear, about 1/2
to 1 minute. Turn pump off and set valve to FILTER position and restart pump.The filter is now operating in the
normal filter mode, filtering dirt particles from the pool water.
5) Adjust pool suction and return valves to achieve desired flow. Check system and filter for water leaks and
tighten connections, bolts, nuts, as required.
6) Note the initial pressure gauge reading when the filter is clean. (It will vary from pool to pool depending upon the
pump and general piping system.) As the filter removes dirt and impurities from the pool water, the
accumulation in the filter will cause the pressure to rise and flow to diminish. When the pressure gauge reading is
1.5 bar, higher than the initial "clean" pressure you noted, it is time to backwash the filter (see BACKWASH under
filter and control valve functions).
NOTE: During initial clean-up of the pool water it may be necessary to backwash frequently due to the unusually
heavy initial dirt load in the water.
INSTALL/START-UP OF FILTER
Key No .
Part N o.
Desc ripti on
Qty
1
0127 1012
Ring lock Nu t
1
2
0102 1004
Span ner for R ingLo ck
1
3
0601 1029
Maxi mum 40P SI Indi catio n, Stai nless Steel Casi ng
1
4
8901 4027
T-Sh ape Exh uaust S witch
1
5
0120 1020
Cove r
1
6
0201 0033
O-Ri ng for Co ver
1
7
8901 0648
S450 R ingLo cK Filt er tank
1
7
8901 0649
S500 R ingLo cK Filt er tank
1
7
8901 0650
S650 R ingLo cK Filt er tank
1
7
8901 0651
S700 R ingLo cK Filt er tank
1
7
8901 1204
S700 (B) Rin gLocK F ilter t ank
1
8
8901 1309
The in ner tan k syste m for S45 0R
1
8
8901 1310
The in ner tan k syste m for S50 0R
1
8
8901 1311
The in ner tan k syste m for S65 0R
1
8
8901 1312
The in ner tan k syste m for S70 0R
1
8
8901 1203
The in ner tan k syste m for S70 0R(B)
1
9
0111 1046
1.5" Tank Sy stem Su pport
1
9
0110 1065
2.0" Tank Sy stem Su pport
1
10
0201 1003
O-Ri ng for 1. 5" adap tor
2
10
0202 0016
O-Ri ng for Co nnect or
2
11
88280810B
6 Way 1. 5" Valv e with Pi ping Ki t, 1.5" u nion set x 3
and pr essur e gauge ( Black )
1
11
88280813B
6 Way 2" V alve wi th Pipi ng Kit, 2 " union s et x 3 and
pres sure ga uge (Bl ack)
1
12
0117 2007
Late rals( 115mm )
8
12
0117 2008
Late rals (1 26mm)
8
12
0117 2010
Late rals (1 85mm)
8
13
0111 1059
16-2 1inch F ilter B ase
1
13
0111 1062
21-2 8inch F ilter B ase
1
14
8901 0107
Wate r Drain S et
