Ferno SAERBAG III User manual

Users’ Manual
Rescue Bag for patient lifting and transport
SAERBAG III
February 2017
Pub. N° MU-094-D
Read this manual
carefully and retain
it for future reference

2© Ferno Washington Italia MU-094-D February 2017
SAERBAG III
© Copyright Ferno Washington Italia s.r.l. All rights reserved.
SAERBAG III serial number ________________________
Location: Main label positioned at the foot area.
USERS’ MANUAL
To request additional free user manuals,
contact Ferno Washington Italia Customer
Relations.
Ferno Technical Support
Customer relations and technical support are important aspects of
each Ferno product. Please have the product serial number available
when calling, and include it in all written communications. For
technical support questions, contact Ferno Washington Italia s.r.l.:
Telephone (Freephone) 800 501 711
Fax [phone]
E-mail [email protected]
Ferno Customer Relations
For service or further information, contact Customer Relations,
Ferno Washington Italia s.r.l.:
MANUFACTURER
Ferno Washington Italia s.r.l., Via Benedetto Zallone 26
40066 - Pieve di Cento (BO) - ITALY
Telephone (Freephone) 800 501 711
Telephone [phone]
Fax [phone]
Internet www.ferno.it
Disclaimer
This manual contains general instructions for the use, operation and
care of this product. These instructions do not cover all possible
applications and operations. Safe and proper use of this product is
solely at the user’s discretion. Safety information is provided for
the user and only ensures the minimum level necessary to avoid
injury to operators and patients. All other safety measures taken
by the user should be within and under consideration of applicable
regulations. Operators must be trained before using this product.
Retain this manual for future reference. Include the manual with
the product in the event of transfer to a new user. Additional free
copies are available upon request from Ferno Washington Italia
Customer Relations.
Proprietary Notice
The information disclosed in this manual is the property of Ferno
Washington Italia s.r.l. - Via Benedetto Zallone 26, 40066 Pieve di
Cento (BO).
Ferno Washington Italia s.r.l. reserves all patent rights, proprietary
design rights, manufacturing rights, reproduction rights, use rights,
and sales rights related to any article in this manual, except to the
extent that those rights are expressly granted to others or where
not applicable to vendor proprietary parts. This manual may
not be reproduced either in whole or in part without the express
authorization of Ferno Washington Italia s.r.l.
Limited Warranty Statement
Ferno products are covered by a 24-month warranty against
manufacturing defects. For complete terms and conditions of the
warranty, and the limitations of liability and disclaimers, consult
chapter Warranty, page 32.

3
© Ferno Washington Italia MU-094-D February 2017
SAERBAG III
TABLE OF CONTENTS
Chapter/Paragraph Page Chapter/Paragraph Page
Ferno Technical Support _______________________ 2
Ferno Customer Relations _____________________ 2
1 - Safety Information___________________________ 4
1.1 Warning________________________________ 4
1.2 Important_______________________________ 4
1.3 Bloodborne Disease ______________________ 4
1.4 Load capacity ___________________________ 4
1.5 Compatibility____________________________ 4
1.6 Symbol Glossary_________________________ 5
1.7 Information and Safety Labels ______________ 5
2 - Operator Skills and Training __________________ 6
2.1 Skills __________________________________ 6
2.2 Training________________________________ 6
3 - The Rescue bag _____________________________ 6
3.1 Description _____________________________ 6
3.2 CE Conformity __________________________ 6
3.3 Components (Rescue bag) _________________ 7
3.4 GeneralTechnicalSpecications ____________ 8
4 - Rescue bag conguration _____________________ 9
4.1 Adjusting the length ______________________ 9
4.2 Straps_________________________________ 10
4.3 Applying the straps________________________12
4.4 The cover______________________________ 15
4.5 Lifting bridle ___________________________ 15
4.5.1 Lifting bridle shortening system _________ 16
4.6 EARS anti rotation sail ___________________ 17
4.7 Anti rotation tag-line links ________________ 19
4.7.1 Top release systems __________________ 19
4.8 Securing straps ________________________ 22
4.9 Lifting Handles_________________________ 22
4.10 Monitor cable access ____________________ 22
5 - Using the rescue bag ________________________ 23
5.1 Before using the rescue bag _______________ 23
5.2 Instructions for use ______________________ 23
5.3 Preparing the rescue bag __________________ 24
5.4 Using the rescue bag as a chair _____________ 26
5.5 Rescuing the patient from a rock face _______ 26
6 - Maintenance _______________________________ 27
6.1 Routine Maintenance ____________________ 27
6.2 Disinfection____________________________ 27
6.3 Cleaning ______________________________ 27
6.4 Inspection _____________________________ 28
6.5 Storage________________________________ 29
7 - Accessories ________________________________ 31
7.1 SAERBAG III Accessories _______________ 31
7.2 SAERBAG III Models___________________ 31
8 - Technical Support __________________________ 31
8.1 Technical Support _______________________ 31
9 - Warranty _________________________________ 32
9.1 Warranty Conditions _____________________ 32
9.2 Disclaimers ____________________________ 32
9.3 Warranty Requests ______________________ 33
9.4 Complaints ____________________________ 33
9.5 Authorization for Returns _________________ 33
Training Record ______________________________ 34
Maintenance Record___________________________ 35

