ETC Source Four CE 405 User manual

Part Number: 7060M2510-06.01 Rev: C
Released: 2017-07
Source Four®
CE Assembly Guide
Production Dates: September 2004–Present

ETC
®
and Source Four
®
are registered trademarks of Electronic Theatre Controls, Inc. in the United
States and other countries.
All other trademarks, both marked and not marked, are the property of their respective owners.
ETC intends this document, whether printed or electronic, to be provided in its entirety.This
product is intended for professional use only. Read this entire document before using this product.

Table of Contents i
Table of Contents
Declaration of Conformity . . . . . . . . . . . . . . . . . 1
Help from ETC Technical Services . . . . . . . . . . . .2
Basic Luminaire . . . . . . . . . . . . . . . . . . . . . . . . . .3
Assembling the Basic Luminaire . . . . . . . . . . . . . . . . . . . . . . . .4
Lamp Socket Assembly . . . . . . . . . . . . . . . . . . . . 5
Assembling the Lamp Socket . . . . . . . . . . . . . . . . . . . . . . . . . .6
Reflector Housing Assembly . . . . . . . . . . . . . . . .9
Removing the Reflector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Installing the Reflector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Cleaning the Reflector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Shutter Barrel Assembly . . . . . . . . . . . . . . . . . .11
Assembling the Shutter Barrel . . . . . . . . . . . . . . . . . . . . . . . .12
Lens Tubes: 19°, 26°, 36°, and 50°. . . . . . . . . . . 14
Assembling the Lens Tube: 19°, 26°, 36°, and 50° . . . . . . . . .15
Lens Positions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Lens Markings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Assembling the Lens Tube . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Cleaning the Glass Lens: 19°, 26°, 36°, 50°, and
all EDLT lenses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Lens Tube: 10° . . . . . . . . . . . . . . . . . . . . . . . . . .19
Lens Tube: 5° . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Assembling the Lens Tubes: 5° and 10° . . . . . . . . . . . . . . . . .21
Cleaning the Polymer Lenses: 5° and 10°. . . . . . . . . . . . . . . .21

ii Source Four CE Assembly Guide
Lens Tube: 14° . . . . . . . . . . . . . . . . . . . . . . . . . .22
Lens Markings and Positions: 14° . . . . . . . . . . . . . . . . . . . . . .23
Assembling the Lens Tube: 14°. . . . . . . . . . . . . . . . . . . . . . . .23
Cleaning the Glass Lenses: 14° . . . . . . . . . . . . . . . . . . . . . . . .23
Lens Tube: 70° . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Lenses: 70° . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Lens Markings and Positions: 70° . . . . . . . . . . . . . . . . . . . . . .26
Assembling the Lens Tube: 70°. . . . . . . . . . . . . . . . . . . . . . . .26
Cleaning the Glass Lens: 70° . . . . . . . . . . . . . . . . . . . . . . . . . .26
Lens Tube: 90° . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Lenses: 90° . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Lens Markings and Positions: 90° . . . . . . . . . . . . . . . . . . . . . .29
Assembling the Lens Tube: 90°. . . . . . . . . . . . . . . . . . . . . . . .29
Cleaning the Glass Lens: 90° . . . . . . . . . . . . . . . . . . . . . . . . . .29

Declaration of Conformity 1
Declaration of Conformity
We, Electronic Theatre Controls, Europe Ltd., declare under sole responsibility that the
product:
Product name: Source Four CE
Product type/model: Source Four CE series (405, 410, 414, 419, 426, 436, 450,
470, 490)
Lot: n/a
Batch/Serial number: n/a
Item numbers: one of each model
to which this declaration relates in conformity with the following standards:
EN60598-1:2000 Luminaires, General requirements and tests
EN60598-2-17:1990 Specification for luminaires for stage lighting, television,
film, and photographic studios (outside and indoor) -
equiv. BS 4533-102.17:1990
following the provisions of EU LV Directive(s) 73/23/EEC
London, United Kingdom Mr. Adam Bennette
(Place of issue) (Name of authorised person)
(Date of issue) (signature of authorised person)
Electronic Theatre Controls, Ltd. Registered office:
Unit 26-28, Victoria Industrial Estate, Grant Thornton House
Victoria Road, London W3 6UU U.K. Melton St., London NW1 28W, England
Telephone (+44) (0)20 8896 1000 Registered in England No. 3057796
Fax (+44) (0)20 8896 2000 VAT No. 6629487 90

