1. Overview
S5U1C17564T Manual Seiko Epson Corporation 1
(Rev.1.0)
1. Overview
S5U1C17564T1 (SVT17564: Software eValuation Tool for S1C17564) and S5U1C17564T2 (SVTmini 17564:
Software eValuation Tool for S1C17564) *1 are evaluation and development boards for S1C17564, a single chip
microcontroller from Seiko Epson.
S5U1C17564T1 is a combination of two boards, a CPU board and a peripheral board. The CPU board is
equipped with an IC socket for S1C17564, an extension connector, a debug connector for S1C17564, etc. The
peripheral board is equipped with an EPD (Electrophoretic Display), a connector for the EPD, jumpers, through
holes, tact switches, etc. By using those peripherals, you can display data on EPD, use switch inputs, etc.
S5U1C17564T2 comes with a CPU board used in S5U1C17564T1 only and can be used for many applications
using an extension connector.
1)CPU S1C17564 (QFP15-128)
2) Power supply voltage External power supply (DC3.0V)
Coin battery (CR2032: 3.0V) CR2032 has been installed in the battery holder.
3) CPU clock generator OSC1 : 32.768kHz Crystal oscillator
OSC3 : 12.000MHz Crystal oscillator
4) Onboard devices
CPU board:
Socket for S1C17564 (S1C17564 has been installed in the socket.)
Crystal oscillator
Reset switch
Extension connector
LED
Connector
Jumper switches for various settings
Peripheral board:
Connector for EPD
EPD panel (2”EPD panel from Chilin)
Tact switches
Jumper switches for various settings
5) Accessories Jumper switches¯( )
Power cable
6) Operating ambient
temperature range
5 °C to 35 °C
7) Operating power
supply voltage range
2.8 V to 3.6 V
*1 S5U1C17564T1 is a package that comes with a peripheral board only.
S5U1C17564T2 is a package that comes with a CPU board only.

1. Overview
2 Seiko Epson Corporation S5U1C17564T Manual
(Rev.1.0)
1.1 Using the board
Follow the steps below to set up an evaluation environment to debug software for S1C17564 along with the
2”EPD panel from PDI.
<When you debug software>
(1) Use the dedicated cables bundled with S5U1C17001H2 (ICDminiVer.2) to connect the 4-pin connector for
target connection and the 4-pin connector for power supply for Flash writing on the ICDminiVer.2 to the
connectors CN2-1(J5) and CN2-2(J6) on the CPU board respectively.
(2) Set the jumper switch for REGEN selection (JP2) on the CPU board to the “EN” side.
(3) Short-circuit the jumper switches JP1, JP5, JP6, and JP7 on the CPU board.
(4) You do not need to supply power for the power connectors JP7, JP8, and JP9 on the CPU board.
(5) Use the USB cable bundled with the ICDminiVer.2 to connect the ICDminiVer.2 to the PC.
<In the case of free running operation using a coin buttery (when the CPU board and the peripheral board are
used in combination.)>
(1) You do not need to change the jumper switch settings on the CPU board.
(2) Disconnect all the cables to the ICDminiVer.2.
(3) Install a coin battery to the battery holder mounted on the peripheral board.
(4) Short-circuit the jumper (SW3) on the peripheral board.
*) Supply the power from the peripheral board (SVT17564: S5U1C17564T11).
*) As for the dip switch settings of the ICDminiVer.2, turn OFF all SW1-7 and turn ON
SW8.

