Source Four Mini LED
User Manual
Part Number: 7063M1220 Rev H
Released: 2023-07

To view a list of ETCtrademarks and patents, go to
etcconnect.com/ip. All other trademarks, both marked and not
marked, are the property of their respective owners.
For a complete list of all third-party licenses that are fully
incorporated herein to the extent required by each third-party
license terms and conditions, please visit etcconnect.com/licenses.
ETC intends this document, whether printed or electronic, to be
provided in its entirety.

Table of Contents
Source Four Mini LED User Manual i
Introduction 1
Safety 2
Installation 4
Install a Lens Tube 4
Install Track-Mounted Luminaire
(OneTrack) 5
Install Track-Mounted Luminaire
(DataTrack) 6
Use the AD1 Track Adapter 7
Install Canopy Luminaire 7
Install Portable Luminaire with C-clamp
(120VOnly) 8
Focus and Setup 9
Adjust the Tilt 9
Lock the Rotation (Canopy and
Track-Mount) 10
Focus the Beam 10
Shape the Beam 10
Use the Color Frame Holder 11

Cleaning 12
Specifications and Reference 13
FCC Compliance 13
ii Source Four Mini LED User Manual

Source Four Mini LED User Manual 1
Introduction
The Source Four Mini LED has three available mounting options:
•Portable: Includes a miniature C-clamp (North America only) and
yoke-mounted driver, and has a permanently installed power cord
with 3-prong Edison connector. Region-specific connectors are
available. Contact ETC for available options. Use L5-15 plugs on
branch circuits with L5-15 receptacles only.
•Track-mount and Canopy:Both the track-mount luminaires and the
canopy luminaire include an integral driver.
You must install a lens tube before you use the Source Four Mini LED. There
are four lens tube sizes available: 19°, 26°, 36°, and 50°. See Install a Lens
Tube on page4 .
Canopy
Track-mount
(DataTrack)
Portable
Track-mount
(OneTrack)
Note: The miniature C-clamp for the portable luminaire is available
only in North America. In the EU and UK, use an M10 bolt to secure
a clamp (provided separately) to the luminaire.

2 Source Four Mini LED User Manual
Yoke
Pattern
holder slot
Shutter
barrel
Lens tube
Color frame
retainer clip
Color
frame
Safety cable
attachment point
Shutters x4
Beam
focus knob
Safety
WARNING: Note the following safety warnings before use:
• Use the luminaire in dry locations only, where humidity
does not exceed 90 percent (non-condensing).
• Do not mount the luminaire on or near a flammable
surface.
• Check that the accessory holder is locked before
mounting the luminaire.
• Do not operate the luminaire without a lens installed.
• Do not use this luminaire if a lens is deeply scratched or
cracked. You must replace a lens when it is damaged.
AVERTISSEMENT : Prendre connaissance des avertissements
de sécurité suivants avant toute utilisation :
• Ne pas installer le projecteur sur ou à côté d’une surface
inflammable.
• Vérifiez que le porte-accessoires est verrouillé avant de
monter le projecteur.
• N’utilisez pas le projecteur sans que la lentille soit
installée.

Source Four Mini LED User Manual 3
IMPORTANT SAFEGUARDS
INSTRUCTIONS PERTAINING TO A RISK OF FIRE, ELECTRIC SHOCK, OR
INJURY TO PERSONS
• Keep lamp away from materials that may burn.
• Do not touch hot lens, guard, or enclosure.
• Do not remain in light if skin feels warm.
• Do not look directly at lighted lamp.
• External temperature after 5 minutes of full-brightness operation:
50°C (122°F).
• External temperature when steady state is achieved: 67°C
(152.6°F).
SAVE THESE INSTRUCTIONS
Canopy Luminaire
WARNING: RISK OF ELECTRIC SHOCK! Power must be off
when you perform this procedure.
The luminaire must be installed by a qualified electrician in
accordance with all national and local electrical and
construction codes and regulations.
AVERTISSEMENT : RISQUE DE DÉCHARGE ÉLÉCTRIQUE!
L'alimentation doit étre éteinte avant d'exécuter cette
procédure.
Track-Mount Luminaire
WARNING: To reduce the risk of fire and electric shock, use
the track-mount luminaire only with its designated track
system (for example, One Track or DataTrack).
AVERTISSEMENT : Pour éviter le risque d'incendie ou de
choc électrique, utiliser le luminaire à adaptateur pour rail
uniquement avec son système de rail désigné (OneTrack ou
DataTrack par exemple).
WARNING: Use the DataTrack track-mount luminaire with
ceiling-mounted track only.