4© Ferno Washington Italia MU-094-D February 2017
SAERBAG III
1.4 Load capacity
Respect the SAERBAG III load capacity. See paragraph 3.4
General Technical Specications, page 8.
1  SAFETY INFORMATION
Safety Information
Read this Users' Manual carefully. It is an integral part of
the device and must always be readily available. For your
own personal safety and that of the patient, please observe
the following:
– Before each use, inspect the device carefully to ensure it
is not worn, damaged or malfunctioning. See paragraph 6.4
Inspection, page 28.
– To avoid infection or bacterial contamination, follow
instructions in paragraphs 6.2 and 6.3, Disinfection and
Cleaning, page 27.
1.1 Warning
Warning notices indicate a potentially hazardous situation
which, if underestimated, could result in accident, damage
or injury.
WARNING
Untrained operators may injure themselves and/or cause damage
or injury. Only trained, qualied operators should be allowed to use
the Saerbag.
Improper use of the rescue bag may cause damage or injury. Use the
Saerbag as shown in this manual.
Unauthorized modications to the Saerbag may cause serious
damage, injury or unforeseen operative problems. Do not modify or
alter the rescue bag in any way.
Any damage to the rescue bag components or the whole system may
aect its performance and safety. Inspect the rescue bag frequently
and especially before and after each use. Do not use the rescue bag
if it appears worn or damaged.
Unattended patients may injure themselves. Never leave a patient
in the rescue bag unattended. Always attend to the patient during
rescue operations.
Incorrect use of the straps can cause the patient to fall and be
injured. Always use the restraint straps as instructed in this manual.
Improper use of the rescue bag can cause injury. Use the rescue bag
only as described in this manual.
Before any rescue operation, ensure that the load is evenly
distributed on the Saerbag lifting bridle arms.
Untrained helpers may cause damage and/or injury or hurt
themselves. Do not allow untrained helpers to prepare the rescue
bag. Take the utmost care during all operations.
Inadequate maintenance may cause serious damage or injury. Carry
out maintenance as described in this manual.
The use of improper or unauthorized devices may cause accidents,
damage or injury. Use only devices approved and authorized by
Ferno W. Italia.
1.2 Important
Boxes with the word “Important” contain important
information on the use and maintenance of this device.
Important
1.3 Bloodborne Diseases
To reduce the risk of infective bloodborne diseases, like
HIV-1 or hepatitis, scrupulously follow the disinfecting and
cleaning instructions in this manual.
WARNING
Repairs carried out by technicians not authorized by Ferno W.
Italia will render any type of warranty void and may make any
operation involving the rescue bag dangerous.
Non-original parts and inadequate technical support may cause
damage or injury. Use only original Ferno parts and contact
Ferno W. Italia Technical Support.
1.5 Compatibility
The rescue bag should be used with the Ferno SCOOPEXL™
stretcher, the Ferno Millennia backboard and with Ferno
vacuum mattresses.
Any other combination, that does not include Ferno products,
has to be used by the user after necessary verication of
the absolute compatibility with the rescue bag and the
compliance with the norm EN 1865.
Ferno Washington Italia will not be held responsible for
injury to operators or third parties caused by improper use
of the Saerbag III.

