Source Four MultiPAR™ CE
User Manual

DECLARATION OF CONFORMITY
We, Electronic Theatre Controls, Europe Limited
Unit 5, Victoria Industrial Estate, London W3 6UU United Kingdom declare under sole responsibility that
the product:
Product name: Source Four MultiPAR
Product type/model: MultiPAR 1x12 & MultiPAR 1x3
Lot: n/a
Batch / Serial number: n/a
Item numbers: one of each type
To which this declaration relates is in conformity with the following Standards:
EN60598-1:2000 Luminaires, General requirements and tests
EN60598-17:1990 Luminaires, Particular requirements, Specification for luminares for
stage lighting, television, film and photographic studios (outside and
indoor) - equiv. BS 4533-102.17:1990
Following the provisions of EU LV Directive(s) 73/23/EEC
EMC: None Unit is EMC benign
London, United Kingdom Adam Bennette
(Place of issue) (Name of authorised person)
(date of issue) (signature of authorized person)
Electronic Theatre Controls Europe Ltd. Registered office:
Unit 5, Victoria Industrial Estate, Grant Thornton House
Victoria Road, London W3 6UU U.K. Melton St., London, NW1 2BW, England
Telephone [phone] Registered in England No.3057796
Fax [phone] VAT No. 662 9487 90
25th Feb 2003

English
4 Source Four MultiPAR CE
Source Four MultiPAR CE guidelines
The Source Four MultiPAR CE is intended for professional use only. Read the entire User Guide before using
equipment.
Please note the following safety precautions:
• Do not mount the Source Four MultiPAR CE on or near a flammable surface.
• Use the Source Four MultiPAR CE in dry locations only, where humidity does not exceed 90 percent.
• The fixture is for indoor use only and is not intended for outdoor use.
• For temporary installations, mount and support the Source Four MultiPAR CE only by the primary suspension
yoke holes. Suspend the fixture from a hook clamp or a stand mount, using a securely tightened steel bolt (up to Ø
12 mm), flat washer and locking washer.
• In addition to primary suspension, attach a safety cable (Model 400SC) or chain to the secondary suspension
point on the Source Four MultiPAR CE.
• If the external cable is damaged, it shall be replaced by ETC or our service agents.
• Always hang the Source Four MultiPAR CE with the colour frame held securely behind the MultiPAR retaining
channel.
• Always replace the lamp if it becomes damaged or thermally deformed.
• Lighted objects at this distance or greater will not exceed 90ºC temperature from projected light.
• Disconnect the unit from power before all cleaning and maintenance.
• The Source Four MultiPAR CE is suitable for indoor use with a maximum ambient temperature: Ta=45°C
• Maximum exterior surface temperature: Tmax=200ºC
• A multilingual label sheet is included with this manual. Affix the label of the appropriate language over the existing
warning label on the extension yoke. Do not cover ETC trademark or CE mark.
• The Source Four MultiPAR CE contains a CE safety screen that covers the lens in the event of accidental dis-
charge. Do not remove the safety screen.
• Keep the luminaire at least 0.7 meters away from anything it is shining on.
Wiring and power information
A plug of at least 2.5 amp (220/240V) rating should be attached to the fixture’s mains lead. The wires in the mains
lead are 1.5mm2each and coloured in accordance with the following code:
WARNING: The CE Source Four MultiPAR must be earthed.
Power requirements
The Source 4 MultiPAR CE has several different standard, as well as custom configurations of electrical circuitry.
Make certain you are familiar with the wiring of the MultiPAR and that you have sufficient power (dimmer capacity)
to operate the fixture. Make sure that the total wattage used by your MultiPAR does not exceed the power avail-
able by dimmer.
Green and Yellow: Earth
Blue: Neutral
Brown: Live
Current rating: 240V/2.5 amp maximum
Operating fre-
quency: 50/60Hz
0.7m
t 180°c