4 Source Four Mini LED User Manual
The following symbols may appear on product labeling.
The luminaire must be installed at
least 0.1m (4.0in) away from all
lighted objects.
Le luminaire doit être installé à au
moins 0,1m (4,0po) de tout objet
éclairé.
This product should not be
discarded as unsorted waste but
must be sent to separate collection
facilities for recovery and recycling.
Ce produit ne doit pas être jeté avec
les déchets ménagers mais doit être
déposé dans une collecte de déchets
électroniques ou dans un point de
collecte.
This product meets the safety
requirements specified for Class II
equipment according to IEC 61140
or IEC60536.
Ce produit à Protection Classe II
Double isolation est conforme aux
normes IEC 61140 ou IEC 60536.
Installation
Install a Lens Tube
You must install a lens tube before you use the Source Four Mini LED. There
are four lens tube sizes available: 19°, 26°, 36°, and 50°.
Lens Tube Description
4M19LT (-1, -5) 19° Source Four Mini Lens Tube Only Black (White, Silver)
4M26LT (-1, -5) 26° Source Four Mini Lens Tube Only Black (White, Silver)
4M36LT (-1, -5) 36° Source Four Mini Lens Tube Only Black (White, Silver)
4M50LT (-1, -5) 50° Source Four Mini Lens Tube Only Black (White, Silver)
1. Unscrew the beam focus knob from the loose lens tube.
2. Slide the lens tube into the shutter barrel.
3. Install the beam focus knob.

Source Four Mini LED User Manual 5
Install Track-Mounted Luminaire (OneTrack)
WARNING: To reduce the risk of fire and electric shock, use
the track-mount luminaire only with its designated track
system (for example, One Track or DataTrack).
AVERTISSEMENT : Pour éviter le risque d'incendie ou de
choc électrique, utiliser le luminaire à adaptateur pour rail
uniquement avec son système de rail désigné (OneTrack ou
DataTrack par exemple).
1. Before you begin, verify that the adapter
is unlocked. (Images at right show just
the OneTrack adapter.)
2. Orient the adapter so that the two tabs
are aligned with the groove in the track,
and then insert the adapter into the
track. The tab at the end of the adapter
locks into the track when the fixture is
fully seated.
WARNING: When using
the circuit selection lock,
ensure that the selected
circuit is a constant
power circuit. Selecting a
dimmable circuit may
cause luminaire damage
that will void the ETC
warranty.
Verify adapter
is unlocked
Align tabs
to groove Tab locks
into track
3. Flip the locking tab to the
opposite side to lock the
adapter, and then rotate the
circuit selection knob to
select the correct circuit.
4. Focus the luminaire.
Flip to lock
Rotate to
align circuit
with triangle

6 Source Four Mini LED User Manual
Install Track-Mounted Luminaire (DataTrack)
WARNING: To reduce the risk of fire and electric shock, use
the track-mount luminaire only with its designated track
system (for example, One Track or DataTrack).
AVERTISSEMENT : Pour éviter le risque d'incendie ou de
choc électrique, utiliser le luminaire à adaptateur pour rail
uniquement avec son système de rail désigné (OneTrack ou
DataTrack par exemple).
WARNING: Use the DataTrack track-mount luminaire with
ceiling-mounted track only.
Tabs
Circuit
selection wheel
Lock
1. Insert the DataTrack adapter into
the track. The adapter only fits into
the track one way with the tabs
nesting into the track’s groove.
2. Rotate the locking mechanism to
lock the adapter into place.
WARNING: When using the circuit selection lock,
ensure that the selected circuit is a constant power
circuit. Selecting a dimmable circuit may cause
luminaire damage that will void the ETC warranty.
3. Use the circuit selection lock to select the circuit. The desired circuit
number should point toward the center of the adapter.
4. Focus the luminaire.
5. Lock the luminaire into place using the yoke lock.
Cable protection
posts on both the
yoke lock and the
yoke prevent the
luminaire from
rotating a full
360°. To lock the
yoke in place use
a 1.5 mm hex key.