S5U1C17564T Manual Seiko Epson Corporation 3
(Rev.1.0)
Table 1.1 List of jumper settings for each selection of power supply
Selection of power supply
Board Series Jumper SW
number Function Coin battery External power
supply ( CN1 )
power supply SW1 External power supply
SW OPEN SHORT : on
SW3 Coin batterySW SHORT : on OPEN
regulater SW2 shutdown OPEN
SW16 REG-enable SHORT
SW4 P52-Lo：shutdown OPEN
SW5 REG-OUT SHORT
SW6 PS-OUT OPEN
level shifter SW29 HVDD-IN SHORT
SW30 RVDD-IN SHORT
SW37 GND SHORT
panel SW9 - SHORT
SW12 - SHORT
SW7 - OPEN
SW8 - OPEN
SW10 - OPEN
SW11 - OPEN
bypass SW31 levelshifter bypass OPEN
SW32 levelshifter bypass OPEN
SW33 levelshifter bypass OPEN
SW34 levelshifter bypass OPEN
SW35 levelshifter bypass OPEN
SW36 levelshifter bypass OPEN
offset SW17 P45:Hi by SHORT OPEN
SW18 P45:Lo by SHORT OPEN
SW19 P44:Hi by SHORT OPEN
SW20 P44:Lo by SHORT OPEN
SW21 P43:Hi by SHORT OPEN
SW22 P43:Lo by SHORT OPEN
SW23 P42:Hi by SHORT OPEN
SW24 P42:Lo by SHORT OPEN
SW25 P41:Hi by SHORT OPEN
SW26 P41:Lo by SHORT OPEN
SW27 P40:Hi by SHORT OPEN
SW28 P40:Lo by SHORT OPEN
Peripheral
SHORT: Short-circuit the jumper switch OPEN: Remove the jumper switch
－: Any setting is OK (Other): Set the jumper switch to the specified side.

2. Function and name of each component
4 Seiko Epson Corporation S5U1C17564T Manual
(Rev.1.0)
2. Function and name of each component
2.1 Name of each component
The function and name of each component are shown below.
Figure 2.1 Names of the components on the front side of the S5U1C17564T1 CPU board.
Extension
connector
(J1)(Not mounted)
Reset SW
(SW1)
HVDD-IN
(J7)
LVDD-IN
(J8)
AVDD-IN
(J9)
Extension
connector
(J2)(Not mounted)
Extension
connector
(J3)(Not mounted)
Extension
connector
(J4)(Not mounted)
S1C17564
(U1)
1 Pin
Regulator
Enable/Disable
Select Jumper
(JP2)

2. Function and name of each component
S5U1C17564T Manual Seiko Epson Corporation 5
(Rev.1.0)
Figure 2.2 Names of the components on the back side of the S5U1C17564T1 CPU board.
Caution! The position of the pin 1 of the CN2-1 (J5) is as shown above. When you connect the
ICDminiVer.2 to this board, pay attention to the direction of the connector.
32.768kHz
Crystal Unit (X2)
12MHz
Crystal Unit
(X1)
ICDmini i/f
connector
(J6)
ICDmini i/f
connector
(J5)

2. Function and name of each component
6 Seiko Epson Corporation S5U1C17564T Manual
(Rev.1.0)
Figure 2.3 Names of the components on the front side of the S5U1C17564T1 peripheral board.
*) Components and circuit diagrams are subject to change without notice.
Important: There are two systems of power-supply, the coin battery and the external power supply.
Do not short-circuit the two power jumper switches (SW1 and SW3) at the same time.
Level-shifte
r
Power
management
Initial settings short
Bypass
Always Open
Powe
r
-supply
CR2032
When it is
On：short
Powe
r
-supply
External power
supply
When it is On：
short
Regulate
r
Output selection
Initial settings
SW5：short
SW6：Open
Offset
Select the input for P40
through P45.
You can select Hi or Lo
for each PORT.
Important:
Do not short-circuit both
Hi and Lo for each PORT.
You can select either Hi
or Lo but not both.
Area used for user
circuits
2.54 mm pitch
10×34 hole
You can fold it apart
from the peripheral
board.

