EtherWAN EX72129A User manual

1
EtherWAN Managed Switch Users Guide
User’s Guide
FastFind Links
Unpacking and Installation
Computer Setup
Setting the initial IP address
EtherWAN Managed Switch –V1.94.2.1

ii
EtherWAN Managed Switch Users Guide
All Rights Reserved
Dissemination or reproduction of this document, or its contents, is not authorized except
where expressly permitted. Violators are liable for damages. All rights reserved, for the
purposes of patent application or trademark registration.
Disclaimer of Liability
The information contained in this document is subject to change without notice. EtherWAN is
not liable for any errors or omissions contained herein or for resulting damage in connection
with the information provided in this manual.
Registered Trademarks
The following words and phrases are registered Trademarks of EtherWAN Systems Inc.
EtherOS™
Ethernet to the World™
All other Trademarks are property of their respective owners.
Warranty
For details on the EtherWAN warranty replacement policy, please visit our web site at:
https://kb.etherwan.com/index.php?View=entry&EntryID=27
Products Supported by this Manual:
V1.94.2 EtherWAN Managed Switch
Contact EtherWAN Systems
Corporate Headquarters
EtherWAN Systems Inc.
4570 E. Eisenhower Circle
Anaheim, CA 92807
Tel: [phone]
Fax: [phone]
Email: [e-mail]

Preface
iii
EtherWAN Managed Switch Users Guide
TABLE OF CONTENTS
Table of Contents ................................................................................................... iii
Table of Figures...................................................................................................... xi
Preface................................................................................................................... xvi
Changes in this Revision ........................................................................................ xvi
Document Conventions ..........................................................................................xvii
Safety and Warnings ..............................................................................................xvii
Typographic Conventions.......................................................................................xvii
Unpacking and Installation................................................................................... 18
Package Contents ...................................................................................................18
Unpacking ...............................................................................................................18
Required Equipment and Software..........................................................................19
Computer Setup..................................................................................................... 20
Management Methods and Protocols ......................................................................20
Default IP.................................................................................................................21
Login Process and Default Credentials....................................................................21
Setting the initial IP address................................................................................. 22
Simple IP Addressing ..............................................................................................22
CLI Command Usage............................................................................................. 23
Navigating the CLI Hierarchy...................................................................................23
CLI Keyboard Shortcuts...........................................................................................23
CLI Command modes..............................................................................................24
General Configuration Mode..............................................................................24
MSTP Configuration Mode.................................................................................24
Interface Configuration Mode.............................................................................25
VLAN Database Configuration Mode .................................................................25
Saving a Configuration from the CLI ..................................................................25
System Menu ......................................................................................................... 26
System Information..................................................................................................26
System Name/Password..........................................................................................28
System Name/Password using the CLI....................................................................29
IP Address...............................................................................................................30

Preface
iv
EtherWAN Managed Switch Users Guide
Static IP.............................................................................................................30
DHCP Client ......................................................................................................30
Default Gateway ................................................................................................30
DNS Server........................................................................................................30
IP Address - Configuration using the CLI.................................................................32
IP Address.........................................................................................................32
Default Gateway ................................................................................................33
Domain Name Server (DNS)..............................................................................34
Enable/Disable DHCP Client on a VLAN............................................................35
Enable/Disable Static IP on a VLAN...................................................................35
Management Interface.............................................................................................37
HTTPS...............................................................................................................37
Telnet.................................................................................................................37
SSH (Secure Shell)............................................................................................38
Management Interface Configuration using the CLI.................................................39
Enabling/Disabling Telnet ..................................................................................39
Enabling/Disabling SSH.....................................................................................40
Enabling/Disabling HTTP and/or HTTPS ...........................................................41
Save Configuration Page.........................................................................................43
Save Configuration ............................................................................................43
Load Configuration.............................................................................................43
Backup Configuration.........................................................................................43
Restore Default..................................................................................................44
Auto Save..........................................................................................................44
Save Configuration Page using the CLI...................................................................45
Saving a Configuration.......................................................................................45
Restore Default Settings....................................................................................45
Load Configuration from a TFTP Server ............................................................46
Save Configuration to a TFTP Server ................................................................46
Auto Save Configuration....................................................................................47
Firmware Upgrade...................................................................................................48
Firmware Update using the CLI...............................................................................49
Reboot.....................................................................................................................50
Reboot using the CLI...............................................................................................50
Logout .....................................................................................................................50
Logout from the CLI.................................................................................................50
User Account Page..................................................................................................51
Changing the User Mode...................................................................................51
Creating a New User..........................................................................................52
Changing an Existing User Account...................................................................53
User Privilege Configuration ....................................................................................54
User Account Settings using the CLI........................................................................56
Multi-User Mode.................................................................................................56

