evertz 7707VT13-4-HS User manual

7700 MultiFrame Manual
7707VT-4-HS Quad SD/Dual HD-SDI Fiber Transmitter
Revision 1.4
TABLE OF CONTENTS
1. OVERVIEW.......................................................................................................................................... 1
2. INSTALLATION................................................................................................................................... 3
2.1. CARE AND HANDLING OF OPTICAL FIBER........................................................................... 5
2.1.1. Safety.............................................................................................................................. 5
2.1.2. Assembly......................................................................................................................... 5
2.1.3. Labeling........................................................................................................................... 5
2.1.4. Handling and Connecting Fibers..................................................................................... 6
3. SPECIFICATIONS............................................................................................................................... 7
3.1. SERIAL VIDEO INPUT............................................................................................................... 7
3.2. SERIAL VIDEO OUTPUT........................................................................................................... 7
3.3. OPTICAL OUTPUT..................................................................................................................... 7
3.4. SYSTEM PERFORMANCE........................................................................................................ 7
3.5. ELECTRICAL ............................................................................................................................. 8
3.6. COMPLIANCE............................................................................................................................ 8
3.7. PHYSICAL.................................................................................................................................. 8
4. STATUS INDICATORS AND DISPLAYS ........................................................................................... 9
4.1. STATUS INDICATOR LEDS......................................................................................................9
4.2. DOT-MATRIX DISPLAY / CARD STATUS AND CONTROLS ................................................ 10
4.2.1. Display of Warning Status Indications........................................................................... 12
4.2.2. Displaying the Video Standard...................................................................................... 12
4.2.3. Displaying the Equalization Strength ............................................................................ 12
4.2.4. Displaying the Input Mode............................................................................................. 13
4.2.5. Displaying the Firmware Version................................................................................... 13
4.2.6. Setting the Input Mode.................................................................................................. 13
4.2.7. Setting Video Error Detection........................................................................................ 14
4.2.8. Controlling Loopback Connector Output....................................................................... 15
4.2.9. Controlling the Behavior of the Laser............................................................................ 15
4.2.10. Setting the Orientation of the Text on the Card Edge Display....................................... 15
4.2.11. Resetting Factory Defaults............................................................................................ 16
5. JUMPERS AND LOCAL CONTROLS .............................................................................................. 17
5.1. SELECTING WHETHER LOCAL FAULTS WILL BE MONITORED
BY THE GLOBAL FRAME STATUS........................................................................................ 17

7700 MultiFrame Manual
7707VT-4-HS Quad SD/Dual HD-SDI Fiber Transmitter
Revision 1.4
5.2. CONFIGURING THE MODULE FOR FIRMWARE UPGRADES ............................................. 17
6. VISTALINK®REMOTE MONITORING/CONTROL........................................................................... 18
6.1. WHAT IS VISTA LINK®?........................................................................................................... 18
6.2. VISTA LINK®MONITORED PARAMETERS ............................................................................ 18
6.3. VISTA LINK®CONTROLLED PARAMETERS ......................................................................... 19
6.4. VISTA LINK®TRAPS................................................................................................................. 19
Figures
Figure 1-1: 7707VT-4-HS Block Diagram .............................................................................................................2
Figure 2-1: 7707VT-4-HS Rear Panel...................................................................................................................3
Figure 2-2: Reproduction of Laser Certification and Identification Label..............................................................5
Figure 4-1: Location of Status Indicators, Jumpers and Controls.........................................................................9
Figure 4-2: Card Edge Menu Structure...............................................................................................................11
Tables
Table 2-1: Input Signal Combinations...................................................................................................................4
Table 4-1: Input Modes and Signal Connections................................................................................................13
Table 4-2: Input Modes and Signal Connections................................................................................................14
Table 6-1: VistaLINK®Monitored Parameters.....................................................................................................18
Table 6-2: VistaLINK®Controlled Parameters....................................................................................................19
Table 6-3: VistaLINK®Traps...............................................................................................................................19