2Source Four CE Assembly Guide
Help from ETC Technical Services
If you are having difficulties, your most convenient resources are the references given in this
assembly guide. To search more widely, try the ETC website at etcconnect.com.
You can also contact ETC Technical Services directly at one of the offices identified below.
Emergency service is available from all ETC offices outside of normal business hours.
When calling for help, please have the following information handy:
• Product name and model
• Other components in your system (Dimmers, consoles, etc.)
Americas United Kingdom
ETC, Inc. ETC Ltd
Technical Services Department Technical Services Department
3031 Pleasant View Road 26-28 Victoria Industrial Estate
Middleton, WI 53562 Victoria Road,
800-775-4382 (USA, toll-free) London W3 6UU England
[phone] [phone]
[email protected] [email protected]
Asia Germany
ETC Asia ETC GmbH
Technical Services Department Technical Services Department
Room 1801, 18/F Ohmstrasse 3
Tower 1, Phase 1 Enterprise Square 83607 Holzkirchen, Germany
9 Sheung Yuet Road [phone]
Kowloon Bay, Kowloon, Hong Kong [email protected]
[phone]
[email protected]

Basic Luminaire 3
Basic Luminaire
Reference Part Number Description Quantity
1 7060A2208 Lamp socket assembly (See
page 6 )1
2 7060A2211 Reflector housing assembly, single clutch 1
2A 7060A2220 Reflector housing assembly, double clutch 1
3 7060A2012 Shutter barrel assembly 1
4 7060A2000-K 5° lens tube, with knob (See
page 20 )1
5 7060A2001-K 10° lens tube, with knob (See
page 19 )1
6 7060A2050-K 14° lens tube, with knob (See
page 22 )1
7 7060A2202-K 19° lens tube (6 x 16), with knob (See
page 14 )1
8 7060A2203-K 26° lens tube (6 x 12), with knob (See
page 14 )1
9 7060A2204-K 36° lens tube (6 x 9), with knob (See
page 14 )1
10 7060A2205-K 50° lens tube (4.5 x 6), with knob (See
page 14 )1
11 7060A2051-K 70° lens tube, with knob (See
page 24 )1
12 7060A2052-K 90° lens tube, with knob (See
page 27 )1
13 7060A4008-01 Knob set with male insert 2
14 HW5143 Washer, flat fiber 1
15 HW5197 Screw, 1/4-20 x 5/8, black zinc 2
17 HW5200 Washer, spacer, .253 x .281 x .438 1
18 HW349 Washer, Ext #8, .170 x .381 x .023, zinc 1
19 HW3117 Screw, 8-32 x 3/8, Taptite 1
1
2
2A
13
13
14
15
Figure 1
4
5
6
7
8
9
10
11
12
3
Colour frame
Gel retainer
clip
15
17
18
19

4Source Four CE Assembly Guide
Assembling the Basic Luminaire
1: Follow instructions under Assembling the Lamp Socket on page 6 .
2: Follow instructions under
Reflector Housing Assembly on page 9 .
3: Follow instructions under
Shutter Barrel Assembly on page 11 .
4: Assemble Lens Tubes following the instructions for your applicable lens degree application.
5: Insert lens tube assembly (4–12) fully into the shutter barrel assembly (3). Align the mounting
hole with the slot and secure with knob (13). Install screw (15) and spacer (16) on top of shutter
barrel. See
Figure 1 .
6: Install reflector housing (2) onto shutter barrel assembly (3) and align the two mounting holes.
Secure with screw (15) top of reflector housing and knob (13) on bottom. Tighten both securely.
See
Figure 1 .
7: Install the lamp socket assembly (1) to the reflector housing (2) and secure with brass knurled
screw on rear of lamp socket assembly.
8: Secure the earth bond wire to the luminaire body using screw (19) and washer (18).
9: Release the gel retaining clip by pushing it sideways while gently pulling backwards.
10: Insert the colour frame.
11: Lock the clip by pushing sideways while gently pushing it forward.