Preface
v
EtherWAN Managed Switch Users Guide
Single User Mode ..............................................................................................56
Creating a New User..........................................................................................57
Permissions.......................................................................................................58
Diagnostics ............................................................................................................ 60
Utilization.................................................................................................................60
System Log..............................................................................................................61
System log using CLI command ..............................................................................61
Remote Logging......................................................................................................62
Remote Logging using CLI commands....................................................................64
ARP Table...............................................................................................................65
ARP Table using CLI Commands............................................................................66
Route Table.............................................................................................................67
Route Table Using CLI Commands .........................................................................67
Alarm Setting...........................................................................................................68
Port ......................................................................................................................... 69
Configuration...........................................................................................................69
Port Status...............................................................................................................71
Rate Control ............................................................................................................72
RMON Statistics ......................................................................................................73
Per Port VLAN Activities..........................................................................................74
Port Security............................................................................................................75
Port Configuration Examples Using CLI Commands................................................76
Setting the Port Description ...............................................................................76
Enable or Disable a Port....................................................................................76
Setting the Port Speed.......................................................................................77
Setting Port Duplex............................................................................................77
Enable or Disable Port FlowControl ...................................................................78
Display Port Status ............................................................................................78
Setting a Ports Rate Control ..............................................................................78
Display a Ports RMON Statistics........................................................................79
Display a Ports VLAN Activities..........................................................................79
Setting MAC Port Security .................................................................................79
Switching................................................................................................................ 81
Bridging...................................................................................................................81
Aging Time.........................................................................................................82
Threshold Level .................................................................................................82
Storm Control Type............................................................................................82
Port Isolation......................................................................................................83
Block Multicast...................................................................................................83
Loopback Detect......................................................................................................85

Preface
vi
EtherWAN Managed Switch Users Guide
Loopback Detection (Global)..............................................................................85
Loopback Detect Action.....................................................................................85
Loopback Detect Recovery Time.......................................................................85
Polling Interval...................................................................................................86
Loopback Detection (Per Port)...........................................................................87
Storm Detect............................................................................................................88
Enable/Disable Storm Detection ........................................................................88
Static MAC Entry .....................................................................................................90
Adding a Static MAC Address to a Port..............................................................90
Removing a Static MAC Address from a Port.....................................................91
Adding a MAC to the Static-MAC-Entry Discard Table.......................................91
Removing a MAC address from the Static-MAC-Entry Discard Table................92
Port Mirroring...........................................................................................................93
Link State Tracking..................................................................................................95
Enable/Disable Link State Tracking ...................................................................95
Port Settings......................................................................................................95
PoE - System and Port Settings...............................................................................97
PoE System Setting...........................................................................................97
PoE Port Setting ................................................................................................98
PoE Scheduling.....................................................................................................100
Switch Configuration Examples Using CLI Commands..........................................102
Setting the Aging Time Value...........................................................................102
Enabling Port Isolation.....................................................................................102
Enabling Block Multicast..................................................................................103
Setting Storm Control.......................................................................................103
Enabling Loopback Detect (Global)..................................................................104
Setting the Loopback Detect Action .................................................................104
Setting the Loopback Detect Recovery Time ...................................................104
Setting the Loopback Detect Polling Interval....................................................105
Enabling Loopback Detect (Port) .....................................................................105
Configuring Storm-Detect.................................................................................106
Adding a MAC Address for Static-MAC-Entry Forwarding................................110
Adding a MAC Address for Static-MAC-Entry Discarding.................................110
Configuring Port Mirroring................................................................................111
Enabling a Link State Tracking Group..............................................................111
Assigning a Port to a Link State Tracking Group..............................................112
Setting PoE Power Budget...............................................................................112
PoE Port Settings.............................................................................................113
PoE Scheduling ...............................................................................................116
Trunking ............................................................................................................... 119
Overview ...............................................................................................................119
Static Channel Trunking...................................................................................119

