Ferno Traverse Rescue Titan Series User manual

Page 2 of 8
Disclaimer
This manual contains general instructions for the use,
operation and care of this product. The instructions are
not all-inclusive. Safe and proper use of this product is
solely at the discrestion of the user. Safety information is
included as a service to the user. All other measures
taken by the user should be within and under
consideration of applicable regulations. It is
recommended that training on the proper use of this
product be provided before using this product in an actual
situation.
Retain this manual for future reference. Include it with the
product in the event of transfer to new users. Additional
free copies are available upon request from Customer
Care.
Proprietary Notice
The information disclosed in this manual is the property of
Traverse Rescue, LLC Mississauga, Ontario, Canada.
Traverse Rescue, LLC. reserves all patent rights,
proprietary design rights, manufacturing rights,
reproduction use rights, and sales use rights thereto, and
to any article disclosed therein except to the extent those
rights are expressly granted to others or where not
applicable to vendor proprietary parts.
© Copyright Traverse Rescue, LLC . All Rights
Reserved
Traverse Rescue, LLC.
755 The Queensway East, Unit 8
Mississauga, Ontario
Canada L4Y 4C5
Toll Free (US and Canada):..................... 1-866-998-7866
Telephone (Worldwide): ...............................905-279-7866
Fax (NA and Worldwide):.............................905-615-1367
Web Site:www.traverserescue.com
1.Safety Information
1.1 Warnings
The following are warnings in this manual:
Untrained operators can cause injury or be
injured. Permit only trained personnel to operate
this stretcher.
Improper use of the stretcher can cause injury.
Use the stretcher only for the purpose described
in this manual
An unrestrained or improperly restrained patient
can suffer injuries. Always secure the patient in
the stretcher with a restraint system suitable to
the situation
Improper operation can cause injury. Operate
the stretcher only as described in this manual
An un-attended patient can be injured. Stay with
the patient at all times
Helpers can cause injury or be injured. Maintain
control of the stretcher and direct all helpers
Improper maintenance can cause injury and
damage. Maintain stretcher only as described in
this manual
Improper parts and service can cause injury.
Use only Traverse-approved parts and service
on the stretcher
Modifying the stretcher can cause injury and
damage. Use the stretcher only as-sold by
Traverse.
Attaching improper or inapprpriate items to the
stretcher can cause injury. Use only Traverse-
Approved items on the stretcher
Traverse Rescue, LLC manufactures its products under a
strict Quality Assurance Program. We also recognize and
comply to any applicable standards that apply to each
product.
The CE symbol on Traverse Rescue LLC products signifies
they have been self certified in accordance with the Medi-
cal Devices Directive 93/42/EEC concerning Class 1
Medical Devices

Page 3 of 8
1.2 Important
Boxes like the one below emphasize important information.
1.3 Bloodborne Disease Notice
OSHA (Occupational Safety and Health Administration) requires
employers to protect workers from workplace exposure to
bloodborne diseases such as HIV-1 and hepatitus. To reduce
the risk of exposure when using the stretcher, follow disinfecting
and cleaning instructions in this manual.
1.4 Safety Labels
Lables place important information from the Users’ Manual on
the stretchers.
Read and follow label instructions. Replace worn or damages
labels immediately. New labels are available from Traverse.
The Load-Limit label shown is affixed to the stretcher.
2. Operator Skills and Training
2.1 Skills
Operators using the stretcher need:
 A working knowlege of emergency patient-handling
procedures.
 The ability to assist the patient
 A complete understanding of the procedures described in
this manual
2.2 Training
Trainees need to:
 Follow a training program designed or approved by their
training officer
 Read this manual. For additional free users’ manuals,
contact Traverse Customer Care.
 Practice with the stretcher before using it in regular service
 Be tested on their understanding of the stretcher
 Record their training information
3.About The Stretcher
3.1 General Specifications
Durathene® Netting...-65°F/-54°C to +200°F/+93°C
Restraint Webbing
Tensile Strength.......................975 lbs. / 442 kg
Load Rating ..............................500 lbs. / 227kg
Restraint Buckles
Minimum Tensile Load.........4000 lbs. / 1814 kg
Buckles meet ANSI Z359.1 and CSA Z259.1
Traverse Rescue LLC reserves the right to change
specifications with out notice.
4.Restraints
4.1 About the Restraints
A total of four restraints are included with your purchase of this
stretcher.
These restraints are to suppliment what you will typically use to
tie-in a patient in a high-angle situation. We have made them to
a suitable strength in order to compliment your own system of
tubular webbing, cord or the like. These restraints are only for
securing the patient into the stretcher, and are not to be used for
lifting or for any other purpose.
Length 83.5” 212 cm
Width - Non Split 23” 58 cm
Width - Split 23.75” 60 cm
Width - 32 32” 81.25 cm
Depth 7.25” 18 cm
Weight - Non Split 31 lbs 14 kg
Weight - Split 36 lbs 16.5 kg
Weight - 32 42 lbs 19.2 kg
Rated Load Limit 2500 lbs. 11 kN

