EtherWAN EX1624W User manual

24-Port Web-Smart Ethernet Switch
User’s Manual 1
FCC Statement
The FCC (Federal Communications Commission) restricts
the amount of radio frequency emission and radiation coming
from computer equipment.
The equipment introduced in this manual has been tested
and found to comply with the limits for a Class A digital
device pursuant to Part 15 of the FCC rules. These limits are
designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial
environment.
This equipment generates, uses, and can radiate radio
frequency energy, and if not installed and used in
accordance with the instruction manual, may cause harmful
interference to radio communications.
Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user is required
to correct the interference at his/her own expense.
Any changes or modifications not expressly approved by the
manufacture would void the user’s authority to operate the
equipment.
Trademarks
Product names mentioned in this manual may be trademarks
or registered trademarks of those products.
All trademarks or brand names mentioned are properties of
their respective companies.

24-Port Web-Smart Ethernet Switch
User’s Manual
2
Preface
This manual describes how to install and use the 24-Port Web-
Smart Ethernet Switch. The TX ports of the switch introduced here
auto-negotiates the presence of 10/100Mbps and full/half-duplex
mode and auto-MDIX. In addition, it allows an optional 100Base-
FX multi-mode or single-mode fiber module, enabling long
distance connection.
To get the most out of this manual, you should have an
understanding of networking concepts such as bridging, IEEE
802.3 10Base-T Ethernet, IEEE 802.3u 100Base-TX/FX Fast
Ethernet, and local area networks (LANs).
For more information about these topics, please refer to the
Appendices.
In this manual, you will find:
•Introduction on the Switch
•Product features
•Illustrative LEDs functions
•Installation instructions
•Specifications

24-Port Web-Smart Ethernet Switch
User’s Manual 3
Table of Contents
FCC STATEMENT 1
TRADEMARKS 1
PREFACE 2
TABLE OF CONTENTS 3
PRODUCT OVERVIEW 5
FRONT VIEW 5
PACKAGE CONTENTS 5
PRODUCT FEATURES 6
FRONT PANEL DISPLAY 7
PHYSICAL PORTS 8
Understanding Front Panel Design 8
INSTALLATION 9
SELECTING A SITE FOR THE EQUIPMENT 9
INSTALLATION AND PLACEMENT INSTRUCTIONS 10
Mounted to 19-inch standard rack 10
Desktop or any flat surface 10
OPTIONAL FIBER MODULE INSTALLATION 11
CONNECTING TO POWER 12
CONNECTING TO YOUR NETWORK 12
Cabling 12
Network Segmentation 13
SWITCH CONFIGURATION 14
SETTING UP CONSOLE PORT CONNECTION (WEB-BASED BROWSER
INTERFACE) 14
LOGGING ON TO THE ETHERNET SWITCH 14
Switch IP Address 14
User Name 14
Password 14
MAIN MENU 15
System Change 15
IP Configuration 16

24-Port Web-Smart Ethernet Switch
User’s Manual
4
Port 17
VLAN 18
Trunking 19
Save Configuration 20
Load Default 21
TECHNICAL SPECIFICATIONS 22
PHYSICAL SPECIFICATIONS 23
CONNECTOR PINOUTS 24
ORDERING INFORMATION 25

24-Port Web-Smart Ethernet Switch
User’s Manual 5
Product Overview
Front View
Figure 1: 24-Port Web-Smart Ethernet Switch
Package Contents
When you unpack the product package, you shall find these items
listed below.
3 The 24-Port Switch
3One AC power cord
3 User’s Manual
Please inspect the contents, and report any apparent damage or
missing items immediately to your authorized reseller.