Preface
vii
EtherWAN Managed Switch Users Guide
Link Aggregation Control Protocol....................................................................119
Port Trunking.........................................................................................................120
LACP Trunking......................................................................................................123
Trunking Configuration Examples Using CLI Commands.......................................127
Adding an Interface to a Static Trunk...............................................................127
Adding an Interface to a LACP Trunk...............................................................127
Setting the LACP Port Priority..........................................................................128
Setting the LACP Timeout................................................................................128
STP/Ring Page –Overview ................................................................................. 129
Choosing the Spanning Tree Protocols..................................................................129
Spanning Tree Protocol (STP).........................................................................129
Rapid Spanning Tree protocol (RSTP).............................................................129
Multiple Spanning Tree Protocol (MSTP).........................................................129
STP/Ring Page - Configuring RSTP................................................................... 130
Global Configuration Page.....................................................................................130
Enabling the RSTP Protocol ............................................................................130
Additional Global Configuration page settings..................................................130
The Root Bridge & Backup Root Bridge...........................................................132
Setting the MAX Age, Forward Delay and Hello Timer.....................................134
RSTP Port Setting Page........................................................................................136
Spanning Tree Port Roles................................................................................136
Path Cost & Port Priority..................................................................................137
Point to Point Link............................................................................................139
Edge Port.........................................................................................................139
RSTP Configuration Examples Using CLI Commands...........................................140
Enabling the Spanning Tree Protocol...............................................................140
Bridge Priority, Max Age, Forward Delay, and Hello Time................................140
Modifying the Port Priority and Path Cost.........................................................141
Manually Setting a Port to be a Shared or Point to Point Link ..........................141
Enabling/Disabling a port to be an Edge Port...................................................142
STP/Ring Page - Configuring MSTP................................................................... 143
Global Configuration Page.....................................................................................143
Enabling the MSTP Protocol............................................................................143
The CIST Root Bridge & Backup CIST Root Bridge.........................................145
Setting Bridge Priority......................................................................................145
Configuring the CST Network Diameter...........................................................147
MSTP Properties Page..........................................................................................148
Configuring an MSTP Region...........................................................................148
Configuring the IST Network Diameter.............................................................150
MSTP Instance Setting Page.................................................................................151

Preface
viii
EtherWAN Managed Switch Users Guide
Setting an MSTP Instance ...............................................................................151
Modifying MSTP parameters for load balancing...............................................152
MSTP Port Setting page........................................................................................154
Adjusting the blocking port in a MSTP network................................................154
MSTI Instance Port Membership......................................................................156
MSTP Configuration Examples Using CLI Commands ..........................................157
Enabling Spanning Tree for MSTP...................................................................157
Bridge Priority, Max Age, Forward Delay, and Hello Time................................158
IST MAX Hops.................................................................................................158
MSTP Regional Configuration Name and the Revision Level...........................159
Creating an MSTI Instance ..............................................................................159
Setting MSTI Priority........................................................................................160
Modifying CIST Port Priority and Port Path Cost..............................................160
Adding a Port to an MSTI Instance ..................................................................161
STP/Ring Page - Alpha Ring............................................................................... 162
Alpha Ring Setting Page........................................................................................162
EtherWAN α-Ring Technology.........................................................................162
Implementing a Simple α-Ring.........................................................................162
Connecting two α-Ring Networks together.......................................................164
Advanced Setting ..................................................................................................165
Advanced Bridge Configuration........................................................................165
Advanced Per Port Configuration.....................................................................166
Configuring Spanning Tree Advanced Settings using CLI commands....................167
Enabling BPDU Guard Globally .......................................................................167
Enabling BPDU Guard on a Port......................................................................167
Enabling BPDU Guard Error Disable-timeout...................................................168
VLAN..................................................................................................................... 169
Port Based VLAN vs. Tagged Based VLAN...........................................................169
Configuring VLANs in Port Based VLAN Mode......................................................169
Enabling Port Based VLAN..............................................................................169
Port Based VLAN Configuration Examples ......................................................170
Port Based VLAN Configuration Examples using CLI Commands ...................172
VLAN Configuration in 802.1Q Tag Based VLAN Mode.........................................173
General Overview............................................................................................173
Enabling 802.1Q Tagged Based VLAN............................................................174
Configuring 802.1Q VLAN Database................................................................175
802.1Q Tag Based VLAN Configuration Examples Using CLI Commands ............176
Configuring a 802.1Q VLAN.............................................................................176
Configuring an IP Address for a Management VLAN .......................................176
Removing an IP Address from a Management VLAN.......................................177
Configuring an Access Port..............................................................................177