2. Function and name of each component
S5U1C17564T Manual Seiko Epson Corporation 7
(Rev.1.0)
Figure 2.4 Names of the components on the back side of the S5U1C17564T1 peripheral board.
*) Components and circuit diagrams are subject to change without notice.
Powe
r
-supply
External power
supply
Connector (CN1)
Powe
r
-supply
CR2032
Coin battery

2. Function and name of each component
8 Seiko Epson Corporation S5U1C17564T Manual
(Rev.1.0)
2.2 Function of each component
2.2.1 Jumper switch function
Table 2.2.1 List of jumper functions on the peripheral board (initial settings)
Selection of power supply
Board Series Jumper SW
number Function Coin battery External power
supply (CN1)
power supply SW1 External power
supply SW OPEN SHORT : on
SW3 Coin battery SW SHORT : on OPEN
regulater SW2 shutdown OPEN
SW16 REG-enable SHORT
SW4 P52-Lo：shutdown OPEN
SW5 REG-OUT SHORT
SW6 PS-OUT OPEN
level shifter SW29 HVDD-IN SHORT
SW30 RVDD-IN SHORT
SW37 GND SHORT
panel SW9 - SHORT
SW12 - SHORT
SW7 - OPEN
SW8 - OPEN
SW10 - OPEN
SW11 - OPEN
bypass SW31 levelshifter bypass OPEN
SW32 levelshifter bypass OPEN
SW33 levelshifter bypass OPEN
SW34 levelshifter bypass OPEN
SW35 levelshifter bypass OPEN
SW36 levelshifter bypass OPEN
offset SW17 P45:Hi by SHORT OPEN
SW18 P45:Lo by SHORT OPEN
SW19 P44:Hi by SHORT OPEN
SW20 P44:Lo by SHORT OPEN
SW21 P43:Hi by SHORT OPEN
SW22 P43:Lo by SHORT OPEN
SW23 P42:Hi by SHORT OPEN
SW24 P42:Lo by SHORT OPEN
SW25 P41:Hi by SHORT OPEN
SW26 P41:Lo by SHORT OPEN
SW27 P40:Hi by SHORT OPEN
Peripheral
SW28 P40:Lo by SHORT OPEN

2. Function and name of each component
S5U1C17564T Manual Seiko Epson Corporation 9
(Rev.1.0)
2.2.2 Function of each part
Table 2.2.3 List of parts and functions of each component of the peripheral board.
Part name Location Function
IC U1 Power regulator for panel
U2, U3 Level-shifter MCU -> EPD
U4 Level-shifter EPD -> MCU
Connecter J1 to J4 Interface to the CPU board
CN1
Connector to the external power supply for the
peripheral board
CN2
Connector to the EPD panel (used for all 1.5", 2",
and 3"W)
CN3
Connector to the power supply for the EPD panel
on the peripheral board
Thermistor R4 Thermistor for the measurement of the ambient
temperature.
MOS-FET Q1 Used for control of the EPD panel
Tact switch SW13 to SW15 P20-P22 port input switches
CR2032 holder V0 Holder for a coin battery used for operation
check

3. Block diagram
10 Seiko Epson Corporation S5U1C17564T Manual
(Rev.1.0)
3. Block diagram
The following figure shows the block diagram of S5U1C17564T1.
Figure 3.1 S5U1C17564T1 block diagram
S1C17564
(IC socket)
EPD Panel
(PDI 2”)
CN2
VPP #RESET DSIO DST2 DCLK
ICDmini
Ver.2
PC(GNU17
v2.0.0 or over)
OSC4
OSC3
OSC2
OSC1
Crystal
12.00MHz
Crystal
32768Hz
J6
Peripheral Board
External Power
CN1
Battery Folder
CR2032
J5
J1
Peripheral Board
CPU Board
(S5U1C17564T2)
CN2
J2
J3
Tact
switch x 3
J4
FET/
SHDN/
THR/
AD
Jumper
Switch x 34
Regulater
Level-shifter