English
Source Four MultiPAR CE 5
Installing the HPL lamp
Always replace the lamp if it becomes damaged or deformed. Use care installing the lamp. Improperly installed
lamps will cause premature lamp and socket failures.
1. Disconnect power before installing the lamp.
2. Let the lamp cool before replacing.
3. Loosen the captured screw on the back of the raceway and open the raceway lid.
4. The raceway lid is designed to remain open using gravity. If lid swings shut, reposition the MultiPAR unit using
the hanging irons or trunnions to lock the unit in position.
5. Remove lamp socket by loosening the gnurled knob and removing the socket assembly. Remove the HPL
lamp from its box, holding it by the base.
6. Insert lamp base into pin holes in socket assembly.
7. Push down on the lamp base until the lamp is firmly inserted. Make sure that the lamp is fully seated, with the
bottom of the lamp heat sink flush to the socket assembly surface.
8. To reinstall the socket assembly, insert until the heat sink base rests flush against the reflector, then tighten the
knurled bolt to secure the socket assembly in place. See (Figure 1)
Note: To avoid premature lamp failure, do not touch the lamp glass with your fingers. If you touch the
lamp during installation, clean it carefully with rubbing alcohol and a clean, lint-free cloth before
operation.
HPL lamps
WARNING: Use of other lamps may pose a safety risk, damage the fixture, and will void your warranty.
Lamp code Watts Volts Color temp Ave rated life
HPL 375/230X 375 230 3,000ºK 1,000 hours
HPL 375/240X 375 240 3,000ºK 1,000 hours
HPL 575/230 575 230 3,200ºK 400 hour
HPL 575/230X 575 230 3,050ºK 1500 hours
HPL 575/240 575 240 3,200ºK 400 hour
HPL 575/240X 575 240 3,050ºK 1500 hours
HPL 750/230 750 230 3,200ºK 300 hours
HPL 750/230X 750 230 3,050ºK 1500 hours
HPL 750/240 750 240 3,200ºK 300 hours
HPL 750/240X 750 240 3,050ºK 1500 hours
Lamp Base Raceway Interior
Figure 1
ReflectorSocket Assembly

English
6 Source Four MultiPAR CE
Lens identification
Lenses for the Source Four MultiPAR CE come in four versions. The type or beam spread can be identified by the
lens texture.
Accessories
Changing Source Four MultiPAR CE lenses
Removing a lens
1. Disconnect power from the fixture before attempting to remove or install a lens.
2. Source Four MultiPAR CE lenses become hot while in operation. Let the fixture cool before handling the lens.
3. Place the fixture on a flat, stable work surface.
4. Tilt the front of the fixture down at least 45 degrees.
5. Press one (or both) of the spring clips with your finger(s) to release the lens. (Figure 2).
6. Allow the lens to drop forward from under the clip.
7. When the lens drops, remove your finger, maintain pressure on the clip while sliding your finger(s) off the clip.
Allow the lens to slide forward until you can grip it securely.
8. Carefully remove the lens from the fixture.
ETC Part #
Colour frame 19 cm
sq./17cm inside diameter) 7061A3047
Safety cable (79 cm) 7060A1022
Very Narrow Spot lens 7061A4002
Narrow Spot lens 7061A4003
Medium Flood lens 7061A4005
Wide Flood lens 7061A4006
Set of four Source Four PAR lenses
(VNSP, NSP, MFL, WFL) 7061A1013
WFL
VNSP
MFL
NSP
Very narrow spot
Clear glass
15° Round beam shape
Narrow spot
Stipple glass (slight diffuse texture)
19° Round beam shape
Medium flood
Fewer facets, sized 6 x 22mm
21° x 34° Oblong beam shape
Wide flood
Many facets, sized 6 x 12mm
30° x 51° Oblong beam shape
Figure 2

English
Source Four MultiPAR CE 7
Installing a lens
Never operate the Source Four MultiPAR CE without a lens in place.
Change lenses if they become cracked or badly scratched
1. Position the fixture with the front of the unit (the lens side) facing you, and tilted up slightly (Figure 3).
2. Hold the lens by the edge, and position it so the convex side faces the back of the fixture (Figure 4). Installing
the lens with the convex side out will not impair the optics, but it will make removing the lens more difficult.
3. From the top of the fixture, slide the lens behind one of the lens clips and into the cast metal lens channel.
4. Gently push the top of the lens inward until it snaps behind the other lens clip
Colour frames and accessories
The Source Four MultiPAR CE does not use colour frame clips. However, both sides of the fixtures have a bent
sheet metal retainer to hold the gel frames in place. One side of the fixture has a piece of spring steel that serves
as a gel frame spring. The spring steel pushes the gel frame into the Source Four MultiPAR CE. ETC identifies
the side of the Source Four MultiPAR CE that holds the colour frame as the colour frame retaining channel.
Note: Use only colour frames or accessories with 17 cm inside diameter.
1. Insert the colour frame or accessory by pressing it against the spring. (Figure 5)
2. Once the edge of the frame has cleared the retaining channel, allow the edge of the frame to spring into the
channel, thereby securing it.
3. Make certain the color frame is secured in the Source Four MultiPar CE opening by the spring clip before
operating.
Figure 3 Figure 4
Figure 5

