Ferno Arachnipod User manual

Users’ Manual
Version 7.0 / August 2020
Read this Manual and Retain for future reference
Total Edge Management System

2
© Ferno Australia / ID: 00184-V7 / AUG 2020
USERS’ MANUALS
To request additional free users’ manuals,
contact Ferno Customer Relations, your
Ferno distributor, or www.ferno.com.au
Ferno Customer Service
For ordering, product assistance or general information:
AUSTRALIA
Telephone (Toll-free) 1800 804 647
Telephone [phone]
Fax [phone]
Email [e-mail]
Internet www.ferno.com.au
ALL OTHER LOCATIONS
For assistance or information, please contact your Ferno distributor. If
you do not have a Ferno distributor, please contact Ferno Customer
Service:
Ferno Australia, 11 Johnstone Road,
Brendale, Queensland 4500, Australia
Telephone Country Code [phone]
Fax Country Code [phone]
Email [e-mail]
Arachnipod serial number(s) located at head end of Legs
Limited Warranty Statement
Ferno products are warranted to be free from defects in material and
workmanship for a period of one year, except as follows:
• External nishes (gelcoat, paint, powdercoat, decals, etc.) are
warranted for 90 days.
• Soft goods (webbing, vinyl, fabric, foam, etc.) are warranted for
90 days.
Ferno repairs are warranted for 90 days from the date of repair.
This limited warranty applies only when you use and care for the
product as described in the instructions provided with the product.
Improper use and care may void this warranty. The warranty period
begins the day the product is shipped from Ferno or the day you
receive it if you have proof of the delivery date. Shipping charges are
not covered by this limited warranty. Ferno is not liable for shipping
damages or damages sustained through using the product, nor does
Ferno assume any liability for products manufactured by others.
Limitation of Liability
If a product is proven defective, Ferno will repair or replace it, or, at
our option, refund the item’s purchase price. In no event is Ferno
liable for more than the selling price of the product. The purchaser
accepts these terms in lieu of all damages.
Except for the limited warranty above, Ferno makes no other
warranties, either expressed or implied. Ferno makes no implied
warranties of merchantability and tness for a particular purpose
for its own product or for the products of others. In no event will
Ferno be liable for any indirect or consequential damages sustained
in connection with the delivery, use, or performance of its products.
CE Compliance Information
CE Certifying Organisation
BSI Group The Netherlands B.V. (NB 2797)
Say Buildng, John M Keynesplein 9
1066 EP, Amsterdam, Netherlands
Certied in 3 & 4 leg congurations to CEN/TS 16415:2013 Type B for
maximum 2 persons and
EN 795:2012 Type B for single person use.
Ferno-Washington Italia S.r.l.
via B. Zallone, n. 26, 40066
Pieve di Cento, Bologna, Italy
+39.051.6860028 234-3468-01
Ferno Australia Pty Ltd
11 Johnstone R oad
Brendale, QLD 4500, Australia
Tel: [phone]
Disclaimer
This manual contains general instructions for the use, operation
and care of this product. The instructions are not all-inclusive. Safe
and proper use of this product is solely at the discretion of the user.
Safety information is included as a service to the user. All other safety
measures taken by the user should be within and under consideration
of applicable regulations and local protocol. Training on the proper
use of this product must be provided before using this product in an
actual situation.
Retain this manual for future reference. Include it with the product in
the event of transfer to new users. Additional free copies are available
upon request from Customer Service.
Proprietary Notice
The information disclosed in this manual is the property of Ferno
Australia (herein referred to as Ferno). Ferno reserves all intellectual
property rights, proprietary design rights, manufacturing rights,
reproduction use rights, and sales use rights thereto, and to any article
disclosed therein except to the extent those rights are expressly
granted to others or where not applicable to vendor proprietary parts.

3
Ferno Customer Service___________________________________________2
1  SAFETY INFORMATION __________________________________________4
1.1 Warning___________________________________________________5
1.2 Notice ____________________________________________________5
1.3 Tip _______________________________________________________5
1.4 Product Lifespan Statement___________________________________5
1.5 Compatible Products ________________________________________5
1.6 Glossary __________________________________________________5
2  ABOUT THE ARACHNIPOD _______________________________________6
2.1 Description and Kit Contents __________________________________6
2.2 Basic Specications_________________________________________10
2.3 Components and Accessories ________________________________12
3  INSTRUCTIONS FOR USE_______________________________________ 17
3.1 General Safety Instructions __________________________________17
3.2 Before Each Use ___________________________________________17
3.3 General Set Up Instructions __________________________________18
3.4 Conguring the Arachnipod _________________________________21
Essential Congurations:
Tripod, Quadpod, Bridge System ___________________________ 21-23
Advanced Congurations:
Gin Pole, A-Frames, Handrail Recovery Monopole _____________ 24-26
Installation Instructions:
Lazy Leg Adaptor __________________________________________27
Equipment Bracket 2:1 Rigging _______________________________28
4  PRINCIPLES OF EDGE MANAGEMENT____________________________ 29
5  STABILISING THE ARACHNIPOD ________________________________ 32
6  INSPECTION & MAINTENANCE__________________________________ 38
6.1 Cleaning, Storage and Transportation _________________________ 38
6.2 Inspection and Maintenance _____________________________ 38-46
Form: Arachnipod Kit Records _______________________________ 47
Form: Regular and Annual Inspection Record___________________ 48
7  DETAILED SPECIFICATION & PARTS _____________________________ 49
Specications ____________________________________________ 49
Kits and Parts_____________________________________________ 50
Declaration of Conformity __________________________________ 52
CONTENTS