Page 4 of 8
4.2 Fastening and Tightening
the Restraints
The strap with the three-bar and two bar buckle is constructed
with a looped end that attaches to the stretcher, and a free end
that that is used to tighten the restraint (figure 1).
1Pass the three-bar buckle and webbing upward
through the opening in the two-bar buckle ( fig. 2).
2Pull slightly on the free end of the webbing to firmly
seat the three-bar buckle on top of the two-bar
buckle (fig. 3).
3Tighten the restraint by pulling on the free end of the
webbing.
4.3 Loosening and unfasten
ing the Restraints
To loosen a restraint, pull the breakaway tab toward the buckle
(fig. 4). Continue pulling until the restraint is as loose as
desired.
To unfasten the restraint, first loosen as in step number 1, then
angle the three-bar buckle and pass it downward through the
opening in the two-bar buckle (fig. 5).
4.4 Attaching the Restraints
The top edge of the Durathene® netting is shaped with coves to
provide points where restraints can easily be fastened to the
lower-rail of the stretcher (fig. 6).
Select attachment points that are appropriate for effective
securing of the patient, as well as for working together with your
own fastening system.
Attach the supplied restraints as folows:
1. Unfasten the buckle to seperate the restraint straps.
2. Starting outside the stretcher, pass the looped end of the
strap inward between the stretcher rail and the netting at a
chosen attachment point.
3. Thread the buckle through the restraint loop (Fig. 8) and
pull until the loop is tight around the stretcher rail.
4. Attach the remaining strap to the opposite side of the
stretcher following steps 2 and 3.
5. Using the Stretcher
5.1 Before Placing the
Stretcher in Service
 Personnel who will work with this stretcher need to read this
manual.
 If using the supplied restraints, attach them as instructed in
Attaching the Restraints.
 Confirm that the stretcher, restraints and mesh netting are
in good condition. Follow instructions in Inspecting the
Stretcher in this manual.
5.2 General
Guidelines for Use
 Using the stretcher requires a
minimum of two trained operators. In
most situations, operators will want or
need additional help. For information
about placement and direction of
helpers, see Carrying the Stretcher in
this manual.
 Follow standard emergency patient-
handling procedures when using the
stretcher.
 Stay with the patient at all times.
Three-Bar
Buckle Webbing,
Free End Webbing, Looped End
Webbing,
Looped End Two-Bar Buckle
Break-Away
Pull-Tab
Figure 1, Components
Three-Bar
Buckle Two-Bar Buckle Webbing, Free-End
Break-Away
Pull-Tab
Figure 2, Fastening the Buckle
Figure 3, Seating the Buckles
Webbing
Free-End
Two-Bar
Buckle
Three-Bar
Buckle
Break-Away
Pull-Tab
Figure 4, Loosening Restraint
Figure 5, Unfastening Buckle Figure 6, Restraint Cove Figure 7, Passing
Looped End Through
Cove
Figure 8, Threading Buckle