4. Connector
S5U1C17564T Manual Seiko Epson Corporation 11
(Rev.1.0)
4. Connector
4.1 CPU board connector
4.1.1 CPU board interface connector (J1 - J4)
Table 4.1 Pin assignment of CPU board interface connector (J1 and J2)
Pin No J1：S1C17564 connected
1 HVDD
2 HVDD
3 Non connected
4 Non connected
5 Non connected
6 Non connected
7 US_SDI0/P50
8 N.C
9 VSS
10 VSS
11 AIN1/P01
12 AIN0/P00
13 VSS
14 VSS
15 Non connected
16 Non connected
17 Non connected
18 Non connected
19 Non connected
20 P31/#BFR/#ADTRG
21 #SPISS/TOUT5/CAP5/P13
22 SDI0/P10
23 SDO0/P11
24 SPICLK0/P12
25 Non connected
26 SIN1/SDI1/P14
27 Non connected
28 SDA1/REMI/P43
29 Non connected
30 SCL1/REMO/P44
31 VSS
32 #BFR/SPISS2/P25
33 AVDD
34 US_SDO0/P51
35 VSS
36 SOUT1/SDO1/P15
37 SCLK1/SPICLK1/P16
38 SDO2/P24(EXCL3)
39 VSS
40 VSS
Pin No J2：S1C17564 connected
1 HVDD
2 HVDD
3 Non connected
4 SIN0/TOUT6/CAP6/P40
5 Non connected
6 Non connected
7 Non connected
8 SOUT0/TOUT7/CAP7/P41
9 Non connected
10 Non connected
11 Non connected
12 SCLK0/TOUT1/CAP1/P42
13 Non connected
14 Non connected
15 Non connected
16 Non connected
17 Non connected
18 Non connected
19 Non connected
20 Non connected
21 SDA0/P45(EXCL0)
22 #RESET
23 Non connected
24 SCL0/P17
25 Non connected
26 Non connected
27 Non connected
28 Non connected
29 Non connected
30 Non connected
31 VSS
32 Non connected
33 AVDD
34 TOUT4/CAP4/FOUTA/P32
35 VSS
36 AIN3/US_SSI1/P03
37 Non connected
38 AIN2/US_SSI0/P02
39 VSS
40 VSS

4. Connector
12 Seiko Epson Corporation S5U1C17564T Manual
(Rev.1.0)
Table 4.1 Pin assignment of CPU board interface connector (J3 and J4)
Pin No J3：S1C17564 connected
1 HVDD
2 HVDD
3 Non connected
4 Non connected
5 Non connected
6 P20/TOUT2/CAP2
7 Non connected
8 Non connected
9 Non connected
10 P21/TOUT3/CACP3
11 Non connected
12 Non connected
13 Non connected
14 Non connected
15 Non connected
16 Non connected
17 Non connected
18 Non connected
19 Non connected
20 Non connected
21 Non connected
22 Non connected
23 Non connected
24 Non connected
25 Non connected
26 Non connected
27 Non connected
28 Non connected
29 Non connected
30 P22(EXCL1)/FOUTB
31 Non connected
32 Non connected
33 Non connected
34 P23(EXCL2)/SDI2
35 Non connected
36 Non connected
37 Non connected
38 Non connected
39 VSS
40 VSS
Pin No J4：S1C17564 connected
1 HVDD
2 HVDD
3 Non connected
4 P52/US_SCK0
5 Non connected
6 P26/SDA1
7 Non connected
8 P27/SCL1
9 Non connected
10 P30/TOUT0/CAP0
11 Non connected
12 Non connected
13 Non connected
14 Non connected
15 DSIO/P36
16 DST2/P37
17 DCLK/P35
18 Non connected
19 Non connected
20 Non connected
21 Non connected
22 Non connected
23 Non connected
24 Non connected
25 Non connected
26 Non connected
27 Non connected
28 Non connected
29 Non connected
30 P53/US_SDI1
31 Non connected
32 P33/REMI/SPICLK2
33 Non connected
34 P34/REMO/#SPISS
35 Non connected
36 P54/US_SDO1
37 Non connected
38 P55/US_SCK1
39 VSS
40 VSS