7700 MultiFrame Manual
7707VT-4-HS Quad SD/Dual HD-SDI Fiber Transmitter
Revision 1.4
REVISION HISTORY
REVISION DESCRIPTION DATE
1.0 First Release Feb 2006
1.1 Made updates to parameters in section 1. Fixed typos. Sept 2007
1.2 Updated specs and card edge control menu structure Oct 2008
1.3 Added delay specification to section 3. Oct 2009
1.4 Updated Output Power specifications. Aug 2010
Information contained in this manual is believed to be accurate and reliable. However, Evertz assumes no responsibility for the use thereof nor for
the rights of third parties, which may be affected in any way by the use thereof. Any representations in this document concerning performance of
Evertz products are for informational use only and are not warranties of future performance, either expressed or implied. The only warranty offered
by Evertz in relation to this product is the Evertz standard limited warranty, stated in the sales contract or order confirmation form.
Although every attempt has been made to accurately describe the features, installation and operation of this product in this manual, no warranty is
granted nor liability assumed in relation to any errors or omissions unless specifically undertaken in the Evertz sales contract or order confirmation.
Information contained in this manual is periodically updated and changes will be incorporated into subsequent editions. If you encounter an error,
please notify Evertz Customer Service department. Evertz reserves the right, without notice or liability, to make changes in equipment design or
specifications.

7700 MultiFrame Manual
7707VT-4-HS Quad SD/Dual HD-SDI Fiber Transmitter
Revision 1.4
WARNING
Never look directly into an optical fiber. Non-reversible damage to the eye can
occur in a matter of milliseconds.
"
Do not hook up the 7707VT-4-HS DWDM cards and any 7707VR-4-HS series
cards directly with a short fiber optic cable. The 7707VT-4-HS DWDM card
produces +7dBm of power, which will damage the receiver if connected directly.
"
Do not hook up the 7707VT-4-HS cards that output more than -7dBm of power
(see 7707VT-4-HS specifications for output power of various laser types) and
7707VR-4-HS-H high sensitivity receiver cards directly with a short fiber optic
cable. The 7707VT-4-HS cards that produce more than -7dBm of power will
damage the receiver if connected directly.

7700 MultiFrame Manual
7707VT-4-HS Quad SD/Dual HD-SDI Fiber Transmitter
Revision 1.4 Page - 1
1. OVERVIEW
The 7707VT-4-HS is a VistaLINK®enabled fiber transmitter for two HD-SDI signals; or one HD-SDI signal
and three SDI/SDTi signals; or four SDI/SDTi signals. This single card combines the input signals using
Time Domain Multiplexing (TDM) technology and transmits them over a single fiber. The companion
7707VR-4-HS Quad SDI/Dual HD-SDI Receiver demultiplexes the signals and converts them back to
separate SDI/SDTi and/or HD-SDI video feeds
The 7707VT-4-HS and companion 7707VR-4-HS will transparently pass incoming HD-SDI or SDI video
feeds with embedded AES audio or any other data in the horizontal or vertical ancillary data space.
Monitoring and control of card status and parameters is provided locally at the card edge or remotely via
VistaLINK®.
The 7707VT-4-HS is available in different versions to meet a variety of applications.
7707VT13-4-HS 1310 nm FP Suitable for distances up to 50 Km
7707VT15-4-HS 1550 nm DFB Suitable for distances up to 75 Km
There are several versions with built in isolators specifically suited to coarse wave division multiplexing
(CWDM) applications. The CWDM versions are suitable for distances up to 75 Km.
7707VT27-4-HS 1270 nm DFB
7707VT29-4-HS 1290 nm DFB
7707VT31-4-HS 1310 nm DFB
7707VT33-4-HS 1330 nm DFB
7707VT35-4-HS 1350 nm DFB
7707VT37-4-HS 1370 nm DFB
7707VT43-4-HS 1430 nm DFB
7707VT45-4-HS 1450 nm DFB
7707VT47-4-HS 1470 nm DFB
7707VT49-4-HS 1490 nm DFB
7707VT51-4-HS 1510 nm DFB
7707VT53-4-HS 1530 nm DFB
7707VT55-4-HS 1550 nm DFB
7707VT57-4-HS 1570 nm DFB
7707VT59-4-HS 1590 nm DFB
7707VT61-4-HS 1610 nm DFB
There are several versions with built in isolators specifically suited to Dense Wave Division Multiplexing
(DWDM) applications. The DWDM versions are suitable for distances more than 75 Km. For DWDM
applications, please contact the factory.
7707VTDyyy-4-HS DWDM DFB laser output, yyy – ITU channel number

