Endress+Hauser Liquiport 2010 CSP44 User manual

Products Solutions Services
BA00470C/07/EN/15.13
71214527
Valid as of:
Softwareversion 01.04.00
Operating Instructions
Liquiport 2010 CSP44
Automatic sampler for liquid media
Maintenance & diagnostics
AUTHORIZED DISTRIBUTOR:
InstrumentsAndControl.com
Houston, Texas USA
[email protected]
281-609-7170

About this manual
This manual describes all the tasks you must perform for maintenance, diagnostics and repair.
A description of the following is provided here:
• General troubleshooting
• Overview of diagnostic messages
• Description of the information in the "Diagnostics" menu
– Diagnostics list
–Logbooks
– System information
–Outputstatus
–Systemtest/Reset
–Sensorchange
– Manual hold
– Term information
– Simulation
– Sensor information
• Cleaning and maintenance
• Accessories and spare parts
This manual does not include the following:
• Setup/General settings
--> Operating Instructions BA00465C "Commissioning"
• Display/Operation
--> Operating Instructions BA00465C "Commissioning"
•Inputs
--> Operating Instructions BA00492C "Operation & settings"
•Outputs
--> Operating Instructions BA00492C "Operation & settings"
• Sampling programs
--> Operating Instructions BA00492C "Operation & settings"
• Additional functions
--> Operating Instructions BA00492C "Operation & settings"
• Data management
--> Operating Instructions BA00492C "Operation & settings"
•Calibration
--> Operating Instructions BA00493C "Calibration"
•Expert
--> Internal Service Manual

Endress+Hauser
Liquiport 2010 CSP44
Table of contents
1 Diagnostics and
troubleshooting . . . . . . . . . . . . . 4
1.1 General troubleshooting . . . . . . . . . . . . . . 4
1.2 Diagnostic information on local display 11
1.3 Adjusting diagnostic information . . . . . 11
1.4 Overview of diagnostic information . . . 14
1.5 Pending diagnostic messages . . . . . . . . . 33
1.6 Diagnostic list . . . . . . . . . . . . . . . . . . . . . . 33
1.7 Logbooks . . . . . . . . . . . . . . . . . . . . . . . . . . 34
1.8 Device information . . . . . . . . . . . . . . . . . 41
1.9 Resetting the measuring device . . . . . . . 42
1.10 Runtime info . . . . . . . . . . . . . . . . . . . . . . 44
1.11 Status of inputs/outputs . . . . . . . . . . . . . 44
1.12 Sensor replacement (for version with
sensors with the Memosens protocol) . 45
1.13 Manual hold (for version with sensors with
the Memosens protocol) . . . . . . . . . . . . . 45
1.14 Firmware history . . . . . . . . . . . . . . . . . . . 46
2 Maintenance. . . . . . . . . . . . . . . 47
2.1 Recommended maintenance . . . . . . . . . 47
2.2 Replacing the pump tube . . . . . . . . . . . . 48
2.3 Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . 50
2.4 Replacing the storage batteries . . . . . . . 53
2.5 Calibration . . . . . . . . . . . . . . . . . . . . . . . . 54
2.6 Simulation . . . . . . . . . . . . . . . . . . . . . . . . 54
3 Repair. . . . . . . . . . . . . . . . . . . . . 56
3.1 Spare parts . . . . . . . . . . . . . . . . . . . . . . . . 56
3.2 Return . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
3.3 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
4 Accessories . . . . . . . . . . . . . . . . 58
4.1 Accessories for Liquiport 2010 CSP44 . 58
4.2 Measuring cable . . . . . . . . . . . . . . . . . . . . 58
4.3 Sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Index. . . . . . . . . . . . . . . . . . . . . . 63