Lamp Socket Assembly 5
Lamp Socket Assembly
Reference Part Number Description Quantity
1 7060A3055 Housing, socket, casting, painted 1
2 7060A3007 Socket, light baffle casting, raw 1
3 7060A4007 Knob, X-Y, lamp set 1
4 7060A4008-02 Knob, Z, lamp set w/female insert 1
5 7060A4011 Bushing, cup 1
6 7060A3011 Hub, index, casting 1
7 7060A3012 Spring, lamp retainer 1
8 HW748 Spring, compression 1
9 7060B7013 Complete CE socket assembly 1
10 HW534 Nut, hex, 1/4-20, black zinc 1
11 7060A3025 Screw, 1/4-20 knurled head 1
12 HW746 Retaining ring, flat, Southco 1
13 HW5123 Nut, hex, 9/16-18, black zinc 1
14 HW747 Washer, wave 1
15 7060A3056 Clamp, strain relief, painted 1
16 HW3103 Screw, 8-32 x 5/8 PhFHMS, black zinc 2
17 HW5122 Bolt, 1/4-20 x 1.75, full thread, black zinc 1
18 HW8209 Clip Tinnerman 1
19 7060B7014 Source Four CE ground wire 1
20 7060B7013 Source Four CE cable assembly 1
21 HW749 Spring, ground 1
22 HW349 Washer, ext. #8 1
23 7060A4037 Handle, insulated rear, black 1
24 HW2181 Screw, 6-32 x 3/4, Taptite 4
25 7060A3085 Source Four lamp retainer wire 1
26 7060A7017 Source Four retainer wire 1
27 HW385 Screw, 8-32 x 3/8, PhPHMS, SEMS 2
28 HW2125 Screw, 6-32 x 3/8, PhFHTC, Typ 1, zinc 1
6
5
1
13
20
21
9
10
19
2
25 17
18
23
24
11
4
3
8
12
15
16
19 7
22
Figure 2
4
28
26
26

6Source Four CE Assembly Guide
Assembling the Lamp Socket
Tools Required:
• Open-end adjustable wrench or a 7/16” (11 mm) socket
• Needle-nose pliers
• #2 Phillips screwdriver
1: Set the crossbar of the retainer clip (25) under the two hooks on the clip bracket as shown in
Figure 3 .
2: Place the Tinnerman clip (18) over the retainer clip crossbar between the two hooks and press it
down firmly until it snaps into place.
3: Insert the bolt (17) through the light baffle socket casting (2). See
Figure 4 .
4: Install the green and yellow ground wire assemblies (19 and 22) on the bolt (17) with the prongs
on the crimped connectors toward the casting. Run both wires through the indent in the lip
around the bolt hole. Secure with nut (10) and tighten securely (6.7 Newton meters).
5: Place the socket assembly (9) into the light baffle socket casting (2). Be sure it is well seated.
6: Install the lamp retainer spring (7). The lamp retainer spring secures the socket. Insert the spring
one end at a time, making sure that the rectangular slot in each side of the spring seats on the
corresponding tab in the casting. See
Figure 4 .
Note:
If the spring does not seat correctly, coax it into place with a screwdriver or needle-
nose pliers.
18
25
Figure 3
18
17
2
22
19
25
9
7
10
Figure 4
28

