Basic Assembly 1
Basic Assembly
WARNING:
Please note the following safety warnings before use:
Do not mount the fixture on or near combustible surfaces.
Do not operate the fixture without a lens installed.
Always hang the fixture with the color frame retaining clip in the locked
position.
Remove cardboard insert from lens tube before connecting power to your
fixture.
Figure 1
Lamp housing
Insulated handle
Reflector housing
Yoke
Pattern holder slot
Drop-in iris slot
Shutters
Color frame
Barrel
25°-50° lens tube
Barrel rotation knob
Focus dial
Color frame
retaining gel clip
15°-30° lens tube
Optional
Balancing yoke
Retainer bolt
Yoke locking knob

2Source Four Zoom User Manual
Fixture information
HPL lamp table
CAUTION:
Do not use lamps other than the HPL in Source Four fixtures. Use of lamps other
than HPL will void UL/cUL safety compliance and your warranty.
Lamp code Watts Volts Initial Lumen Color temp. Average rated life
HPL 780/77* 750 77 22,950 3,250° 300 hours
HPL 550/77* 550 77 16,170 3,250° 300 hours
HPL 550/77X* 550 77 12,160 3,050° 2000 hours
HPL 750/115 750 115 21,900 3,250°K 300 hours
HPL 750/115X 750 115 16,400 3,050° 1500 hours
HPL 575/115 575 115 16,520 3,250°K 300 hours
HPL 575/115X 575 115 12,360 3,050°K 2000 hours
HPL 375/115 375 115 10,540 3,250°K 300 hours
HPL 375/115X 375 115 8,000 3,050°K 1000 hours
HPL 750/120 750 120 21,900 3,250°K 300 hours
HPL 750/120X 750 130 16,400 3,0500°K 1500 hours
HPL 575/120 575 120 16,520 3,250°K 300 hours
HPL 575/120X 575 120 12,360 3,050°K 2000 hours
HPL 750/230 750 230 19,750 3,200°K 300 hours
HPL 750/230X 750 230 15,600 3,050°K 1500 hours
HPL 575/230 575 230 14,900 3,200°K 400 hours
HPL 575/230X 575 230 11,780 3,050°K 1500 hours
HPL 375/230X 375 230 7,250 3,000°K 1000 hours
HPL 750/240 750 240 19,750 3,200°K 300 hours
HPL 750/240X 750 240 15,600 3,050°K 1500 hours
HPL 575/240 575 240 14,900 3,050°K 400 hours
HPL 575/240X 575 240 11,780 3,050°K 1500 hours
HPL 375/240X 375 240 7,250 3,000°K 1000 hours
* To be used with ETC Dimmer Doubler™

Basic Assembly 3
Color frame holder
The color frame holder is equipped with a spring-loaded retaining clip that prevents color frames
and accessories from falling out. See Figure 2.
Step 1: Release the retaining clip by pushing it sideways while gently pulling backwards.
Step 2: Insert the color frame.
Step 3: Lock the retaining clip by pushing sideways while gently pushing forward.
WARNING:
Make sure all color frame accessories are locked in position with the
retaining clip before hanging the Source Four.
Note:
The performance of saturated colors may be less than desirable in any theatrical
lighting fixture, especially when equipped with a 750w lamp. For best results,
always use high-quality color media rated for high-temperature use.
ETC’s optional Gel Extender, part # PSF1029, will provide maximum color media
life. The use of any gel extender accessory may limit the coverage of any wide-
angle lens or beam setting.
A variety of heat shield products is also available from many color media
manufacturers. Follow the manufacturer’s instructions for the use of these
products.
Figure 2
Retaining clip in the
locked position