24-Port Web-Smart Ethernet Switch
User’s Manual
6
Product Features
♦PROVIDES 24 ×10/100MBPS PORTS USING RJ-45
CONNECTORS
♦AN OPTIONAL SINGLE-PORT FIBER MODULE ALLOWS:
-100BASE-FX MULTI-MODE FIBER WITH SC, ST, MT-RJ, VF-45 OR LC
CONNECTOR
-100BASE-FX SINGLE-MODE FIBER WITH SC CONNECTOR
♦AUTO-NEGOTIATION FOR SPEED AND DUPLEX MODE ON TX
PORTS
♦8192 MAC ADDRESSES,1.5M BITS BUFFER MEMORY
♦AUTO-MDIX FOR ALL TX PORTS
♦STORE-AND-FORWARD MECHANISM
♦TRUE NON-BLOCKING ARCHITECTURE
♦FULL WIRE SPEED FORWARDING RATE
♦BROADCAST STORM FILTERING CONTROL
♦BACK-PRESSURE AND IEEE 802.3X COMPLIANT FLOW
CONTROL
♦SYSTEM,IP CONFIGURATION,PORT,PORT-BASED VLAN,
AND PORT-BASED TRUNKING SETTING THROUGH THE WEB-
BASED CONSOLE PORT.
♦FRONT PANEL PUSH BUTTON TO CHOOSE 100BASE-FX OR
PORT 24
♦PRESS THE FRONT PANEL IP RESET PUSH BUTTON FOR
FIVE SECONDS TO RESET THE ETHERNET SWITCH BACK TO
THE DEFAULT IP ADDRESS.(THE PORT,VLAN, AND
TRUNKING SETTINGS WILL REMAIN THE SAME AS WHEN
THEY WERE LAST SAVED).
♦FRONT PANEL PORT AND POWER STATUS LEDS
♦STANDARD 19” RACKMOUNT SIZE,ONE-UNIT IN HEIGHT

24-Port Web-Smart Ethernet Switch
User’s Manual 7
Front Panel Display
The LED indicators on the front panel provide you with instant
feedback on each port status, and help you monitor and
troubleshoot the switch.
Figure 2: Front Panel LEDs
Power
This LED comes on when the switch is properly connected to power and
turned on.
Push Button
The push button is located at the right side of port 24 on the 24-Port Switch.
Depress this button to use twisted pair port 24, and press this button to use
the 100Base-FX module.
IP RESET Push Button
Press the Front panel IP RESET push button around five seconds to reset
the Ethernet Switch back with the default IP Address.
Port Status
The RJ-45 ports are numbered from 1 to 24 on the 24-Port Switch.
The LEDs are located on the ports of the switch, displaying status for each
respective port. Please refer to the table below for more information.
Consult the following table for details.
LBefore you use this table for troubleshooting, make sure the switch is
properly connected to power and turned on.

24-Port Web-Smart Ethernet Switch
User’s Manual
8
Physical Ports
The 24-Port Switch has twenty-four 10/100Mbps ports using RJ-45
connectors and provides one slot for the optional single-port fiber
module. The optional module allows fiber type (multi-mode or
single-mode fiber) and connector (SC, ST, MT-RJ, VF-45, or LC)
at user’s discretion.
UNDERSTANDING FRONT PANEL DESIGN
On Power feeding in
Power switched off
Power LED
Off
Improper connection
On A valid network connection
LNK stands for LINK
LNK
Off No connection
Flashing Transmitting or receiving data
ACT stands for ACTIVITY
Console
Port LED
ACT
Off Neither transmitting nor receiving
data
On A valid network connection
LNK stands for LINK
Flashing Transmitting or receiving data
ACT stands for ACTIVITY
LNK/ACT
Off Neither connection nor activity
On A valid 100Mbps connection
Port LED
SPEED
Off A valid 10Mbps connection
On A valid network connection
LNK stands for LINK
LNK
Off No connection
Flashing Transmitting or receiving data
ACT stands for ACTIVITY
100FX Port
LED
ACT
Off Neither transmitting nor receiving
data

24-Port Web-Smart Ethernet Switch
User’s Manual 9
Installation
Selecting a Site for the Equipment
As with any electric device, you should place the equipment where
it will not be subjected to extreme temperatures, humidity, or
electromagnetic interference. Specifically, the site you select
should meet the following requirements:
- The ambient temperature should be between 0 to 45 degrees
Celsius.
- The relative humidity should be less than 95 percent,
non-condensing.
- Surrounding electrical devices should not exceed the
electromagnetic field (RFC) standards for IEC 801-3, Level 2
(3V/M) field strength.
- Make sure that the equipment receives adequate ventilation.
Do not block the ventilation holes on each side of the switch or
on the rear of the equipment.
-The power outlet should be within 6 feet (1.8 meters) of the
switch.

