evertz 7700 Series User manual

7700 MultiFrame Manual
7707CATV Cable TV Fiber Transmitter / Receiver
Revision 2.1 7707CATV-i
TABLE OF CONTENTS
1. OVERVIEW.......................................................................................................................................... 1
2. INSTALLATION............................................................................................................................... 3
2.1. 7707CATVT CONNECTIONS..................................................................................................... 4
2.2. 7707CATVR CONNECTIONS .................................................................................................... 4
2.3. GPO CIRCUIT............................................................................................................................. 5
2.4. CARE AND HANDLING OF OPTICAL FIBER........................................................................... 5
2.4.1. Safety.............................................................................................................................. 5
2.4.2. Handling and Connecting Fibers..................................................................................... 5
3. 7707CATVT SPECIFICATIONS.......................................................................................................... 7
3.1.1. RF INPUT........................................................................................................................ 7
3.1.2. RF OUTPUT.................................................................................................................... 7
3.1.3. OPTICAL OUTPUT......................................................................................................... 7
3.1.4. ELECTRICAL.................................................................................................................. 7
3.1.5. GENERAL PURPOSE OUTPUTS .................................................................................. 7
3.1.6. PHYSICAL....................................................................................................................... 8
4. 7707CATVR SPECIFICATIONS ......................................................................................................... 9
4.1.1. OPTICAL INPUT............................................................................................................. 9
4.1.2. CATVR OUTPUT ............................................................................................................ 9
4.1.3. ELECTRICAL.................................................................................................................. 9
4.1.4. GENERAL PURPOSE OUTPUTS .................................................................................. 9
4.1.5. PHYSICAL....................................................................................................................... 9
5. STATUS INDICATORS AND DISPLAYS ......................................................................................... 10
5.1.1. 7707CATVT (rev. 1) STATUS INDICATORS................................................................ 10
5.1.2. 7707CATVR (rev. 1) STATUS INDICATORS ............................................................... 10
5.1.3. 7707CATVT (rev. A) STATUS INDICATORS ............................................................... 11
5.1.4. 7707CATVR (rev. A) STATUS INDICATORS............................................................... 11
6. JUMPERS AND SETTINGS.............................................................................................................. 13
6.1. 7707CATVT / 7707CATVR (REVISION 1 BOARD) JUMPERS............................................... 13
6.2. 7707CATVT / 7707CATVR (REVISION A BOARD) JUMPERS.............................................. 15
6.2.1. SELECTING WHETHER LOCAL FAULTS WILL BE MONITORED
BY THE GLOBAL FRAME STATUS............................................................................. 16
6.2.2. SELECTING WHETHER MODULE WILL BE CONTROLLED FROM THE
LOCAL CONTROLS OR THROUGH THE VISTALINK
®
INTERFACE
(REVISION 1 Board ONLY) .......................................................................................... 17
6.2.3. CATVT (Rev. A board) GPOs ....................................................................................... 17
6.2.4. CATVT (Rev. 1 board) GPOs........................................................................................ 17
6.2.5. CATVR (Rev. A board) GPOs....................................................................................... 18