4
© Ferno Australia / ID: 00184-V7 / AUG 2020
SAFETY INFORMATION
NOTICE
EMPLOYER: It is your responsibility to ensure all users are instructed and trained in the correct use and maintenance of the
equipment. Once equipment is issued, it is assumed this has been completed.
USER: Only competent users should use this equipment. It is your responsibility to read and understand these instructions
and be properly trained in the use of this equipment. Always use equipment safely and properly. Check equipment before
and after each use
GENERAL: This document is not intended as a substitute for appropriate training. Training, practice and experience in
technical rigging are essential for safe use. Modifying the equipment can cause injury and damage and will nullify any
warranty and place full responsibility for any accident or injury on the equipment owner.
Working at heights and in conned spaces can be dangerous. If you use Ferno equipment, you are responsible for
learning and observing safe techniques. Ferno Australia disclaims all liability for any injury or loss arising from the
use of this equipment when any of its components are damaged or weakened by wear and tear.

5
1  SAFETY INFORMATION
SAFETY INFORMATION
1.1 Warning
1.2 Notice
1.6 Glossary and Symbols
1.3 Tip
1.4 Product Lifespan Statement
The actual life span of the Arachnipod cannot be predicted
exactly, as it is inuenced by many factors including but not
limited to frequency and intensity of use, environment, weather,
storage conditions, etc.
For metallic products it is advisable to replace after 12 years from
date of rst commission, however the life span is theoretically
indenite with strict adherence to the maintenance and
inspection guidelines contained within the user manual. Non-
metallic components such as leg stoppers, and standard foot
treads may require more frequent replacement.
If there is any doubt about the safety of the product, do not use
and contact your safety representative or the manufacturer for
further advice.
It is always recommended to review the manufacturer’s
instructions as a life span may be restricted due to application or
applicable product standards.
WARNING
Warning safety alerts indicate a potentially hazardous
situation that, if not avoided, could result in injury or death.
NOTICE
Notices emphasise important, but not hazard-related
information. Failure to follow Notices could result in product
or property damage.
Anchor
Articial High Direction (AHD) An elevated change-of-direction
anchor point used to change the direction of the Main Line.
CEN/TS 16415:2013 and EN795:2012 Standard for anchor systems
Fall Hazard Any location or situation that exposes equipment or
personnel to a fall.
Footprint The surface area between the feet of the congured
Arachnipod.
Guy Line / Tension Rigging A tensioned line that stabilises and
prevents the Arachnipod from toppling.
Hazard Zone An area usually within 2m (6 ft) from any edge in
which a potential fall hazard exists.
kN Kilonewton
Load
Main / Working Line The primary line supporting the load.
MBS Minimum Breaking Strength
NB2797 Number of notied body for PPE
N/A Not applicable
PPE Personal Protective Equipment
Resultant Force The single linear directional force equal to the sum
of all forces applied to an object.
Safety / Belay / Backup Line A second rope system used to
support the load should the Main Line fail.
Tether Line A line used to prevent an object from falling over an
edge.
Travel Restraint A lanyard, tether or safety line device that
prevents a person from reaching the edge.
WLL Working Load Limit
Tips
Handy hints to make a task simpler, more ecient or
your job a bit easier.
1.5 Compatible Components
The use of the Arachnipod is limited to combinations of
approved and registered components only. Examples include:
1. Retractable type fall arrestor with rescue winch according
to EN360.
2. Rescue, lifting and descending devices according to
EN361, EN341, EN1496, EN67, EN1891, EN1497 and any
other relevant Standard pertaining to the task that is to
be completed.
3. Approved and tested componentry by Ferno Australia.
Other combinations and components not meeting these
standards and should not be used as they may compromise the
safe operation of the system.

6
© Ferno Australia / ID: 00184-V7 / AUG 2020
2  ABOUT THE ARACHNIPOD
2.1 Description & Kit Contents
The Arachnipod is a portable anchor device and is used for securing
persons operating in situations where a fall from height may occur.
The Arachnipod system adapts to most terrains to enable access
to dicult locations such as conned spaces, sheer edges, steep
terrain and voids.
Various Arachnipod components are combined in order to build
an appropriate conguration for the job: from a simple tripod or
quadpod through to more technical bridge systems, A-frames and
gin poles or monopods.
ARACHNIPOD UNITS ARE AVAILABLE AS:
• Standard tripod
• Advantage tripod
• Quadpod
• Standard bridge
• Advantage Kit
• TEMS (Total Edge Management System) Kit
OPTIONAL ACCESSORIES
• Accessories can be combined with your existing Arachnipod
unit to create more technical or complex configurations. This
increases your choices when faced with a complex scenario.
• For explanations of of Arachnipod components and
accessories, refer to section Components & Accessories, page
12 - 16.
STANDARD TRIPOD APODSTD
FEATURES
• Rectangular, adjustable legs with leg pins
• Two stainless steel swivel eye bolt anchor points
• Stainless steel double-grooved pulley accommodates 8mm
steel/stainless steel wire rope cable and bre rope up to 13mm
• Each leg includes a stabilisation attachment point
• Standard feet pivot to adjust to ground variations and
incorporates an aggressive non-slip tread pattern
IN THE BOX
• 1 x Standard tripod comprising 2 standard legs with eye bolts
and 1 pulley leg
• 1 x Foot tether with rope grab
• 1 x Arachnipod standard bag
The above legs can be variously combined to build:
• Tripod
• A-Frame (Rigging Plate required, optional extra)
• Sideways A-Frame
• Handrail Recovery Monopole
ABOUT THE ARACHNIPOD
There may be instances within this manual where Arachnipod
models are shown with the original Standard Foot. Arachnipod
will be supplied with the dual-function Standard Foot 2 as
illustrated above on and after 24 August 2020.