7700 MultiFrame Manual
7707VT-4-HS Quad SD/Dual HD-SDI Fiber Transmitter
Page - 2Revision 1.4
Features:
•Single card multiplexor allowing the flexibility of various combinations of HD-SDI and SDI/SDTi
signals:
oTwo HD-SDI signals or;
oOne HD-SDI signal and three SDI/SDTi signals or;
oFour SDI/SDTi signals
•Two auto-sensing inputs for HD-SDI or SDI/SDTi signals
•Two inputs for SDI/SDTi signals
•One SDI/SDTi or HD-SDI loopback output, user selectable from the four video inputs
•Signal transport is uninterrupted by the loss of any HD-SDI or SDI/SDTi input feed
•Transparently passes embedded AES or any other data in the horizontal or vertical ancillary data
space
•Comprehensive signal and card status monitoring via four-digit card-edge display
•VistaLINK®–enabled for remote monitoring and control when installed in a 7700FR-C frame with
7700FC VistaLINK®Frame Controller
•Automatic coaxial equalization up to 100m at 1.485Gb/s and 250m at 270Mb/s (Belden 1694A or
equivalent cable)
•Fully hot swappable from front of frame with no fiber/coax disconnect/reconnect required
•Supports single-mode and multi-mode fiber optic cable
•Optical output wavelengths of 1310nm, 1550nm and up to 16 CWDM wavelengths
•DWDM wavelengths also available
•SC/PC, ST/PC, FC/PC fiber connectors available
HD/SDI VIDEO
INPUT
HD/SDI VIDEO
INPUT FIBER
OUTPUT
OPTICAL
TRANSMITTER
TDM
MUX
CONTROL/
INDICATION
VistaLINK
®
Interface
LOCAL
CONTROL
LOCAL
INDICATION
SDI VIDEO
INPUT
SDI VIDEO
INPUT
INPUT
STAGE
INPUT
STAGE
INPUT
STAGE
INPUT
STAGE
1
4
3
2
HD/SDI
OUTPUT
INPUT
SELECTOR
Figure 1-1: 7707VT-4-HS Block Diagram

7700 MultiFrame Manual
7707VT-4-HS Quad SD/Dual HD-SDI Fiber Transmitter
Revision 1.4 Page - 3
2. INSTALLATION
The 7707VT-4-HS comes with a companion rear plate that has five BNC connectors and one SC/PC
(shown), ST/PC or FC/PC optical connector. For information on mounting the rear plate and inserting the
module into the frame see section 3 of the 7700FR chapter.
7707VT-4-HS
FIBER
OUTPUT
HD/SDI INPUTSSDI INPUTS
1
2
3
4
HD/SDI OUT
Figure 2-1: 7707VT-4-HS Rear Panel
HD/SDI INPUTS: Two independent BNC input connectors for HD-SDI or SDI/SDTi video signals
compatible with HD-SDI (SMPTE 292M), SD-SDI (SMPTE 259M-C) or SDTi (SMPTE 305.2M)
standards (auto sensing). These inputs provide adaptive compensation for up to 100m of
industry standard Belden 1694A cable at 1.485Gb/s or 250m of 1694A cable at 270Mb/s.
SDI INPUTS: Two independent BNC input connectors for SDI/SDTi video signals compatible with SD-SDI
(SMPTE 259M-C) or SDTi (SMPTE 305.2M) standards. These inputs provide adaptive
compensation for up to 250m of industry standard Belden 1694A cable at 270Mb/s.

7700 MultiFrame Manual
7707VT-4-HS Quad SD/Dual HD-SDI Fiber Transmitter
Page - 4Revision 1.4
The following signal combinations may be installed on the input connectors:
Connector Input
Combination #1 Input Combination #2 Input Combination #3 Input Combination #4
1 HD-SDI HD-SDI SDI/SDTi SDI/SDTi
2 HD-SDI SDI/SDTi HD-SDI SDI/SDTi
3 N/A SDI/SDTi SDI/SDTi SDI/SDTi
4 N/A SDI/SDTi SDI/SDTi SDI/SDTi
Table 2-1: Input Signal Combinations
HD/SDI OUTPUT: There is one BNC output which acts as a loopback for the input signals. The signal
present at the output is user selectable among the four input signals via local or VistaLINK®
controls. Reclocking is provided at this output.
OPTICAL OUTPUT: Output SC/PC (Shown), ST/PC or FC/PC female connector. The optical output
signal at this connector contains the TDM multiplexed input HD-SDI and/or SDI/SDTi video
signals. Any ancillary data (e.g. embedded audio, closed captioning, etc) present in the input
video streams prior to multiplexing are transparently passed through to this output.
This optical output is available in 1310nm, 1550nm, up to sixteen CWDM wavelengths
(ITU-T G.694.2 compliant) and up to 40 DWDM wavelengths (ITU-T G.694.1 compliant). The
output wavelength is marked on the rear panel of each module. When connected directly to a
companion module, the output is compatible with multi-mode fiber optic cable. If not connected
directly (i.e. connected through CWDM, DWDM, WDM or a splitter/combiner) the output is
compatible only with single-mode fiber optic cable.
"
Do not hook up 7707VT-4-HS DWDM cards and any 7707VR-4-HS series cards
directly with a short fiber optic cable. The 7707VT-4-HS DWDM card produces
+7dBm of power, which will damage the receiver if connected directly.
"
Do not hook up the 7707VT-4-HS cards that output more than -7dBm of power
(see 7707VT-4-HS specifications for output power of various laser types) and
7707VR-4-HS-H high sensitivity receiver cards directly with a short fiber optic
cable. The 7707VT-4-HS cards that produce more than -7dBm of power will
damage the receiver if connected directly.