7700 MultiFrame Manual
7707CATV Cable TV Fiber Transmitter / Receiver
7707CATV -ii Revision 2.1
6.2.6. CATVR (Rev. 1 board) GPOs ....................................................................................... 18
6.2.7. CONFIGURING THE MODULE FOR FIRMWARE UPGRADES.................................. 18
7. DOT-MATRIX DISPLAY.................................................................................................................... 19
7.1. CARD EDGE MENU SYSTEM ................................................................................................. 19
7.1.1. NAVIGATING THE MENU SYSTEM............................................................................. 19
7.2. 7707CATVT MENU STRUCTURE (REV. 1 BOARD)............................................................... 20
7.2.1. User Menu / CTRL (Control) ......................................................................................... 20
7.2.2. User Menu / STAT (Status)........................................................................................... 21
7.3. 7707CATVT (REVISION 1 BOARD) USER MENU-CTRL....................................................... 21
7.3.1. 7707CATVT Setting the RF Threshold.......................................................................... 21
7.3.2. 7707CATVT Laser Output Level................................................................................... 21
7.3.3. 7707CATVT Input Channel Number ............................................................................. 21
7.3.4. 7707CATVT Display Setting.......................................................................................... 21
7.3.5. 7707CATVT Restoring Factory Defaults....................................................................... 22
7.4. 7707CATVT (REVISION 1 BOARD) USER MENU – STAT..................................................... 22
7.4.1. 7707CATVT RF Input Power......................................................................................... 22
7.4.2. 7707CATVT Optical Output Power ............................................................................... 22
7.4.3. 7707CATVT Number of CATV input channels.............................................................. 22
7.4.4. 7707CATVT Upper RF input threshold ......................................................................... 22
7.4.5. 7707CATVT Lower RF input threshold ......................................................................... 22
7.4.6. 7707CATVT Software Version...................................................................................... 22
7.5. 7707CATVT MENU STRUCTURE (REV. A BOARD).............................................................. 23
7.5.1. User Menu / CTRL (Control) ......................................................................................... 23
7.5.2. User Menu / STAT (Status)........................................................................................... 24
7.6. 7707CATVT (REVISION A BOARD) USER MENU - CTRL..................................................... 24
7.6.1. 7707CATVT Setting the RF Threshold.......................................................................... 24
7.6.2. 7707CATVT Input Channel Number ............................................................................. 24
7.6.3. 7707CATVT Display Setting.......................................................................................... 24
7.6.4. 7707CATVT Optical Power Setting............................................................................... 24
7.7. 7707CATVT (REVISION A BOARD) USER MENU – STAT.................................................... 25
7.7.1. 7707CATVT RF Input Power......................................................................................... 25
7.7.2. 7707CATVT Optical Output Power ............................................................................... 25
7.7.3. 7707CATVT RF input thresholds .................................................................................. 25
7.7.4. 7707CATVT Number of channels ................................................................................. 25
7.7.5. 7707CATVT Software Version...................................................................................... 25
7.8. 7707CATVR (REVISION 1 BOARD) MENU STRUCTURE ..................................................... 26
7.8.1. User Menu / CTRL (Control) ......................................................................................... 26
7.8.2. User Menu / STAT (Status)........................................................................................... 27
7.9. 7707CATVR (REVISION 1 BOARD) USER MENU-CTRL....................................................... 27
7.9.1. 7707CATVR Setting the Upper Optical Threshold........................................................ 27
7.9.2. 7707CATVR RF Power Monitoring ON/OFF................................................................. 27
7.9.3. 7707CATVR RF Upper Threshold Level....................................................................... 27

7700 MultiFrame Manual
7707CATV Cable TV Fiber Transmitter / Receiver
Revision 2.1 7707CATV -iii
7.9.4. 7707CATVR RF Lower Threshold Level....................................................................... 27
7.9.5. 7707CATVR Display Setting......................................................................................... 28
7.9.6. 7707CATVR Gain Setting ............................................................................................. 28
7.9.7. 7707CATVR Restoring Factory Defaults....................................................................... 28
7.10. 7707CATVR (REVISION 1 BOARD) USER MENU – STAT.................................................... 28
7.10.1. 7707CATVR RF Output Power ..................................................................................... 28
7.10.2. 7707CATVR Optical Received Power........................................................................... 28
7.10.3. 7707CATVR RF Power Monitoring ............................................................................... 28
7.10.4. 7707CATVR Software Version...................................................................................... 28
7.10.5. 7707CATVR RF Upper Threshold Level....................................................................... 29
7.10.6. 7707CATVR RF Lower Threshold Level....................................................................... 29
7.10.7. 7707CATVR Setting the Upper Optical Threshold........................................................ 29
7.10.8. 7707CATVR Setting the Lower Optical Threshold........................................................ 29
7.11. 7707CATVR (REVISION A BOARD) MENU STRUCTURE..................................................... 30
7.11.1. User Menu / CTRL (Control) ......................................................................................... 30
7.11.2. User Menu / STAT (Status)........................................................................................... 31
7.12. 7707CATVR (REVISION A BOARD) USER MENU-CTRL ...................................................... 31
7.12.1. 7707CATVR Setting the Optical Input Threshold.......................................................... 31
7.12.2. 7707CATVR Setting the RF output thresholds.............................................................. 31
7.12.3. 7707CATVR Input Channel Number............................................................................. 31
7.12.4. 7707CATVR Gain Setting ............................................................................................. 32
7.12.5. 7707CATVR Display Setting......................................................................................... 32
7.13. 7707CATVR (REVISION A BOARD) USER MENU – STAT.................................................... 32
7.13.1. 7707CATVR RF Output Power ..................................................................................... 32
7.13.2. 7707CATVR Optical Received Power........................................................................... 32
7.13.3. 7707CATVR Monitoring RF output thresholds.............................................................. 32
7.13.4. 7707CATVR Monitoring the Gain Setting...................................................................... 33
7.13.5. 7707CATVR Monitoring the Optical Input Threshold.................................................... 33
7.13.6. 7707CATVR Software Version...................................................................................... 33
8. VISTALINK
®
REMOTE MONITORING/CONTROL........................................................................... 34
8.1. WHAT IS VISTALINK
®
?............................................................................................................. 34
8.1.1. 7707CATVT VISTALINK
®
MONITORED PARAMETERS .............................................. 34
8.1.2. 7707CATVT VISTALINK
®
CONTROLLED PARAMETERS............................................ 35
8.1.3. 7707CATVR VISTALINK
®
MONITORED PARAMETERS.............................................. 35
8.1.4. 7707CATVR VISTALINK
®
CONTROLLED PARAMETERS ........................................... 36
8.1.5. 7707CATVT VISTALINK
®
Traps..................................................................................... 36
8.1.6. 7707CATVR VISTALINK
®
Traps .................................................................................... 37