7
QUADPOD APODQUAD
FEATURES
• Rectangular, adjustable legs with leg pins
• Two stainless steel swivel eye bolt anchor points
• Two stainless steel double-grooved pulley accommodates
8mm steel/stainless steel wire rope cable, and bre rope
up to 13mm
• Each leg includes a stabilisation attachment point
• Standard feet pivot to adjust to ground variations and
incorporates an aggressive non-slip tread pattern
IN THE BOX
• 1 x Quadpod made up of 2 Standard legs and 2 Pulley
legs
• 1 x Quad Plate (accessory)
• 1 x Foot tether and rope grab
• 1 x Arachnipod standard bag
• 1 x Single leg bag
These parts can be variously combined to build:
• Tripod
• Quadpod (Quad Plate required, supplied)
• A-Frame (Rigging Plate required, optional extra)
• Sideways A-Frame (Rigging Plate required, optional
extra)
• Handrail Recovery Monopole
ABOUT THE ARACHNIPOD
ADVANTAGE TRIPOD APODADV
FEATURES
• Rectangular, adjustable legs with leg pins
• Two stainless steel swivel eye bolt anchor points
• Stainless steel double-grooved pulley accommodates 8mm
steel/stainless steel wire rope cable and bre rope up to 13mm
• The versatile Lazy Leg also functions as a Standard leg
• Each leg includes a stabilisation attachment point
• Standard feet pivot to adjust to ground variations and
incorporates an aggressive non-slip tread pattern
IN THE BOX
• 1 x Advantage tripod comprising 1 Standard leg with eye bolt,
1 Lazy Leg with eye bolt and 1 Pulley leg
• 1 x Lazy Leg Adaptor (accessory)
• 1 x Foot tether with rope grab
• 1 x Arachnipod standard bag
These parts can be variously combined to build:
• Tripod
• A-Frame (Rigging Plate required, optional extra)
• Sideways A-Frame (Rigging Plate required, optional extra)
• A-Frame with Lazy Leg (Reverse Head and Quad Plate required,
optional extra)
• Handrail Recovery Monopole
q
w
t
e
r
y
u
i
o

8
© Ferno Australia / ID: 00184-V7 / AUG 2020
STANDARD BRIDGE APODS*B
FEATURES
• The bridge system is a unique feature of the Arachnipod
• The bridge spans larger openings
• Beam provided with trolley, trolley positioning line
and heads
• Four rectangular, adjustable legs provide support and
stability
• Three load attachment eye bolts
• One stainless steel double-grooved pulley for 8mm steel/
stainless steel wire rope, and bre rope up to 13mm
• Each leg includes a stabilisation attachment point
• Standard feet pivot to adjust to ground variations and
incorporates an aggressive non-slip tread pattern
IN THE BOX
• Standard Bridge (3 x standard legs, 1 pulley leg and 1
2m, 3m or 4m bridge)
• 1 x Quad Plate (accessory)
• 2 x Foot tether and rope grab
• 1 x Arachnipod standard bag
• 1 x Bridge bag
These parts can be variously combined to build:
• Tripod
• Quadpod (Quad Plate required, provided)
• A-Frame (Rigging Plate required, optional extra)
• Sideways A-Frame (Rigging Plate required, optional extra)
• Handrail Recovery Monopole
• Bridge System
ADVANTAGE KIT APODADV+
FEATURES
• Rectangular, adjustable legs with leg pins
• Two stainless steel swivel eye bolt anchor points
• Stainless steel double-grooved pulley accommodates 8mm
steel/stainless steel wire rope cable, and bre rope up to 13mm
• The versatile Lazy Leg also functions as a Standard leg
• Each leg includes a stabilisation attachment point
• Standard feet pivot to adjust to ground variations and
incorporates an aggressive non-slip tread pattern
IN THE BOX
• Advantage Tripod (1 each standard, pulley and Lazy Leg)
• 1 x Lazy Leg Adaptor
• 1 x Foot tether and rope grab
• 1 x Arachnipod standard bag
• 1 x Advantage Accessory Kit containing essential extras:
(Refer to Figure A, page 9 for parts identification)
› 1 x Advantage Accessory Kit Bag q
› 1 x Reverse Head w
› 1 x Gin Head e
› 1 x Rigging Plate r
› 3 x Spike Feet t
› 1 x Quad Plate y
These parts can be variously combined to build:
• Tripod
• A-Frame (Rigging Plate required, supplied)
• Sideways A-Frame (Rigging Plate required, supplied)
• A-Frame with Lazy Leg (Quad Plate and Reverse Head required,
supplied)
• Gin / Monopole (Lazy Leg and Gin Head required, supplied)
• Handrail Recovery Monopole
ABOUT THE ARACHNIPOD