5
© Ferno Washington Italia MU-094-D February 2017
SAERBAG III Safety Information
1.7 Information and Safety Labels
The information and safety labels provide important information that the user must be aware of.
Read and follow label instructions. Replace worn or damaged labels immediately. To request new labels, contact Ferno
Washington Italia Customer Service (page 2). The label shown below is applied to the rescue bag.
Main Label
1.6 Symbol Glossary
The following symbols are present in this manual and/or on the rescue bag label. The rescue bag and this manual both carry
the CE marking.
Read the Users’ Manual
carefully
This product meets
European Union
Standards
Load capacity (in kilos and
pounds)
Do not clean with high
pressure water
Manufacturer
MAX
160 kg
352 lb
QR Code

6© Ferno Washington Italia MU-094-D February 2017
SAERBAG III
Training/The Rescue Bag
3.2 CE Conformity
MEDICAL DEVICES DIRECTIVE
Ferno products meet the requirements of
European Directive 93/42/CEE concerning
medical devices. The rescue bag belongs to
Class I.
The rescue bag has been tested according EASA CS 29.865
a), amdt. III.
2  OPERATOR SKILLS AND TRAINING
2.1 Skills
Operators using the rescue bag must have:
● Specic experience of patient-handling and rescue
procedures.
● The ability to assist the patient.
● The necessary qualication according to current
regulations for helicopter rescue operations.
2.2 Training
Operators should:
● Carefully read and understand all the information in
this manual.
● Undergo adequate training in the use of the rescue bag.
● Practice with the rescue bag before using it in a real
situation with a patient.
WARNING
Untrained operators may injure themselves and/
or cause damage or injury. Only trained, qualied
operators should be allowed to use the SAERBAG.
3  THE RESCUE BAG
3.1 Description
The SAERBAG III lift and rescue bag (simply called “the
rescue bag” for short in this manual) is a device for patient
rescueandtransportinadifcultenvironment.
The rescue bag must be used by trained and qualied
operators. Additional assistance may be needed for heavy
patients and/or if the situation requires it, according to
local health protocol. It allows an immobilized patient to
be transported on a Ferno SCOOPEXL stretcher, a Ferno
Millennia backboard or a Ferno vacuum mattress and
to be rescued using a winch and/or ropes in a difcult
environment, thanks to its special integrated lifting bridle.
It can be used for rescue with a winch from a rotary wing
aircraft, according to the winch use procedures.
The rescue bag has 4 adjustable straps to correctly
immobilize the patient. The two upper torso straps must be
crossed; the leg strap must be fastened horizontally and the
footstrapmustbefastenedina“8”gure.
WARNING
Improper use of the rescue bag may cause damage
or injury. Use the SAERBAG as shown in this manual.
RESCUE BAG COMPONENTS
● Mylar cover to monitor the patient
● Safety straps with metal buckle (4): upper torso straps
(2), leg strap and foot strap
● Lateral red lifting handles (6)
● Anti rotation tag-line links (6)
● EARS lateral anti rotation sails (2)
● Integrated lifting bridle for rescue
● Lifting bridle central lifting rings (2)
● Lifting bridle shortening system (with 4 loops)
● Inner rescue bag length adjustment system (with 2
straps)
● Inner straps to stabilize the stretcher/backboard (6)
● Lateral access for monitor cables
STANDARD ACCESSORIES SUPPLIED
● Transport and storage rescue bag (1 standard supply)
● Users’ Manual
● Maintenance handbook (The Service Book)
● Record training sessions. An example of the training
session record form is shown on page 34.
Important
Operators must be able to ensure their own safety and that
of the patient while using the rescue bag. Technical Rescue
procedures require special skills and are potentially hazardous
activities. No rescue personnel should attempt technical rescue
procedures unless they have received professional instruction
and training.

