evertz 7700 MultiFrame User manual

7700 MultiFrame Manual
7708LT Wideband RF Fiber Transmitter
Revision 1.1
TABLE OF CONTENTS
1. OVERVIEW.............................................................................................................................................1
2. INSTALLATION......................................................................................................................................3
2.1. 7708LT CONNECTIONS ..............................................................................................................4
2.2. CARE AND HANDLING OF OPTICAL FIBER.............................................................................4
2.2.1. Safety.................................................................................................................................4
2.2.1.1. 7708LT 1310nm FP and CWDM Versions........................................................4
2.2.1.2. 7708LT DWDM Versions....................................................................................4
2.2.2. Assembly...........................................................................................................................5
2.2.3. Labeling.............................................................................................................................5
2.2.4. Handling and Connecting Fibers......................................................................................6
3. SPECIFICATIONS..................................................................................................................................7
3.1. RF INPUT ......................................................................................................................................7
3.2. RF MONITOR OUTPUT................................................................................................................7
3.3. OPTICAL OUTPUT .......................................................................................................................7
3.4. ELECTRICAL................................................................................................................................7
3.5. PHYSICAL (NUMBER OF SLOTS)..............................................................................................7
3.6. COMPLIANCE...............................................................................................................................8
3.7. RF SYSTEM PERFORMANCE 7708LT13+7708LRA PAIR .......................................................8
4. STATUS INDICATORS..........................................................................................................................9
5. JUMER POSITIONS ............................................................................................................................11
5.1. 7708LT JUMPERS AND LEDS..................................................................................................11
5.2. SELECTING WHETHER LOCAL FAULTS WILL BE MONITORED
BY THE GLOBAL FRAME STATUS..........................................................................................11
5.3. CONFIGURING THE MODULE FOR FIRMWARE UPGRADES ..............................................11
5.4. FACTORY AND BDM JUMPERS...............................................................................................12
6. DOT-MATRIX DISPLAY.......................................................................................................................13
6.1. 7708LT CONTROLLED PARAMETERS ...................................................................................16

7700 MultiFrame Manual
7708LT Wideband RF Fiber Transmitter
Revision 1.1
6.1.1. Adjusting the RF Input Power Alarm...............................................................................16
6.1.2. Selecting the Input Gain Mode........................................................................................16
6.1.3. Enabling/Disabling Squelch Mode..................................................................................17
6.1.4. Adjusting the Squelch Mode Threshold..........................................................................17
6.1.5. Adjusting the RF Gain .....................................................................................................17
6.1.6. Adjusting the AGC Target Level .....................................................................................18
6.1.7. Setting the Passcode (DWDM versions only) ................................................................18
6.1.8. Setting the LNB Voltage Level........................................................................................18
6.1.9. Configuring the 22KHz Tone...........................................................................................19
6.1.10.Setting the LNB Current Threshold Level.......................................................................19
6.1.11.Default Card-Edge Display..............................................................................................19
6.1.12.Setting the Display Orientation........................................................................................19
6.1.13.Displaying the RF Threshold...........................................................................................20
6.1.14.Displaying the Gain Mode...............................................................................................20
6.1.15.Displaying the Gain Level................................................................................................20
6.1.16.Displaying the Squelch Status ........................................................................................20
6.1.17.Displaying the Laser Status.............................................................................................20
6.1.18.Displaying the LNB Voltage Level...................................................................................21
6.1.19.22KHz Tone Status..........................................................................................................21
6.1.20.Displaying the LNB Current.............................................................................................21
6.1.21.Displaying the LNB Current Threshold Level.................................................................21
6.1.22.Displaying the Firmware Version....................................................................................22
7. VISTALINK®REMOTE MONITORING/CONTROL.............................................................................23
7.1. WHAT IS VISTALINK®?................................................................................................................23
7.2. VISTALINK®MONITORED PARAMETERS................................................................................24
7.3. 7708LT VISTALINK®CONTROLLED PARAMETERS..............................................................24
7.4. VISTALINK®TRAPS.....................................................................................................................25

7700 MultiFrame Manual
7708LT Wideband RF Fiber Transmitter
Revision 1.1
Figures
Figure 1-1: 7708LT Block Diagram .......................................................................................................2
Figure 2-1: 7708LT Module ...................................................................................................................3
Figure 2-2: Reproduction of 7708LT Certification and Identification Label
for Models that are Class 1 Laser Products .......................................................................5
Figure 2-3: Reproduction of 7708LT Certification and Identification Label
for Models that are Class 1M Laser Products ....................................................................5
Figure 5-1: Location of 7708LT Jumpers and LEDs...........................................................................11
Figure 6-1: Card Edge Menu Structure...............................................................................................15
Tables
Table 4-1: LED Status Indicators.........................................................................................................10
Table 7-1: VistaLINK®Monitored Parameters.....................................................................................24
Table 7-2: VistaLINK®Controlled Parameters....................................................................................24
Table 7-3: VistaLINK®Traps................................................................................................................25