9
FEATURES
• The top of the line Total Edge Management System includes all the equipment needed to manage just about any scenario
• The TEMS kit includes all the features of the Standard Bridge, with the addition of the Full Accessory Kit included.
IN THE BOX
• 2 x Standard leg with eye bolt
• 1 x Pulley leg
• 1 x Lazy Leg with eye bolt
• 1 x 2m, 3m or 4m Bridge
• 1 Lazy Leg Adaptor
• 2 x Foot tether and rope grab
• 1 x Arachnipod standard bag
• 1 x Bridge bag to suit bridge length
• 1 x Full Accessory Kit containing:
› 1 x Full Accessory Kit bag q
› 4 x Hold Down Stakes w
› 2 x Steps e
› 1 x Equipment Bracket r
› 1 x Gin Head t
› 1 x Reverse Head y
› 1 x Rigging Plate u
› 1 x Quad Plate i
› 4 x Spike Feet o
› Spare Parts Pouch with 1)
2 Spare Qik Link Head Pins, 1 Spare Leg Pin,
2 Spare Detent Pins, 8 M12 Tru-Bolts and
1 M12 Masonry Drill Bit
› 4 x Soft Ground Shoes 1!
The Total Edge Management System can be congured as:
• Tripod
• A-Frame
• Sideways A-Frame
• A-Frame with Lazy Leg
• Quadpod
• Gin / Monopole
• Handrail Recovery Monopole
• Bridge System
ABOUT THE ARACHNIPOD
TOTAL EDGE MANAGEMENT SYSTEM APODTEMS
q
wer
t
y
u
io
1)
1! A

10
© Ferno Australia / ID: 00184-V7 / AUG 2020
2.2 Basic Specications
Basic specications for the Arachnipod models are shown in the table below. General specications are rounded. For more detailed
specications, refer to Detailed Specications, page 49.
Specications Standard Tripod Advantage Tripod Quadpod
Max. Inside Clearance Height 2671mm / 105” 2671mm / 105” 2671mm / 105”
Inside Feet Footprint 2533mm / 99.7” 2533mm / 99.7” 2551mm x 2171mm / 100.4”
Congured Device Weight 27kg / 60lb 26kg / 57lb 37kg / 82lb
Stowed in bag(s) Weight 35kg / 74lb 34kg / 75lb Bag 1: 36kg / 79lb
Bag 2: 10kg / 21lb
WLL External Anchor Point 400kg / 880lb at max. height 400kg / 880lb at max. height 400kg / 880lb at max. height
Minimum Breaking Strength 40kN 40kN 40kN
WLL Load Anchored to Leg 220kg / 485lb 220kg / 485lb 220kg / 485lb
Legs included in package 2 x Standard Legs
1 x Pulley Leg
1 x Standard Leg
1 x Pulley Leg
1 x Lazy Leg
2 x Standard Legs
2 x Pulley Legs
Certication Certied in 3 and 4 leg congurations to CEN/TS 16415:2013 for maximum 2 persons and
EN 795:2012 for single person use
Specications Standard Bridge 2m / 3m / 4m Bridge
Advantage Kit
Tripod & Accessory Kit
TEMS Kit
Total Edge Management System
Max. Inside Clearance Height 2696mm / 106.1” 2671mm / 105” 2696mm / 106.1”
Inside Feet Footprint
2m: 3346mm x 2171mm / 131.7” x 85.5”
3m: 4346mm x 2171mm / 171” x 85.5”
4m: 5346mm x 2171mm / 210.5” x 85.5”
2533mm / 99.7”
2m: 3346mm x 2171mm / 131.7” x 85.5”
3m: 4346mm x 2171mm / 171” x 85.5”
4m: 5346mm x 2171mm / 210.5” x 85.5”
Congured Device Weight
2m: 57kg / 125lb
3m: 64kg / 141lb
4m: 71kg / 156lb
26kg / 57lb
2m: 57kg / 125.6lb
3m: 64kg / 141lb
4m: 71kg / 156.5lb
Stowed in bag(s) Weight
2m Bridge
Bag 1: 34kg
75lb
Bag 2æ:40kg
88lb
3m Bridge
Bag 1: 34kg
75lb
Bag 2æ: 51kg
112lb
4m Bridge
Bag 1: 34kg
75lb
Bag 2æ: 63kg
139lb
Bag 1: 33kg / 73lb
Accessory Kit: 5.5kg / 12lb
2m Bridge
Bag 1: 34kg
75lb
Bag 2æ: 40kg
88lb
3m Bridge
Bag 1: 34kg
75lb
Bag 2æ: 51kg
112lb
4m Bridge
Bag 1: 34kg
75lb
Bag 2æ: 63kg
139lb
Full Accessory Kit: 12kg / 26lb
WLL External Anchor Point
At max. height and mid-beam
2m: 280kg / 616lb *
3m: 230kg / 506lb *
4m: 190kg / 418lb *
400kg / 880lb at max. height
At max. height and mid-beam
2m: 280kg / 616lb *
3m: 230kg / 506lb *
4m: 190kg / 418lb *
Minimum Breaking Strength
At max. height and mid-beam
2m: 28kN **
3m: 23kN **
4m: 19kN **
40kN
At max. height and mid-beam
2m: 28kN **
3m: 23kN **
4m: 19kN **
WLL Load Anchored to Leg
2m: 220kg / 485lb
3m: 220kg / 485lb
4m: 190kg / 418lb
220kg / 485lb
2m: 220kg / 485lb
3m: 220kg / 485lb
4m: 190kg / 418lb
Legs included in package 3 x Standard Legs
1 x Pulley Leg
1 x Standard Leg
1 x Pulley Leg
1 x Lazy Leg
2 x Standard Legs
1 x Pulley Leg
1 x Lazy Leg
Certication Certied in 3 and 4 leg congurations to CEN/TS 16415:2013 for maximum 2 persons and
EN 795:2012 for single person use
* The Bridge trolley WLL is 250kg / 550lb (ultimate strength 24.5kN)
** The Bridge beam MBS will dier depending on where the load is positioned along the beam. On a 2m bridge beam, the safety factors reduce from
10:1 to <7:1 as the trolley moves from the centre to the end of the beam.