7700 MultiFrame Manual
7707CATV Cable TV Fiber Transmitter / Receiver
7707CATV -iv Revision 2.1
Figures
Figure 1-1: 7707CATVT Block Diagram................................................................................................................2
Figure 1-2: 7707CATVR Block Diagram...............................................................................................................2
Figure 2-1: 7707CATVT Rear Panel.....................................................................................................................3
Figure 2-2: CATVR Rear Panel.............................................................................................................................4
Figure 2-3: GPO Configuration .............................................................................................................................5
Figure 6-1: Location of 7707CATVT (Rev. 1) Jumpers and LEDs......................................................................13
Figure 6-2: Location of 7707CATVR (Rev. 1) Jumpers and LEDs.....................................................................14
Figure 6-3: Location of Jumpers and LEDs on CATVT (Rev. A) Card Edge......................................................15
Figure 6-4: Location of 7707CATVR (Rev. A) Jumpers and LEDs.....................................................................16
Figure 7-1: 7707CATVT (Revision 1 Board) Card Edge Menu Flow Chart........................................................20
Figure 7-2: 7707CATVT (Revision A Board) Card Edge Menu Flow Chart........................................................23
Figure 7-3: 7707CATVR (Revision 1 Board) Card Edge Menu Flow Chart........................................................26
Figure 7-4: 7707CATVR (Revision A Board) Card Edge Menu Flow Chart .......................................................30
Tables
Table 8-1: 7707CATVT VistaLINK
®
Monitored Parameters................................................................................34
Table 8-2: 7707CATVT VistaLINK
®
Controlled Parameters...............................................................................35
Table 8-3: 7707CATVR VistaLINK
®
Monitored Parameters...............................................................................35
Table 8-4: 7707CATVR VistaLINK
®
Controlled Parameters...............................................................................36
Table 8-5: 7707CATVT VistaLINK
®
Traps..........................................................................................................36
Table 8-6: 7707CATVR VistaLINK
®
Traps..........................................................................................................37

7700 MultiFrame Manual
7707CATV Cable TV Fiber Transmitter / Receiver
Revision 2.1 7707CATV -v
REVISION DESCRIPTION DATE
1.0 First Release January 2005
2.0 Updated Menu System, VistaLINK
®
information for Revision 1 boards May 2005
2.1 Updated VistaLINK
®
description and fixed format Nov 08
Information contained in this manual is believed to be accurate and reliable. However, Evertz assumes no responsibility for the use thereof nor for
the rights of third parties, which may be affected in any way by the use thereof. Any representations in this document concerning performance of
Evertz products are for informational use only and are not warranties of future performance, either expressed or implied. The only warranty offered
by Evertz in relation to this product is the Evertz standard limited warranty, stated in the sales contract or order confirmation form.
Although every attempt has been made to accurately describe the features, installation and operation of this product in this manual, no warranty is
granted nor liability assumed in relation to any errors or omissions unless specifically undertaken in the Evertz sales contract or order confirmation.
Information contained in this manual is periodically updated and changes will be incorporated into subsequent editions. If you encounter an error,
please notify Evertz Customer Service department. Evertz reserves the right, without notice or liability, to make changes in equipment design or
specifications.