Diagnostics and troubleshooting Liquiport 2010 CSP44
4Endress+Hauser
1 Diagnostics and troubleshooting
The sampler continuously monitors its own functions.
The color of the display background changes to red if a diagnostics message for error category
"F" occurs.
The LED beside the display flashes red if a diagnostics message for error category "M" occurs.
1.1 General troubleshooting
1.1.1 Troubleshooting
A diagnostic message appears on the display, measured values are not plausible or you
encounter a problem.
1. See the Diagnostics menu for details on the diagnostic message.
Follow the instructions to rectify the problem.
2. If this does not help: Search for the diagnostic message under "Overview of diagnostic
information" () in this manual. Use the message number as a search criterion. Ignore the
letters indicating the Namur error category.
Follow the troubleshooting instructions provided in the last column of the error tables.
3. If the measured values are implausible, the onsite display is faulty or you encounter other
problems, search under "Process errors without messages" (ä4) or "Device-specific errors"
(ä10).
Follow the recommended measures.
4. Contact the Service Department if you cannot rectify the error yourself. Only cite the error
number.
1.1.2 Process errors without messages
pH/ORP measurement
Problem Possible cause Tests and/or remedial measures
Display values deviate
from reference
measurement
Incorrect calibration Repeat the calibration.
Where necessary, check and repeat the calibration
with the reference device.
Sensor fouled Clean the sensor.
Temperature measurement Check the temperature measured values of both
devices.
Temperature compensation Check the settings for temperature compensation
and adjustment for both devices.

Liquiport 2010 CSP44 Diagnostics and troubleshooting
Endress+Hauser 5
Measuring chain
zero-point cannot be
adjusted
Contaminated reference system Test with new sensor
Junction clogged Clean or grind junction
Asymmetric sensor voltage too high Clean junction or test with another sensor
No change or subtle
change in display
– Sensor fouled
–Sensorold
– Sensor defective (reference lead)
Clean the sensor.
Reference has low level of KCl Check KCl supply: 0.8 bar (12 psi) over medium
pressure
Measuring chain slope:
– Cannot be adjusted
–Tolow
–Noslope
Device input defective Check device directly.
–Sensorold
– Hair-line crack in the glass
membrane
Renew sensor.
Constant, incorrect
measured value
Sensor does not immerse properly
or protection cap not removed
Check installation position, remove protection cap.
Air pockets in assembly Check assembly and orientation.
Ground fault at or in device Perform test measurement in isolated vessel, with
buffer solution if applicable.
Hair-line crack in the glass
membrane
Renew sensor.
Device in impermissible operating
condition (does not respond when
key pressed)
Switch off device and switch it on again.
Incorrect temperature
value
Sensor failure Replace sensor
Fluctuations in measured
value
Interference on signal output cable Check cable routing, route cable separately if
necessary.
Interference potential in medium Eliminate source of interference or ground medium
as close as possible to sensor.
No current output signal Cable disconnected or shortcircuited Disconnect cable and measure directly at device.
Output defective See "Device-specific errors" section.
Fixed current output
signal
Current simulation active Switch off simulation.
Incorrect current output
signal
Total load in current loop too high Measure the load and reduce it to the permitted
value if necessary (--> Technical data, BA
"Commissioning").
EMC (interference coupling) Check wiring. Identify and eliminate cause of
interference.
Problem Possible cause Tests and/or remedial measures

Diagnostics and troubleshooting Liquiport 2010 CSP44
6Endress+Hauser
Conductivity measurement
Problem Possible cause Tests and/or remedial measures
Display values deviate
from reference
measurement
Incorrect calibration Repeat the calibration.
Where necessary, check and repeat the calibration
with the reference device.
Sensor fouled Clean the sensor.
Temperature measurement Check the temperature measured values of both
devices.
Temperature compensation Check the settings for temperature compensation
and adjustment for both devices.
Display values deviate
from reference
measurement
Polarization fields Use suitable sensor:
• Larger cell constant
• Graphite instead of stainless steel (observe
material resistance properties)
Implausible measured
values:
– Measured value
constantly 000
– Measured value too low
– Measured value too
high
– Measured value frozen
– Current output value
not as expected
Short-circuit/moisture in sensor Check sensor.
Short-circuit in cable or socket Check cable and socket.
Disconnection in sensor Check sensor.
Disconnection in cable or socket Check cable and socket.
Incorrect cell constant setting Check cell constant.
Incorrect output assignment Check assignment of measured value to current
signal.
Air pockets in assembly Check assembly and orientation.
Ground fault at or in device Measure in isolated vessel.
Device in impermissible operating
condition (does not respond when
key pressed)
Switch off device and switch it on again.
Incorrect temperature
value
Sensor failure Replace sensor

