Endress+Hauser Liquistation CSF48 User manual

Products Solutions Services
BA00463C/07/EN/17.12
71208856
Valid as of:
Softwareversion 01.04.00
Operating Instructions
Liquistation CSF48
Automatic sampler for liquid media
Maintenance & diagnostics

About this manual
These instructions describe all the tasks you must perform for diagnostics, maintenance and
repair.
A description of the following is provided here:
• General troubleshooting
• Overview of the diagnostic messages
• Description of the information of the "Diagnostics" menu
– Diagnostics list
–Logbooks
– System information
–Outputstatus
–Systemtest/Reset
–Sensorchange
– Manual hold
– Term information
– Simulation
– Sensor information
• Cleaning and maintenance
• Accessories and spare parts
This manual does not include the following:
• Setup/General settings
--> Operating Instructions BA00443C "Commissioning"
• Display/Operation
--> Operating Instructions BA00443C "Commissioning"
•Inputs
--> Operating Instructions BA00464C "Operation&settings"
•Outputs
--> Operating Instructions BA00464C "Operation&settings"
• Sampling programs
--> Operating Instructions BA00464C "Operation&settings"
• Additional functions
--> Operating Instructions BA00464C "Operation&settings"
• Data management
--> Operating Instructions BA00464C "Operation&settings"
•Calibration
--> Operating Instructions BA00467C "Calibration"
•Expert
--> Internal Service Manual

Endress+Hauser
Liquistation CSF48
Table of contents
1 Diagnostics and
troubleshooting . . . . . . . . . . . . . 4
1.1 General troubleshooting . . . . . . . . . . . . . . 4
1.2 Diagnostic information on the onsite
display . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
1.3 Diagnostic information via web browser 13
1.4 Diagnostic information via fieldbus . . . 13
1.5 Adjusting diagnostic information . . . . . 14
1.6 Overview of diagnostic information . . . 16
1.7 Pending diagnostic messages . . . . . . . . . 39
1.8 Diagnostics list . . . . . . . . . . . . . . . . . . . . . 40
1.9 Logbooks . . . . . . . . . . . . . . . . . . . . . . . . . . 40
1.10 Device info . . . . . . . . . . . . . . . . . . . . . . . . 47
1.11 Simulation . . . . . . . . . . . . . . . . . . . . . . . . 49
1.12 Reset measuring instrument . . . . . . . . . 51
1.13 Term information . . . . . . . . . . . . . . . . . . 54
1.14 Status of inputs/outputs . . . . . . . . . . . . . 55
1.15 Sensor change (for version with sensors
with the Memosens protocol) . . . . . . . . 55
1.16 Manual hold (for version with sensors with
the Memosens protocol) . . . . . . . . . . . . . 56
1.17 Firmware history . . . . . . . . . . . . . . . . . . . 56
2 Maintenance. . . . . . . . . . . . . . . 58
2.1 Recommended maintenance . . . . . . . . . 58
2.2 Replacing the pump tube . . . . . . . . . . . . 59
2.3 Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . 61
2.4 Replacing the storage batteries . . . . . . . 66
2.5 Calibration . . . . . . . . . . . . . . . . . . . . . . . . 67
2.6 Technical support . . . . . . . . . . . . . . . . . . 67
3 Repair. . . . . . . . . . . . . . . . . . . . . 68
3.1 Spare parts . . . . . . . . . . . . . . . . . . . . . . . . 68
3.2 Return . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
3.3 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
4 Accessories . . . . . . . . . . . . . . . . 75
4.1 Accessories for Liquistation CSF48 . . . . 75
4.2 Measuring cable . . . . . . . . . . . . . . . . . . . . 77
4.3 Sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Index. . . . . . . . . . . . . . . . . . . . . . 82