7700 MultiFrame Manual
7707CATV Cable TV Fiber Transmitter / Receiver
7707CATV -vi Revision 2.1
DANGER
!
INVISIBLE RADIATION IS EMITTED FROM THE END OF THE FIBER OR
CONNECTOR. AVOID DIRECT EXPOSURE TO THE BEAM. DO NOT VIEW WITH
OPTICAL INSTRUMENTS.
WARNING
!
DO NOT CONNECT THE 7707CATVT/CATVR CARDS DIRECTLY WITH A SHORT
FIBER OPTIC CABLE. THE 7707CATVT-110-11 CARD PRODUCES +11dBm OF
OPTICAL POWER WHICH WILL DAMAGE THE RECEIVER IF CONNECTED
DIRECTLY. DO NOT EXCEED +7dBm OPTICAL POWER INTO THE RECEIVER.

7700 MultiFrame Manual
7707CATV Cable TV Fiber Transmitter / Receiver
Revision 2.1 7707CATV -1
1. OVERVIEW
The 7707CATVT and 7707CATVR CATV Transmitter/Receiver modules are used for transmission of
wide band CATV signals over fiber optic cable. The 7707CATVT accepts one wide band RF coaxial
input and provides a fiber optic output signal. A F-Type (BNC optional) RF output is also available for
monitoring or further signal distribution. The 7707CATVR accepts a fiber optic input from the
7707CATVT and provides two output signals via F-Type (BNC optional) connectors. Monitoring and
control of card status and parameters is provided locally via card edge and remotely via VistaLINK
®
capability.
The 7707CATVT and 7707CATVR modules each occupy one card slot and can be housed in either a
1RU frame, which will hold up to three modules, or a 3RU frame which will hold up to 15 modules.
Features:
•80/110 Channel PAL/NTSC CATV fiber optic transmitter
•40-860 MHz operational bandwidth
•Supports single mode fiber
•Low CSO and CTB intermod products
•Fully hot swappable from front of frame
•Provides up to 35km extension of CATV systems
•Comprehensive signal and card status monitoring via four digit card-edge display or remotely
through SNMP and VistaLINK
®
capability
7707CATVT Features
•Two optical output power versions available at 1310nm wavelength, +11dBm and +8dBm
•RF input power monitoring and alarm thresholds
•Two setting adjustable optical output power level
7707CATVR Features
•Two RF outputs for extra signal distribution or monitoring functions
•Adjustable gain setting from –3 to +3 dB
•Optical power monitoring and alarm thresholds
•RF output power monitoring and alarm thresholds

7700 MultiFrame Manual
7707CATV Cable TV Fiber Transmitter / Receiver
7707CATV -2 Revision 2.1
Optical
Receiver
CPU
Vista LINK
®
Interface
Local
Control
Local
Indication
Splitter
CATV
Output
Fiber
Input CATV
Output
Splitter
RF
AMP
RF Detector
Figure 1-1: 7707CATVT Block Diagram
Optical
Receiver
CPU
Vista LINK
®
Interface
Local
Control
Local
Indication
Splitter
CATV
Output
Fiber
Input CATV
Output
Splitter
RF
AMP
RF Detector
Figure 1-2: 7707CATVR Block Diagram

7700 MultiFrame Manual
7707CATV Cable TV Fiber Transmitter / Receiver
Revision 2.1 7707CATV -3
2. INSTALLATION
Each of the modules in the 7707CATV series comes standard with a companion +3RU rear plate. The
rear plate must be specified during the time of order. SC/APC or FC/APC optical connectors are
available for these modules and must be specified during the time of order. For information on mounting
the rear plate and inserting the module into the frame, see the 7700FR manual for detailed instructions.
Figure 2-1: 7707CATVT Rear Panel