Preface
ix
EtherWAN Managed Switch Users Guide
Configuring a Trunk Port..................................................................................178
Add an IP to the Management VLAN.....................................................................179
Configuring the Port Type and the PVID setting.....................................................180
Configuring the VLAN Egress (outgoing) Member Ports ..................................181
QoS....................................................................................................................... 183
Global Configuration Page.....................................................................................184
Web GUI Interface...........................................................................................184
QoS Global Configuration using the CLI Interface .................................................186
Enable/Disable QoS Trust................................................................................187
Configuring the Egress Expedite Queue..........................................................187
802.1p Priority Page..............................................................................................189
Web GUI Interface...........................................................................................189
802.1p Priority Submenu –CLI Interface...............................................................190
DSCP Page –HTTP Interface ...............................................................................191
DSCP Submenu –CLI Interface............................................................................192
QoS Interface Commands –CLI Interface.............................................................193
ACL (Access Control List) .................................................................................. 194
General Overview..................................................................................................194
Configuring ACL....................................................................................................195
ACL Policy Map.....................................................................................................197
IP Access List..................................................................................................198
IP Access List (Extended)................................................................................199
Mac Access List...............................................................................................201
Layer 4.............................................................................................................203
Bandwidth Limiting...........................................................................................204
Applying a Policy Map to a Port .......................................................................206
Modifying/Adding an Existing Policy Map.........................................................207
Adding a New ACL Class to an Existing Policy Map ........................................207
Adding an Existing ACL Class to an Existing Policy Map.................................208
Removing an ACL Class..................................................................................210
ACL Configuration Examples Using CLI Commands .............................................214
Enabling QoS...................................................................................................214
Creating a Standard IP Access List..................................................................215
Creating an Extended IP Access List...............................................................215
Creating a MAC Access List ............................................................................216
Creating an ACL Class Map with Layer 4 Access List......................................217
Creating a ACL Class Map with an IP or MAC Access List ..............................218
Creating an ACL Policy Map............................................................................219
Appling an Existing ACL Policy to a Port..........................................................220
Deleting an ACL Class.....................................................................................220
Deleting an ACL Policy ....................................................................................221

Preface
x
EtherWAN Managed Switch Users Guide
SNMP.................................................................................................................... 222
SNMP General Settings.........................................................................................222
Configuring SNMP v1 & v2 Community Groups.....................................................225
Configuring SNMP v3 Users..................................................................................226
Adding SNMP v3 Users to the switch...............................................................226
Deleting SNMP v3 Users from the switch.........................................................229
SNMP Configuration Examples Using CLI Commands..........................................230
Enabling SNMP and configuring general settings.............................................230
Configuring SNMP Traps.................................................................................231
Configuring SNMP v1 & v2 Community Groups...............................................233
Adding SNMP v3 Users ...................................................................................233
IEEE 802.1X.......................................................................................................... 234
Configuring 802.1X from the GUI system...............................................................234
Enabling Radius...............................................................................................234
Adding a Radius Server...................................................................................235
Enabling 802.1X on a Port...............................................................................237
LLDP..................................................................................................................... 239
LLDP General Settings..........................................................................................240
Enable/Disable LLDP.......................................................................................240
Holdtime Multiplier ...........................................................................................240
Global TLV Setting...........................................................................................241
LLDP Ports Settings ..............................................................................................243
Enabling LLDP transmission for a specific Port................................................243
Enabling LLDP Reception for a specific Port....................................................243
Enabling Notifications ......................................................................................243
LLDP Neighbors....................................................................................................245
LLDP Statistics......................................................................................................246
LLDP Configuration Examples Using CLI Commands ...........................................247
Enable/Disable LLDP.......................................................................................247
LLDP Holdtime Multiplier..................................................................................248
LLDP Transmit Interval ....................................................................................248
Enable/Disable Global LLDP TLVs ..................................................................249
Enabling LLDP Transmit on a Port...................................................................250
Enabling LLDP Receive on a Port....................................................................250
Enabling LLDP Notify.......................................................................................251
Enabling Transmission of the Management IP.................................................251
Enabling Specific TLV’s on a Port ....................................................................252
Other Protocols.................................................................................................... 253
GVRP....................................................................................................................253
General Overview............................................................................................254