7
© Ferno Washington Italia MU-094-D February 2017
SAERBAG III The Rescue bag
3.3 Components(Rescue Bag)
FRONT VIEW
HEAD SIDE
FOOT SIDE
Torso Straps (2)
Leg strap
EARS lateral anti rotation
sail (2)
Foot strap
Anti rotation tag-line links
(6)
Integrated lifting bridle with
central lifting rings (2)
Monitor cable access
Lateral red lifting
handles (2)
Mylar cover Straps to secure the
immobilization device (6)
Length Adjustment
System (2)
Velcro fastening at head
side (2)
Velcro fastening
at foot side
Patient body Velcro
fastening
HEAD SIDE
FOOT SIDE

8© Ferno Washington Italia MU-094-D February 2017
SAERBAG III
The Rescue bag
3.4 General Technical Specications
Ferno reserves the right to change specications without
notice. For further information, contact Ferno Customer
Relations (page 2).
Maximum length 2000 mm
Minimum length 1450 mm
Width 600 mm
Weight 5 kg
Load Limit 160 kg
* Note: the weight includes straps, lifting bridle and all rescue bag
components.
Load Limit
Never exceed the Saerbag load
limit. Inspect the rescue bag if
the load limit has been exceeded
(see paragraph 6.4 Inspection, page 28).
WARNING
Untrained operators may injure themselves and/
or cause damage or injury. Only trained, qualied
operators should be allowed to use the SAERBAG.
WARNING
Do not exceed the load limit of the rescue bag
shown in this manual.
To request additional free users'
manuals, contact Ferno Washington
Italia Customer Relations (page 2).
USERS' AND
MAINTENANCE
MANUAL
MAX
160 kg
352 lb
Technical Rescue
The SAERBAG III is used to transport
a person during rescue. Specialized
training is required for use.
MAX
160 kg
352 lb
WARNING
Check the load limit of the devices used to lift the
Saerbag III. Never exceed the lower load limit of
devices used for lifting.

9
© Ferno Washington Italia MU-094-D February 2017
SAERBAG III Rescue Bag Conguration
4  RESCUE BAG CONFIGURATION
4.1 Length Adjustment
The Saerbag III has an internal length adjustment system
(Figure 1). This system allows the rescue bag to be adapted
to the patient immobilization device placed inside. It has two
straps on both sides of the rescue bag that can be adjusted
by the operator.
Adjust the rescue bag to the length of the immobilization
device inside when preparing it for use and before any
rescue operation.
Figure 1 – Internal length adjustment system
Figure 2 – Inserting the head area Figure 3 – Inserting the foot area
ADJUSTING THE LENGTH
To adjust the rescue bag length:
1. Place the immobilization device in the rescue bag. First insert the head area (Figure 2) then the foot area (Figure 3) of the
SCOOPEXL stretcher/backboard.
2. After having placed the immobilization device in the rescue bag correctly, pull the inner straps (on the right and left) towards
the head side of the rescue bag to adjust the length of the rescue bag to the SCOOPEXL stretcher/backboard (Figure 4, 5).
3. Ensure that the rescue bag is correctly adjusted to the length of the device used.
Figure 4 – Rescue bag length adjustment Figure 5 – Adapting the rescue bag length to the
SCOOPEXL stretcher