Diagnostics and troubleshooting Liquistation CSF48
4Endress+Hauser
1 Diagnostics and troubleshooting
The sampler continuously monitors its own functions.
The color of the display background changes to red if a diagnostics message for error category
"F" occurs.
The LED beside the display flashes red if a diagnostics message for error category "M" occurs.
1.1 General troubleshooting
1.1.1 Troubleshooting
A diagnostic message appears on the display or via the fieldbus indicating that the measured
values are not plausible, or you identify a fault.
1. See the Diagnostics menu for the details on the diagnostic message.
Follow the instructions to rectify the problem.
2. If this does not help: Search for the diagnostic message under "Overview of diagnostic
information" () in this manual. Use the message number as a search criterion. Ignore the
letters indicating the Namur error category.
Follow the troubleshooting instructions provided in the last column of the error tables.
3. If the measured values are implausible, the onsite display is faulty or you encounter other
problems, search for the faults under "Process errors without messages" () or "Device-specific
errors" ().
Follow the recommended measures.
4. Contact the Service Department if you cannot rectify the error yourself. Only cite the error
number.
1.1.2 Process errors without messages
pH/ORP measurement
Problem Possible cause Tests and/or remedial measures
Display values deviate
from reference
measurement
Incorrect calibration Repeat the calibration.
Where necessary, check and repeat the calibration
with the reference device.
Sensor fouled Clean the sensor.
Temperature measurement Check the temperature measured values of both
devices.
Temperature compensation Check the settings for temperature compensation
and adjustment for both devices.

Liquistation CSF48 Diagnostics and troubleshooting
Endress+Hauser 5
Measuring chain
zero-point cannot be
adjusted
Contaminated reference system Test with new sensor
Junction clogged Clean or grind junction
Asymmetric sensor voltage too high Clean junction or test with another sensor
No change or subtle
change in display
– Sensor fouled
–Sensorold
– Sensor defective (reference lead)
Clean the sensor.
Reference has low level of KCl Check KCl supply: 0.8 bar (12 psi) over medium
pressure
Measuring chain slope:
– Cannot be adjusted
–Tolow
–Noslope
Device input defective Check device directly.
–Sensorold
– Hair-line crack in the glass
membrane
Renew sensor.
Constant, incorrect
measured value
Sensor does not immerse properly
or protection cap not removed
Check installation position, remove protection cap.
Air pockets in assembly Check assembly and orientation.
Ground fault at or in device Perform test measurement in isolated vessel, with
buffer solution if applicable.
Hair-line crack in the glass
membrane
Renew sensor.
Device in impermissible operating
condition (does not respond when
key pressed)
Switch off device and switch it on again.
Incorrect temperature
value
Sensor failure Replace sensor
Fluctuations in measured
value
Interference on signal output cable Check cable routing, route cable separately if
necessary.
Interference potential in medium Eliminate source of interference or ground medium
as close as possible to sensor.
No current output signal Cable disconnected or shortcircuited Disconnect cable and measure directly at device.
Output defective See "Device-specific errors" section.
Fixed current output
signal
Current simulation active Switch off simulation.
Incorrect current output
signal
Total load in current loop too high Measure the load and reduce it to the permitted
value if necessary (--> Technical data, Operating
Instructions "Commissioning").
EMC (interference coupling) Check wiring. Identify and eliminate cause of
interference.
Problem Possible cause Tests and/or remedial measures