Source Four Mini LED User Manual 7
Use the AD1 Track Adapter
ETC offers the option of installing a track-mounted luminaire with an
adapter that is compatible with Halo Track Systems. Halo Track Systems are
not available from ETC, but the Source Four Mini LED luminaire can be
custom-ordered from ETC with the AD1 track adapter.
To use the adapter with the Source Four Mini LED
luminaire, push the tab on the adapter to the lower
position (see image at right).
To install a luminaire with the AD1 adapter:
1. Pull back on the retaining sleeve.
2. Insert the adapter into the track with the gold tabs parallel to the
track.
3. Release the sleeve and rotate until you feel the adapter snap securely
into place.
Install Canopy Luminaire
WARNING: RISK OF ELECTRIC SHOCK! Power must be off
when you perform this procedure.
The luminaire must be installed by a qualified electrician in
accordance with all national and local electrical and
construction codes and regulations.
AVERTISSEMENT : RISQUE DE DÉCHARGE ÉLÉCTRIQUE!
L'alimentation doit étre éteinte avant d'exécuter cette
procédure.
Mounting plate
Ground
bolt
Ground
braid
Mounting
plate bolts
Canopy plate
(four indentations
allow for multiple
bolt nesting
positions)
Canopy
bolts

8 Source Four Mini LED User Manual
1. Remove the mounting plate from the luminaire by removing the two
canopy bolts and the ground bolt. Set the ground bolt aside.
2. Using the mounting plate bolts, secure the mounting plate to the
installed back box (not included).
CAUTION: The canopy plate has built-in indentations
allowing the mounting plate bolts to nest into the canopy
plate. For an ideal flush-mount installation, you may need to
rotate the plate to accommodate these indentations. See the
following image.
1
1
2
2
Mounting plate
installation detail
Canopy
bolt hole
3
3
Canopy
bolt hole
Install the mounting plate screws in one of the three
position-pairings shown. Only the slots on the outer
circumference will allow a true flush mounting.
3. Place the copper ground braid loop over the ground bolt and attach
the ground bolt to the back box.
4. Connect the building ground wire to the ground wire on the
luminaire, following local electrical codes.
5. Connect the supply power wires to the luminaire wiring using the
included WAGO®connectors.
• For 120 V luminaires: Connect the black wire to line and the
white wire to neutral.
• For 230 V luminaires: Connect the brown wire to line and the
blue wire to neutral.
6. Use the canopy bolts to secure the luminaire to the mounting plate.
7. Open all four shutter blades by sliding them outward until they stop.
8. Install a gobo and gel as desired and confirm that they are properly
secured.
9. Restore power at the disconnect device.
10. Focus the luminaire as needed.

Source Four Mini LED User Manual 9
Pipe bolt
Yoke bolt
C-clamp
Install Portable Luminaire
with C-clamp (120VOnly)
The C-clamp attaches the luminaire to the
mounting pipe and allows you to adjust the
position of the luminaire once it is mounted.
The C-clamp will fit a 3/8in to 1in pipe.
1. Tightly fasten the C-clamp to the yoke
with the provided yoke bolt and
washers.
2. Place the C-clamp on the mounting pipe, and then tighten the pipe
bolt to secure it.
3. Loosen the yoke bolt and rotate the yoke as needed.
CAUTION: Tighten the C-clamp pipe bolt to about 2 Nm
(1.5ft-lb), which is approximately finger-tight plus up to
one-quarter turn. Do not use excessive force.
4. Tighten the bolt to lock the luminaire position.
Note: The miniature C-clamp for the portable luminaire is available
only in North America. In the EU and UK, use an M10 bolt to secure
a clamp (provided separately) to the luminaire.
5. Open all four shutter blades by sliding them outward until they stop.
6. Focus the luminaire as needed. See Focus and Setup below .
Focus and Setup
Yoke locking
knob
Adjust the Tilt
1. Loosen, but do not remove the
yoke locking knob.
2. Tilt the luminaire as needed.
3. Tighten the yoke locking knob.

10 Source Four Mini LED User Manual
Lock the Rotation (Canopy and Track-Mount)
Yoke lock
1. Rotate the luminaire
to the desired
position. To protect
the wiring, the
luminaire cannot
rotate completely
around.
2. Insert a 1.5 mm hex key into the small hole on the yoke lock, and turn
it to tighten the yoke lock.
Beam focus knob
Focus the Beam
Loosen the beam focus knob, adjust the
lens tube position as needed, and then
tighten the knob.
Shape the Beam
You can shape the beam using the four shutters or with a pattern.
Shape the Beam with
Shutters
The luminaire has four shutters: left,
right, top, and bottom. Each shutter can
be pulled out or pushed in to create the
desired beam shape.