Tripod Bag
æ Bridge Bag
ABOUT THE ARACHNIPOD

11
ABOUT THE ARACHNIPOD
Ø2533
INSIDE OF FEET
2173 OUTSIDE OF FEET
1879 INSIDE OF FEET
2508 OUTSIDE OF FEET
2328 CTR OF FEET
2171 INSIDE OF FEET
2671 CTR OF EYEBOLT
2959
SHOWN AT HIGHEST SETTING (A1)
Dimensions: Tripod
Dimensions: Quadpod Dimensions: Bridge System
2696
2 9 5 9
FRONT VIEW
2MTR BRIDGE - 3346
FEET SPAN WITH 3MTR BRIDGE - 4346
4MTR BRIDGE - 5346
BRIDGE (3000)
2171
TOP VIEW
2626

12
© Ferno Australia / ID: 00184-V7 / AUG 2020
ARACHNIPOD LEGS
All Arachnipod legs (Figure 1) are made up of three telescopic
sections, a head and a foot socket for attachment of a foot. All legs
are supplied with a Standard foot and feature alpha-numeric labels to
aid communication during the setting up of leg heights.
The patented leg heads are designed with a cut-out edge which
forms a movable hinge when one head is slotted together with
another leg.
There are three styles of Arachnipod legs, distinguished by their
heads: Standard, Pulley and Lazy Leg. All heads are tted with a
stabilisation attachment point.
Legs join together via the leg heads and secure in place with Qik
Link pins. By removing a Qik Link head pin, this system enables an
Arachnipod tripod to be stored at for easy transportation, and for
rapid set-up.
Pulley Leg
A Pulley leg (Figure 3) can be used in place of a Standard leg to add a
pulley function to a tripod or A-frame conguration. It is also used as
a handrail monopole.
The double grooved pulley accommodates either bre rope up to
13mm diameter, or steel/stainless steel wire rope cable up to 8mm.
A detent pin prevents the rope or cable from escaping the pulley
grooves. The Pulley leg has a red head with:
• Double groove pulley
• Removable stabilisation point
Lazy Leg
The Lazy Leg’s head (Figure 4) is blue coloured and designed to pivot
so the leg can be angled to a range of 180°. Lazy Leg 2 (eective
August 2020) features an additonal eye bolt (not available with
original Lazy Leg), plus a removable stabilisation point. The Lazy Leg
may be used to congure:
• A Gin pole (gin head required)
• An A-frame with Lazy Leg (two additional legs, reverse head
and quad plate required).
The Lazy Leg can be converted to a Standard leg by locking its
pivoting head with a Lazy Leg Adaptor.
NOTE: Due to its slightly dierent prole, Lazy Leg 2 can only be
used with Gin Head 2.
ABOUT THE ARACHNIPOD
Standard Leg
The Standard leg (Figure 2) has a red head with:
• One rated load attachment point (360° swivelling eyebolt)
• Stabilisation attachment point (D-shackle)
2.3 Components & Accessories
2
3
4
1
Leg Pin
Leg Middle Section
Leg Lower Section
Alpha-Numeric Labels
Standard Foot
Head
Leg Top Section
Stabilisation Attachment Point
Stabilisation Attachment Point
Foot Socket