24-Port Web-Smart Ethernet Switch
User’s Manual
10
Installation and Placement Instructions
MOUNTED TO 19-INCH STANDARD RACK
Locate the accessories supplied in the product package. Use the
rackmount brackets and screws to install the switch into any EIA
19” standard rack.
Step 1: Attach the brackets to each side of the chassis.
Step 2: Apply the screws to each side and secure them tightly.
Step 3: Carefully position the switch into the rack.
Step 4: Align the brackets to the side holes on the rack and use rack
screws to secure the chassis with the rack.
Step 5: Proceed to the “Connecting to Power” section.
DESKTOP OR ANY FLAT SURFACE
The switch can sit on desktop or any flat surface with adequate
space and ventilation. If you want to place it onto a shelf, make
sure the shelf can withstand the weight of the switch.
Step 1: Simply put the switch on the desired place.
Step 2: Ensure the switch receives good ventilation.
Step 3: Proceed to the “Connecting to Power” section.

24-Port Web-Smart Ethernet Switch
User’s Manual 11
Optional Fiber Module Installation
Consult the following illustrations before installation.
Step 1: Make sure the power is switched off. The module is not hot-
swappable.
LIt may cause electric shock or any possible damage to the switch if the
power is not switched off.
Step 2: Remove the module from the static-free container.
Step 3: Unscrew the cover plate of the expansion slot.
(The slot for single-port module is located at the right side of the
switch.)
Step 4: Remove the plate.
(Keep it for future use if you decide to remove this module later.)
Step 5: Carefully slide the module into the slot, following the internal
plastic guide rails.
Step 6: Once it is fully slid in, snap in the module to make a proper
connection.
Step 7: Fasten the module screws.
Step 8: Finally, turn on the power.
Figure 3: Removal of cover plate Fiber module being installed

24-Port Web-Smart Ethernet Switch
User’s Manual
12
Connecting to Power
Locate the supplied AC power cord.
Step 1: Connect the AC power cord to the receptacle at the back of the
switch.
Step 2: Attach the plug into a standard AC outlet with a voltage range from
100~240VAC.
Step 3: The power LED on the front panel will then illuminate.
Figure 4: Rear view of the switch
Connecting to Your Network
CABLING
Step 1: First, ensure the power of the switch (and end devices) is turned
off.
LIt may cause an electric shock or any possible harm to you if the
power is not switched off.
Step 2: Prepare cable with corresponding connectors for each type of port
in use.
(Consult the table below for cabling requirements based on
connectors and speed considerations.)
Step 3: Connect one end of the cable to the switch and the other end to a
desired device.
Step 4: Once the connections between two end devices are made
successfully, turn on the power and the switch is operational.

24-Port Web-Smart Ethernet Switch
User’s Manual 13
NETWORK SEGMENTATION
The maximum segment distance between a node and a directly
connected switch port on a 100Base-FX network is 100km using
10/125 (or 9/125) µm single-mode fiber optic cable. It is capable of
a maximum span of 2km when 62.5/125 (or 50/125) µm multi-
mode fiber optic cable is used.
Cable Specifications Table
Ethernet
Standards
Connector Port
Speed
Half/Full
Duplex
Cable Max.
Distance
10Base-T RJ-45 10/20
Mbps
Cat. 3, 4 or 5
UTP/STP
100m
100Base-TX RJ-45 100/200
Mbps
Cat. 5
UTP/STP
100m
100Base-FX
Multi-mode
ST, SC,
MT-RJ, VF-
45, LC
100/200
Mbps
50 or
62.5/125 µm
multi-mode
fiber
Up to
2km
100Base-FX
Single-mode
ST, SC 100/200
Mbps
9 or 10/125
µm single-
mode fiber
Up to
100km
100Base-FX
WDM
Single-mode
SC 100/200
Mbps
9 or 10/125
µm single-
mode fiber
Up to
40km