Source Four Mini LED User Manual 11
Shape the Beam with a Pattern
25.4 mm
(1 in)
Diameter
The luminaire has a pattern-holder slot on the top side of
the shutter barrel, in front of the shutter. It accommodates
a glass or stainless steel E-size (37.5mm with a 25.4mm
image area) pattern. The maximum pattern thickness that
can be accommodated is 1.1mm (0.04in).
Use an optional donut in the color frame holder to enhance
pattern projection.
When the slot is not in use, a small sheet metal cover
secured with a Phillips screw prevents light leakage.
1. Use a Phillips screwdriver to loosen the screw on the slot cover. Do not
remove the screw.
2. Slide the cover knob on the luminaire completely to the side to expose
the slot.
3. Insert the pattern holder.
4. Slide the slot cover back toward the shutters until it meets the pattern
handle. Leave enough space to move the handle.
5. Secure the slot cover by tightening the screw.
Use the Color Frame Holder
The Source Four Mini LED comes equipped with a color frame (either 70mm
or 2 3/4in), which is a metal frame used to hold color media (often referred
to as gel) in front of the lens. The color frame holder is equipped with a
retaining clip that prevents the color frame from falling out.
Additional accessories are available that also fit into the color frame holder:
top hat, short top hat, half hat, short half hat, and donut. When you use an
accessory, install the color frame in the rear slot of the holder.
WARNING: Check that the accessory holder is locked before
mounting the luminaire.
AVERTISSEMENT : Vérifiez que le porte-accessoires est
verrouillé avant de monter le projecteur.
Note: The color frame should be inserted with the open side down.
1.
Retaining clip
Color frame
holder
Release the retaining clip by gently
pushing it up.
2. Insert the color frame.
3. Lock the retaining clip by gently pushing
it down.

12 Source Four Mini LED User Manual
Cleaning
WARNING: Do not use ammonia-based cleaners or other
harsh commercial cleaners. Clean lens only as directed.
Commercially available glass cleaning agents should be
avoided as they may contain ammonia, other harsh chemical
detergents, or abrasive agents. These cleaners may damage
the lens surface. Do not immerse or soak the lens in any
cleaning solution.
1. Remove the beam focus knob from the shutter barrel.
2. Remove the lens tube from the shutter barrel.
3. Remove dust with a blast of oil-free air or wipe with a clean, lint-free
cloth.
4. Slide the lens tube back into the shutter barrel with the color frame
retainer clip on the top.
5. Reinstall the beam focus knob.

Source Four Mini LED User Manual 13
Specifications and Reference
For current and complete compliance and specifications, see the Source
Four Mini LED datasheet at etcconnect.com.
FCC Compliance
Source Four Mini LED
(For any FCC matters):
Electronic Theatre Controls, Inc.
3031 Pleasant View Road
Middleton, WI 53562
[phone]
etcconnect.com
This device complies with Part 15 of the FCCRules. Operation is subject to
the following two conditions:(1) this device may not cause harmful
interference, and (2)this device must accept any interference received;
including interference that may cause undesired operation. Visit
etcconnect.com/products for current and complete compliance information
including FCC compliance.
Note: This equipment has been tested and found to comply with
the limits for a Class A digital device, pursuant to Part 15 of the FCC
rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to
radio communications. Any modifications or changes to this product
not expressly approved by Electronic Theatre Controls, Inc. could
void the user’s authority to operate the product. Operation of this
equipment in a residential area is likely to cause harmful
interference, in which case the user will be required to correct the
interference at their own expense.

14 Source Four Mini LED User Manual

Source Four Mini LED User Manual 15

Corporate Headquarters nMiddleton, WI, USA|[phone]
Global Offices nLondon|Rome|Holzkirchen|Paris|Hong Kong|Dubai|Singapore
New York|Orlando|Los Angeles|Austin|©2023 Electronic Theatre Controls, Inc.
Web etcconnect.com |Support support.etcconnect.com
Contact etcconnect.com/contactETC |Trademark and patent info:etcconnect.com/ip
Third-party license agreement info:etcconnect.com/licenses |Product information and
specifications subject to change.ETCintends this document to be provided in its entirety.
7063M1220RevHReleased2023-07