Page 5 of 8
 Always use the patient restraints provided, as well as a
supplimentary restraining system as per your training and
team protocols, and the situation.
 Personnel using the stretcher in high-angle environments
are responsible for learning the the proper techniques
involved, and for selecting the equipment and procedures
best ssuited to the rescue situation.
5.3 Carrying the Stretcher
Carrying the stretcher requires a minimum of two operators.
Additional personnel will be helpful or even needed in most
situations. Use an even number of personnel and position them
to keep the stretcher as even as possible.
Using Additional Help
Operators should maintain control of the stretcher and direct any
helpers.
5.4 Sliding the Stretcher
Slide the stretcher on its runners over smooth surfaces. Avoid
rock, stumps, branches or other hazards that could penetrate
the netting, or cause discomfort or injury to the patient.
5.5 Transporting the Stretcher
on a Cot
Use the cot restraints to secure the stretcher to the cot.
5.6 Using High-Angle Rescue
Procedures
High angle and rope-access rescue can involve any
combination of ropes, winches, pulleys, litter bridles, belay
devices any many other specialized items and devices too
numerous to mention. Proper and safe use of these tools
requires professional instruction and training.
When using high-angle or rope-access equipment with the
stretcher, ensure the equipment has an adequate load-rating,
and that it is at least as great as that of the stretcher.
During a high-angle rescue, the stretcher may be oriented
vertically, horizontally or in other positions. Secure the patient in
the stretcher so that he/she does not slip in any direction, or be
able to accidentally come out of the stretcher.
Tie-In Points
The Stretcher has several Tie-In points where carabiners or
ropes may be attached to the upper rail. In addition, This
stretcher has incorporated into it a patent StrātLoad™ feature
which allows for dedicated attachment points when being rigged
with a four-point litter-bridle for a horizontal raise or lower.
5.7 Using Split-Apart Feature
The Traverse Split-Apart stretchers offer very fast assembly
time, and there are no pins to place etc. Before starting, be sure
to clean all parts of dirt, mud, snow etc. To assemble:
1. Face the two open parts of stretcher toward each other
2. Lift the open ends simultaneously to about a 30° angle, and
slide the two parts together, interlocking all of the teeth of
the Bottom Connectors.
3. Lower the now-inter-locked parts to the floor
4. Ensure Upper Connector parts mate
5. Turn Collets onto the opposing threaded parts of the Upper
Connectors. Ensure these Collets are snug, and that there
are no threads showing.
To disassemble, simply reverse the above sequence
Please Note: It is imperative that throughout the operation
of this stretcher during a rescue or in practice, that you
check the integrity of the connection. If you see threads on
the Upper Connector, re-tighten the collets.
Lower Connector, Teeth Interlocked
Collet
Threaded Upper-
Connector Part
Fully Connected

Page 6 of 8
6. Maintaining The Stretcher
6.1 Maintenance Schedule
The stretcher requires regular maintenance. Set up and follow a
maintenance schedule, such as provided by the form below.
This form represents minimum maintenance, and you can modi-
fy your own program based on your needs.
When using maintenance products, follow the manufacturers’
directions and read the manufacturers’ material safety data
sheets.
6.2 Disinfecting and Cleaning
the Restraints
1. Remove restraints from stretcher.
2. Buckle restraints before cleaning. This helps prevent dam-
age to buckles or washing machine.
3. Place buckled restraints inside a mesh bag (not supplied)
and place in an industrial washing machine.
4. Launder restraints in warm water, using a disinfectant soap
and gentle agitation. Do not use bleach.
5. Remove restraints from mesh bag and hang to dry. Do not
put restraints into dryer.
6. Attach clean, dry restraints to stretcher as instructed in
Section 4.
6.3 Disinfecting and Cleaning
the Stretcher
Wipe or spray all surfaces of stretcher and netting with disinfect-
ant. Follow disinfectant manufacturers’ directions.
Traverse recommends inspecting the stretcher for obvious dam-
age as you disinfect it.
Hand clean the stretcher and netting with a mild detergent in
warm water. Rinse well, and dry with a towel.
6.4 Inspecting the Stretcher
Have your stations/services’ maintenance personnel check the
following:
 All components should be present
 Weld joints should be free of cracks or any other sign of
breakage
 Stretcher frame (top and lower rails, runners, ribs) should
be free of dents, cracks or un-intentional bends
 Durathene® netting should be free of breaks and tears, and
should be securely fastened to the lower rail.
 Yellow back support should be securely fastened into place
 Warning labels should be clear and legible for all users to
see and read.
 Restraint webbing should be in good condition with no cuts
or frays
 Restraint buckles should be free of visible damage, and
should operate properly.
If inspection shows damage or excessive wear, remove the
stretcher from service until appropriate repairs are completed
(see Repair, Parts and Service, Section 7).
6.5 Storing the Stretcher
Store the stretcher in a dry area. Make sure the stretcher is
clean and dry before placing it into storage.
Each Use
As Needed Each Month
Disinfecting (See 6.3) •
Cleaning (See 6.3) •
Inspecting (See 6.4) ••