Liquiport 2010 CSP44 Diagnostics and troubleshooting
Endress+Hauser 7
Oxygen measurement
Measured value in process
incorrect
No/incorrect temperature
compensation
ATC: select type of compensation; if linear, set
suitable coefficients.
MTC: set process temperature.
Incorrect temperature measurement Check temperature measured value.
Bubbles in medium Suppress formation of bubbles by:
– Gas bubble trap
– Creating counterpressure (orifice plate)
– Measurement in bypass
Flow rate too high (can lead to
bubble formation)
Reduce flow rate or select less turbulent mounting
location.
Voltage potential in medium (only
for conductive)
Ground medium close to sensor.
Sensor fouling or buildup on sensor Clean sensor (see "Cleaning the conductivity sensors"
section).
Fluctuations in measured
value
Interference on signal output cable Check cable routing, route cable separately if
necessary.
Interference potential in medium Eliminate source of interference or ground medium
as close as possible to sensor.
Interference on measuring cable Connect cable shield as per wiring diagram.
No current output signal Cable disconnected or shortcircuited Disconnect cable and measure directly at device.
Output defective See "Device-specific errors" section.
Fixed current output
signal
Current simulation active Switch off simulation.
Incorrect current output
signal
Total load in current loop too high Measure the load and reduce it to the permitted
value if necessary (--> Technical data, BA
"Commissioning").
EMC (interference coupling) Check wiring. Identify and eliminate cause of
interference.
Problem Possible cause Tests and/or remedial measures
Display value - - - -
Sensor failure Test with new sensor
Sensor cable disconnected Check cable or cable extension.
Incorrect sensor connection Check the connection at input module (--> BA
"Commissioning", "Wiring" section).
Electronics module defective Replace the module.
Problem Possible cause Tests and/or remedial measures

Diagnostics and troubleshooting Liquiport 2010 CSP44
8Endress+Hauser
No change or subtle
change in display
– Sensor fouled
– Sensor old (membrane)
• Clean the sensor.
• If necessary:
– Change electrolyte, change membrane cap
(amperometric sensor)
– Change fluorescence cap (optical sensor)
Constant, incorrect
measured value
Device in impermissible operating
condition (does not respond when
key pressed)
Switch off device and switch it on again.
Measured value too low
Membrane fouled Clean or replace cap
Electrolyte exhausted or
contaminated
Change electrolyte
Anode coating worn Repolarize sensor
Black anode coating Regenerate sensor in factory
Measured value too high
Air pocket under membrane Clean sensor, optimize installation where necessary
Polarization not complete Wait until polarization time elapses (--> Technical
data in sensor operating manual)
Implausible measured
value
Incorrect temperature measurement Check/correct value.
Incorrect altitude setting Incorrect calibration
Reset and repeat calibration.
Incorrect air pressure
Incorrect temperature
value
Incorrect sensor connection Check the connection at input module (--> BA
"Commissioning", "Wiring" section).
Temperature sensor defective Replace sensor
Fluctuations in measured
value
Interference on signal output cable Check cable routing, route cable separately if
necessary.
Interference potential in medium Eliminate source of interference or ground medium
as close as possible to sensor.
No current output signal Cable disconnected or shortcircuited Disconnect cable and measure directly at device.
Output defective See "Device-specific errors" section.
Fixed current output
signal
Current simulation active Switch off simulation.
Incorrect current output
signal
Total load in current loop too high Measure the load and reduce it to the permitted
value if necessary.
EMC (interference coupling) Disconnect both output cables and measure directly
at device.
Problem Possible cause Tests and/or remedial measures