7700 MultiFrame Manual
7707VT-4-HS Quad SD/Dual HD-SDI Fiber Transmitter
Revision 1.4 Page - 5
2.1. CARE AND HANDLING OF OPTICAL FIBER
2.1.1. Safety
CLASS 1 LASER PRODUCT
2.1.2. Assembly
Assembly or repair of the laser sub-module is done only at Evertz facility and performed only by qualified
Evertz technical personnel.
2.1.3. Labeling
Certification and Identification labels are combined into one label. As there is not enough room on the
product to place the label, it is reproduced here in the manuals.
•There is no date of manufacture on this label as it can be traced by the bar code label placed on
the printed circuit board of each Evertz plug-in module
•The Model number is one of: 7707VT13-4-HS, 7707VT15-4-HS
7707VTxx-4-HS, (xx = 27, 29, 31, 33, 35, 37, 43, 45, 47, 49, 51, 53, 55, 57, 59, 61)
7707VTDyyy-4-HS (Dyyy represents ITU Grid Channel: D200, D210, D220, D230, D240, D250,
D260, D270, D280, D290, D300, D310, D320, D330, D340, D350, D360, D370, D380, D390,
D400, D410, D420, D430, D440, D450, D460, D470, D480, D490, D500, D510, D520, D530,
D540, D550, D570, D580, D590, D600)
Figure 2-2: Reproduction of Laser Certification and Identification Label

7700 MultiFrame Manual
7707VT-4-HS Quad SD/Dual HD-SDI Fiber Transmitter
Page - 6Revision 1.4
2.1.4. Handling and Connecting Fibers
"
Never touch the end face of an optical fiber. Always keep dust caps on optical fiber
connectors when not connected and always remember to properly clean the optical
end face of a connector before making a connection.
The transmission characteristics of the fiber are dependent on the shape of the optical core and therefore
care must be taken to prevent fiber damage due to heavy objects or abrupt fiber bending. Evertz
recommends that you maintain a minimum bending radius of 5 cm to avoid fiber-bending loss that will
decrease the maximum attainable distance of the fiber cable. The Evertz fiber optic modules come with
cable lockout devices. This prevents the user from damaging the fiber by installing a module into a slot in
the frame that does not have a suitable I/O module. For further information about care and handling of
fiber optic cable, see section 3 of the Fiber Optics System Design section of this manual binder.