4Source Four Zoom User Manual
Replacing the HPL Lamp
A lamp must be installed before you use the fixture.
Step 1: Disconnect power to the Source Four before installing the lamp.
Step 2: Loosen the knurled bolt on the back of the lamp housing and pull the housing out.
Step 3: Holding by the base, remove the HPL lamp from its box.
Step 4: Align the flat sides of the lamp base with the retention brackets on either side of the
socket as shown in Figure 3.
Step 5: Push down on the lamp base until the lamp seats firmly. When properly installed, the top
of the lamp’s base will be even with he top edges of the retention brackets.
Step 6: Press lamp retaining clip across lamp base to secure.
Step 7: Reinstall the lamp housing by aligning the bolt hole and tightening the knurled bolt.
Note:
Verify that the HPL lamp you intend to install is suitable for your facility’s voltage;
115-, 120-, 230-, and 240-volt HPL lamps are available. See Fixture information,
page 2. Operating HPL lamps above their rated voltage reduces lamp life and can
cause premature lamp failure.
WARNING:
Let the lamp cool before replacing.
CAUTION:
Use caution when installing or replacing any lamp.
When installing/replacing lamp, be sure to point the lamp away from your face and
away from others before inserting it firmly into the assembly.
This may prevent injuries if the lamp should break.
Note:
To avoid premature lamp failure, do not touch the lamp glass. If you do, clean it
carefully with isopropyl alcohol and a clean lint-free cloth. Allow to dry before
operation.
CAUTION:
Improperly installed lamps cause premature lamp failure and socket problems.
HPL lamp
Lamp retention
brackets
Lamp housing Figure 3
Knurled bolt
Lamp retainer clips
INCORRECT CORRECT

Adjustments 5
Adjustments
Centering lamp and adjusting the field
The two concentric knobs located on the lamp housing allow you to align the lamp and adjust its
field. See Figure 4. The outer knob centers the lamp within the reflector. The inner knob adjusts the
lamp’s field.
Step 1: Turn on the Source Four and aim it at a flat surface. Adjust the barrel to create a hard
edge.
Step 2: Unlock and loosen the outer knob by turning it counterclockwise.
Step 3: Gently move the outer knob from side to side and up and down until the lamp is centered
within the reflector.
Step 4: Once the lamp is centered, turn the outer knob clockwise to lock it in place.
Step 5: Finally, turn the inner knob either clockwise or counterclockwise to achieve an optimum
flat field. See Figure 5.
Selecting the field angle and focusing the beam
Step 1: Press the locking lever push button and lift the locking lever to unlock the focus dial as
shown in Figure 6.
Step 2: To reduce the field angle, rotate the focus dial clockwise. To enlarge the field, rotate the
dial counterclockwise.
Outer Knob - lamp
center adjustment
Inner Knob -
peak/flat field
adjustment
Rear lamp
housing
Figure 4 Figure 5
Flat field-best adjustment
Hot spot - lamp pulled out
too far
Field with hole - lamp
pushed in too far
Locking lever
push button
Locking lever
Beam focus dial Figure 6
Light baffle

6Source Four Zoom User Manual
Step 3: Once the desired field angle is established, slide the light baffle forward to soften or
backward to sharpen the edge.
Step 4: Once the field and edge are established, press the locking lever to lock the focus dial into
position.
Shaping the beam
The beam can be shaped using the shutters (see Figure 1), a pattern, an optional drop-in iris, or by
rotating the barrel.
Pattern Projection
The pattern holder slot is on the top side of the barrel and in front of the shutters. It accommodates
A-size, B-size and glass pattern holders (see Figure 7).
Use an optional donut in the accessory holder to enhance pattern projection. Donut diameter range
should be 2.5” to 2.75”.
Drop-In Iris Slot
The drop-in iris slot is located on the top of the barrel and in front of the pattern holder slot. It
accommodates either a drop-in iris or a motorized pattern device. When the slot is not in use, a
small sheet metal cover secured with two Phillips screws prevents light leakage (see Figure 8).
Step 1: Use a screwdriver to loosen the screws on the drop-in iris slot cover. Do not remove
thumbscrews.
Step 2: Slide the cover completely forward to expose the slot.
Step 3: Insert the iris or motorized pattern device. For an iris, install the flat side toward the
shutters and make sure the iris handle extends from the slot.
Note:
Because the Source Four aperture is 3 inches wide, ETC recommends
using A-size patterns for maximum pattern effectiveness.
3.12" Diameter
3.70"
2.75" Diameter
3.70"
Figure 7
A-Size Pattern holder:
holds 3” diameter patterns B-Size Pattern holder:
holds 2.5” and 2.75”
diameter patterns
Drop-in iris slot Iris
Figure 8