Preface
xi
EtherWAN Managed Switch Users Guide
Enabling the GVRP Protocol at the Global Level .............................................255
Enabling the GVRP Protocol at the Port Level.................................................256
GVRP Configuration Examples Using CLI Commands ....................................257
IGMP Snooping.....................................................................................................260
General Overview............................................................................................260
Enabling the IGMP Snooping Modes ...............................................................261
Configuring IGMP Snooping General properties..............................................262
Configuring IGMP Passive Mode Specific properties.......................................263
Configuring IGMP Querier Mode Specific properties........................................264
Configuring IGMP Unknown Multicast Forwarding...........................................265
Monitoring Registered Multicast Groups ..........................................................269
IGMP Configuration Examples Using CLI Commands .....................................270
Network Time Protocol ..........................................................................................278
Enabling NTP...................................................................................................278
Setting the NTP Server IP Address..................................................................278
Setting the Timezone.......................................................................................278
Setting the Polling Period.................................................................................278
Manually Syncing Time....................................................................................279
Daylight Savings Time - Weekday Mode..........................................................279
Daylight Savings Time –Date Mode................................................................280
Network Time Protocol Configuration Examples Using CLI Commands...........282
GMRP....................................................................................................................285
General Overview............................................................................................285
GMRP Normal mode........................................................................................285
GMRP Fixed mode ..........................................................................................285
GMRP Forbidden mode...................................................................................286
GMRP Forward All mode.................................................................................286
GMRP Disabled mode .....................................................................................286
Enabling the GMRP Feature Globally on the Switch........................................286
Configuring the GMRP Feature Per Port..........................................................287
GMRP Configuration Examples Using CLI Commands....................................290
DHCP Server.........................................................................................................292
General Overview............................................................................................292
Configuring the DHCP Server..........................................................................292
DHCP Configuration Examples Using CLI Commands ....................................295
TABLE OF FIGURES
Figure 1: Login screen.........................................................................................................21

Preface
xii
EtherWAN Managed Switch Users Guide
Figure 2: Assigning an IP address.......................................................................................22
Figure 3: System Information ..............................................................................................27
Figure 4: System Name/Password......................................................................................28
Figure 5: IP Address............................................................................................................31
Figure 6: Management Interface..........................................................................................38
Figure 7: Save Configuration Page......................................................................................44
Figure 8: Firmware Upgrade Page ......................................................................................49
Figure 9: User Mode............................................................................................................51
Figure 10: Creating Users ...................................................................................................52
Figure 11: Selecting an Existing User Account....................................................................53
Figure 12: Deleting a User Account.....................................................................................53
Figure 13: User Privilege Page............................................................................................55
Figure 14: Utilization Page ..................................................................................................60
Figure 15: System Log........................................................................................................61
Figure 16: Remote Logging Page........................................................................................63
Figure 17: ARP Table..........................................................................................................65
Figure 18: Route Table........................................................................................................67
Figure 19: Alarm Trigger .....................................................................................................68
Figure 20: Trigger Enable....................................................................................................68
Figure 21: Port Configuration ..............................................................................................70
Figure 22: Port Status .........................................................................................................71
Figure 23: Rate Control.......................................................................................................72
Figure 24: RMON Page.......................................................................................................73
Figure 25: Port VLAN Activities ...........................................................................................74
Figure 26: Port Security.......................................................................................................75
Figure 27: Bridging..............................................................................................................84
Figure 28: Loopback Detection............................................................................................86
Figure 29:Loopback Detection (port)...................................................................................87
Figure 30: Storm Detect –Global........................................................................................88
Figure 31: Storm Detect –Per Port .....................................................................................89
Figure 32: MAC Static Entry................................................................................................90
Figure 33: Removing a Static MAC .....................................................................................91
Figure 34: Adding a MAC –Static-MAC-Entry Table...........................................................91
Figure 35: Deleting a MAC –Static-MAC-Entry Table.........................................................92
Figure 36: Port Mirroring .....................................................................................................94
Figure 37: Disabling Port Mirroring......................................................................................94
Figure 38: Link State Tracking.............................................................................................95
Figure 39: Link State Tracking –Port Settings.....................................................................96
Figure 40: PoE System Setting ...........................................................................................97
Figure 41: PoE Port Setting.................................................................................................99
Figure 42: Selecting a Port................................................................................................100
Figure 43: PoE Power Scheduling.....................................................................................101
Figure 44: Port Trunking –Version 1.................................................................................121