4. Connector
S5U1C17564T Manual Seiko Epson Corporation 13
(Rev.1.0)
4.1.2 Debug interface connector (J5 - J6)
Table 4.5 Pin assignment of CPU board debug interface (J5)
No. Pin name I/O Function
1 DCLK O Clock signal for debugging
2 GND - Power (GND)
3 DSIO I/O Input/Output signal for serial interface
for debugging
4 DST2 O Debug status signal
Caution! The position of the pin 1 of the CN2-1 (J5) is as shown above. When you connect the ICDminiVer.2
to this board, pay attention to the direction of the connector.
Table 4.6 Pin assignment of CPU board interface connector (J6)
No. Pin name I/O Function
1 VPP I Power input for flash memory
programming
2 GND - Power (GND)
3 RESET I Reset signal input for the target
4 VCCIN O Target voltage output
4.1.3 Power connector (J7 - J9)
Table 4.7 Pin assignment of CPU board power connector (J7)
No. Pin name I/O Function
1 HVDD - Power(+)
2 GND - Power(GND)
Table 4.8 Pin assignment of CPU board power connector (J8)
No. Pin name I/O Function
1 LVDD - Power(+)
2 GND - Power(GND)
Table 4.9 Pin assignment of CPU board power connector (J9)
No. Pin name I/O Function
1 AVDD - Power(+)
2 GND - Power(GND)
4 3 2 1
1 2 3 4

4. Connector
14 Seiko Epson Corporation S5U1C17564T Manual
(Rev.1.0)
4.2 Peripheral board connector
4.2.1 Power connector (CN1)
Table 4.9 Pin assignment of peripheral board power connector (CN1)
No. Pin name I/O Function
1 VDD - Power(+)
2 GND - Power(GND)
*) When you supply external power to the peripheral board, connect the power to CN1.
4.2.2 Power connector (CN3)
Table 4.10 Pin assignment of peripheral board power connector (CN3)
No. Pin name I/O Function
1 VDD - Power(+)
2 GND - Power(GND)
*) If you need to supply power for the EPD panel on the peripheral board, connect the power to CN3.
(Normally, this connector is not used.)

4. Connector
S5U1C17564T Manual Seiko Epson Corporation 15
(Rev.1.0)
4.2.3 EPD panel interface connector (CN2)
Table 4.11 Pin assignment of EPD interface connector (CN2)
No Pin name I/O Function
1 CSB O cs
2 BUSY I Panel-BUSY
3 ID - -
4 SCLK O Clk
5 SI O DATA OUT(MCU)
6 SO I DATA IN(MCU)
7 RESET O RESET OUT(MCU)
8 - - -
9 - - -
10 - - -
11 - - -
12 - - -
13 - - -
14 - - -
15 - - -
16 - - -
17 - - -
18 - - -
19 - - -
20 - - -
21 - - -
22 - - -
23 - - -
24 - - -
25 - - -
26 - - -
27 - - -
28 - - -
29 - - -
30 - - -
31 - - -
32 - - -
33 - - -
34 - - -
35 - - -
36 - - -
37 - - -
38 - - -
39 - - -
40 - - -

Appendix A File organization of the sample software
16 Seiko Epson Corporation S5U1C17564T Manual
(Rev.1.0)
Appendix A File organization of the sample software
The following diagram shows the organization of the sample software.
[s1c17564-EPD_Demo]
│
├◆ GNU17 project files, command files, etc.
├.cproject
├.gnu17project
├.project
├.settings
├EPD_Demo_gnu17IDE.cmd
├EPD_Demo_NW_gnu17IDE.cmd
├EPD_Demo_gnu17IDE.lds
├EPD_Demo_gnu17IDE.mak
├EPD_Demo_gnu17IDE.par
├GDB17 Debugger for EPD_Demo.launch
├GDB17 Launch for EPD_Demo.launch
├GDB17 Launch for EPD_Demo_NW.launch
│
│
├◆ Boot, Model-dependent register offset header files
├boot.c
├s1c175xx.h
│
│
├◆ Application-related source files
├main.c
├datatbl.h
│
│
├◆ Driver-related libraries, header files
├epd.a
├epd.h
├osc.c
├osc.h
├osc1_wait.s
├init.h
│
│
├◆ Application-related header files
└datatbl.h