7700 MultiFrame Manual
7707VT-4-HS Quad SD/Dual HD-SDI Fiber Transmitter
Revision 1.4 Page - 7
3. SPECIFICATIONS
3.1. SERIAL VIDEO INPUT
Number of Inputs: 2 HD/SDI/DVB-ASI and 2 SDI/DVB-ASI video signals
Standards:
HD/SDI Inputs: SMPTE 292M, SMPTE 259M-C, DVB-ASI
SDI Inputs: SMPTE 259-C, DVB-ASI
Connector: 4 BNC per IEC 61169-8 Annex A
Equalization: Automatic to 100m at 1.485Gb/s and 250m at 270Mbp/s with Belden 1694A or
equivalent cable
Return Loss: > 15 dB up to 1.5Gb/s
3.2. SERIAL VIDEO OUTPUT
Number of Outputs: 1, loopback signal user selectable from above 4 inputs
Connector: BNC per IEC 61169-8 Annex A
Standards: SMPTE 292M, SMPTE 259-C, SMPTE 305.2M
Signal Level: 800mV nominal
DC Offset: 0V ±0.5V
Rise and Fall Time: <270ps at 1.485Gb/s and 900ps nominal at 270Mb/s
Overshoot: <10% of amplitude
Return Loss: >12dB to 1.5Gb/s
Wideband Jitter: < 0.2UI
3.3. OPTICAL OUTPUT
Number of Outputs: 1
Connector: Female SC/PC, ST/PC or FC/PC
Return Loss: > 14 dB
Rise and Fall Time: 200 ps nominal
Wide Band Jitter: < 0.20UI
Fiber Size: 9 µm core / 125 µm overall
Wavelengths:
Standard: 1310nm, 1550nm (nominal)
CWDM: 1270nm to 1610nm (ITU-T G.694.2 compliant)
DWDM: ITU channel 20 to 60, 100GHz spacing, (ITU-T G.694.1 compliant)
Output Power:
1310nm FP (Standard): -6dBm ± 1dBm
1550nm & CWDM DFB: +1dBm ± 0.5dBm
DWDM DFB: +7dBm ± 1dB
3.4. SYSTEM PERFORMANCE
Delay of Transmitter/Receiver Pair: <1.6ms
"Delay is through a 1 meter length fiber cable between the transmitter/receiver
modules.

7700 MultiFrame Manual
7707VT-4-HS Quad SD/Dual HD-SDI Fiber Transmitter
Page - 8Revision 1.4
3.5. ELECTRICAL
Voltage: +12 VDC
Power: 10 Watts (Non DWDM)
13 Watts (DWDM)
3.6. COMPLIANCE
Electrical Safety: CSA Listed to CSA C22.2 No. 60065-03, UL 60065-03
IEC 60065-(2001-12) 7th Edition
Complies with CE Low voltage directive 93/68/EEC
Laser Safety: Complies with 24 CFR 1040.10 and 1040.11 except for deviations
pursuant to LN No. 50, dated July 26, 2001
Complies with IEC 60825-1, Am. 2
EMI/RFI: Complies with FCC regulations for class A devices
Complies with EU EMC directive 89/336/EEC
3.7. PHYSICAL
7700 or 7701 Frame Mounting
Number of Slots: 1

7700 MultiFrame Manual
7707VT-4-HS Quad SD/Dual HD-SDI Fiber Transmitter
Revision 1.4 Page - 9
4. STATUS INDICATORS AND DISPLAYS
The 7707VT-4-HS has 7 LED Status indicators and a 4 digit alphanumeric display on the front card edge
to show operational status of the card at a glance. The card edge pushbutton is used to select various
displays on the alphanumeric display. Figure 4-1 shows the locations of the indicators and pushbutton.
FRAME STATUS
ON/OFF
/ MODULE OK
LOCAL FAULT
LED 1
SERIAL
RUN/UPGRADE
SERIAL
LED 2
VIDEO 1 STATUS
VIDEO 2 STATUS
LED 3
LED 4
VIDEO 3 STATUS
VIDEO 4 STATUS
MENU
NAVIGATION
PUSH BUTTON
MENU
NAVIGATION
TOGGLE
SWITCH
Figure 4-1: Location of Status Indicators, Jumpers and Controls
4.1. STATUS INDICATOR LEDS
LOCAL FAULT: This Red LED indicates poor module health, will be ON if a laser fault exists, if a
local internal power fault exists (i.e.: a blown fuse), or the laser is set to
Discontinuous mode with no valid inputs present. Whether or not this LOCAL
FAULT indication is reported to the frame may be determined by the FRAME
STATUS jumper (see section 5.1).
MODULE OK: This Green LED indicates good module health. It will be ON when a valid input
signal is present and the laser and internal power are good.
On the edge of the 7707VT-4-HS there are four small multi-coloured LEDs that indicate the status of the
video signals:
VIDEO 1 STATUS: Green indicates the presence of a valid signal on channel 1.
Yellow indicates that the signal connected to channel 1 conflicts with the currently
selected input mode (see section 4.2.4).
Red indicates the detection of bit errors on channel 1 (when bit error detection is
enabled – see section 4.2.7).
LED Off indicates signal loss on channel 1.