Liquiport 2010 CSP44 Diagnostics and troubleshooting
Endress+Hauser 9
Turbidity and nitrate measurement
Problem Possible cause Tests and/or remedial measures
Display value - - - -
Sensor failure Test with new sensor
Sensor cable disconnected Check cable or cable extension.
Incorrect sensor connection Check the connection at input module (--> BA
"Commissioning", "Wiring" section).
Electronics module defective Replace the module.
No change or subtle
change in display
Sensor fouled Clean the sensor.
Constant, incorrect
measured value
Device in impermissible operating
condition (does not respond when
key pressed)
Switch off device and switch it on again.
Implausible measured
value
Sensor not calibrated or incorrectly
calibrated
Calibration with original sample might be necessary
for concentration or solids content.
Sensor fouled Clean sensor
Sensor installed in "dead zone" or air
pocket in assembly or flange
Check installation position, move sensor to area that
receives good flow. Pay attention when mounting in
horizontal pipes
Incorrect sensor orientation Align sensor:
•Normalmedia:
Direct flow to measuring window
• For high solids content:
Align measuring window at angle of 90˚to flow
Incorrect temperature
value
Incorrect sensor connection Check the connection at input module (--> BA
"Commissioning", "Wiring" section).
Temperature sensor defective Replace sensor
Fluctuations in measured
value
Interference on signal output cable Check cable routing, route cable separately if
necessary.
Irregular flow / turbulence / air
bubbles / large solid particles
Select a better mounting location or reduce
turbulence, use a large measured value damping
factor if necessary
Set gas bubble threshold to 100 %
No current output signal Cable disconnected or shortcircuited Disconnect cable and measure directly at device.
Output defective See "Device-specific errors" section.
Fixed current output
signal
Current simulation active Switch off simulation.
Incorrect current output
signal
Total load in current loop too high Measure the load and reduce it to the permitted
value if necessary.
EMC (interference coupling) Disconnect both output cables and measure directly
at device.
Value switches to zero and
back to measured value
Air bubbles Do not mount sensor above aeration discs

Diagnostics and troubleshooting Liquiport 2010 CSP44
10 Endress+Hauser
1.1.3 Device-specific errors
Problem Possible cause Tests and/or remedial measures
The device cannot be
switched on/display remains
dark
No supply voltage Check if voltage supplied
Basic module defective Replace basic module
Values appear on display
but:
– Display does not change
and / or
– Device cannot be
operated
Module not wired correctly Check modules and wiring
Impermissible operating system
condition
Switch off device and switch it on again
Control signals are not
accepted or outputs do not
switch
Incorrect program setting Check program setting
Incorrect wiring Check wiring
Electronics failure Replace basic module
Sample not representative
Siphon in sampling hose Check sampling hose
Connection not air-tight/sampling
hose taking in air
– Check tubes/connections
– Check the sampling hose is routed correctly
Bottles not being filled correctly – Incorrect distribution selected in the controls
– Calibrate the distribution arm
Distribution arm does not move – Incorrect distribution selected in the controls
– Check distribution arm connection
– Distributor defective, replace distributor or
– Have repaired by E+H Service
Incorrect bottle filled – Incorrect distribution selected in the controls
Wrong pump tube Only use genuine pump tube
Faulty sensory mechanism Replace sensory mechanism (contact E+H
Service)
No sampling
Connection leaking Check tubes/connections for leaks
Sampling hose taking in air Check the sampling hose is routed correctly
Wrong pump tube Only use genuine pump tube
Faulty sensory mechanism Replace sensory mechanism (contact E+H
Service)
Implausible measured values
(only for version with
sensors with the Memosens
protocol)
Inputs defective First perform tests and take measures as
outlined in "Process-specific errors" section
Measuring input test:
– Connect a resistor instead of the
conductivity sensor
Current output, incorrect
current value
Incorrect adjustment Check with integrated current simulation,
connect mA meter directly to current output.
Load too large
Shunt / short to ground in current loop