24-Port Web-Smart Ethernet Switch
User’s Manual
14
Switch Configuration
Setting up Console Port Connection (Web-
Based Browser Interface)
The Ethernet Switch provides a browser interface that lets
you configure and manage the Ethernet Switch from a Web
browser (such as Microsoft Internet Explorer or Netscape
Navigator) remotely.
By connecting to the Ethernet Switch’s console port, you can
access the Ethernet Switch’s web interface applications
directly in your web browser by entering the default IP
address of the Ethernet Switch (192.168.1.10). You can then
use your web browser to list and manage the Ethernet Switch
configuration parameters from one central location.
Logging on to The Ethernet Switch
SWITCH IP ADDRESS
In your web browser, specify the default IP address of the
Ethernet Switch (192.168.1.10).
USER NAME
Enter the factory default user name: admin.
PASSWORD
Enter the factory default password (no password, press
Enter directly).
Otherwise, enter a user-defined password if you followed the
instructions later and changed the factory default password.

24-Port Web-Smart Ethernet Switch
User’s Manual 15
Main Menu
SYSTEM CHANGE
The System Change parameters can be displayed by
clicking the System Change button in the left sub-menu.
zSwitch Name: Type a switch name and replace the
current switch name with a new one. (Please restart
your Computer once the Switch Name is replaced

24-Port Web-Smart Ethernet Switch
User’s Manual
16
and saved under “ Save Configuration “ by the new
name).
<Note> (Only “ a-z “, “A-Z”, “0-9”, “under line” & “Space”
can be acceptable, totally can not exceed 16 characters).
zPassword: Enter a user-defined password and change
the factory default password.
<Note> (Only “ a-z “, “A-Z”, “0-9”, “under line” & “Space”
can be acceptable, totally can not exceed 16 characters).
zApply: Click the Apply button and apply the new System
settings.
IP CONFIGURATION
zRefresh: Click the Refresh button and refresh back to
the last saved IP Configurations.
zIP Address, Netmask, Default Gateway: You can see
and change the IP Address, Netmask, and Default
Gateway of the Ethernet Switch.
zApply: Click the Apply button and apply the new IP
Configurations.

24-Port Web-Smart Ethernet Switch
User’s Manual 17
PORT
zRefresh: Click the Refresh On or Refresh Off button to
or not to refresh back to the last saved settings of the
ports.
<Note> It is recommended to change the Refresh On
button to Refresh Off while you change the settings of
the ports. The Refresh On will refresh the settings of
the ports shown on the screen around every ten
seconds.
zMode: Choose AUTO, 10HD, 10FD, 100HD or 100FD
for the ports.
zFlow Control: Choose Enable or Disable to enable or
disable the flow control of the ports.
zTransmit / Receive: Choose On or Off to turn on or off
transmit / receive of the ports.
zApply: Click the Apply button and apply the new
settings of the ports.

24-Port Web-Smart Ethernet Switch
User’s Manual
18
VLAN
zVLAN: Click and choose the ports to be added into the
VLAN groups.
zApply: Click the Apply button and apply the new
settings of the VLAN groups.
<Note> All Ports have to be selected to one of the
VLAN Groups, those Port/Ports were not selected will
be notified by the alarm message which shows “ Non-
Identify VLAN Group On Port “.

24-Port Web-Smart Ethernet Switch
User’s Manual 19
TRUNKING
zTrunking Group 1: Click and choose any four ports to
be added into the Trunking Group 1.
zTrunking Group 2: Click and choose any four ports to
be added into the Trunking Group 2.
zApply: Click the Apply button and apply the new
settings of the Trunking Groups.
<Note> Each Trunking Group can not be selected more
than four ports, the alarm message will show
“ Maximum Four Ports For Group 1, or 2, “ if it’s
exceeded.

24-Port Web-Smart Ethernet Switch
User’s Manual
2
0
SAVE CONFIGURATION
zClick Save Configuration.
zClick the Ok or Cancel button to or not to save the
configurations.
<Note> The Cancel button will discard any data you
have changed since the last "Save" operation. Without
clicking Ok button, the switch does not save any
changes you may have made.