Diagnostics and troubleshooting Liquistation CSF48
6Endress+Hauser
Conductivity measurement
Problem Possible cause Tests and/or remedial measures
Display values deviate
from reference
measurement
Incorrect calibration Repeat the calibration.
Where necessary, check and repeat the calibration
with the reference device.
Sensor fouled Clean the sensor.
Temperature measurement Check the temperature measured values of both
devices.
Temperature compensation Check the settings for temperature compensation
and adjustment for both devices.
Display values deviate
from reference
measurement
Polarization fields Use suitable sensor:
• Larger cell constant
• Graphite instead of stainless steel (observe
material resistance properties)
Implausible measured
values:
– Measured value
constantly 000
– Measured value too low
– Measured value too
high
– Measured value frozen
– Current output value
not as expected
Short-circuit/moisture in sensor Check sensor.
Short-circuit in cable or socket Check cable and socket.
Disconnection in sensor Check sensor.
Disconnection in cable or socket Check cable and socket.
Incorrect cell constant setting Check cell constant.
Incorrect output assignment Check assignment of measured value to current
signal.
Air pockets in assembly Check assembly and orientation.
Ground fault at or in device Measure in isolated vessel.
Device in impermissible operating
condition (does not respond when
key pressed)
Switch off device and switch it on again.
Incorrect temperature
value
Sensor failure Replace sensor

Liquistation CSF48 Diagnostics and troubleshooting
Endress+Hauser 7
Measured value in process
incorrect
No/incorrect temperature
compensation
ATC: select type of compensation; if linear, set
suitable coefficients.
MTC: set process temperature.
Incorrect temperature measurement Check temperature measured value.
Bubbles in medium Suppress formation of bubbles by:
– Gas bubble trap
– Creating counterpressure (orifice plate)
– Measurement in bypass
Flow rate too high (can lead to
bubble formation)
Reduce flow rate or select less turbulent mounting
location.
Voltage potential in medium (only
for conductive)
Ground medium close to sensor.
Sensor fouling or buildup on sensor Clean sensor (see "Cleaning the conductivity sensors"
section).
Fluctuations in measured
value
Interference on signal output cable Check cable routing, route cable separately if
necessary.
Interference potential in medium Eliminate source of interference or ground medium
as close as possible to sensor.
Interference on measuring cable Connect cable shield as per wiring diagram.
No current output signal Cable disconnected or shortcircuited Disconnect cable and measure directly at device.
Output defective See "Device-specific errors" section.
Fixed current output
signal
Current simulation active Switch off simulation.
Incorrect current output
signal
Total load in current loop too high Measure the load and reduce it to the permitted
value if necessary (--> Technical data, Operating
Instructions "Commissioning").
EMC (interference coupling) Check wiring. Identify and eliminate cause of
interference.
Problem Possible cause Tests and/or remedial measures

Diagnostics and troubleshooting Liquistation CSF48
8Endress+Hauser
Oxygen measurement
Problem Possible cause Tests and/or remedial measures
Display value - - - -
Sensor failure Test with new sensor
Sensor cable disconnected Check cable or cable extension.
Incorrect sensor connection Check the connection at input module (--> BA
"Commissioning", "Wiring" section).
Electronics module defective Replace the module.
No change or subtle
change in display
– Sensor fouled
– Sensor old (membrane)
• Clean the sensor.
• If necessary:
– Change electrolyte, change membrane cap
(amperometric sensor)
– Change fluorescence cap (optical sensor)
Constant, incorrect
measured value
Device in impermissible operating
condition (does not respond when
key pressed)
Switch off device and switch it on again.
Measured value too low
Membrane fouled Clean or replace cap
Electrolyte exhausted or
contaminated
Change electrolyte
Anode coating worn Repolarize sensor
Black anode coating Regenerate sensor in factory
Measured value too high
Air pocket under membrane Clean sensor, optimize installation where necessary
Polarization not complete Wait until polarization time elapses (--> Technical
data in sensor operating manual)
Implausible measured
value
Incorrect temperature measurement Check/correct value.
Incorrect altitude setting Incorrect calibration
Reset and repeat calibration.
Incorrect air pressure
Incorrect temperature
value
Incorrect sensor connection Check the connection at input module (--> BA
"Commissioning", "Wiring" section).
Temperature sensor defective Replace sensor
Fluctuations in measured
value
Interference on signal output cable Check cable routing, route cable separately if
necessary.
Interference potential in medium Eliminate source of interference or ground medium
as close as possible to sensor.
No current output signal Cable disconnected or shortcircuited Disconnect cable and measure directly at device.
Output defective See "Device-specific errors" section.
Fixed current output
signal
Current simulation active Switch off simulation.