Preface
xiii
EtherWAN Managed Switch Users Guide
Figure 45: Port Trunking –Version 2.................................................................................122
Figure 46: LACP Trunking Version 1.................................................................................124
Figure 47: LACP Trunking –Version 2..............................................................................126
Figure 48: STP/Ring Global Configuration.........................................................................131
Figure 49: Bridge ID..........................................................................................................132
Figure 50: Bridge ID Display..............................................................................................133
Figure 51: Max Age, Hello Timer & Forward Delay............................................................135
Figure 52: Spanning Tree Port Roles................................................................................136
Figure 53: Port ID..............................................................................................................137
Figure 54: Port Priority and Path Cost...............................................................................138
Figure 55: Enabling MSTP ................................................................................................144
Figure 56: Bridge ID..........................................................................................................145
Figure 57: Bridge ID Display..............................................................................................146
Figure 58: Max Age, Hello Timer & Forward Delay............................................................148
Figure 59: MSTP Region and Revision Level....................................................................149
Figure 60: MSTP Properties –Max Hops..........................................................................150
Figure 61: VLAN Instance Configuration ...........................................................................152
Figure 62: VLAN Instance ID.............................................................................................152
Figure 63: Setting the MSTI Regional Root Bridge............................................................153
Figure 64: Port Cost & Priority...........................................................................................155
Figure 65: Port Instance Configuration..............................................................................156
Figure 66: Port Instance - Adding Ports.............................................................................157
Figure 67: α-Ring Settings.................................................................................................163
Figure 68: Ring Coupling...................................................................................................164
Figure 69: Advanced Bridge Configuration........................................................................165
Figure 70: Advanced Per Port Configuration .....................................................................166
Figure 71: Port Based VLAN.............................................................................................169
Figure 72: Port Based VLAN –Example 1.........................................................................170
Figure 73: Port Based VLAN –Example 2.........................................................................171
Figure 74: Tag-based VLAN..............................................................................................174
Figure 75: Add VLAN ........................................................................................................175
Figure 76: Add VLAN Page...............................................................................................175
Figure 77: Management VLAN IP Address........................................................................179
Figure 78: VLAN Port Setting............................................................................................180
Figure 79: VLAN Links ......................................................................................................181
Figure 80: VLAN Ports ......................................................................................................182
Figure 81: Tag or Untag ports ...........................................................................................182
Figure 82: Global Configuration.........................................................................................184
Figure 83: 802.1p Priority..................................................................................................189
Figure 84: DSCP...............................................................................................................191
Figure 85: Enabling QoS...................................................................................................196
Figure 86: Policy Map........................................................................................................197
Figure 87: IP Access List...................................................................................................198