7700 MultiFrame Manual
7708LT Wideband RF Fiber Transmitter
Revision 1.1
This page left intentionally blank

7700 MultiFrame Manual
7708LT Wideband RF Fiber Transmitter
Revision 1.1
REVISION HISTORY
REVISION DESCRIPTION DATE
1.0 First Release Apr 09
1.1 Added note in Installation section Aug 13
Information contained in this manual is believed to be accurate and reliable. However, Evertz assumes no responsibility for the
use thereof nor for the rights of third parties, which may be affected in any way by the use thereof. Any representations in this
document concerning performance of Evertz products are for informational use only and are not warranties of future
performance, either expressed or implied. The only warranty offered by Evertz in relation to this product is the Evertz standard
limited warranty, stated in the sales contract or order confirmation form.
Although every attempt has been made to accurately describe the features, installation and operation of this product in this
manual, no warranty is granted nor liability assumed in relation to any errors or omissions unless specifically undertaken in the
Evertz sales contract or order confirmation. Information contained in this manual is periodically updated and changes will be
incorporated into subsequent editions. If you encounter an error, please notify Evertz Customer Service department. Evertz
reserves the right, without notice or liability, to make changes in equipment design or specifications.

7700 MultiFrame Manual
7708LT Wideband RF Fiber Transmitter
Revision 1.1
CAUTION
If the LNB POWER LED is on, there will be DC voltage for LNB power at the RF
INPUT connector. This can damage some test equipment. The user can turn
off the LNB power under using the card-edge control system under the LNBV
menu item. See section 6.1.8 for details.

7700 MultiFrame Manual
7708LT Wideband RF Fiber Transmitter
Revision 1.1 Page-1
1. OVERVIEW
The 7708LT is a fiber optic transmitter for RF signals in the extended L-Band frequencyrange and below,
for frequencies such as over-the-air DTV. It accepts a single RF input on coaxial cable and provides a
single output for optical transmission. An RF monitor output provides a convenient means of obtaining
peak satellite signal strength, or additional signal distribution.
Gain may be adjusted manually or managed automatically via AGC. With SmartMON™, incoming RF
signal strength, LNB current, and other data are relayed over the fiber output for monitoring through
SNMP/VistaLINK®at the fiber receiver (requires SmartMON™ capable companion fiber receiver). LNB
power with selectable 13/18V DC and 22 kHz tone is also provided.
Features:
•Extended frequency response for L-Band and other frequencies
•Protocol independent design - transports all modulation formats
•High power +11 dBm DWDM laser option for extended reach on long-haul applications
•LNB power with selectable 13/18V DC
•LNB current limit & short circuit protection
•LNB current monitoring
•22kHz tone on/off for LNB local oscillator control
•RF monitor output for signal peaking and signal distribution
•Manually adjustable gain
•AGC mode
•The 7708LT occupies one card slot and can be housed in a 1RU frame that will hold up to 3
modules, a 3RU frame that will hold up to 15 modules or a standalone enclosure which holds 1
module
•SmartMON™ capability provides remote status monitoring via SNMP without a separate data
connection
•VistaLINK®capability is available for monitoring and control when modules are used in a 3RU
7800FR frame and a 7700FC VistaLINK®frame controller is installed in slot 1 of the frame.

7700 MultiFrame Manual
7708LT Wideband RF Fiber Transmitter
Page-2 Revision 1.1
Figure 1-1: 7708LT Block Diagram

7700 MultiFrame Manual
7708LT Wideband RF Fiber Transmitter
Revision 1.1 Page-3
2. INSTALLATION
The 7708LT comes with a companion rear plate appropriate for a 1RU, 3RU or standalone enclosure as
specified at the time of order. SC/UPC, SC/APC, ST/UPC, FC/UPC, FC/APC or ST/UPC optical
connectors are available and the type specified at the time of order will be installed. For information on
mounting the rear plate and inserting the module into the frame, see the 7700FR manual for detailed
instructions.
Figure 2-1: 7708LT Module