Liquiport 2010 CSP44 Diagnostics and troubleshooting
Endress+Hauser 11
1.2 Diagnostic information on local display
Up-to-date diagnostic events are displayed along with their status category, diagnostic code and
short text. By clicking the navigator, you can call up additional information and tips on remedial
measures.
1.3 Adjusting diagnostic information
1.3.1 Classification of diagnostics messages
More detailed information on the current diagnostics messages displayed is provided in the
DIAG/Diagnostics list menu.
In accordance with Namur specification NE 107, the diagnostics messages are characterized by:
• Message number
• Error category (letter in front of the message number)
–F= Failure. A malfunction has been detected.
The cause of the malfunction is to be found in the sampling point/measuring point. Any
controller connected should be set to manual mode.
–M= Maintenance required. Action should be taken as soon as possible.
The device still measures/takes a sample correctly. Immediate measures must not be taken.
However, proper maintenance efforts would prevent a possible malfunction in the future.
–C= Function check, (no error)
Maintenance work is being performed on the device. Wait until the work has been
completed.
–S= Out of specification. The measuring point is being operated outside specifications.
Operation is still possible. However, you run the risk of increased wear, shorter operating
life or lower accuracy levels. The cause of the problem is to be found outside the measuring
point.
• Message text
If you contact the Service Department, please cite the message number only. Since you can
individually change the assignment of an error to an error category, the Service Department
cannot use this information.
No current output signal Basic module defective Check with integrated current simulation,
connect mA meter directly to current output.
Problem Possible cause Tests and/or remedial measures

Diagnostics and troubleshooting Liquiport 2010 CSP44
12 Endress+Hauser
1.3.2 Adjusting the device behavior
All the diagnostics messages are assigned to specific error categories at the factory. Since other
settings might be preferred depending on the application, error categories and the effect errors
have on the measuring point can be configured individually. Furthermore, every diagnostics
message can be disabled.
Example
The controller returns diagnostics message 531 "Logbook full". You want to change this message
so that an error is not indicated on the display for example.
1. Go to:
– Menu/Setup/General settings/Extended setup/Diagnostics/Device behavior
for device-specific diagnostics messages (as in this example)
– Menu/Setup/Inputs/<Sensor type>/Extended setup/Diagnostics settings/Diag.
behavior
for sensor-specific diagnostics messages.
2. Select the diagnostics message and press the navigator button.
3. Decide:
a. Should the message be deactivated?
b. Do you want to change the error category?
c. Should an error current be output?
d. Do you want to trigger a cleaning program?
4. Deactivate the message, for example (Diagnostics message to "Off").
Configuration options
The list of diagnostic messages displayed depends on the path selected. There are
device-specific messages, and messages that depend on what sensor is connected.
Path: ... /Extended setup/Diagnostics settings/Diag. behavior (optional)
Function Options Info
List of diagnostic messages Select the message to be changed. Only then can you
make the settings for this message.
Diag. code Read only
Diagnostic message Options
•On
•Off
Factory setting
Depends on the message
You can deactivate or reactivate a diagnostics message
here.
Deactivating means:
• No error message in the measuring mode
• No error current at the current output

Liquiport 2010 CSP44 Diagnostics and troubleshooting
Endress+Hauser 13
Error current Options
•On
•Off
Factory setting
Depends on the message
Decide whether an error current should be output at the
current output if the diagnostic message display is
activated.
If general device errors occur, the error current is
output at all the current outputs.
In the case of channel-specific errors, the error
current is only output at the particular current
output.
Status signal Options
• Maintenance (M)
• Out of specification (S)
•Functioncheck(C)
• Failure (F)
Factory setting
Depends on the message
The messages are divided into different error categories
in accordance with NAMUR NE 107.
--> BA00470C "Maintenance & diagnostics"
Decide whether you want to change a status signal
assignment for your application.
Diag. output Options
•None
•Binaryoutput
Factory setting
None
You can use this function to select an output to which
the diagnostic message should be assigned.
For sensors with the Memosens protocol:
You first have to configure a relay output for
"Diagnostics" (Menu/Setup/Outputs, assign "Diagnostics"
function and set Operating mode to "as assigned") before
being able to assign the message to an output.
--> BA00492C "Operation & settings"
Cleaning
program(optional)
Options
•None
• Cleaning 1
• Cleaning 2
• Cleaning 3
• Cleaning 4
Factory setting
None
Decide whether the diagnostic message should trigger a
cleaning program.
You can define the cleaning programs under:
Menu/Setup/Additional functions/Cleaning.
Detail information Read only Here you can find more information on the diagnostic
message and instructions on how to resolve the
problem.
Path: ... /Extended setup/Diagnostics settings/Diag. behavior (optional)
Function Options Info