Preface
xiv
EtherWAN Managed Switch Users Guide
Figure 88: Access List Extended.......................................................................................199
Figure 89: MAC Access list ...............................................................................................201
Figure 90: Layer 4.............................................................................................................203
Figure 91: IP Access List Name........................................................................................204
Figure 92: Police Rate.......................................................................................................205
Figure 93: Policy Map Name.............................................................................................205
Figure 94: Applying a Policy Map to a Port........................................................................206
Figure 95: Modifying a Policy Map.....................................................................................207
Figure 96: Adding a New ACL Class to an Existing Policy Map.........................................208
Figure 97: Policy Map Setting –Class Name.....................................................................209
Figure 98: Policy Map Setting............................................................................................209
Figure 99: Removing an ACL Class ..................................................................................210
Figure 100: Verifying ACL Class Removal.........................................................................211
Figure 101: Removing a Policy Map..................................................................................212
Figure 102: Policy Map 2...................................................................................................213
Figure 103: Policy Map 3...................................................................................................214
Figure 104: SNMP General Settings .................................................................................224
Figure 105: Community Name V1/V2c ..............................................................................225
Figure 106: Add User........................................................................................................226
Figure 107: SNMP v3 Settings..........................................................................................227
Figure 108: User name & Access Mode............................................................................227
Figure 109: Auth Password...............................................................................................228
Figure 110: Privacy PassPhrase .......................................................................................228
Figure 111: Delete User....................................................................................................229
Figure 112: Select User.....................................................................................................229
Figure 113: Enable Radius................................................................................................235
Figure 114: Radius Setup..................................................................................................236
Figure 115: Resulting Radius Server Setup.......................................................................237
Figure 116: Enabling 802.1X on a Port..............................................................................238
Figure 117: LLDP Global Settings.....................................................................................242
Figure 118: LLDP Ports Settings.......................................................................................244
Figure 119: LLDP Neighbors.............................................................................................245
Figure 120: LLDP Statistics...............................................................................................246
Figure 121: GVRP.............................................................................................................253
Figure 122: GVRP Configuration Distribution Switch.........................................................255
Figure 123: GVRP Configuration Access Switch...............................................................255
Figure 124: GVRP Per Port Settings.................................................................................256
Figure 125: IGMP Mode....................................................................................................261
Figure 126: IGMP General Properties ...............................................................................262
Figure 127: IGMP Passive Mode.......................................................................................263
Figure 128: Querier Mode Properties................................................................................264
Figure 129: Disabled Mode Forwarding Port.....................................................................265
Figure 130: PassiveForwardMode.....................................................................................266

Preface
xv
EtherWAN Managed Switch Users Guide
Figure 131: ForceForwardMode........................................................................................267
Figure 132: IGMP Querier Mode Forwarding.....................................................................268
Figure 133: Current Multicast Groups................................................................................269
Figure 134: NTP Settings..................................................................................................279
Figure 135: Daylight Savings –Weekday Mode................................................................280
Figure 136: Daylight Savings –Date Mode .......................................................................281
Figure 137: GMRP Global Setting.....................................................................................287
Figure 138: DHCP Server .................................................................................................293
Figure 139: DHCP Bindings ..............................................................................................294
Figure 140: DHCP Binding Table ......................................................................................294

Preface
xvi
EtherWAN Managed Switch Users Guide
PREFACE
Audience
This guide is designed for the person who installs, configures, deploys, and maintains the
Ethernet network. This document assumes the reader has moderate hardware, computer,
and Internet skills.
Document Revision Level
This section provides a history of the revision changes to this document.
Revision
Document Version
Date
Description
B
Version 1
12/3/2014
Updated for Firmware version 1.94.2
Changes in this Revision
Updated Setting the initial IP address Section
Updated System Menu/IP Address Section
Updated GUI Images to 1.94.2 Firmware
Updated Port Security Section
Updated Storm Control Section
Updated Port Trunking Section to support multiple switch models
New sections added:
Storm Detect (GUI)
Storm Detect CLI
Global PoE GUI
Global PoE CLI
PoE Port GUI
PoE Port CLI