7700 MultiFrame Manual
7707CATV Cable TV Fiber Transmitter / Receiver
7707CATV -4 Revision 2.1
Figure 2-2: CATVR Rear Panel
2.1. 7707CATVT CONNECTIONS
CATV IN: Input F-Type (BNC optional) connector for CATV signals.
CATV OUT: Output F-Type (BNC optional) is a CATV wide band RF output for monitoring or
further signal distribution of your CATV signals.
FIBER OUTPUT: There is one SC/APC (shown) or FC/APC female connector that is the optical
output from the 7707CATVT. This connector should be coupled to the FIBER IN
connector of a 7707CATVR module at the destination end with a suitable fiber
optic cable. The 7707CATVT transmits at 1310nm wavelength.
2.2. 7707CATVR CONNECTIONS
FIBER INPUT: There is one SC/APC (shown) or FC/APC female connector that is the optical
input to the 7707CATVR as shown in section. This connector should be coupled
to the FIBER OUT connector of a 7707CATVT module at the destination end with
a suitable fiber optic cable. The 7707CATVT transmits at 1310nm wavelength.

7700 MultiFrame Manual
7707CATV Cable TV Fiber Transmitter / Receiver
Revision 2.1 7707CATV -5
CATV OUT: Two F-Type (BNC optional) CATV wide band RF outputs for monitoring and
further signal distribution of the CATV signals.
2.3. GPO CIRCUIT
GPO: The NC, NO and COM pins on the 6 pin terminal strip are used for the General Purpose
Output (GPO). The GPO output is a set of normally open and normally closed relay contacts
as shown in Figure 2-3.
NO GPO Contact
GPO Common
from
internal
circuit
NC GPO Contact
Figure 2-3: GPO Configuration
2.4. CARE AND HANDLING OF OPTICAL FIBER
2.4.1. Safety
!
DANGER:
Never look directly into an optical fiber. Non-reversible damage to the eye can
occur in a matter of milliseconds.
Invisible radiation is emitted from the end of the fiber or connector. Avoid direct
exposure to the beam. Do not view with optical instruments.
Use of controls, adjustments and procedures other than those specified herein
may result in hazardous laser radiation exposure.
The laser modules used in the Evertz 7707CATVT fiber optic modules are Class I (7707CATVT-110-6)
and Class IIIB (7707CATVT-110-11).
2.4.2. Handling and Connecting Fibers
"
Never touch the end face of an optical fiber. Always keep dust caps on optical
fiber connectors when not connected and always remember to properly clean the
optical end facet of a connector before making a connection.

7700 MultiFrame Manual
7707CATV Cable TV Fiber Transmitter / Receiver
7707CATV -6 Revision 2.1
The transmission characteristics of the fiber are dependent on the shape of the optical core and
therefore care must be taken to prevent fiber damage due to heavy objects or abrupt fiber bending.
Evertz recommends that the user maintains a minimum bending radius of 5 cm to avoid fiber-bending
loss that will decrease the maximum attainable distance of the fiber cable. The Evertz fiber optic
modules come with cable lockout devices, to prevent the user from damaging the fiber by installing a
module into a slot in the frame that does not have a suitable I/O module.
"
Never connect a PC optical connector to an APC optical connector. APC stands for
Angle Polish Contact and means the end face has been angled to reduce optical
back reflection. A PC connector has a flat end face. APC connectors have GREEN
plastic connector housings whereas the PC type has BLUE housings. Never mate
a GREEN connector to a BLUE connector. Due to the angle polish, both
connectors can be physically damaged and will need to be replaced.

7700 MultiFrame Manual
7707CATV Cable TV Fiber Transmitter / Receiver
Revision 2.1 7707CATV -7
3. 7707CATVT SPECIFICATIONS
3.1.1. RF INPUT
Connector: 1 F type, ( BNC optional )
I/O Impedance: 75 Ω(50 Ωoptional)
Return Loss: > 18dB
Input Frequency Range: 50MHz – 850MHz
Maximum Input Power: +45dBmV / channel ( +40dBmV / channel typical )
3.1.2. RF OUTPUT
Connector: 1 F type, ( BNC optional )
I/O Impedance: 75 Ω(50 Ωoptional)
Signal Level: Input level – 25dB
Return Loss: > 15dB
Output Frequency Range: 50MHz – 850MHz
Flatness: ±1dB* @ 50MHz – 850MHz
Composite Second Order: >65dB*
Composite Triple Beat: > 67dB*
Carrier to Noise: > 50dB*
•Measured with input level: +40dBmV / channel, fully loaded spectrum
3.1.3. OPTICAL OUTPUT
Number of outputs: 1
Connector: Female SC/APC, FC/APC
Operating Wavelength: 1310nm
Optical Power: +11dBm ± 1dBm ( 7707CATVT13-110-11 )
+8dBm ± 1dBm ( 7707CATVT13-110-8 )
Fiber Size: 9 µm core / 125 µm overall
3.1.4. ELECTRICAL
Voltage: +12VDC
Power: 12 Watts
EMI/RFI: Complies with FCC regulations for class A devices
Complies with EU EMC directive.
3.1.5. GENERAL PURPOSE OUTPUTS
Number of Outputs: 3 (Revision A board), 2 (Revision 1 board, GPOs 1 and 3 only)
Type: “Dry Contact” relay contacts - normally open and normally closed contact
provided
Connector: 6 pins on 6 pin terminal strip