10 © Ferno Washington Italia MU-094-D February 2017
SAERBAG III
4.2 Straps
The rescue bag has two upper torso straps, one leg strap and
a foot strap (Figure 6).
The two upper torso straps must be crossed; the leg strap
must be fastened horizontally and the foot strap must be
fastened in a “8” gure. Straps can be adjusted in both
directions (right and left).
Fasten all straps before using the rescue bag. Adjust the
straps properly so they do not constrict the patient. Ensure
you have fastened and secured the straps correctly before
any rescue operation.
LENGTHENING THE RESCUE BAG
To open the rescue bag to its original length, pull the buckles of the inner straps (on the right and left) in the opposite direction
(towards the foot area of the rescue bag).
Figure 6 – Using the straps
SECURING THE STRAPS
Each strap has two buckles: a large one and a small one (Figure 7).
To secure the straps:
1. Take the small buckle in one hand and the large one in the other (Figure 7).
2. Insert the small buckle in the large one (Figure 8, 9).
Figure 7 – Small and large strap buckles Figure 8 – Placing the small buckle in the large one
3. Place the small buckle on the large one so that the strap is secured correctly (Figure 10).
Figure 9 – Placing the small buckle in the large one Figure 10 - Strap Secured Correctly
Rescue bag Conguration

11
© Ferno Washington Italia MU-094-D February 2017
SAERBAG III Rescue Bag Conguration
ADJUSTING THE STRAPS
Once the strap has been applied and secured correctly, it should be adjusted. To adjust the straps:
1. Once the strap has been secured correctly, take the free end of the strap and pull the red tab through the buckle to adjust it to
the correct length. (Figure 11).
2. Ensure that the straps are correctly adjusted and do not constrict the patient before any operation.
Figure 11 – Adjusting the straps
UNDOING THE STRAPS
To undo the straps:
1. Lift the small buckle (Figure 12).
2. Unhook the small buckle by passing it through the large buckle (Figure 13).
Figure 12 – Lifting the small buckle Figure 13 – Unhooking the small buckle
Important
Before rescue, ensure that any excess strap length has
been secured in order not to hamper operations.
Important
Before any rescue operations ensure that the patient is
secured by the rescue bag straps AND by the strap of
the immobilization device.

12 © Ferno Washington Italia MU-094-D February 2017
SAERBAG III
4.3 Applying the straps
TORSO STRAPS
Figure 15 – Placing the small buckle in the large one Figure 16 - Placing the small buckle in the large one
Figure 17 – Adjusting the strap Figure 18 -Torso straps correctly applied
To apply the torso straps:
1.Place(Figure15)thesmallbuckleofthersttorsostrapontheleftoftherescuebag(3,Figure14)inthelargebuckleofthe
rsttorsostrapontherightoftherescuebag(1,Figure14).
2. Follow instructions in “Securing the straps”, page 10.
Torso straps are positioned so that they can be crossed easily
by the operator.
Torso straps are numbered in this manual to make application
easier (Figure 14). They are numbered clockwise (from the
operator’s point of view).
3. Place the small buckle of the second torso strap on the left of the rescue bag (4, Figure 14) in the large buckle of the second
torso strap on the right of the rescue bag (2, Figure 14). Fasten the strap by following instructions in “Securing the straps”, page
10, and position it so that the two torso straps are crossed.
4. Adjust the straps (Figure 17). To adjust the straps see “Adjusting the straps”, page 11.
Figure 14 -Torso Strap Numbers
1 2
34
Rescue bag Conguration

13
© Ferno Washington Italia MU-094-D February 2017
SAERBAG III Rescue Bag Conguration
FOOT STRAP
To apply the foot strap:
1. Fasten the foot area with the Velcro fastenings (Figure 21).
2. Insert the sides of the foot area into the rescue bag (Figure 22). Always close the foot area before applying the foot strap.
LEG STRAP
To apply the leg strap:
1. Hold the strap with the large buckle (right side, operator’s point of view) and the part of the strap with the small buckle (left
side, operator’s point of view).
2. Follow instructions in “Securing the straps”, page 10.
3. Adjust the straps (Figure 19).
4. Tuck in the excess of the straps using the integrated elastics. Ensure that any excess strap length has been secured in order
not to hamper rescue operations.
Ensure that the straps are applied correctly so that the patient is secure inside the rescue bag.
Figure 19 – Adjusting the straps Figure 20 –Leg strap correctly applied
Figure 21 - Closing the foot area Figure 22 - Closing the foot area
5. Tuck in the excess of the straps using the integrated elastics. Ensure that any excess strap length has been secured in order
not to hamper rescue operations. Ensure that the straps are applied correctly so that the patient is secure inside the rescue bag.