7700 MultiFrame Manual
7708LT Wideband RF Fiber Transmitter
Page-4 Revision 1.1
2.1. 7708LT CONNECTIONS
FIBER OUTPUT: SC/UPC, SC/APC, FC/UPC, FC/APC or ST/UPC female connector with the optical
output from the 7708LT. This connector should be connected to the FIBER IN
connector of an appropriate Evertz companion receiver model at the destination
end with a suitable fiber optic cable. The 7708LT may transmit 1310nm, CWDM or
DWDM wavelengths as indicated by the part number on the card ejector. The
standard connector type is UPC. This connector type is compatible with standard
PC connectors, but for optimal return loss performance, Evertz recommends the
use of UPC fiber terminations throughout the system. The optional APC
connectors provide further enhanced return loss performance, and when specified,
should be used throughout the system.
RF IN: Input connector for RF signals. This connector can also provide LNB power and 22
kHz tone back to the LNB.
The RF input is protected to
the same degree as other professional RF devices,
and will withstand a degree of ESD from handling, etc.
Regardless, proper
precautions should be taken during handling, such as the use of static bags and
wrist straps. The input is not protected against lightning or other coupling of
large energy spikes.
If the installation is such that the RF input may be
susceptible to spikes (e.g. direct connection to the antenna/LNB) then
appropriate supplemental surge protection should be installed (e.g. Polyphaser).
RF OUT: Output connector provides a buffered copy of the incoming RF signal for monitoring
purposes (signal peaking, etc.) or coaxial distribution. Although not essential, if this
connector is to remain unused, it is recommended that it be terminated with an
appropriate 75 Ohm or 50 Ohm load.
2.2. CARE AND HANDLING OF OPTICAL FIBER
2.2.1. Safety
2.2.1.1. 7708LT 1310nm FP and CWDM Versions
!
CLASS 1 LASER PRODUCT
Background colour: yellow
Triangular band: black
Symbol: black
2.2.1.2. 7708LT DWDM Versions
!
INVISIBLE LASER RADIATION
DO NOT VIEW DIRECTLY WITH OPTICAL INSTRUMENTS
CLASS 1M LASER PRODUCT
Background colour: yellow
Triangular band: black

7700 MultiFrame Manual
7708LT Wideband RF Fiber Transmitter
Revision 1.1 Page-5
Symbol: black
2.2.2. Assembly
Assembly or repair of the laser sub-module is to be done only at the Evertz facility and performed only by
Evertz technical personnel.
2.2.3. Labeling
Certification and Identification labels are combined into one label. As there is inadequate space on the
product to place the label, it is reproduced here in the manuals.
•There is no date of manufacture on this label as it can be traced by bar code label placed on the
PCB of each Evertz plug-in product
•Class 1 Laser Products: Model number is one of 7708LT13 or 7708LTxx (xx = 27, 29, 31, 33, 35, 37,
43, 45, 47, 49, 51, 53, 55, 57, 59, 61)
•Class 1M Laser Products: Model number is one of 7708LTDxxx (Dxxx represents ITU Grid Channel:
D200, D210, D220, D230, D240, D250, D260, D270, D280, D290, D300, D310, D320, D330, D340,
D350, D360, D370, D380, D390, D400, D410, D420, D430, D440, D450, D460, D470, D480, D490,
D500, D510, D520, D530, D540, D550, D570, D580, D590, D600)
Figure 2-2: Reproduction of 7708LT Certification and Identification Label for
Models that are Class 1 Laser Products
Figure 2-3: Reproduction of 7708LT Certification and Identification Label for
Models that are Class 1M Laser Products

7700 MultiFrame Manual
7708LT Wideband RF Fiber Transmitter
Page-6 Revision 1.1
2.2.4. Handling and Connecting Fibers

Never touch the end face of an optical fiber. Always keep dust caps on optical fiber
connectors when not connected and always remember to properly clean the optical end
facet of a connector before making a connection.
The transmission characteristics of the fiber are dependent on the shape of the optical core and therefore
care must be taken to prevent fiber damage due to heavy objects or abrupt fiber bending. Evertz
recommends that the user maintain a minimum bending radius of 5 cm to avoid fiber-bending loss that
will decrease the maximum attainable distance of the fiber cable. Evertz fiber optic modules are
equipped with lockout devices that prevent the user from damaging the fiber connector by installing a
module into a slot in the frame that does not have a suitable rear plate installed.