7700 MultiFrame Manual
7707CATV Cable TV Fiber Transmitter / Receiver
7707CATV -8 Revision 2.1
Please refer to section 6 for GPO function.
3.1.6. PHYSICAL
7700 or 7701 frame mounting:
Number of slots: 1

7700 MultiFrame Manual
7707CATV Cable TV Fiber Transmitter / Receiver
Revision 2.1 7707CATV -9
4. 7707CATVR SPECIFICATIONS
4.1.1. OPTICAL INPUT
Number of outputs: 1
Connector: Female SC/APC, FC/APC
Operating Wavelength: 1310nm
Maximum Optical Power: +6dBm
Fiber Size: 9µm core / 125 µm overall
4.1.2. CATVR OUTPUT
Number of outputs: 2
Connector: F-Type (BNC optional)
I/O Impedance: 75 Ω
Return Loss: > 17dB
Flatness: ±1dB* @ 50MHz – 850MHz
Composite Second Order: >65dB*
Composite Triple Beat: > 67dB*
Carrier to Noise: > 50dB*
* Measured with input to CATVT at +40dBmV / channel, fully loaded spectrum with 0dBm optical input
power into CATVR and 0dB gain setting on the CATVR. In this
configuration, the RF peak level / channel is 11dB down from the input.
4.1.3. ELECTRICAL
Voltage: +12VDC
Power: 12 Watts
EMI/RFI: Complies with FCC regulations for class A devices
Complies with EU EMC directive.
4.1.4. GENERAL PURPOSE OUTPUTS
Number of Outputs: 3
Type: “Dry Contact” relay contacts - normally open and normally closed contact
provided
Connector: 6 pins on 6 pin terminal strip
Please refer to section 6 for GPO function.
4.1.5. PHYSICAL
7700 or 7701 frame mounting:
Number of slots: 1

7700 MultiFrame Manual
7707CATV Cable TV Fiber Transmitter / Receiver
7707CATV -10 Revision 2.1
5. STATUS INDICATORS AND DISPLAYS
5.1.1. 7707CATVT (rev. 1) STATUS INDICATORS
The 7707CATVT module has 6 LED Status indicators on the front card edge to show operational status
of the card at a glance.
Two large LEDs on the front of the board indicate the general health of the module
LOCAL FAULT: This Red LED indicates poor module health and will be illuminated if a board
power fault exists (i.e. a blown fuse) or if the laser is nearing the end of the life
cycle. The LOCAL FAULT indication can also be reported to the frame through
the FRAME STATUS jumper.
MODULE OK: This Green LED indicates good module health. It will be On when the board
power is good and has a valid CATV RF input signal.
There are 4 small LEDs that indicate the status of the incoming RF signal, laser status.
LASER OK: This green LED (LED D24) will be On when the output laser is operating at the
maximum output power, +8dBm (Selectable in CTRL/OPWR).
RF LOW: This green LED (LED D13) will be On when the input RF signal is below the lower
RF threshold range.
RF HIGH: This red LED (LED10) will be On when the input RF signal is higher than the
upper threshold RF signal range.
RF OK: This green LED (LED D1) will be On when the RF signal is above the lower RF
threshold and below the upper RF threshold.
5.1.2. 7707CATVR (rev. 1) STATUS INDICATORS
The 7707CATVR module has 4 LED Status indicators on the front card edge to show operational status
of the card at a glance.
Two large LEDs on the front of the board indicate the general health of the module.
LOCAL FAULT: This Red LED indicates poor module health and will be On during the absence of
a valid optical input signal, or if a local power fault exists (i.e. a blown fuse). The
LOCAL FAULT indication can also be reported to the frame through the FRAME
STATUS jumper.
MODULE OK: This Green LED indicates good module health. It will be On when a valid optical
input signal is present, and the board power is good.
There are 2 small LEDs that indicate the status of the incoming optical signal.
RF HIGH: This red LED (D14) will be On when the input RF signal is above the upper
threshold level.