Liquistation CSF48 Diagnostics and troubleshooting
Endress+Hauser 9
Chlorine measurement
Incorrect current output
signal
Total load in current loop too high Measure the load and reduce it to the permitted
value if necessary.
EMC (interference coupling) Disconnect both output cables and measure directly
at device.
Problem Possible cause Tests and/or remedial measures
Display value - - - -
Sensor failure Test with new sensor
Sensor cable disconnected Check cable or cable extension.
Incorrect sensor connection Check the connection at input module (--> BA
"Commissioning", "Wiring" section).
Electronics module defective Replace the module.
Slope too low Sensor was in chlorine-free water or
in air.
Short conditioning over (not in!) chlorine bleach,
wait for adjustment time in water to elapse before
calibration.
Values do not match the
DPD control measurement
Measurement is performed without
pH compensation while DPD
measurement is always buffered to
pH 6.3.
Measure the chlorine value with pH compensation
DPD measured value far
too high
Organic chlorination agents
(possibly also only used temporarily
or for shock chlorination). In this
instance, no correlation between
actual free available chlorine, DPD
measurement and amperometric
measurement. DPD value up to 5
times too high.
Use free (gaseous) chlorine or chlorine from
inorganic chlorine compounds.
Chlorine value too high
Membrane defective Replace membrane cap
Polarization not complete Wait for the polarization time to elapse
Alien oxidizing agents Analyze medium
Shunt in chlorine sensor Replace sensor
Chlorine value too low
Measuring chamber not closed Refill and carefully screw closed
Air bubble outside in front of
membrane
Remove air bubble, select a better installation
position if possible
Air bubble inside membrane Refill and screw closed so that it is air-free
No change or subtle
change in display
Sensor fouled Clean sensor
Sensor old Replace sensor
Sensor defective (ref. lead) Replace sensor
Problem Possible cause Tests and/or remedial measures

Diagnostics and troubleshooting Liquistation CSF48
10 Endress+Hauser
Turbidity and nitrate measurement
Constant, incorrect
measured value
Sensor does not immerse properly
or protection cap not removed
Check installation position, remove protection cap
Air pockets in assembly Check assembly and orientation
No current output signal Cable disconnected or shortcircuited Disconnect cable and measure directly at device.
Output defective See "Device-specific errors" section.
Fixed current output
signal
Current simulation active Switch off simulation.
Incorrect current output
signal
Total load in current loop too high Measure the load and reduce it to the permitted
value if necessary (--> Technical data, Operating
Instructions "Commissioning").
EMC (interference coupling) Check wiring. Identify and eliminate cause of
interference.
Problem Possible cause Tests and/or remedial measures
Display value - - - -
Sensor failure Test with new sensor
Sensor cable disconnected Check cable or cable extension.
Incorrect sensor connection Check the connection at input module (--> BA
"Commissioning", "Wiring" section).
Electronics module defective Replace the module.
No change or subtle
change in display
Sensor fouled Clean the sensor.
Constant, incorrect
measured value
Device in impermissible operating
condition (does not respond when
key pressed)
Switch off device and switch it on again.
Implausible measured
value
Sensor not calibrated or incorrectly
calibrated
Calibration with original sample might be necessary
for concentration or solids content.
Sensor fouled Clean sensor
Sensor installed in "dead zone" or air
pocket in assembly or flange
Check installation position, move sensor to area that
receives good flow. Pay attention when mounting in
horizontal pipes
Incorrect sensor orientation Align sensor:
•Normalmedia:
Direct flow to measuring window
• For high solids content:
Align measuring window at angle of 90˚to flow
Incorrect temperature
value
Incorrect sensor connection Check the connection at input module (--> BA
"Commissioning", "Wiring" section).
Temperature sensor defective Replace sensor
Problem Possible cause Tests and/or remedial measures