13
ABOUT THE ARACHNIPOD
ARACHNIPOD FOOT OPTIONS
The Arachnipod system oers various foot options to suit various
ground surfaces and conditions. Feet are secured to the base of the
lower leg with a detent pin.
Leg with Standard Foot
The Standard Foot (Figure 5) is ideal for at surface applications
such as concrete. Lashing holes are provided at front and rear of the
foot to accommodate leg restraint rope or other lashing technique.
For uneven surfaces, the Standard Foot may be pivoted to deploy
its spiked tips. Unused lower leg holes can be used with the leg
restraint rope or for other lashing techniques.
Spike Foot
The Spike Foot (Figure 6) has a round end and a spike end. It is
reversible. The spiked end features a stainless steel tip which
extends the service life of the spike. It is used for point loading and
ground penetration applications.
The round end is used in situations where the spike may damage or
scratch the supporting surface.
One end of the spike foot ts into the foot socket in the base of the
leg, and held in place with a detent pin (Figure 6).
Included in the Advantage and the Full Accessory Kit, or sold separately.
Soft Ground Shoe
The Soft Ground Shoe (Figure 6) ts over the spike foot and clips to
the foot socket. It is used to limit ground penetration in soft ground
applications. Included in the Full Accessory Kit, or sold separately.
Hold Down Stake
A Hold Down Stake is used to secure a standard foot to the ground
(Figure 7).
• Insert the foot-locating spike through one of the holes in the
standard foot. Ensure this foot locating spike remains in the
foot while hammering the hold down stake into position.
• Using a soft-faced or shot-lled hammer, hammer on the
impact plate until the stake is half way into the ground.
• Pause to check the alignment of the foot locating spike, then
continue to drive the stake into the ground.
Included in the Advantage and the Full Accessory Kit, or sold separately.
Tru Bolt
12mm Tru Bolts (Figure 8) which are supplied in the Full Accessory
Kit and available from hardware stores, can be used in place of hold
down stakes to secure the foot to concrete and other hard rock
surfaces.
Tru Bolts t through the same holes in the standard foot as the hold
down stake (Figure 8).
Included in the Full Accessory Kit, or sold separately.
Foot Locating Spike
Impact Plate
5
6
7
8

14
© Ferno Australia / ID: 00184-V7 / AUG 2020
ABOUT THE ARACHNIPOD
Quad Plate
A Quad Plate is used in the formation of a quadpod or A-Frame with
Lazy Leg. It helps to form and maintain the shape of the congured
head. Included in the Advantage and Full Accessory Kits, or sold separately.
Gin Head
The Gin Head may be used as an anchor plate, or combined with a
Lazy Leg to form a gin pole. There are two versions of the Gin Head,
both performing the same function. Gin Head 2 is compatible with
both the Lazy Leg and Lazy Leg 2. The original Gin Head (DOM prior
to 24 August 2020) ts the Lazy Leg.
Included in the Advantage and Full Accessory Kits, or sold separately.
Lazy Leg Adaptor
The Lazy Leg Adaptor converts a Lazy Leg into a standard leg.
Included with kits that include a Lazy Leg, or sold separately.
Reverse Head
The Reverse Head is used in the formation of an A-frame with Lazy
Leg. When tted, it enables two legs to connect at 180°.
Included in the Advantage and Full Accessory Kits, or sold separately.
Rigging Plate
The Rigging Plate is used to provide additional stabilisation
attachment points when two legs are connected as an A-frame.
The Rigging Plate is not for live loads.
Included in the Advantage and the Full Accessory Kit, or sold separately.
Equipment Bracket
The Equipment Bracket is designed to be attached to the middle
leg section and provides an additional tie-o and/or anchor point.
When the leg it is attached to is used as an anchor, the WLL of the
Arachnipod is reduced to 220kg. This attachment point may only
be used if the main line passes through a change of direction pulley
at the head of the conguration.
Included in the Full Accessory Kit, or sold separately.
OPTIONAL ACCESSORIES (For product codes and comprehensive list of spare parts, refer Arachnipod Kits & Parts, page 50)
Gin Head 2
910
11 12
13 14

15
ABOUT THE ARACHNIPOD
Step
The Step enables an operator to reach and adjust high rigging
without having to lower the whole set up. The Step attaches to the
middle or lower leg sections. For enhanced safety, the Step should
only be attached to the inside of the leg so the leg is between the
user and the void.
Steps are not rated for load applications. Before using the Step,
ensure the operator is secured with appropriate fall protection and
PPE. Included in the Full Accessory Kit, or sold separately.
Fall Arrest Block with Retrieval Winch
The APOD-FA Type 3 fall arrest block is supplied with a bracket that
mounts to the middle section of any supporting leg. 15m length.
WLL 136kg / 300lb. Sold separately.
I.K. Fall Arrest Block Adaptor
The I.K. Adaptor enables an IKAR 12m, 18m or 24m inertia reel or
similar-shaped fall arrest block to be attached to an Arachnipod leg.
Sold separately.
Winch with Cable
The Arachnipod Winch with cable is tted with a bracket that
mounts to the middle section of any leg. The winch is available in
10m, 20m and 25m cable lengths.
Type 2 Winch with a WLL of 220kg / 485lb.
Sold separately.
APOD-FBA Fall Arrest Block Adaptor
This adaptor enables SALA Type 3 fall arrest blocks, Pelsue winches
and other similar-shaped blocks to be attached to an Arachnipod
leg. Sold separately.
Bridge Kit
The Bridge Kit includes a bridge beam with trolley (2m, 3m or 4m
length), a standard leg, foot tether and rope grab plus storage
bag. This kit is used to upgrade the functions of an Arachnipod
tripod to a bridge system.
Sold separately. Note: Kit illustrated with original Standard Foot. The next generation
Standard Foot 2 (part # 90-0472) is supplied with all Arachnipod units after 24/08/2020
15 16
17 18
19 20