7700 MultiFrame Manual
7707VT-4-HS Quad SD/Dual HD-SDI Fiber Transmitter
Page - 10 Revision 1.4
VIDEO 2 STATUS: Green indicates the presence of a valid signal on channel 2.
Yellow indicates that the signal connected to channel 2 conflicts with the currently
selected input mode (see section 4.2.4).
Red indicates the detection of bit errors on channel 2 (when bit error detection is
enabled – see section 4.2.7).
LED Off indicates signal loss on channel 2.
VIDEO 3 STATUS: Green indicates the presence of a valid signal on channel 3.
Yellow indicates that the signal connected to channel 3 conflicts with the currently
selected input mode (see section 4.2.4).
Red indicates the detection of bit errors on channel 3 (when bit error detection is
enabled – see section 4.2.7).
LED Off indicates signal loss on channel 3.
VIDEO 4 STATUS: Green indicates the presence of a valid signal on channel 4.
Yellow indicates that the signal connected to channel 4 conflicts with the currently
selected input mode (see section 4.2.4).
Red indicates the detection of bit errors on channel 4 (when bit error detection is
enabled – see section 4.2.7).
LED Off indicates signal loss on channel 4.
4.2. DOT-MATRIX DISPLAY / CARD STATUS AND CONTROLS
Additional status monitoring and controls are provided via the 4-digit dot-matrix display located at the card-
edge. The card-edge toggle-switch (see Figure 4-1) is used to navigate through the display menus and the
pushbutton is used to select options. Figure 4-2 provides a quick reference to the display menu structure.

7700 MultiFrame Manual
7707VT-4-HS Quad SD/Dual HD-SDI Fiber Transmitter
Revision 1.4 Page - 11
LASR...ERR (Laser Error)
OK (Laser OK)
BACK (Abort)
Pushbutton Ö
Top Level Menu Level 1 Menu Level 2
Indications
CTRL (Control)
Selections
STAT (Status)
VER (Software Version) Software Version
Indications
Selections
FRST(Factory Reset)
BACK (Abort)
DISP (Display Orientation) VERT (Vertical)
HORZ (Horizontal)
Selections
YES (Accept)
NO (Abort)
Menu Level 3
Selections
Selections
CONT (Continuous)
DISC (Discontinuous)
Selections
EDET (Error Detection) ON (Indicate VIdeo Errors)
OFF (Disable Error Indication)
Selections
LASR (Laser Enable Mode)
VID2 (Video Input 2)
VID1 (Video Input 1)
VID3 (Video Input 3)
VID4 (Video Input 4)
MODE (Input Mode) HHXX (HHXX Mode)
HSSS (HSSS Mode)
Indications
SHSS (SHSS Mode)
MODE (Input Mode) AUTO (Auto Mode)
HSSS (HSSS Mode)
SHSS (SHSS Mode)
Selections
HHXX (HHXX Mode)
×
Toggle
Switch
Ø
VOUT (Loopback Output) VID1 (Output Video 1)
VID3 (Output Video 3)
VID4 (Output Video 4)
Selections
VID2 (Output Video 2)
EQ (Cable Length) 0% to 100%
Indications
Standards Per Table
LOS (Loss of Signal)
Indications
STD (Video Standard)
Selections
EQ (Cable Length) 0% to 100%
Indications
Standards Per Table
LOS (Loss of Signal)
Indications
STD (Video Standard)
Selections
EQ (Cable Length) 0% to 100%
Indications
Standards Per Table
LOS (Loss of Signal)
Indications
STD (Video Standard)
Selections
EQ (Cable Length) 0% to 100%
Indications
Standards Per Table
LOS (Loss of Signal)
Indications
STD (Video Standard)
Selections
Menu Level 4
Figure 4-2: Card Edge Menu Structure
If a specific menu selection has a configuration value associated with it, then this may be changed using
the toggle switch. Pressing the pushbutton will apply the displayed value and return you to the previous
menu level.
The most recent user selection will be maintained in non-volatile memory in the event of power
loss to the module.