Page 7 of 8
If your stretcher is showing excessive wear or cracks (either in
the material or at welds), it is time to retire it from service. Do
not attempt to repair or replace any metal component or weld.
If the Mesh Liner, the Back Support, Patient Restraint straps or
any labels are damaged and need repair, please call your
Dealer or us to have them replaced.
See the table below for further description
Related Products
7. Repair, Parts and Service
Part Number Description
15-0108 Hard-Eye Litter Bridle
15-0109 Soft-Eye Litter Bridle
11-0110 Mule Litter Wheel
17-0100 Fastrap Restraint System
17-0105 Quick-Connect Restraint Straps
15-0140 Stretcher Handle
Part Number Description
16-0100 540°™ Rescue Belay-Large
16-0200 540°™ Rescue Belay-Small
Traverse Rescue, LLC (Traverse) Limited Warranty
All Traverse Rescue, LLC products are warranted for a
period of one year after the date of invoice, to the original
purchaser. This warranty is provided against any material
or workmanship flaws or defects. In the event of such a
flaw or defect during this warranty period, please contact
Traverse immediately. Traverse Rescue agrees to repair
or replace (at our choice) the defective product. Our Lim-
ited Warranty does not cover damage due to abuse, mis-
use, lack of care, improper use or accidents. It also does
not cover damage due to attempted repair by the purchas-
er that was not authorized by Traverse Rescue, LLC. No
other warranties exist or are implied by Traverse. This lim-
ited warranty excludes, and Traverse shall not be held liable for
any punitive, incidental, special or exemplary damages arising
out of the breach of the warranty on sales by Traverse Rescue,
LLC or otherwise, or through the performance or non-
performance of any third-party part, products, service or sys-
tem. This limited warranty does not limit in any way, nor alter
in any way, other manufacturer’s warranties on products that
are sold by Traverse Rescue, LLC.
8. Limited Warranty
9. Traverse Rescue Customer Care
Customer Care and product support are important aspects of
each Traverse product.
For assistance with this, or any other Traverse Rescue prod-
uct, please contact Traverse Customer Care.
Please have the serial number of your Traverse stretcher avail-
able when calling Traverse Customer Care, and include this
number with any written communications
Traverse Rescue, LLC.
755 Queensway East, Unit 8
Mississauga, Ontario
Canada L4Y 4C5
Telephone: …………………..........................905 279 7866
Toll Free (Canada & US): .........................1 866 998 7866
Fax : .............................................................905 615 1367
Email: [email protected]
Web site: www.traverserescue.com
Part Number Description
05-0102 Full Back Support
05-0103 Split Back Support, Regular
05-0104 Split Back Support, Tapered
05-0125, Reg Mesh, Titan Regular
05-0125, RS Mesh, Titan Split-Regular
05-0125, TAP Mesh, Titan Tapered
05-0125, TS Mesh, Titan Split Tapered
04-0108 Restraint Strap
08-0102 Load-Limit Label
05-0116 Mesh, Titan 32
Accessories
Traverse offers a full line of accessories that are approved for
use with the Titan Series stretchers.
Always follow the instructions packaged with accessories. Keep
the instructions with this manual. Be aware of any special con-
siderations (loading heights, door heights, etc.)

Page 8 of 8
Training Schedule
Date Name Training Method
Maintenance Record
Date Maintenance Performed By