7700 MultiFrame Manual
7707CATV Cable TV Fiber Transmitter / Receiver
Revision 2.1 7707CATV -11
RF OK: This green LED (D16) will be On when the RF input signal is within the lower and
upper threshold level.
5.1.3. 7707CATVT (rev. A) STATUS INDICATORS
The 7707CATVT module has 6 LED Status indicators on the front card edge to show operational status
of the card at a glance.
Two large LEDs on the front of the board indicate the general health of the module.
LOCAL FAULT: This Red LED indicates poor module health and will be illuminated if a board
power fault exists (i.e. a blown fuse) or if the laser is nearing the end of the life
cycle or if the RF input level is outside the threshold levels. The LOCAL FAULT
indication can also be reported to the frame through the FRAME STATUS jumper.
MODULE OK: This Green LED indicates good module health. It will be On when the board
power is good and has a valid CATV RF input signal.
There are 4 small LEDs that indicate the status of the incoming RF signal, laser status.
LASER OUTPUT POWER: This green LED (D24) will be On when the output laser is set to the
highest output level, +11dBm for –11 version and +8dBm for –8 version.
RF HIGH: This red LED (D13) will be On when the input RF signal is above the upper
threshold level.
RF LOW: This yellow LED (D10) will be On when the input RF signal is below the lower
threshold level.
RF OK: This green LED (D1) will be On when the RF input signal is within the lower and
upper threshold level.
5.1.4. 7707CATVR (rev. A) STATUS INDICATORS
The 7707CATVR module has 6 LED Status indicators on the front card edge to show operational status
of the card at a glance.
Two large LEDs on the front of the board indicate the general health of the module
LOCAL FAULT: This Red LED indicates poor module health and will be On during the absence of
a valid optical input signal, or if a local power fault exists (i.e.: a blown fuse) or the
optical level is outside the threshold levels. The LOCAL FAULT indication can
also be reported to the frame through the FRAME STATUS jumper.
MODULE OK: This Green LED indicates good module health. It will be On when a valid optical
input signal is present, and the board power is good.

7700 MultiFrame Manual
7707CATV Cable TV Fiber Transmitter / Receiver
7707CATV -12 Revision 2.1
There are 4 small LEDs that indicate the status of the incoming optical signal.
OPTICAL INPUT OK: This green LED (D25) will be On when the input optical power is within the
lower and upper threshold levels.
RF HIGH: This red LED (D14) will be On when the output RF power is above upper
threshold level.
RF LOW: This yellow LED (D15) will be On when the output RF power is below the
lower threshold level.
RF OK: This green LED (D16) will be On when the output RF power is within the
lower and upper threshold levels.

7700 MultiFrame Manual
7707CATV Cable TV Fiber Transmitter / Receiver
Revision 2.1 7707CATV -13
6. JUMPERS AND SETTINGS
6.1. 7707CATVT / 7707CATVR (REVISION 1 BOARD) JUMPERS
/ MODULE OK
LOCAL FAULT
MASTER/SLAVE
COM
RUN/UPGRADE
FRAME STATUS
FACTORY
LASER OK
RF LOW
RF HIGH
RF OK
DOT MATRIX DISPLAY
Figure 6-1: Location of 7707CATVT (Rev. 1) Jumpers and LEDs

7700 MultiFrame Manual
7707CATV Cable TV Fiber Transmitter / Receiver
7707CATV -14 Revision 2.1
/ MODULE OK
LOCAL FAULT
LOCAL/REMOTE
COM
RUN/UPGRADE
FRAME STATUS
FACTORY
RF HIGH
DOT MATRIX DISPLAY
RF OK
Figure 6-2: Location of 7707CATVR (Rev. 1) Jumpers and LEDs