7700 MultiFrame Manual
7707VT-4-HS Quad SD/Dual HD-SDI Fiber Transmitter
Page - 12 Revision 1.4
4.2.1. Display of Warning Status Indications
The top level, default display indicates overall card status and warnings:
OK Card is functioning properly
LASR…ERR Laser Error Warning – Flashing indication alternates between LASR and ERR.
Pressing the pushbutton from this default display will allow the user to select from STAT (status) and
CTRL (control) menu items.
4.2.2. Displaying the Video Standard
The 7707VT-4-HS detects the video standard of the signals present at its inputs. To display the video
standard, select the STAT menu item in menu level 1, then use the toggle switch to display the desired
video channel (from VID1 to VID4) and press the pushbutton to select it. Use the toggle switch to
display the STD option and use the pushbutton to select it. For the sake of brevity, only the description for
Video Input 1 (VID1) will be provided. The video standard will be displayed from the list below:
1080i/60
1080i/59.94
1080i/50
1035i/60
1035i/59.94
1080i/48
1080i/47.96
720p/60
720p/59.94
N270
P270
SDTI-N270
SDTI-P270
LOS (Loss of Signal)
STAT
VID1
STD
Standard
LOS
Standard: One of the above mentioned video standards will be listed.
LOS Loss of Signal – A valid output is not present.
4.2.3. Displaying the Equalization Strength
The 7707VT-4-HS performs automatic cable equalization to compensate for up to 100m of Belden 1694
(or equivalent) cable at 1.485Gb/s or 250m at 270Mb/s. To display the applied equalization, select the
STAT menu item in menu level 1, then use the toggle switch to display the desired video channel (from
VID1 to VID4) and press the pushbutton to select it. Use the toggle switch to display the EQ option and
use the pushbutton to select it. For the sake of brevity, only the description for Video Input 1 (VID1) will be
provided.
STAT
VID1
EQ
0% to 100%
Applied equalization is indicated as follows:
0% to 100% Indicates applied equalization in percentage of maximum
available equalization strength. A very weak or
disconnected input signal will indicate 100% equalization.

7700 MultiFrame Manual
7707VT-4-HS Quad SD/Dual HD-SDI Fiber Transmitter
Revision 1.4 Page - 13
4.2.4. Displaying the Input Mode
The input mode of the 7707VT-4-HS is configured either automatically or manually by the user depending
on the signals connected to the inputs of the card (see section 4.2.6 for details). To display the input
mode, select the STAT menu item in menu level 1 then use the toggle switch to display the MODE option
and press the pushbutton to select it.
STAT
MODE
HHXX
HSSS
SHSS
See Table 4-1 for more information on input modes and signal
connections.
HHXX HHXX Mode
HSSS HSSS Mode
SHSS SHSS Mode
The possible modes and connected signals are as follows:
Connector HHXX HSSS SHSS
1 HD-SDI or SDI/SDTi HD-SDI or SDI/SDTi SDI/SDTi
2 HD-SDI or SDI/SDTi SDI/SDTi HD-SDI or SDI/SDTi
3 N/A SDI/SDTi SDI/SDTi
4 N/A SDI/SDTi SDI/SDTi
Table 4-1: Input Modes and Signal Connections
4.2.5. Displaying the Firmware Version
The VER option displays the card’s current firmware version. To display the firmware version, select the
STAT menu item in menu level 1 then use the toggle switch to display the VER option and press the
pushbutton to select it.
STAT
VER
VER xx BLD xxx
The firmware version will scroll across the display.
For example: VER 1.0 BLD 067
4.2.6. Setting the Input Mode
Several input modes are available depending on the input signal combination the user wishes to connect
to the 7707VT-4-HS. The input mode may be manually set for a specific input signal combination, or the
card may be configured to automatically select the optimum mode depending on the connected input
signals. To set the input mode, select the CTRL menu item in menu level 1, then use the toggle switch to
display the MODE option and press the pushbutton to select it. Use the toggle switch to go through the
available settings and press the pushbutton to select the desired option.
CTRL
MODE
AUTO
HHXX
HSSS
SHSS
See Table 4-2 for more information on input modes and signal connections.
AUTO Auto selects the optimum input mode based on connected signals
HHXX HHXX Mode
HSSS HSSS Mode
SHSS SHSS Mode