7700 MultiFrame Manual
7708LT Wideband RF Fiber Transmitter
Revision 1.1 Page-7
3. SPECIFICATIONS
3.1. RF INPUT
Number of Inputs: 1
Connector: BNC per IEC 61169-8 Annex A (F-Type Optional)
Input Impedance: 75Ω (50Ω Optional)
Return Loss: > 15dB
Frequency Range: 120MHz-2250MHz
Input Power Range: -10dBm to -60dBm
AGC Gain Range: 0 to +31.5 dB
Input IP3: +10dBm
LNB Power:
Voltage: 13V DC, 17V DC, off (selectable)
Current: 400mA
Protection: Short Circuit, current limited
LO Control: 22kHz on/off (selectable)
3.2. RF MONITOR OUTPUT
Number of Outputs: 1
Connector: BNC per IEC 61169-8 Annex A (F-Type Optional)
Output Impedance: 75Ω (50Ω Optional)
Return Loss: > 15dB
Frequency Range: 120MHz to 2250MHz
Output Level: within -2.0dB of input signal
3.3. OPTICAL OUTPUT
Number of Outputs: 1
Connector: Female FC/UPC, ST/UPC, FC/UPC, SC/APC, FC/APC
Operating Wavelength:
Standard: 1310nm
CWDM: 1270-1610nm
DWDM: C-Band (ITU G.694.1 compliant)
Output Power:
Standard 1310nm: +2dBm
CWDM: +2dBm
DWDM: +10dBm
3.4. ELECTRICAL
Voltage: +12V DC
Power: 6W max excluding LNB Power
3.5. PHYSICAL (NUMBER OF SLOTS)
350FR:
7700FR-C: 1

7700 MultiFrame Manual
7708LT Wideband RF Fiber Transmitter
Page-8 Revision 1.1
7800FR:
3.6. COMPLIANCE
Laser Safety: Class 1 laser product for 1310nm FP and CWDM versions
Class 1M laser product for DWDM versions
Complies with 24 CFR 1040.10 and 1040.11 IEC 60825-1
EMI/RFI: Complies with FCC Part 15, Class A EU EMC directive
3.7. RF SYSTEM PERFORMANCE 7708LT13+7708LRA PAIR
Frequency Range: 120MHz-2250MHz
Flatness: ±1.5dB @ 850MHz-2250MHz

7700 MultiFrame Manual
7708LT Wideband RF Fiber Transmitter
Revision 1.1 Page-9
4. STATUS INDICATORS
The 7708LT has eight LED status indicators on the front card edge to show operational status of the card
at a glance. See Figure 5-1 for LED locations.
Two large LEDs on the front of the board indicate the general health of the module:
LOCAL FAULT: This red LED will be on during the absence of a valid RF input signal (too
low, too high or out of AGC range), an LNB short/overload, or if a local
internal power fault exists (i.e.: a blown fuse). Whether or not this LOCAL
FAULT indication is reported to the frame may be selected by the FRAME
STATUS jumper (see section 5.1).
MODULE OK: This green LED will be on when the RF input signal is within range, LNB
power conditions are normal and the board power is good.
There are six small LEDs that indicate the status of the input RF signal, LNB, and AGC mode signals.
RF HIGH: This red LED will be on when the input RF signal is higher than the RF high
threshold setting.
RF OK: This green LED will be on when the input RF signal is within threshold
settings.
RF LOW: This yellow LED will be on when the input RF signal is lower than the RF
low threshold setting.
GAIN MODE: This LED is on when AGC mode is enabled and off when Manual mode is
enabled. It will be green when power levels are within the AGC hold range
and a constant RF output level is being maintained. It will be red if power
levels are either above or below the power levels required for the AGC
circuit to be able to maintain a constant level.
LNB MODE: This LED is on when LNB power is ON. It will green when LNB is active and
OK (no short). It will be red when an LNB short or overload is detected (fault
present).
SQUELCH MODE: This LED is on when squelch is enabled. It will be green when squelch is
enabled but not active. It will be red when squelch mode is enabled and the
output signal is squelched.

7700 MultiFrame Manual
7708LT Wideband RF Fiber Transmitter
Page-10 Revision 1.1
LED # Colour Function
LOCAL /
FAULT
RED
LED 1 is red or LED 2 is off or LED 3 is yellow or LED 4 is red or LED 5 is red.
GREEN LED 1 is off and LED 2 is green and LED 3 is off and LED 4 is green or off
and LED 5 is green or off.
1
RED
RF Input Power is greater then or equal to the upper threshold setting.
OFF
RF Input Power is less then the upper threshold setting.
2 GREEN RF Input Power is less the upper threshold setting and greater then the lower
threshold setting.
OFF RF Input Power is less then the lower threshold setting or greater then the
upper threshold setting.
3
YELLOW
RF Input Power less then or equal to the lower threshold setting.
OFF
RF Input Power greater then the lower threshold setting.
4
RED
AGC is on but unable to maintain output power setting.
GREEN
AGC is on and can maintain output power setting.
OFF AGC is off (manual mode)
5
RED
LNB Short/Overload
GREEN
LNB power on and OK
OFF
LNB power OFF
6
RED
Squelch active
GREEN
Squelch on but not active
OFF
Squelch off
Table 4-1: LED Status Indicators

