Fisher-Price GeoTrax Transportation System R6357 User manual

1
www.fisher-price.com
Please keep this instruction sheet for future reference, as it contains important information.
Requires six “AAA” alkaline batteries (not included) and six button cell
batteries (included) for operation.
Adult assembly is required.
Tool required for assembly: Phillips screwdriver (not included).
R6357

2
Consumer Information
FCC Statement (United States Only)
This equipment has been tested and found
to comply with the limits for a Class
B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses and can
radiate radio frequency energy and, if not
installed and used in accordance with the
instructions, may cause harmful interference
to radio communications. However, there is
no guarantee that interference will not occur
in a particular installation. If this equipment
does cause harmful interference to radio or
television reception, which can be determined
by turning the equipment off and on, the user
is encouraged to try to correct the interference
by one or more of the following measures:
Reorient or relocate the receiving antenna.
•
Increase the separation between the•
equipment and receiver.
Consult the dealer or an experienced
•
radio/TV technician for help.
Note: Changes or modifications not expressly
approved by the manufacturer responsible for
compliance could void the user’s authority to
operate the equipment. This device complies
with Part 15 of the FCC Rules.
Operation is subject to the following two
conditions: (1) This device may not cause
harmful interference and (2) this device must
accept any interference received, including
interference that may cause
undesired operation.
Care
Wipe this toy with a clean, damp cloth.
•
Do not immerse the vehicles or
remote controller.
This toy has no consumer serviceable parts.
•
Do not take this toy apart.
Visit us on line at
www.service.fisher-price.com
Call our Consumer Relations Department,
toll-free at 1-800-432-5437. Hearing-impaired
consumers using TTY/TDD equipment, please
call 1-800-382-7470. Write to us at: Fisher-
Price®Consumer Relations, 636 Girard Avenue,
East Aurora, New York 14052.
For countries outside the United States:
CANADA: Questions? 1-800-432-5437.
Mattel Canada Inc., 6155 Freemont Blvd.,
Mississauga, Ontario L5R 3W2;
www.service.mattel.com.
GREAT BRITAIN: Mattel UK Ltd, Vanwall
Business Park, Maidenhead SL6 4UB.
Helpline: 01628 500303.
www.service.mattel.com/uk
AUSTRALIA: Mattel Australia Pty. Ltd., 658
Church Street, Locked Bag #870, Richmond,
Victoria 3121 Australia. Consumer Advisory
Service 1300 135 312.
NEW ZEALAND: 16-18 William Pickering Drive,
Albany 1331, Auckland.
ASIA: Mattel East Asia Ltd, Room 1106, South
Tower, World Finance Centre, Harbour City,
Tsimshatsui, HK, China.
ICES-003
This Class B digital apparatus complies with
•
Canadian ICES-003.
Operation is subject to the following two
•
conditions: (1) this device may not cause
harmful interference and (2) this device
must accept any interference received,
including interference that may cause
undesired operation.
NMB-003
Cet appareil numérique de la classe B est
•
conforme à la norme NMB-003 du Canada.
L’utilisation de ce dispositif est autorisée
•
seulement aux conditions suivantes : (1) il
ne doit pas produire de brouillage et
(2) l’utilisateur du dispositif doit être prêt
à accepter tout brouillage radioélectrique
reçu, même si ce brouillage est susceptible
de compromettre le fonctionnement
du dispositif.