Adjustments 7
Step 4: Slide the slot cover back toward the shutters until it meets the iris handle. Leave enough
space to move the iris handle.
Step 5: Secure the drop-in iris slot cover by tightening the screws.
Rotating the barrel assembly
Step 1: Loosen the barrel rotation knob directly behind the shutters on the underside of the
reflector housing (see Figure 9). Do not remove the barrel rotation knob.
Step 2: Rotate the barrel to the desired position (up to 25° in either direction from the centered
position).
Step 3: Once the barrel is positioned, tighten the barrel’s rotation knob to lock it in place.
Adjusting the C-clamp
The C-clamp attaches the fixture to the mounting pipe and allows you to adjust the position of the
fixture once it is mounted (see Figure 10).
Step 1: Tightly fasten the C-clamp to the yoke with the provided yoke bolt and lock washer.
Step 2: Place the C-clamp on mounting pipe, then tighten the pipe bolt to secure it.
Step 3: Loosen the C-clamp pan screw and rotate the yoke to the desired position.
Step 4: Tighten the pan screw to lock the fixture..
CAUTION:
Tighten C-clamp pipe bolt to 15-20 ft./lbs. (approximately finger tight plus up to
one-quarter turn). Do not exceed 25 ft./lbs. Do not use excessive force.
Tighten the yoke pivot bolt to 5-10 ft./lbs. (approximately finger tight plus up to
one-eighth turn). Do not exceed 15 ft./lbs. Do not use excessive force.
Figure 9
Barrel
rotation knob
ET C
C-clamp
Pipe bolt
Pan screw
Yoke bolt and
lockwasher
Figure 10
Yoke

8Source Four Zoom User Manual
Adjusting the yoke position — 25°-50° Zoom
The Source Four 25°-50° Zoom provides multi-positioning capabilities within its yoke for overall
fixture height and angle.
Setting the fixture height within the yoke
The Source Four 25°-50° Zoom has a two-position yoke for modifying the overall height in which
the fixture is mounted (see Figure 11). To change the height position, perform the following steps.
Step 1: Remove the yoke locking knobs, washers, and hex bolts from either side of the fixture.
Step 2: Raise or lower the fixture to the desired position within the yoke.
Step 3: Reinstall the yoke’s hex bolts, washers, and locking knobs.
Step 4: Tighten the yoke knobs to secure in position.
Setting the angle within the yoke
Step 1: Loosen the yoke locking knobs (see Figure 12). Do not remove them.
Step 2: Tilt the fixture to the desired position.
Step 3: Tighten the yoke locking knobs to secure in position.
Figure 11
Low clearance position
General use position
Yoke locking knob
Yoke locking knob Figure 12

Adjustments 9
Adjusting the optional balance yoke position — 15°-30° Zoom
The Source Four 15°-30° Zoom has an optional balance yoke bracket (ETC part # 7060A2028) for
repositioning the fixture’s center of gravity. It is also equipped with a moveable yoke for setting the
fixture’s angle.
Setting the balance yoke
Step 1: Loosen the balance yoke’s clutch hex bolts on either side of the fixture.
Step 2: Adjust the balance yoke so it is perpendicular to the fixture as shown in Figure 13. If front
of the fixture has several accessories attached, you may need to tilt the balance yoke
towards the front of the fixture to adjust the balance.
Step 3: Tighten the balance yoke’s clutch hex bolts to secure the yoke into position.
Setting the angle within the moveable yoke
Step 1: Loosen the moveable yoke’s locking knobs. Do not remove them.
Step 2: Tilt the fixture to the desired position as shown in Figure 14.
Step 3: Tighten the yoke’s locking knobs to secure the fixture in position.
CAUTION:
Once the balance yoke is locked, adjustments should only be made to the
moveable yoke.
Moveable yoke
Figure 13
Clutch hex bolt
Balance yoke
Figure 14
Yoke locking knob
Horizontal mounting Vertical mounting