Liquistation CSF48 Diagnostics and troubleshooting
Endress+Hauser 11
Fluctuations in measured
value
Interference on signal output cable Check cable routing, route cable separately if
necessary.
Irregular flow / turbulence / air
bubbles / large solid particles
Select a better mounting location or reduce
turbulence, use a large measured value damping
factor if necessary
Set gas bubble threshold to 100 %
No current output signal Cable disconnected or shortcircuited Disconnect cable and measure directly at device.
Output defective See "Device-specific errors" section.
Fixed current output
signal
Current simulation active Switch off simulation.
Incorrect current output
signal
Total load in current loop too high Measure the load and reduce it to the permitted
value if necessary.
EMC (interference coupling) Disconnect both output cables and measure directly
at device.
Value switches to zero and
back to measured value
Air bubbles Do not mount sensor above aeration discs
Problem Possible cause Tests and/or remedial measures

Diagnostics and troubleshooting Liquistation CSF48
12 Endress+Hauser
1.1.3 Device-specific errors
Problem Possible cause Tests and/or remedial measures
The device cannot be
switched on/display remains
dark
No supply voltage Check if voltage supplied
Basic module defective Replace basic module
Values appear on display
but:
– Display does not change
and / or
– Device cannot be
operated
Module not wired correctly Check modules and wiring
Impermissible operating system
condition
Switch off device and switch it on again
Control signals are not
accepted or outputs do not
switch
Incorrect program setting Check program setting
Incorrect wiring Check wiring
Electronics failure Replace basic module
Sample not representative
Siphon in sampling hose Check sampling hose
Connection not air-tight/sampling
hose taking in air
– Check tubes/connections
– Check the sampling hose is routed correctly
Bottles not being filled correctly – Incorrect distribution selected in the controls
– Calibrate the distribution arm
Distribution arm does not move – Incorrect distribution selected in the controls
– Check distribution arm connection
– Distributor defective, replace distributor or
– Have repaired by E+H Service
Incorrect bottle filled – Incorrect distribution selected in the controls
No sample cooling – Check the setting for the sample
compartment temperature in the controls
– Cooling system defective
--> Have repaired by E+H Service
Wrong pump tube Only use genuine pump tube
Faulty sensory mechanism Replace sensory mechanism (contact E+H
Service)
No sampling
Connection leaking Check tubes/connections for leaks
Sampling hose taking in air Check the sampling hose is routed correctly
Air manager defective Have repaired by E+H Service
Vacuum pump defective Have repaired by E+H Service
Wrong pump tube Only use genuine pump tube
Faulty sensory mechanism Replace sensory mechanism (contact E+H
Service)

Liquistation CSF48 Diagnostics and troubleshooting
Endress+Hauser 13
1.2 Diagnostic information on the onsite display
Up-to-date diagnostic events are displayed along with their status category, diagnostic code and
short text. Clicking on the Navigator lets you retrieve more information and tips on remedial
measures.
1.3 Diagnostic information via web browser
The same diagnostic information as for the onsite display is available via the web server.
1.4 Diagnostic information via fieldbus
Diagnostic events, status signals and more information are transmitted according to the
definitions and technical capabilities of the respective fieldbus systems
Implausible measured values
(only for version with
sensors with the Memosens
protocol)
Inputs defective First perform tests and take measures as
outlined in "Process-specific errors" section
Measuring input test:
– Connect a resistor instead of the
conductivity sensor
Current output, incorrect
current value
Incorrect adjustment Check with integrated current simulation,
connect mA meter directly to current output.
Load too large
Shunt / short to ground in current loop
No current output signal Basic module defective Check with integrated current simulation,
connect mA meter directly to current output.
Problem Possible cause Tests and/or remedial measures