14 © Ferno Washington Italia MU-094-D February 2017
SAERBAG III
3. Follow instructions in “Securing the straps”, page 10.
4.Afterhavingfastenedthestrap,stretchittoitsfullestlengthtomakeiteasiertocreatea“8”gure.
5.Crossthestraptoforma“8”gure(Figure23).
6. Apply it to the foot area to ensure the patient’s feet are secured correctly (Figure 24).
Figure 23 - Crossing the foot strap Figure 24 – Applying it to the foot area
7. Adjust the strap to secure the foot area (Figure 25). To adjust the straps see “Adjusting the straps”, page 11.
8. Tuck in the excess of the straps using the integrated elastics. Ensure that any excess strap length has been secured in order
not to hamper rescue operations.
Ensure that all the straps are applied correctly so that the patient is secure inside the rescue bag.
Figure 25 – Adjusting the foot strap Figure 26 – Foot strap correctly applied
Important
Observe the following when using the rescue bag:
● SAERBAG III is designed to lift and rescue a person
secured on an immobilization device (maximum
load 160 kg).
● Check that ALL straps have been fastened as
shown in this manual:
● Torso Straps (2)
● Leg strap
● Foot strap
Rescue bag Conguration

15
© Ferno Washington Italia MU-094-D February 2017
SAERBAG III
4.4 The cover
The rescue bag has a semi-rigid Mylar cover with 3 windows:
one at the front and two at the sides (Figure 27, 28).
These allow the operator to monitor the patient and offer
greater comfort during rescue operations.
Ensure that the cover is closed using the Velcro fastenings
and secured with the two torso straps before any rescue
operation (Figure 27).
4.5 – Lifting bridle
The rescue bag has an integrated lifting bridle (Figure 29).
The lifting bridle has 10 arms (5 per side) and two central
lifting rings that karabiners must be attached to before any
rescue operation.
It has a shortening system with 4 integrated red loops on the
outer arms of the lifting bridle (on the right and left), that
ensure correct load distribution if the rescue bag has been
shortened to adapt it to the length of the immobilization
device inside. For the shortening system see paragraph 4.5.1
“Lifting bridle shortening system”, page 16.
Figure 27 - Mylar cover (front view)
Figure 29 – Integrated lifting bridle
Figure 28 - Mylar cover (side view)
Rescue Bag Conguration

16 © Ferno Washington Italia MU-094-D February 2017
SAERBAG III
4.5.1 Lifting bridle shortening system
The lifting bridle shortening system ensures a correct and
adequate distribution of load on the arms of the lifting bridle
if the rescue bag has been shortened to adapt it to the length
of the SCOOPEXL stretcher inside.
The red loops of the lifting bridle shortening system are
positioned on the outer arms of both sides of the lifting
bridle (right and left, Figure 30).
Figure 30 – Lifting bridle shortening system
Shown by the arrows: red loops
To shorten the lifting bridle :
1. Use the red loops sewn on the outer arms of the lifting bridle (Figure 30).
2. Place correctly sized karabiners in the loops (Figure 31).
3. Attach both karabiners to the central ring (Figure 31).
4. Carry out the same operation on the lifting bridle arms on the opposite side (Figure 32A).
Use the loops of the lifting bridle shortening system to ensure the arms are correctly positioned during rescue operations.
Figure 31 - Karabiners connected to loops and the
central ring
Figure 32 - A: Karabiners connected correctly on both
sides
B: Lifting bridle shortening system
Rescue Bag Conguration
Red loops
32A
32B