Diagnostics and troubleshooting Liquiport 2010 CSP44
14 Endress+Hauser
1.4 Overview of diagnostic information
1.4.1 Device-specific, general diagnostics messages
No. Message Factory settings Tests or remedial measures
Cat. Diag.
on/off
Error
current
202 Selftest active F On Off Wait for self-test to be finished
216 Hold active C On Off Output values and status of the channel are on
hold
241 Device error F On On Internal device error
1. Update the software
2. Contact the Service Department
3. Replace the backplane (Service)
242 Software incomp. F On On
243 Device error F On On
261 Electr. module F On On Electronics module defective
1. Replace the module
2. Contact the Service Department
262 Module connect. F On On Electronics module not communicating
1. Check cable connection, replace if necessary
2. Check the power supply of the sampling
control module
3. Contact the Service Department
263 Electr. module F On On Wrong kind of electronics module
1. Replace the module
2. Contact the Service Department
284 Firmware update M On Off Update completed successfully
285 Update error F On On Firmware update failed
1. Repeat update
2. SD card error --> use another card
3. Incorrect firmware --> repeat with suitable
firmware
4. Contact the Service Department
302 Battery low M On Off Buffer battery of real time clock is low
The date and time are lost if the power is
interrupted.
--> Contact the Service Department (battery
replacement)
304 Module data F On On At least 1 module has incorrect configuration
data
1. Check the system information
2. Contact the Service Department
305 Power consum. F On On Total power consumption too high
1. Check installation
2. Remove sensors/modules
306 Software error F On On Internal firmware error
--> Contact the Service Department

Liquiport 2010 CSP44 Diagnostics and troubleshooting
Endress+Hauser 15
311 Temp. sensor F On On Temperature sensor PT2 in sample compartment
is defective.
• Sample temperature measurement not
possible
• A sampling program will not be canceled
-> Replace sensor
314 No sample flow F On On Negative pressure cannot be created in the
peristaltic pump.
-> Check pump tube for leaks
-> Immerse suction line in medium
322 Read sub-program F On On Selected subprogram cannot be read from the
program memory
--> Create new subprogram
323 Write sub-prg. F On On Subprogram created cannot be saved
-> Hardware error
-> Contact the Service Department
324 Delete sub-prg. F On On Selected subprogram cannot be deleted from the
program memory
-> Reset the software
325 Readsub-prg.list F On On Subprogram list cannot be read from the program
memory
-> Reset the software
328 Distribution arm F On On Distribution arm zero point not found during test
run
-> Perform distribution arm test under
Diagnostics/System test/Distribution arm
-> Contact the Service Department
331 Peristaltic pump F On On • Peristaltic pump defective
• Motor cable broken
-> Contact the Service Department
332 Peristaltic pump F On On Control of peristaltic pump defective
--> Contact the Service Department
333 Pressure sensor F On On Medium detection not possible
No sampling possible.
• Suction line not drained before sampling
• Pressure sensor defective
-> Check suction line, where necessary purge it
using the pump test under Diagnostics/System
test/Pump test
-> Contact the Service Department
No. Message Factory settings Tests or remedial measures
Cat. Diag.
on/off
Error
current