Diagnostics and troubleshooting Liquistation CSF48
14 Endress+Hauser
1.5 Adjusting diagnostic information
1.5.1 Classification of diagnostics messages
More detailed information on the current diagnostics messages displayed is provided in the
DIAG/Diagnostics list menu.
In accordance with Namur specification NE 107, the diagnostics messages are characterized by:
• Message number
• Error category (letter in front of the message number)
–F= (Failure) a malfunction has been detected
The cause of the malfunction is to be found in the sampling point/measuring point. Any
controller connected should be set to manual mode.
–M= (Maintenance required) Action should be taken as soon as possible
The device still measures/takes a sample correctly. Immediate measures must not be taken.
However, proper maintenance efforts would prevent a possible malfunction in the future.
–C= (Function check) (No error)
Maintenance work is being performed on the device. Wait until the work has been
completed.
–S= (Out of specification) The measuring point is being operated outside its specification
Operation is still possible. However, you run the risk of increased wear, shorter operating
life or lower accuracy levels. The cause of the problem is to be found outside the measuring
point.
• Message text
If you contact the Service Department, please cite the message number only. Since you can
individually change the assignment of an error to an error category, the Service Department
cannot use this information.
1.5.2 Adjusting the device behavior
All the diagnostics messages are assigned to specific error categories at the factory. Since other
settings might be preferred depending on the application, error categories and the effect errors
have on the measuring point can be configured individually. Furthermore, every diagnostics
message can be disabled.
Example
The controller returns diagnostics message 531 "Logbook full". You want to change this message
so that an error is not indicated on the display for example.
1. Go to:
– Menu/Setup/General settings/Extended setup/Diagnostics/Device behavior
for device-specific diagnostics messages (as in this example)
– Menu/Setup/Inputs/<Sensor type>/Extended setup/Diagnostics settings/Diag.
behavior
for sensor-specific diagnostics messages.
2. Select the diagnostics message and press the navigator button.
3. Decide:
a. Should the message be deactivated?

Liquistation CSF48 Diagnostics and troubleshooting
Endress+Hauser 15
b. Do you want to change the error category?
c. Should an error current be output?
d. Do you want to trigger a cleaning program?
4. Deactivate the message, for example (Diagnostics message to "Off").
Configuration options
The list of diagnostic messages displayed depends on the path selected. There are
device-specific messages, and messages that depend on what sensor is connected.
Path: ... /Extended setup/Diagnostics settings/Diag. behavior (optional)
Function Options Info
List of diagnostic messages Select the message to be changed. Only then can you
make the settings for this message.
Diag. code Read only
Diagnostic message Options
•On
•Off
Factory setting
Depends on the message
You can deactivate or reactivate a diagnostic message
here.
Deactivating means:
• No error message in the measuring mode
• No error current at the current output
Error current Options
•On
•Off
Factory setting
Depends on the message
Decide whether an error current should be output at the
current output if the diagnostic message display is
activated.
If general device errors occur, the error current is
output at all the current outputs.
In the case of channel-specific errors, the error
current is only output at the particular current
output.
Status signal Options
• Maintenance (M)
• Out of specification (S)
•Functioncheck(C)
• Failure (F)
Factory setting
Depends on the message
The messages are divided into different error categories
in accordance with NAMUR NE 107.
Decide whether you want to change a status signal
assignment for your application.
Diag. output Options
•None
• Alarm relay
• Relay 1 to n (depends on
the device version)
Factory setting
None
You can use this function to select a relay output and/or
binary output to which the diagnostic message should be
assigned.
For sensors with the Memosens protocol:
Before you can assign the message to an output, you
must first configure a relay output to "Diagnostics"
(Menu/Setup/Outputs, assign the "Diagnostics" function
and set the Operating mode to "as assigned").