17
© Ferno Washington Italia MU-094-D February 2017
SAERBAG III
4.6 EARS anti rotation sail
The rescue bag has two EARS anti rotation sails (Figure
33). The EARS anti rotation sails control rotations caused
by the movement of the helicopter during rescue operations.
They are positioned in the foot area on both sides of the
rescue bag and are stored in pockets on the sides of the
rescue bag. The sails have an orange handle outside the
pocket.
Always leave the handle visible and easily reachable for the
operator by fastening it with Velcro to the outside of the
pocket. Figure 33 – EARS, anti rotation sails
TAKING OUT THE SAIL
1. Hold the orange handle (Figure 34).
2. Pull the handle outwards so the sail comes out completely (Figure 35).
Figure 34 - EARS anti rotation sail handle Figure 35 – Taking out the EARS anti rotation sail
PUTTING THE SAIL BACK
1. Open the pocket.
2. Fold the sail in a concertina shape inside the pocket (Figure 36 e 37).
Figure 36 – Placing the sail in the pocket
36A 36B
EARS anti
rotation sail
Handle
Rescue Bag Conguration

18 © Ferno Washington Italia MU-094-D February 2017
SAERBAG III
Figure 37 – Completing the insertion of the sail in its pocket
3. Once completely inserted, attach the handle to the Velcro fastenings on both sides (Figure 38).
Figure 38 - Securing the handle to the Velcro
4. Close the pocket with the Velcro fastening, leaving the handle outside (Figure 39).
Figure 39 - Closing the pocket
Keep the two EARS sails in the pockets when not in use.
37A 37B
38A 38B
Technical Rescue
Technical Rescue procedures require special skills
and are potentially hazardous activities. No rescue
personnel should attempt technical rescue procedures
unless they have received professional instruction and
training.
Rescue Bag Conguration

19
© Ferno Washington Italia MU-094-D February 2017
SAERBAG III
4.7 Anti rotation tag-line links
The rescue bag has 6 anti rotation tag-line links at the head,
sides and foot area of the rescue bag (see paragraph 3.3
Components (Rescue bag), page 7).
Among the 6 links there are two top release systems on both
sides of the rescue bag in the foot area (Figure 40).
4.7.1Top release systems
The two lateral release systems allow the operator to undo
the tag line at any time without a fuse system. Figure 40 – Top release system
Both systems are positioned in the foot area (after the EARS
sails) on both sides of the rescue bag. They have a red
handle.
Each system has (Figure 41):
1. a red handle,
2. a green string,
3. a strap, with:
○two differently-sized rings (a small one and a large
one) sewn on,
○an eyelet in the strap
○a white loop.
Prepare the top release system before use.
PREPARING THE SYSTEM
1. Position the connector between the two rings sewn onto the strap (Figure 42).
2.Flipthelargeringoverthesmallonesothatthesmallringisinsidethelargeoneandtheconnectorisxedbetweenthetwo
rings (Figure 43).
Figure 41 – Top release system components
Handle
Green string
Strap
Figure 42 – Positioning the connector
between the two rings
Figure 43 – Securing the connector
between the two rings
Rescue Bag Conguration
Top
release
system

20 © Ferno Washington Italia MU-094-D February 2017
SAERBAG III
3. Flip the small ring over the large ring to line up with the eyelet hole (Figure 44).
4. Take the white loop and place it inside the small ring and eyelet (Figure 45).
Figure 44 – Flipping the small ring over the large one Figure 45 – Placing the loop in the small ring and eyelet
Figure 46 – Placing the green string in the loop Figure 47 – Replacing the green string in the pocket
5. Take the green string and place it in the loop coming out at the back of the strap (Figure 46).
6. Replace the green string in its pocket (Figure 47).
Check that each step has been carried out correctly and that the system is ready for use. After having prepared the system, check
that it will hold. To check that it will hold, pull the connector from the opposite part of the system. If the system does not undo
and the connector remains secured correctly, then it is ready for use.
Figure 48 – Top release system correctly prepared
Rescue Bag Conguration
Pocket