Lamp Socket Assembly 7
7: Install the bushing cup (5) into the housing socket casting (1) as shown in Figure 5 . The cup
should slide smoothly up and down, but not side to side.
8: Insert the threaded end of the index hub (6) through the holes in the bushing cup and the back
of the housing socket casting (1).
9: Slide the X-Y knob (3) over the exposed index hub bolt (6), then insert the wave washer (14) on
the bolt and secure with the 9/16 hex nut (13). Hand-tighten the X-Y knob (3).
10: Insert the knurled head screw (11) through the housing socket casting (1) as shown in
Figure 6 .
11: Install the ground spring (21) onto the screw and secure it with the Southco flat retaining
ring (12). Install the Southco ring with its prongs away from the casting.
12: Lay the leads in the bottom half of the cable clamp (located in the housing socket casting [1]),
making sure that the cable insulation jacket extends slightly past the screw holes in the housing
socket casting. Then, route the wires as shown in
Figure 7 .
13: Install the top half of the cable clamp (15) and secure it with the two screws (16). Tighten the
screws alternately to ensure a solid connection.
Note:
Install the wave washer with the upward curve toward the hex nut.
Note:
Use pliers to straighten the Southco retaining ring (12) if it bends when you install it
on the bolt.
CAUTION:
You must follow the wire routing diagram to ensure that the socket leads do
not interfere with the lamp focus mechanism.
5
1
6
14
13
3Figure 5
11
15
122
21
12
Cable Clamp in
Housing
16
8
4
Figure 6 Figure 7
Brown wire
Green/Yellow
wire
17
26
9
Safety wire
Blue wire
Green/Yellow
wire

8Source Four CE Assembly Guide
14: Using the four screws (24), attach the handle (23) to the lamp socket assembly. See Figure 2 .
15: Place the compression spring (8) on the protrusion on the inside of the index hub. See
Figure 6 .
16: Insert bolt (17) through spring (8) and through the index hub (6) of the housing socket (1), joining
the two castings as shown in
Figure 6 . Make sure that the wires are not pinched between the
two pieces.
17: Before proceeding, check again to make sure that the wires are still positioned as indicated in
Figure 7 . Adjust if necessary.
18: Press the two castings together firmly so the bottom of the light baffle (2) sits on top of the cable
clamp (15), then install the Z knob (4). Hand-tighten the knob all the way to the right. See
Figure 6 .
Note:
Make sure that the top edge of the cable clamp is even with the edge of the socket
to prevent interference with lamp focus movement. Make sure that the insulation
jacket is not pinched.
CAUTION:
You must install the Z knob as described above to ensure proper lamp focus
travel.

Reflector Housing Assembly 9
Reflector Housing Assembly
Removing the Reflector
Tools Required:
• Minimally padded work surface (cardboard, carpet, or rubber mat recommended)
1: Place the reflector housing facedown on your work surface so that the concave reflector surface
points downward.
2: Loosen the clutch and rotate the yoke so that it is perpendicular to the housing at roughly a
90° angle. Tighten the clutch.
Reference Part Number Description Quantity
1 7060A2013 Housing, reflector casting, single clutch 1
1A 7060A2019 Housing, reflector casting, double clutch 1
2 7060A3006 Clip, reflector retainer 4
3 7060A4010 Bushing, gate 4
4 7060A3016 Plate, clutch 1
5 7060A3019 Spring, reflector support 1
6 7060A4015 Reflector, molded glass, coated 1
7 7060A3058 Bracket, yoke, painted 1
8 HW8144 Handle, yoke knob, 5/16 - 18 2
9 HW753 Rivet, machine, 3/16 x.720, flat head, black zinc 2
10 HW5126 Washer, flat, 5/16, black zinc 4
11 HW5193 Bolt 5/16-18 x 3/4, black zinc 2
12 HW5125 Bolt, carriage, 5/16-18 x.75, black zinc 2
13 HW752 Rivet machine, 3/16 x 5/16, black zinc 4
WARNING: This procedure may crack or break the reflector. Always wear gloves, safety
glasses, and a dust mask when performing this procedure.
SOURCE FOUR
UL
Double-clutch reflector housing
for 5° and zoom luminaires
1
1A
2
38
5
6
7
9
10
11
12
13 Figure 8
4