Diagnostics and troubleshooting Liquistation CSF48
16 Endress+Hauser
1.6 Overview of diagnostic information
1.6.1 Device-specific, general diagnostic settings
Cleaning
program(optional)
Options
•None
• Cleaning 1
• Cleaning 2
• Cleaning 3
• Cleaning 4
Factory setting
None
Decide whether the diagnostic message should trigger a
cleaning program.
You can define the cleaning programs under:
Menu/Setup/Additional functions/Cleaning.
Detail information Read only Here you can find more information on the diagnostic
message and instructions on how to resolve the
problem.
No. Message Factory settings Tests or remedial measures
Cat. Diag.
on/off
Error
current
202 Selftest active F On Off Wait for self-test to be finished
216 Hold active C On Off Output values and status of the channel are on
hold
241 Device error F On On Internal device error
1. Update the software
2. Contact the Service Department
3. Replace the backplane (Service)
242 Software incomp. F On On
243 Device error F On On
261 Electr. module F On On Electronics module defective
1. Replace the module
2. Contact the Service Department
262 Module connect. F On On Electronics module not communicating
1. Check cable connection, replace if necessary
2. Check the power supply of the sampling
control module
3. Contact the Service Department
263 Electr. module F On On Wrong kind of electronics module
1. Replace the module
2. Contact the Service Department
284 Firmware update M On Off Update completed successfully
Path: ... /Extended setup/Diagnostics settings/Diag. behavior (optional)
Function Options Info

Liquistation CSF48 Diagnostics and troubleshooting
Endress+Hauser 17
285 Update error F On On Firmware update failed
1. Repeat update
2. SD card error --> use another card
3. Incorrect firmware --> repeat with suitable
firmware
4. Contact the Service Department
302 Battery low M On Off Buffer battery of real time clock is low
The date and time are lost if the power is
interrupted.
--> Contact the Service Department (battery
replacement)
304 Module data F On On At least 1 module has incorrect configuration
data
1. Check the system information
2. Contact the Service Department
305 Power consum. F On On Total power consumption too high
1. Check installation
2. Remove sensors/modules
306 Software error F On On Internal firmware error
--> Contact the Service Department
310 Temp. sensor F On On Temperature sensor PT1 in climate control
module for sample compartment measurement is
defective.
• Not possible to regulate temperature of sample
compartment
• A sampling program will not be canceled
-> Contact the Service Department
311 Temp. sensor F On On Temperature sensor PT2 in sample compartment
is defective.
• Sample temperature measurement not
possible
• A sampling program will not be canceled
-> Replace sensor
312 Temp. sensor F On On Temperature sensor PT3 for ambient
temperature measurement is defective.
• Winter operation regulation not possible
• Sampling and distribution arm blocked to
protect against freezing
-> Disable winter operation under
Setup/Inputs/Temperature S:3/Winter operation
-> Replace sensor
No. Message Factory settings Tests or remedial measures
Cat. Diag.
on/off
Error
current

Diagnostics and troubleshooting Liquistation CSF48
18 Endress+Hauser
313 Safety sensor M On On Safety switch LF2 for sample sensor active
• Contact electrodes for sample detection are
fouled
• The sample continues to be taken
-> Clean sample detection sensor LF1 in the
dosing glass
-> Contact the Service Department
314 No sample flow F On On Negative pressure cannot be created in the
peristaltic pump.
-> Check pump tube for leaks
-> Immerse suction line in medium
315 Refrigeration F On On • Sample compartment target temperature not
reached
• Refrigeration regulation not possible
-> Check the sample compartment door
-> Carry out a module test under
Diagnostics/Systemtest/Climate control
module/Test cooling
-> Contact the Service Department
316 Heating F On On • Sample compartment target temperature not
reached
• Heating regulation not possible
-> Check the sample compartment door
-> Carry out a module test under
Diagnostics/Systemtest/Climate control
module/Test heating
-> Contact the Service Department
317 Liquidsensor M On On • Sensor LF1 for sample detection fouled.
• Five sampling processes still possible.
-> Clean sensor LF1 in the dosing glass
318 Liquidsensor F On On • Sensor LF1 for sample detection defective.
• No sampling possible.
-> Contact the Service Department
319 Safety sensor M On On • Safety switch LF2 fouled.
• Five sampling processes still possible.
-> Clean sensor LF2 in the dosing glass
320 Safety sensor F On On • Safety switch LF2 defective.
• No sampling possible.
-> Contact the Service Department
No. Message Factory settings Tests or remedial measures
Cat. Diag.
on/off
Error
current