Diagnostics and troubleshooting Liquiport 2010 CSP44
16 Endress+Hauser
337 Pump tubing M On Off Pump tube operating time reached shortly
Display under Diagnostics/Runtime info/Tubing
age
-> Schedule replacement
-> After replacement, reset the operating time
under Diagnostics/Runtime info
338 Pump tubing M On Off Pump tube operating time reached
Display under Diagnostics/Runtime info/Tubing
age
-> Change the pump tubing
->After replacement, reset the operating time
under Diagnostics/Runtime info
343 Power supply M On Off Power supply failure
344 Program pause C On Off Sampling program paused
345 Time changeover M On Off Daylight saving time/winter time setting
Normal time (winter time) active.
346 Time changeover M On Off Daylight saving time/winter time setting
Daylight saving time active
347 Sample confirm. F On On Sampling command has not been processed
-> Check internal cable to 1IF
-> Reset the software
348 Read program F On On Selected program cannot be read from the
program memory
--> Create new program
349 Write program F On On Program created cannot be saved
Hardware error has occurred
--> Contact the Service Department
351 Delete prog. F On On Selected program cannot be deleted from the
program memory
--> Reset the software
352 Read Prog.list F On On Program list cannot be read from the program
memory
--> Perform device reset under
Diagnostics/System test/Reset/Device reset
353 Overfill check F On Off Total capacity of bottle reached
• No further sampling to current bottle is
triggered
-> Adjust the sampling program under Program
selection if desired
354 Bottle check F On Off No empty bottles available for current program
• No further sampling
-> Check the program settings under Program
selection
No. Message Factory settings Tests or remedial measures
Cat. Diag.
on/off
Error
current

Liquiport 2010 CSP44 Diagnostics and troubleshooting
Endress+Hauser 17
355 Start time over M On Off Start time entered is in the past
• Enter a new start time
356 Overfill check F On Off The total sample volume does not fit in the
sample bottle
-> Change the sample volume
357 Sampling faulted M On Off • Sample discarded
• There are too many sampling requests pending
-> Adjust the sampling program under Program
selection
358 Configuration F On On Program configuration does not match the
current device configuration
-> Adjust the configuration
359 Emptying error F On On • Error when draining
• Draining and sampling program cancelled
-> Check connection to FMSY1 module
-> Check 4R module, replace if necessary
-> Restart the software under
Setup/Diagnostics/System test/Restart
366 Module connect. F On On No communication with actuator module
-> Check internal connecting cable to module 1IF
370 Intern. Voltage F On On Internal voltage outside the valid range
--> Check supply voltage
373 Electr. temp. M On Off High electronics temperature
--> Check ambient temperature and energy
consumption
374 Sensor check F On Off No measurement signal from sensor
-> Check sensor connection
-> Check sensor, replace if necessary
375 No 4R module F On On No connection to 4R module
-> Check 4R module, replace if necessary
-> Restart the software under
Setup/Diagnostics/System test/Restart
401 Reset to default F On On Factory reset is performed
406 Param. active C Off Off --> Wait for configuration to be finished
407 Diag. active C Off Off --> Wait for maintenance to be finished
412 Writing backup F On Off --> Wait for the write process to be finished
413 Reading backup F On Off --> Wait
No. Message Factory settings Tests or remedial measures
Cat. Diag.
on/off
Error
current

Diagnostics and troubleshooting Liquiport 2010 CSP44
18 Endress+Hauser
460 Curr. under-run S On Off Reasons
•Sensorinair
• Air pockets in assembly
• Sensor fouled
• Incorrect flow to sensor
Measures
1. Check sensor installation
2. Clean sensor
3. Adjust assignment of current outputs
461 Current exceeded S On Off
462 Output Deviation S On Off When the current output is read back, the value
deviates from the target value displayed.
Possible reasons: Current load outside
specification, short-circuit or open current loop,
module defective
1. Check installation of current loop
2. Check module
3. Contact the Service Department
502 No text catalog F On On --> Contact the Service Department
503 Language change M On Off Language change failed
--> Contact the Service Department
530 Logbook at 80% M On Off 1. Save the logbook to the SD card and then
delete the logbook in the device
2. Set memory to ring memory
3. Deactivate logbook
531 Logbook full M On Off
532 License error M On Off --> Contact the Service Department
540 Parameter save M On Off Configuration saving has failed, --> repeat
541 Parameter load M On Off Configuration successfully loaded
542 Parameter load M On Off Configuration loading has failed, --> repeat
543 Parameter load M On Off Configuration loading aborted
544 Parameter reset M On Off Factory default successful
729 Filter candle M On Off • Filter cartridge change necessary
• The limit value for operating hours has been
exceeded
-> Replace the filter cartridge for the sample
preparation system and reset the operating hours
counter in the Diagnostics menu
No. Message Factory settings Tests or remedial measures
Cat. Diag.
on/off
Error
current