10 Source Four CE Assembly Guide
3: Using the yoke as your handle, raise the housing assembly off of the work surface a few inches
and then firmly tap the housing on the work surface. This should force the reflector out of its
clips.
4: Carefully lift the housing to see if the reflector is released. If it is not, repeat step 3 with slightly
more force.
Installing the Reflector
1: Place the reflector housing casting (1) on a flat work surface with the large opening facing up.
2: Install the reflector support spring (5) in the circular opening at the base of the casting.
3: Insert the reflector (6) at an angle, under any three adjacent legs of the reflector’s clips.
4: Gently press down on the opposite side of the reflector until it snaps into place under the
remaining clips.
Cleaning the Reflector
Remove dust with a blast of oil-free air or wipe with a clean, lint-free cloth. Isopropyl alcohol,
distilled water, or a 50%-50% mixture of each can be used to clean the glass surface.
Note:
The following assumes that all four reflector retainer clips (2) have already been
riveted to the reflector housing casting (1) and the gate bushings (3) have been
installed on the retainer clips. See Figure 8.
Note:
If the reflector does not snap in, turn the casting over. Gently pull on the side of the
reflector that has not snapped in until the rest of the reflector slides into place.
WARNING: Do not use ammonia-based or other harsh commercial cleaners. Clean
reflector only as directed.
Commercially available glass cleaning agents should be avoided as they may
contain ammonia, other harsh chemical detergents or abrasive agents. These
cleaners may damage the glass surface and the Anti-Reflective coatings. Do
not immerse or soak the glass in any cleaning solution.
Step 3 Step 4
Under three
adjacent legs
of the
reflector’s
clips

Shutter Barrel Assembly 11
Shutter Barrel Assembly
Reference Part Number Description Quantity
1 7060A3052 Shutter barrel, top casting, black 1
2 7060A3053 Shutter barrel, bottom casting, black 1
3 7060A2025 Shutter blade assembly, 0.65 mm 4
4 7060A3001-01 Plate, divider with dimples (bottom) 1
5 7060A3003 Plate, gate (middle) 2
6 7060A3001-02 Plate, divider (top) 1
7 HW754 Shutter spring 4
8 HW3165 Screw, 8/32 x 1/2, Taptite 4
9 7060A3045 Cover, iris slot 1
10 HW372 Screw, 8-32 x 1/4, black zinc 2
Shutter Assembly: The bottom divider
plate (4) has four dimples punched into
the surface; the top plate (6) has none.
The middle divider plates (5) are
noticeably thinner metal than the other
two.
1
2
See detail to
the right
7
8
9
10
3
5
6
4
Figure 12
Figure 13
3
3

12 Source Four CE Assembly Guide
Assembling the Shutter Barrel
Tools Required:
• #2 Phillips head screwdriver
1: Stand the top and bottom shutter barrel castings (1 and 2) upright with the shutter end of the
castings toward the bottom.
2: Slide the bottom divider plate (4) into its place in the bottom casting (2). The dimples on the
divider plate must point down.
3: With the bottom barrel casting (2) to your left, place two shutter blades (3) on top of the dimple
plate (4) and opposite each other so that together they form a barrier. The handles should extend
past the barrel casting, rivets pointed down. These will be the side shutters (See
Figure 13 ).
4: Place a divider plate (5) on top of the two shutter blades.
5: Place another shutter blade on top of the middle divider plates and perpendicular to the
previously installed shutter blades. This will be the top shutter, so align the handle away from the
bottom casting (2) and then place the other divider plate on top.
6: Place the fourth shutter blade on top of the divider and through the bottom casting in the final
shutter position. Pull the blade and plate assembly slightly forward to allow the handle to slip
through the slot in the bottom casting, and then fully seat the blade assembly into the casting
again.
7: Place the top divider plate (6) on top of the fourth shutter blade.
8: With both shutter barrel castings still standing upright, join the two halves, sliding the handle of
the top shutter blade through the slot in the top shutter barrel casting (1).
9: Starting at the bottom of the castings (closest to the shutters), use four PHMS screws (9) to fasten
the shutter barrel casting halves together, as shown. Hand-tighten only (2.8 Newton meters).
WARNING: During assembly, the shutter springs can pop out of place. Always wear
protective eyewear during this procedure.
Note:
The top shutter barrel casting contains the iris slot.
Note:
The bottom divider plate (4) has four dimples punched into the surface; the top
plate (6) has none. The middle divider plates (5) are noticeably thinner-gauge metal
than the other two.
The notches on the divider plates must fit against the flanges in the casting so that
the plates do not move.
WARNING: Divider plate edges are sharp. Handle with caution.
Note:
Make sure that no shutter assembly components are under the gobo holder guides.
Note:
The ends of the two shutter barrel castings must be even. Adjust them as necessary
before completely tightening the nuts and screws. Failure to do this could interfere
with the barrel rotation.