Liquistation CSF48 Diagnostics and troubleshooting
Endress+Hauser 19
321 Liquid sensor F On On Capacitance sensor misaligned or defective.
• Medium detection in dosing chamber not
possible
• No sampling possible
-> Clean sensor
-> Contact the Service Department
322 Read sub-program F On On Selected subprogram cannot be read from the
program memory
-> Create a new subprogram
323 Write sub-prg. F On On Subprogram created cannot be saved
-> Hardware error
-> Contact the Service Department
324 Delete sub-prg. F On On Selected subprogram cannot be deleted from the
program memory
-> Reset the software
325 Readsub-prg.list F On On Subprogram list cannot be read from the program
memory
-> Reset the software
326 Membrane pump F On On • Vacuum pump defective
• Motor cable broken
-> Contact the Service Department
327 Air-Manager F On On • Air manager for compressed air distribution
defective
• Photoelectric barrier defective
• Cable defective
-> Contact the Service Department
328 Distribution arm F On On Distribution arm zero point not found during
reference run
-> Carry out a distribution arm test under
Diagnostics/Systemtest/Distribution arm
-> Contact the Service Department
329 Pump failure F On On Pump motor is drawing excess current
-> Contact the Service Department
330 Membrane pump F On On Vacuum pump control defective
-> Contact the Service Department
331 Peristaltic pump F On On • Peristaltic pump defective
• Motor cable broken
-> Contact the Service Department
332 Peristaltic pump F On On Control of peristaltic pump defective
--> Contact the Service Department
No. Message Factory settings Tests or remedial measures
Cat. Diag.
on/off
Error
current

Diagnostics and troubleshooting Liquistation CSF48
20 Endress+Hauser
333 Pressure sensor F On On Medium detection not possible
No sampling possible.
• Suction line not drained before sampling
• Pressure sensor defective
-> Check the suction line, purge it using the pump
test under Diagnostics/Systemtest/Pump test if
necessary
-> Contact the Service Department
334 Cooling system F On On Climate control module defective
-> Replace the climate control module
-> Contact the Service Department
335 Fan F On On Ventilator defective.
-> Replace the ventilator
-> Contact the Service Department
337 Pump tubing M On Off Pump tube operating time reached shortly
Display under Diagnostics/Runtime info/Tubing
age
-> Schedule replacement
-> After replacement, reset the operating time
under Diagnostics/Runtime info
338 Pump tubing M On Off Pump tube operating time reached
Display under Diagnostics/Runtime info/Tubing
age
-> Change the pump tubing
-> After replacement, reset the operating time
under Diagnostics/Runtime info
339 Liquidsensor M On Off Sensor conductivity 1 fouled
-> Clean the sensor soon
-> The sensitivity can be configured under
Setup/General settings/Sampling/Conductive
sensor
340 Liquidsensor M On Off Sensor conductivity 1 fouled
-> Clean sensor
-> The sensitivity can be configured under
Setup/General settings/Sampling/Conductive
sensor
343 Power supply M On Off Power supply failure
344 Program pause C On Off Sampling program paused
345 Time changeover M On Off Daylight saving time/winter time setting
Normal time (winter time) active.
346 Time changeover M On Off Daylight saving time/winter time setting
Daylight saving time active
347 Sample confirm. F On On Sampling command has not been processed
-> Check the internal cable to 1IF
-> Reset the software
No. Message Factory settings Tests or remedial measures
Cat. Diag.
on/off
Error
current