7700 MultiFrame Manual
7708LT Wideband RF Fiber Transmitter
Revision 1.1 Page-11
5. JUMER POSITIONS
5.1. 7708LT JUMPERS AND LEDS
/ MODULE OK
LOCAL FAULT
AGC Status
Squelch Status
DOT MATRIX DISPLAY
RF High
RF OK
RF Low
RUN/UPGRADE
FRAME
STATUS
OFF/ON
J6
Serial Upgrade Port
Pushbutton
Toggle
Switch
BDM
FACTORY
LNB Power Status
Figure 5-1: Location of 7708LT Jumpers and LEDs
5.2. SELECTING WHETHER LOCAL FAULTS WILL BE MONITORED
BY THE GLOBAL FRAME STATUS
The FRAME STATUS jumper J3 determines whether local faults (as shown by the Local Fault indicator)
will be connected to the 7700FR frame's global status bus.
FRAME STATUS: To monitor faults on this module with the frame status indicators (on the Power
Supply FRAME STATUS LEDs and on the Frame's Fault Tally output) install this
jumper in the ON position (default).
When this jumper is installed in the Off position local faults on this module will not
be monitored.
5.3. CONFIGURING THE MODULE FOR FIRMWARE UPGRADES
UPGRADE: The UPGRADE jumper J5 is used when firmware upgrades are being done to the
module. For normal operation it should be installed in the RUN position. See the
Upgrading Firmware section of this manual for more information.

7700 MultiFrame Manual
7708LT Wideband RF Fiber Transmitter
Page-12 Revision 1.1
To upgrade the firmware:
1. Pull the module out of the frame.
2. Move the UPGRADE jumper into the UPGRADE position.
3. Install the Upgrade cable provided (located in the vinyl pouch in the front of this manual) onto the
SERIAL header at the card edge.
4. Re-install the module into the frame.
5. Run the upgrade as described in the Upgrading Firmware section of this manual.
6. When the upgrade is completed, remove the module from the frame, move the UPGRADE jumper
into the RUN position, remove the upgrade cable and re-install the module.
The module is now ready for normal operation.

If installed in a frame with a 7700FC frame controller, the 7708T may also be
conveniently upgraded through Evertz VistaLINK®
PRO, without service interruption.
Consult VistaLINK®PRO documentation for details on this feature.
5.4. FACTORY AND BDM JUMPERS
When shipped from the Evertz facility, the FACTORY and BDM jumpers will not be installed. These
jumpers should not be installed for any reason. If jumpers are on these positions they should be
removed.

7700 MultiFrame Manual
7708LT Wideband RF Fiber Transmitter
Revision 1.1 Page-13
6. DOT-MATRIX DISPLAY
Signal and status monitoring and control of the card’s parameters are provided via the four-digit
alphanumeric display located on the card edge. The card-edge toggle-switch (see Figure 5-1) is used to
navigate through the display menus and the push button is used to select options. Figure 6-1 provides a
quick reference to the display menu structure.
CTRL menu items have user-adjustable configuration values associated with them. STAT menu items
display operating conditions or configuration values, but do not allow adjustment.
If a specific menu selection has a configuration value associated with it, then this may be changed using
the toggle switch. Pressing the pushbutton will apply the displayed value and return you to the previous
menu level.
The most recent user selection will be maintained in non-volatile memory in the event of power
loss to the module.

7700 MultiFrame Manual
7708LT Wideband RF Fiber Transmitter
Page-14 Revision 1.1
Top Level Level 1 Level 2 Level 3 Level 4
DEFD
selection
BACK
CTRL
BACK
RFTH LWR 0 to -60 dBm
Default -60 dBm
UPPR 0 to -60 dBm
Default 0 dBm
MODE AGC
MAN (default)
SQL ON
OFF (default)
SQTH 0 to -60dBm
Default: -60dBm
GAIN
(visible in manual mode
only)
0 to 31.5dB
Default: 0dB
OUTL
(visible in AGC mode
only)
0 to -50dBm
Default: -20dBm
PSWD+ 0 to 9999
(Default 7154)
This area visible only if
correct password
entered.
PSWL+ 0000 - 9999
LASR+ ON
OFF
LNBV 18V13V
OFF (Default)
22KT
ON
OFF (Default, also can
only be off if LNBV is off)
LNTH
LWR 0 to 500mA
Default = 0
UPPR 0 to 500mA
Default = 500