7700 MultiFrame Manual
7707VT-4-HS Quad SD/Dual HD-SDI Fiber Transmitter
Page - 14 Revision 1.4
The available manual settings and signal combinations are as follows:
Connector HHXX HSSS SHSS
1 HD-SDI or SDI/SDTi HD-SDI or SDI/SDTi SDI/SDTi
2 HD-SDI or SDI/SDTi SDI/SDTi HD-SDI or SDI/SDTi
3 N/A SDI/SDTi SDI/SDTi
4 N/A SDI/SDTi SDI/SDTi
Table 4-2: Input Modes and Signal Connections
If a new signal is connected that conflicts with the present mode setting, it will not be transmitted by the
7707VT-4-HS. The corresponding Signal Status LED will be yellow, indicating a signal conflict on that
channel. The 7707VT-4-HS will NOT drop or otherwise interrupt any of the existing signals in the event
that a new conflicting signal is connected.
The AUTO input mode will automatically select the optimum input mode (HHXX, HSSS or SHSS) depending
on the signals that are connected to the 7707VT-4-HS. If a signal is connected that the 7707VT-4-HS
cannot accommodate in any of the above modes, the Signal Status indicator corresponding to that
channel will be yellow. The 7707VT-4-HS will NOT drop or otherwise interrupt any of the existing signals
in the event that a new conflicting signal is connected.
Whether the input mode is selected automatically or manually by the user, it may be displayed by the
MODE selection under the STAT menu (see section 4.2.4).
4.2.7. Setting Video Error Detection
The 7707VT-4-HS can detect bit errors in the incoming video signals. The EDET menu item turns this
error detection on or off. When turned on, the Signal Status Indicator corresponding to a signal containing
bit errors will turn red and a trap value will be set (see section 6.4). To set the error detection mode, select
the CTRL menu item in menu level 1, then use the toggle switch to display the EDET option and press the
pushbutton to select it. Use the toggle switch to select between ON and OFF.
CTRL
EDET
ON
OFF
The EDET settings are as follows:
ON Video error detection is turned on
OFF Video error detection is turned off

7700 MultiFrame Manual
7707VT-4-HS Quad SD/Dual HD-SDI Fiber Transmitter
Revision 1.4 Page - 15
4.2.8. Controlling Loopback Connector Output
The VOUT menu item allows the user to control which input video signal will be passed through to the
“HD/SDI OUT” connector on the 7707VT-4-HS. To select the output signal, select the CTRL menu item in
menu level 1, then use the toggle switch to display the VOUT option and press the pushbutton to select it.
CTRL
VOUT
ON
OFF
The possible selections are as follows:
VID1 Video input channel 1 signal will be available at the output
VID2 Video input channel 2 signal will be available at the output
VID3 Video input channel 3 signal will be available at the output
VID4 Video input channel 4 signal will be available at the output
4.2.9. Controlling the Behavior of the Laser
On the 7707VT-4-HS the LASR option allows the user to set the behavior of the laser transmitter when
there is no video signal applied to the video inputs. To set the laser behavior, select the CTRL menu item
in menu level 1, then use the toggle switch to display the LASR menu selection and press the pushbutton
to select it. Use the toggle switch to choose between CONT and DISC and press the pushbutton to select
the mode of operation.
CTRL
LASR
CONT
DISC
The possible selections are as follows:
CONT Laser will transmit continuously regardless of whether there are
valid input video signals present on the inputs of the 7707VT-4-
HS.
DISC The laser will turn off when there is no recognizable video on
the 7707VT-4-HS inputs.
"
Note: With the 7707VT-4-HS set to discontinuous mode, due to the laser turning
off, the companion 7707VR-4-HS will indicate an optical signal loss when no input
video signal is present at the 7707VT-4-HS.
4.2.10. Setting the Orientation of the Text on the Card Edge Display
The DISP display option allows the user to set a horizontal or vertical orientation for the card edge display
messages. To set the display orientation, select the CTRL menu item in menu level 1, then use the toggle
switch to display the DISP menu selection and use the pushbutton to select it. Use the toggle switch to
change between HOR and VERT. Press the pushbutton to make your selection.
CTRL
DISP
HOR
VERT
The possible selections are as follows:
HOR Horizontal display used when the module is housed in the 1
rack unit 7701FR frame or the stand-alone enclosure.
VERT Vertical display used when the module is housed in the 3-rack
unit 7700FR frame.

7700 MultiFrame Manual
7707VT-4-HS Quad SD/Dual HD-SDI Fiber Transmitter
Page - 16 Revision 1.4
4.2.11. Resetting Factory Defaults
The FRST menu option will return the 7707VT-4-HS to factory defaults. To return all settings to factory
defaults, select the CTRL menu item in menu level 1, then use the toggle switch to display the FRST menu
selection and use the pushbutton to select it. Use the toggle switch to change between YES and NO.
Press the pushbutton to make your selection.
CTRL
FRST
YES
NO
The possible selections are as follows:
YES Return all card settings to factory default.
NO Retain current settings.