16
© Ferno Australia / ID: 00184-V7 / AUG 2020
ABOUT THE ARACHNIPOD
Bridge Ratchet Kit
The Bridge Ratchet Kit includes everything needed to stabilise the
Arachnipod bridge system. The kit includes 15m ratchet straps,
1200mm round slings, 2500mm snake slings and round slings
neatly packed into a handy grab and go bag.
Sold separately.
Lazy Leg Extension Kit
When a Lazy Leg is used as a compression member and extra
length is required, the APOD-EKLL Extension Kit extends the
length of the Lazy Leg by 1.7m / 67”.
Sold separately.
21 22

17
3  INSTRUCTIONS FOR USE
3.1 General Safety Instructions
1. The Arachnipod and associated hardware must always be secured
to prevent it from tipping and falling over. The Arachnipod may
become unstable if used without an assessment of the resultant
force and direction. Additional rigging may be required to ensure
complete stabilisation.
2. Ensure the Operator is in good physical and mental health and
is trained and competent in the use of the device. The Operator
must employ all relevant PPE for the job prior to commencement
of working at height. PPE may include, but is not limited to a
harness, lanyard, helmet, gloves and appropriate foot wear.
3. Ensure you have a rescue plan in place prior to working at height
or conned space. A rescue plan is mandatory and all operators
within the team must be aware of it prior to commencing work.
4. Do not alter, modify or tamper with the Arachnipod in any way
or form. The Arachnipod may not be rectied or serviced by any
person unless they are appropriately trained and authorised by
Ferno Australia.
5. When the Arachnipod is used as part of a fall arrest system, the
User must be equipped with a means of limiting the maximum
dynamic forces exerted on the user during the arrest of a fall to a
maximum of 6kN.
6. A lanyard assembly should be secured to an anchorage point
which is at a level that will result in the minimum free fall and
the least total fall distance consistent with the wearer’s ability to
carry out work tasks.
7. When making a connection to any point on a harness which
cannot be seen by the wearer of the harness, it should either be
made before putting the harness on, or the connection should
be connected or checked for security by a second person.
8. Always ensure anchor points are positioned to avoid a pendulum
eect during a fall which may cause body contact with structures
or machinery below. The maximum angle from the anchor point
must not exceed 15° either side of the centre of the anchor point.
9. If any part of an assembly is to be exposed to chemicals such
as caustic materials or hazardous atmospheres, the user should
consult Ferno Australia to determine whether the part is suitable
for continued use.
3.2 Before Each Use
Operator Inspection
The product should be inspected by a competent person
before and after each use to ensure it functions correctly and all
components are damage free.
A guide is provided below for use in conjunction with your
approved workplace protocols.
For periodic and annual inspections, comprehensive instructions
are provided in the Inspection and Maintenance section, page
38-56.
Inspect the Arachnipod for:
1. Do the legs t together and extend smoothly?
2. Are the legs bent, cracked or deformed?
3. Are all fasteners (e.g. bolts, pins) present and securely
tightened?
4. Is retaining hardware on pins present and in good condition?
5. Are the pins in good condition and functioning correctly?
6. Are the pulleys in good condition and functioning correctly?
7. Do any plastic parts show signs of wear or chemical damage?
8. Are the feet and lashing holes showing signs of deformation,
damage and sharp edges?
9. Is the adjustable foot tether present and in good condition?
Refer any signs of deterioration to a competent person for a
decision on the safety and serviceability of the product. If in
doubt, tag it out!
ESSENTIALS: GENERAL SAFETY INSTRUCTIONS
WARNING
• Do not use the Arachnipod beyond its specied limitations,
or for any purpose other than that for which it is intended.
• Ensure the compatibility of equipment used within the
system. Dangers may arise when the safe function of any
one item of equipment is aected by or interferes with the
safe function of another.
• Do not use your Arachnipod® if any parts are missing.
NOTICE
Operating in, or exposing the Arachnipod to extreme
temperatures, caustic chemicals, hazardous environments or
excessively rough handling / treatment may cause damage.