Liquiport 2010 CSP44 Diagnostics and troubleshooting
Endress+Hauser 19
730 Clean. solution M On Off • Warning for level of cleaning solution for
sample preparation system
• Depending on the cleaning duration, the
cleaning interval and external events, the
remaining quantity is sufficient for a few hours
or days
-> Top up cleaning solution for sample
preparation system
-> Check level switch for cleaning solution
910 Limit switch S On Off Limit switch activated
921 Pump bracket F On On The pump bracket is detected as open.
•Pumpbracketopen
• Reed contact defective
-> Close pump bracket
-> Contact the Service Department
969 Modbus Watchdog S Off Off The device did not receive a Modbus telegram
from the master within the specified time. The
status of Modbus process values received is set to
invalid.
970 Input Overload S On On Current input overloaded
The current input is switched off from 23 mA due
to overload and reactivated automatically when a
normal load is present.
971 Input low S On On Current input too low
At 4 to 20 mA, the input current is less than the
lower error current.
--> Check the input for short-circuits.
972 Input > 20 mA S On On Current output range exceeded
973 Input < 4 mA S On On Current output range undershot
974 Diag. confirmed C Off Off User has acknowledged the message displayed in
the measuring menu.
975 Device reset C Off Off Device Reset
991 CO2 conc. range F On On CO2concentration (degassed conductivity)
outside the measuring range
992 pH calc range F On On pH calculation outside the measuring range
993 rH calc range F On On rH calculation outside the measuring range
994 Dual cond range F On On Dual conductivity outside the measuring range
No. Message Factory settings Tests or remedial measures
Cat. Diag.
on/off
Error
current

Diagnostics and troubleshooting Liquiport 2010 CSP44
20 Endress+Hauser
1.4.2 Sensor-specific diagnostics messages
Abbreviations used for sensor types
• P ... pH/ORP (general)
– P (glass) ... glass electrode
– P (ISFET) ... ISFET sensor
• C ... Conductivity (general)
– C (cond.) ... Conductive sensor
– C (ind.) ... Inductive sensor
• O ... Oxygen (general)
– O (opt.) ... Optical sensor
– O (amp.) ... Amperometric sensor
• N ... Nitrate
• T ... Turbidity and solids
• S ... SAC
• I ... ISE
• Cl ... Chlorine
No. Message Factory settings Sensor type Tests or remedial measures
Cat. Diag. Error
curren
t
002 Sensor unknown F On On All Replace sensor
004 Sensor problem F On On All
005 Sensor data F On On All Invalid sensor data
1. Check the firmware compatibility for the
sensor and transmitter, load suitable
firmware if necessary
2. Reset sensor to factory setting,
disconnect sensor and connect it again
3. Update transmitter date
4. Replace sensor
010 Sensor scanning F Off On All Wait for initialization to be finished
012 Writing data F On On All Could not write sensor data
1. Repeat write process
2. Replace sensor
013 Sensor type F On On All Replace sensor, making sure correct sensor
type is used
018 Sensor not ready F On On All Sensor communication blocked
1. Sensor fails tag check. Replace.
2. Internal software error. Contact Service
Department
022 Temp. sensor F On On P, C, O, I, Cl Temperature sensor defective
Replace sensor
061 Sensor electr. F On On All Sensor electronics defective
Replace sensor