Shutter Barrel Assembly 13
10: Turn over the shutter barrel assembly so that the narrower end is on your work surface.
11: Install the four shutter springs (7) between the four dimples in the shutter plate and the tabs in
the lip of the casting.
12: Place the iris slot cover (9) over the iris slot. Use two screws (10) to secure the cover.
Note:
Install the springs at the joints in the castings on either of the tabs at the joint. Once
they are installed, the springs at the joints will sit at a slight angle.

14 Source Four CE Assembly Guide
Lens Tubes: 19°, 26°, 36°, and 50°
Reference Part Number Description Quantity
1 7060A3169 Lens tube, left, black 1
2 7060A3171 Lens tube, right, black 1
3 7060A4009 Bushing, guide 8
4 7060A4012 Pad lens support - asphere 5
Pad lens support - meniscus set 10
5 7060A4077 Aspheric lens, 19° 1
6 7060A4001 Aspheric lens, 26° 1
7 7060A4004 Aspheric lens, 50° 1
8 7060A4020 Meniscus lens, 36° set, front 1
8A 7060A4123 Bi-convex lens, 36° set, coated, rear (36° Only) 1
9 7060A3079 Clip, gel retainer, 90° bend 1
10 HW750 Spring, retainer 1
11 HW369 Screw, Phillips, 8-32 x 5/8, Taptite 4
12 HW534 Nut, hex, 1/4-20, black zinc 2
13 7060A4008-01 Knob set with male insert 1
14 HW5143 Washer, flat, 1/4 1
15 7060A4033 19° lens tube label 1
16 7060A4034 26° lens tube label 1
17 7060A4035 36° lens tube label 1
18 7060A4036 50° lens tube label 1
19 7060A1047 Safety Screen, S4 Enhanced 1
20 HW5200 Washer, .251 x .281 x .438, brass 1
21 HW5197 Screw, 1/4-20 x 5/8, PHRMS, black zinc 1
11
1
2
3
4
5
6
7
8
8A
9
10
12
13
14
15, 16, 17, 18
Figure 14
Note: Lenses are
degree-specific. Do not
interchange lenses (i.e.,
do not place a 19° lens in
a 26° slot).
19
21
20

Lens Tubes: 19°, 26°, 36°, and 50° 15
Assembling the Lens Tube: 19°, 26°, 36°, and 50°
Lens Positions
The lens tube casting can accept either original or Enhanced Definition (ED) lenses. The lens
positions are colour-coded within the lens casting to match the coloured dots on the lenses
(see
Figure 15 ). Only lenses bearing at least one dot of the indicated colour should be placed
in that position.
Figure 15
Blue 
BLU
36
36ED
19ED
50ED
Yellow 
YLW
50
26ED
Green 
GRN
50ED
Orange 
ORNG
36
36ED
Black 
BLK
26
Red 
RED
19
19ED
26ED
Align lens dots toward this end

16 Source Four CE Assembly Guide
Lens Markings
The lenses are colour-coded for identification. Normal lenses have a single dot of colour while
Enhanced Definition lenses have a combination of white dots and colour dots. See
Figure 16
for lens colour coding.
Standard Lenses
19°
26°
36°
50°
19° ED
26° ED
36° ED
50° ED
Rear lens: 1 white dot & 1 blue dot
Front lens: 1 white dot & 1 red dot
Rear lens: 1 white dot & 1 yellow dot
Front lens: 1 white dot & 2 red dots
Rear lens: 1 white dot & 2 blue dots
Front lens: 1 white dot & 1 orange dot
Rear lens: 1 white dot & 3 blue dots
Front lens: 1 white dot & 1 green dot
Lens: Red Dot*
(one or two dots)
Lens: Black Dot*
(one or two dots)
Lens - Yellow Dot*
(one or two dots)
Rear lens: Blue dot
Front lens: Orange dot
Align lens dots toward this end
Enhanced Definition Lenses
For maximum gel life with specific lens tubes, refer to these tables
Figure 16
* Some pre-2006 luminaires have lenses with two colour-code dots. There is no difference between lenses with
one dot or two dots.