18
© Ferno Australia / ID: 00184-V7 / AUG 2020
ESSENTIALS: GENERAL SET UP INSTRUCTIONS
3.3 General Set Up Instructions
Assembling the Arachnipod is easiest with two or more people.
Where possible, it is safest to congure the Arachnipod away from
the edge before moving the unit into position with the help of
several people. Once in position, secure the feet, tether and stabilise
the Arachnipod.
Step 1) Joining legs together
All Arachnipod legs are made up of three telescoping sections, a
head and a foot ( Figure 1 on page 12). The patented leg heads are
designed with a cut-out edge which forms a movable hinge when
one head is slotted together with the head of another leg.
To join two legs together:
1. Remove Qik Link pins from the heads of the two legs being
joined together. (Step q Figure 23)
2. Holding both legs in an upright position, join the two head
edges so they interlock to form a hinge. (Step w Figure 23)
3. Insert the Qik Link head pin through the combined hinge
channel to secure the two legs together. When fully inserted, a
spring-loaded pin retainer at the base of the hinge will engage
with, and prevent the Qik Link pin from accidental removal
(Step e Figure 24).
Inserting the Qik Link head pin
If the two leg heads are slightly misaligned, the Qik Link
pin may not travel smoothly into and down the hinge
channel. If this occurs, do not force the pin. Leave the
pin partially inserted, then gently rattle / shake the two
legs. This motion will align the two heads, allowing the
pin to self-drop fully into the hinge channel.
Step 2) Check the Surface(Figure 25)
• Make sure the substrate or oor below the Arachnipod
feet can sustain the anticipated loads.
• Beware of soft ground and unsupported oors. Manage
these accordingly.
q
w
e
For instructions on how to form a tripod, quadpod,
and basic bridge system refer to “ESSENTIAL
ARACHNIPOD CONFIGURATIONS”on page 21.
For gin pole, easel or A-frames and other advanced
congurations, refer to “ADVANCED ARACHNIPOD
CONFIGURATIONS”on page 24.
23
24
25
Qik Link head pin

19
ESSENTIALS: GENERAL SET UP INSTRUCTIONS
Step 3) Select feet to suit the surface
Consideration should be given to the ground surface Arachnipod
will be operating on, and which foot style is most appropriate to
surface conditions.
The Arachnipod is supplied with Standard feet which has a
thermoplastic elastomer tread moulded to a stainless steel foot
with integrated spike.
Additional foot options are available to provide the most stable
solution for dierent ground conditions.
The Foot Options Table provides a quick reference of each foot’s
function.
Step 4) Extend Arachnipod legs
Extending legs is most eciently performed when two or more
people are involved. When only one person is available, this is still
achievable by moving from leg to leg, making small adjustments
to each leg.
Foot Options
Standard Foot
Supplied standard with all Arachnipod units. Ideal for
at or smooth surfaces, accommodates slight inclines.
Spike Foot
The spike tip of this reversible foot is ideal for point
loading and ground penetration applications.
Spike Foot
The rounded end of the Spike Foot is good for wedging
into corners or when supporting surfaces require
additional care.
Soft Ground Shoe
The soft ground shoe is used in conjunction with
the spike foot to limit the leg sinking in soft ground
applications.
Hold Down Stake
Used in conjunction with a standard foot, the stake is
driven into the ground to secure the foot.
Tru-bolts
Used to secure the standard foot to concrete and hard
rock surfaces.
• Remove both leg pins to release the three sections of leg.
• Extend the top section to desired height, then insert the leg pin
to secure the top and mid section together.
• Next, extend the middle section to desired height and insert the
leg pin to secure the middle and lower sections together.
• Check that all leg pins are securely engaged.
Ensure the Arachnipod remains stable while adjusting the legs.
Extending Arachnipod Legs
It is easier to raise and / or adjust the height of the legs
when they are positioned close together, with all legs in
an upright position.
WARNING
• When extending legs, sliding parts can create pinch
points. Always wear appropriate PPE and gloves when
setting up and operating Arachnipod.
• NEVER place ngers into leg pin holes.

20
© Ferno Australia / ID: 00184-V7 / AUG 2020
Step 5) Tether the feet
Position the legs then tether the Arachnipod’s feet to prevent the
legs from splaying outwards and becoming unsafe.
Tethering the feet does not replace stabilisation of the unit.
To tether a tripod with standard feet:
1. Feed the foot tether rope through the inner hole of the
standard foot and all subsequent feet.
2. When the foot tether is threaded through all feet, join the
ends together to form a loop by feeding the tail end of the
rope through the rope grab. Tighten to ensure there is no
slack in the tether (Figure 26).
ESSENTIALS: GENERAL SET UP INSTRUCTIONS
Step 6) Keep the Arachnipod head level where
possible
This is easier to achieve with tripods and quadpod
• On at surfaces all the legs will be the same length.
• On uneven surfaces the legs can be dierent lengths.
• Adjust the length of one or more legs so the Arachnipod’s head is
level and directly over the opening or work area.
• Figure 27: Floor of dierent heights
• Figure 28: Sloping surface
Step 7) Stabilise the Arachnipod
• Assess the resultant force and direction.
• Provide additional rigging as required to ensure stability of
Arachnipod.
• For stabilisation guidelines, refer to “Stabilising the Arachnipod”on
page 32
Step 8) Rig a two-rope system whenever possible
• Rig a two-rope system to provide a backup to both the main line and
the edge management rigging.
Step 9) Carry out a safety check and continue to
monitor Arachnipod for stability
• Visually check all anchors, rigging, karabiners, friction devices and
PPE before committing anyone to the edge. Travel restraints must
be provided for persons working close to the edge.
• Many factors can change during operation and aect the stability
of the Arachnipod. Continuously monitor the Arachnipod and if
any instabiity is detected, the safety line can be set to safely hold
the load while adjustments are made.
NOTICE
The unit may be damaged if legs splay apart while under load.
Always tether the feet together when the Arachnipod is being
used.
26
27
28