10 Source Four Zoom User Manual
Cleaning Lens and Reflector
Replace lenses if they contain visible damage (cracks or deep scratches) that may impair their
effectiveness.
Cleaning glass lens
Step 1: Rotate the extrusion door fastener 1/4 turn to the right or left and open extrusion door.
Step 2: Set the lens to the narrowest field angle to maximize the distance between the lenses.
Step 3: Remove dust with a blast of oil-free air or wipe with a clean, lint-free cloth. Isopropyl
alcohol, distilled water or a 50%-50% mixture of each can be used to clean the glass
surface.
Step 4: Close the extrusion door and turn the fastener 1/4 turn to secure it.
WARNING:
Do not use ammonia-based or other harsh commercial cleaners. Clean lens
and reflector only as directed.
Commercially available glass cleaning agents should be avoided as they
may contain ammonia, other harsh chemical detergents or abrasive agents.
These cleaners may damage the glass surface and the Anti-Reflective
coatings. Do not immerse or soak the glass in any cleaning solution.
Note:
To clean the 15°-30° Zoom, rotate the lens tube to its limit in one direction
(approximately 25°) so the extrusion door will clear the balance yoke. See
Figure 15.
Turn to
the left
or right
Figure 15
Extrusion door

Cleaning Lens and Reflector 11
Cleaning the reflector
To quickly clean the reflector, remove the lens tube and clean the dust from the reflector with a blast
of oil-free air. You may also wipe the reflector with a clean lint-free cloth. If either method is not
sufficient, follow these steps.
Step 1: To protect the lamp housing during cleaning, remove the lamp housing by loosening the
knurled bolt and pulling the housing straight out. See Figure 3.
Step 1: Remove the barrel rotation knob located at the bottom of the barrel (see Figure 1). Use
a Phillips screwdriver to remove the retainer bolt located on top of the reflector housing.
Step 2: Rotate the barrel 45° in either direction. Carefully remove the barrel from the reflector
housing.
Step 3: Remove dust with a blast of oil-free air or wipe with a clean, lint-free cloth. Isopropyl
alcohol, distilled water or a 50%-50% mixture of each can be used to clean the glass
surface.
Step 4: Gently wipe the reflector.
Step 5: Insert the barrel into the reflector housing with the iris/pattern slot on top. Align the
triangles on both parts.
Step 6: While gently pressing in, rotate the barrel 45° clockwise until it sets into position, then
rotate the barrel counterclockwise 45°. The barrel should be firmly attached and the
triangles should be aligned.
Step 7: Reinstall the barrel rotation knob and tighten the retainer bolt.
Step 1: Reinstall the lamp housing and tighten the knurled bolt.
WARNING:
Unplug the fixture before attempting to clean the reflector.

12 Source Four Zoom User Manual

Cleaning Lens and Reflector 13

Corporate Headquarters  3031 Pleasant View Road, P.O. Box 620979, Middleton, Wisconsin 53562-0979 USA  Tel [phone]  Fax [phone]
London, UK  Unit 26-28, Victoria Industrial Estate, Victoria Road, London W3 6UU, UK  Tel [phone]  Fax [phone]
Rome, IT  Via Ennio Quirino Visconti, 11, 00193 Rome, Italy  Tel [phone]  Fax [phone]
Holzkirchen, DE  Ohmstrasse 3, 83607 Holzkirchen, Germany  Tel [phone]  Fax [phone]
Hong Kong  Rm 1801, 18/F, Tower 1 Phase 1, Enterprise Square, 9 Sheung Yuet Road, Kowloon Bay, Kowloon, Hong Kong  Tel [phone]  Fax [phone]
Service: (Americas) [email protected]  (UK) [email protected]  (DE) [email protected]  (Asia) [email protected]
Web: www.etcconnect.com  Copyright © 2008 ETC. All Rights Reserved.  Product information and specifications subject to change.
7060M1250-06.01  Rev C  Released 2010-01
