Epson S1C17 Series User manual

Dec/26/2012
errata_s5u1c17001h2_1
S1C17 Manual errata
ITEM:
Object manuals Document codes Items Pages
S5U1C17001H2 User Manual
(ICDmini Ver2.0)
411153403 4.1.1 Target Interface Connector 14
Same as above Same as above 8.3 Notes on Use of S5U1C17001H 32,33
(Error)
4.1.1 Target Interface Connector
Notes:
-When wiring the S1C processor to the target connector for connecting the S5U1C17001H,
insert a 33ohm resistor in series between the S1C processor DSIO pin and the connector.
This resistor must be placed as close to the S1C processor as possible. Although the
system can operate without this 33ohm resistor, we recommend inserting this resistor to
prevent malfunctions. The other pins are connected directly. A low-level input to the DSIO
pin issues a forced break to set the S1C processor into debug mode. Although this signal is
pulled up through about 100kohm internally, when not debugging, we recommend either
removing the 33ohm resistor to reduce noise and other problems or pulling this line up to
the VDD level.

Dec/26/2012
errata_s5u1c17001h2_1
8.3 Notes on Use of S5U1C17001H
Wiring between the S1C processor and target connector
When wiring the S1C processor to the target system connector for connecting the
S5U1C17001H, insert a 33ohm resistor in series between the S1C processor DSIO pin and
the connector. This resistor must be placed as close to the S1C processor as possible. If
the reset line is not connected, the system can be operated without this 33ohm resistor.
However, we recommend inserting this resistor to prevent malfunctions. The other pins are
connected directly. The total length of the line must be under 5 cm. A low-level input to the
DSIO pin issues a forced break to set the S1C processor into debug mode. Although this
signal is pulled up through about 100k ohm internally, when not debugging, we recommend
either removing the 33ohm resistor to reduce noise and other problems or pulling this line
up to the VDD level.

Dec/26/2012
errata_s5u1c17001h2_1
(Correct)
4.1.1 Target Interface Connector
Notes:
-Please refer to a technical manual of each model for the connection method with the
target system.
8.3 Notes on Use of S5U1C17001H
Wiring between the S1C processor and target connector
Please refer to a technical manual of each model for the connection method with the target
system. Moreover, The total length of the line must be under 5 cm.
(Delete Figure 8.3.1)

Oct/04/2013
errata_s5u1c17001h2_2
S1C17 Manual errata
ITEM:
Object manuals Document codes Items Pages
S5U1C17001H2 User Manual
(ICDmini Ver2.0)
411153403 8.3 Notes on Use of S5U1C17001H 33
(Error)
There is no description.
(Correct)
About how to put this product
Please use this product with the rubber foot below.
About the accessory
Please use the USB cable attached to this product.
About the using environment requirements
Please use this product indoors.

Oct/04/2013
errata_s5u1c17001h2_3
S1C17 Manual errata
ITEM:
Object manuals Document codes Items Pages
S5U1C17001H2 User Manual 411153403 7. Firmware Update 28
(Error)
Added.
(Correct)
(6) Check the current firmware version, and enter the following commands if updating is required.
When S1C17 processor is selected
(gdb) c17 fwe 0
(gdb) c17 fwe 1
(gdb) c17 firmupdate path¥filename.saf
When S1C33 processor is selected
(gdb) c33 firmupdate path¥filename.saf
path: Path for location of new firmware
filename.saf: File name for new firmware
The process is complete when the following is displayed after the commands have been entered.
When S1C17 processor is selected
(gdb) c17 fwe 0
Erase flash data …done
(gdb) c17 fwe 1
Erase flash erase/write program …done
(gdb) c17 firmupdate path¥filename.saf
Erase flash data ...done
Load flash data ....done
ICD firmware update ...done
Please quit gdb, and power off ICD when LED2／LED3／LED4 is green.
(LED is green in the case of SVT17701).
When S1C33 processor is selected
(gdb) c33 firmupdate path¥filename.saf
Erase flash data ...done
Load flash data ....done
ICD firmware update ...done
Please quit gdb, and power off ICD when OK LED is on.
This procedure may take about 15 minutes.
While firmware updating is in progress, do not reset the S5U1C17001H or turn off the power.
Otherwise it may not be possible to restart the S5U1C17001H.

Oct/04/2013
errata_s5u1c17001h2_4
S1C17 Manual errata
ITEM:
Object manuals Document codes Items Pages
S5U1C17001H2 User Manual
(ICDmini Ver2.0)
411153403 4.1.2.1 Target reset signal output
(TARGET RST OUT)
16
(Error) 4.1.2.1 Target reset signal output (TARGET RST OUT)
When using the TARGET RST OUT output, a reset circuit as shown in the figure below is
recommended.

Oct/04/2013
errata_s5u1c17001h2_4
(Correct) 4.1.2.1 Target reset signal output (TARGET RST OUT)
The TARGET RST OUT terminal of S5U1C17001H2 is the following circ its.
Figure 4.1. 2.1 Target reset terminal output circuit
The reset p lse is the following waveforms. Please note that the rising p
waveform changes by the load sit ation of the target board.
Figure 4.1.2.2(a) Reset terminal output waveform
Target system reset signal
Selected by dip
switch (SW4,5)
3.3V 1.8V
4
3
2
1
S5U1C17001H2
Power supply
input from target
system
Voltage
Time
About14msec
RESET/START
switch
TARGET RST OUT Irregular
output
ON OFF
TARGET VCC IN
TARGET RST OUT

Oct/04/2013
errata_s5u1c17001h2_4
Figure 4.1.2.2(b) Reset terminal output waveform
Voltage
Time
About14msec
Input reset
command
on debugger
TARGET RST OUT