Preface
xvii
EtherWAN Managed Switch Users Guide
Document Conventions
This guide uses the following conventions to draw your attention to certain information.
Safety and Warnings
This guide uses the following symbols to draw your attention to certain information.
Symbol
Meaning
Description
Note
Notes emphasize or supplement important points of the main text.
Tip
Tips provide helpful information, guidelines, or suggestions for performing tasks more
effectively.
Warning
Warnings indicate that failure to take a specified action could result in damage to the
device, or could result in serious bodily injury.
Electric Shock Hazard
This symbol warns users of electric shock hazard. Failure to take appropriate
precautions such as not opening or touching hazardous areas of the equipment could
result in injury or death.
Typographic Conventions
This guide also uses the following typographic conventions.
Convention
Description
Bold
Indicates text on a window, other than the window title, including menus, menu options, buttons, fields, and labels.
Italic
Indicates a variable, which is a placeholder for actual text provided by the user or system. Angled brackets (< >)
are also used to indicate variables.
screen/code
Indicates text that is displayed on screen or entered by the user.
< > angled
brackets
Indicates a variable, which is a placeholder for actual text provided by the user or system. Italic font is also used to
indicate variables.
[ ] square
brackets
Indicates optional values.
{ } braces
Indicates required or expected values.
| vertical bar
Indicates that you have a choice between two or more options or arguments.

18
EtherWAN Managed Switch Users Guide
UNPACKING AND INSTALLATION
This chapter describes how to unpack and install the EtherWAN Managed Switch
The topics covered in this chapter are:
Package Contents (Page 18)
Unpacking (Page 18)
Required Equipment and Software (Page 19)
Computer Setup (Page 20)
Management Methods and Protocols (Page 20)
Default IP (Page 21)
Login Process and Default Credentials (Page 21)
Setting the initial IP address (Page 22)
Package Contents
When you unpack the product package, you will find the items listed below. Please inspect
the contents, and report any apparent damage or missing items immediately to your
authorized reseller.
This Managed Switch
Product CD
Quick Installation Guide
External power adapter/Cable (depending on model)
Unpacking
Follow these steps to unpack the EtherWAN Managed Switch and prepare it for operation:
1. Open the shipping container and carefully remove the contents.
2. Return all packing materials to the shipping container and save it.
3. Confirm that all items listed in the "Package Contents" section are included in the
shipment. Check each item for damage. If any item is damaged or missing, notify your
authorized EtherWAN representative.

19
EtherWAN Managed Switch Users Guide
Required Equipment and Software
The following hardware and software are needed in order to manage the switch from the
web interface:
Computer with an Ethernet Interface (RJ-45)
Managing the switch requires a personal computer (PC) or notebook computer
equipped with a 10/100base-TX Ethernet interface and a physical RJ-45
connection. The preferred operating system for the computer is Microsoft Windows
XP/Vista/7. It is possible to use Apple OSX or Linux systems as well, but, for the
sake of brevity, all web configurations in this manual will be shown using Windows
7 as the underlying operating system.
Cat 5+ Ethernet Cables
An Ethernet cable of at least Category 5 rating is required to connect your
computer to the switch. The cable can be configured as “straight-through” or
crossover.
TFTP Server Software
Trivial file transfer protocol (TFTP) server software is needed to update the switch
firmware and to upload/download configuration files to the switch. Users not
performing these tasks do not need TFTP software installed. Several good TFTP
servers are available for free online. The server that will be used in this manual is
TFTPD32 by Philippe Jounin.
Web Browser Software
The end user can employ any of the following web browsers during switch
configuration: Internet Explorer, Firefox, or Chrome. Internet Explorer is the
preferred browser for EtherWAN switch configuration. If there is trouble with other
browsers while attempting to program the switch, Internet Explorer should be used.

20
EtherWAN Managed Switch Users Guide
COMPUTER SETUP
The end user’s management computer may need to be reconfigured prior to connecting to
the switch in order to access the switch’s web interface through its default IP address (See
Default IP).
Management Methods and Protocols
There are several methods that can be used to manage the switch. This manual
will show the details of configuring the switch using a web browser. Each section
will be followed by the CLI (Command Line Interface) commands needed to
achieve the same results as described in that section.
The methods available to manage the EtherWAN Managed Switch include:
SSH - Secure Shell CLI that is accessible over TCP/IP networks which and
is generally regarded as the most secure method of remotely accessing a
device.
Telnet - is like SSH in that it allows a CLI to be established across a
TCP/IP network, but it does not encrypt the data stream.
HTTP (Hypertext Transfer Protocol) is the most popular switch
management protocol involving the use of a web browser.
RS232 –The EtherWAN Managed Switch is equipped with a RS232 serial
port that can be used to access the switches CLI. The Serial port is DCE
DB9F. A straight through serial cable is used to connect to a typical
computer serial port.