English
8 Source Four MultiPAR CE
Cleaning the reflector
Do not use glass or window cleaners on the reflector. Chemicals in the cleaners will harm the reflective coating.
Do not use paper towels or harsh materials to wipe the reflector. These materials can scratch the surface of the
reflector.
1. Unplug the fixture before attempting to clean the reflector.
2. Remove the lamp before attempting to clean the reflector.
3. Remove the lens so you can access the reflector from the front of the fixture. See Removing a lens on page 6.
4. Remove dust with a blast of oil free air, or wipe with a clean, soft, lint-free cotton cloth. If this is sufficient to
remove dust, go to step 7. Otherwise, continue to step 5.
5. Dampen a clean, soft, lint-free cotton cloth with a mild, soapy water solution and gently wipe the reflector.
6. Remove any soapy water residue with a clean, soft, lint-free cotton cloth dampened with water.
7. Reinstall a lens before using the fixture.
Adding hanging brackets and clamps to Source Four MultiPAR CE
Note: The hanging irons attach to the Source Four MultiPAR CE. The clamp is bolted to the other end
of the hanging iron and then secured to the hanging pipe.
1. Loosen and remove the bolt and washer in the end casting.
2. Attach the hanging iron to the Source Four MultiPAR CE with the bolts and washers provided. (Figure 6)Be
certain to attach the longer section of the hanging iron to the MultiPAR and the shorter section to the c-clamp.
3. Make sure the smaller length of the hanging iron is secured over the MultiPAR fixture body when attaching it to
the unit.
4. The clamp attaches the fixture to the mounting pipe.
5. Tightly fasten the clamp to the yoke with the provided yoke bolt and lock washer.
6. Place the clamp on mounting pipe, then tighten the pipe bolt to secure it.
7. Tighten the pan screw to lock the fixture into position.
Figure 6

English
Source Four MultiPAR CE 9
Spare parts list
Source Four MultiPAR CE Final Assembly
Reference
Number Part Number Description Quantity Required
17061A3051 Hanger Bracket, MultiPar 2
2HW587 1/2” washer 4
3HW5138 1/2 -13 x 1” HH bolt 2
not pictured 7061A1030 Source 4 Par safety
screen varies
not pictured 7061A3050 Trunnion Bracket, Multi-
Par 2
2
3
1

English
10 Source Four MultiPAR CE
Spare parts list
Lamp Burner Assembly
Reference
Number Part Number Description Quantity Required
1W330-01
TP22 CLCLM assembly,
1, 5 mm Wire, Silver con-
tact
2
2W330-02 TP22 CLCM assembly,
ceramic 1
3W330-03 TP22 CLCM assembly,
mica 1
1-6 7061A2027 Lamp Burner Assembly
90 cm 1
1-6 7061A2028 Lamp Burner Assembly
150 cm 1
1-6 7061A2029 Lamp Burner Assembly
210 cm 1
67061A3061 Thumbscrew 1
7various HPL lamp 1

English
Source Four MultiPAR CE 11
Circuit wiring configurations for the MultiPar-12.
The Source 4 MultiPAR CE can be wired for 3 circuit or 4 circuit configurations. Before changing the configuration,
make sure that you have sufficient power (dimmer capacity) to operate the fixture. There are four terminal blocks
inside the unit to place wiring. Each terminal block has four lead connection points. All of the hot and neutrals are
labeled with a number for your convenience.
Three circuit configuration
1. Disconnect power before changing the wiring.
2. Loosen the captured screw on the back of the raceway and open the raceway lid.
3. In the first terminal block on the left, insert the wires labeled 1,4,7,10.
4. In the second terminal block from the left, insert the wires labeled 2,5,8,11.
5. In the third terminal block from the left, insert the wires labeled 3,6,9,12
6. The fourth terminal block from the left is not used and is left empty.See Figure 7 for detail.
Four circuit configuration
1. Disconnect power before changing the wiring.
2. Loosen the captured screw on the back of the raceway and open the raceway lid.
3. In the first terminal block on the left, insert the wires labeled 1,5,9.
4. In the second terminal block from the left, insert the wires labeled 2,6,10.
5. In the third terminal block from the left, insert the wires labeled 3,7,11.
6. In the fourth terminal block from the left, insert the wires labeled 4,8,12. See Figure 7 for detail.
Figure 7

Americas  3030 Laura Lane, P.O. Box 620979, Middleton, Wisconsin 53562-0979 USA  Tel: [phone]  [phone]  Fax: [phone]  [phone]
 Email: (US) [e-mail]
Europe  Unit 5, Victoria Industrial Estate, Victoria Road, London W3 6UU, UK  Tel: [phone]  Fax: [phone]
 (UK) [email protected]
Asia  Room 605-606, Tower III Enterprise Square, 9 Sheung Yuet Road, Kowloon Bay, Kowloon, Hong Kong  Tel: [phone]  Fax: [phone]
 (Asia) [email protected]
W eb: www.etcconnect.com  Service: [e-mail]  Toll free: 800 775 4382  Comments about this document:[email protected]
7061M1018  Rev A  Released 2/03 Copyright © 2002 Electronic Theatre Controls, Inc. All Rights Reserved. Product information and specifications subje ject to change