3
Assembled Parts
Mountain
Bridge Track
Cafe Base
2 Canopies
2 Y-Tracks
2 Trestles
2 Ramp Tracks
3 Small Ramps
Cafe Wall
Cross Track
4 Curve Tracks
2 Long Straight Tracks
2 Guardrails
M3 x 10mm Screw - 4
Shown Actual Size
Tighten and loosen all screws with a Phillips screwdriver.
Do not over-tighten.
T-Track
2 Short Straight Tracks

4
Battery Installation
(Lightning McQueen and Remote Controller)
Lightning McQueen
Loosen the screws in the bottom of•
the vehicle. Remove the top of the
vehicle off of the chassis to access
the battery compartment. Insert three
“AAA” (LR03) alkaline batteries.
Replace the top of the vehicle and
•
tighten the screws.
Remote Controller
Locate the battery compartment on the•
bottom of the remote controller.
Loosen the screw in the battery compartment
•
door. Remove the battery compartment
door and insert three “AAA” (LR03)
alkaline batteries.
Replace the battery compartment door
•
and tighten the screw.
IMPORTANT! Under normal use conditions, the batteries in Lightning McQueen will require
replacement more often than the batteries in the remote controller.
1.5V x 6
“AAA” (LR03)

5
Battery Replacement
(Sheriff and Flo)
Sheriff and Flo
Loosen the screws in the bottom of each vehicle. Remove the top of each vehicle off of the•
chassis to access the battery compartment.
Remove the exhausted batteries and throw them away.
•
Insert three, new button cell (LR44)• alkaline batteries into each vehicle.
Replace the top of each vehicle and tighten the screws.
•
1.5V x 6
LR44 or equivalent
Notes:
We recommend using
• alkaline batteries for longer battery life.
When sounds, lights or movement become faint or stop, it’s time for an adult to change
•
the batteries.
If the vehicles or the remote controller operate erratically, you may need to reset the
•
electronics. Remove the batteries and replace them.
Protect the environment by not disposing of this product with household waste•
(2002/96/EC).Check your local authority for recycling advice and facilities
(Europe only).

6
Assembly
Mountain
Fit the mountain onto the bridge track. Push
•
to “snap” in place.
Fit the cafe wall into the cafe base.
• Turn the base over.•
Insert four screws into the base and tighten.•
1
4 5
Bridge Track
©Disney/Pixar
Disney/Pixar elements ©Disney/Pixar, not including underlying vehicles owned by third parties: Hudson Hornet™, Chevrolet Impala™,
Porsche™, Mercury™, and Jeep®. Sarge’s rank insignia design used with the approval of the U.S. Army
Fisher-Price, Inc., a subsidiary of Mattel, Inc., East Aurora, NY 14052 U.S.A.
©2009 Mattel, Inc. All Right Reserved. ® and ™ designate U.S. trademarks of Mattel, Inc., unless otherwise indicated.
PRINTED IN CHINA R6357a-0920
Cafe Base
Cafe Wall
CAUTION
This package contains small
parts in its unassembled state.
Adult assembly is required.

7
and Setup
Fit a guardrail onto each curve track,•
as shown.
Turn the base upright.
•
Insert the canopies and push to "• snap"
in place.
Hint: The canopies are designed to fit one
way. If they do not seem to fit turn them
around and try again!
At an angle, fit the tab on a trestle into
•
the slot on the underside of the mountain.
Push to “snap” in place.
Repeat this procedure to assemble the
•
other trestle to the mountain.
3
6
2Trestle Curve Track
Guardrail
Track pieces easily snap together.•
7
Canopies

8
Track Layout

9
All Aboard!
4-Position Remote Controller
➊FORWARD
(With Sound Effects)
➋FORWARD
➌OFF
➍REVERSE
➊ ➋➌➍
Hints:
If you do not operate the remote controller for a few minutes, Lightning McQueen shuts off
•
and the ready light turns off. Press the power button on Lightning McQueen and operate
the remote controller to restart.
This toy works best if you have a clear path between the remote controller and
•
Lightning McQueen.
Point the remote controller at Lightning McQueen. The maximum range of the remote
•
controller is about 12 feet (3.7 m).
Hint: We do not recommend using the engine on carpets. For best performance, use on the
track provided or hard, flat surfaces.
Place the vehicles on the track.•
Push down on Sherriff or Flo to hear fun phrases!•
Press the power button on top of the Lightning McQueen car. The ready light turns on.•
Hold the remote controller with the stick facing you. Point the remote controller toward the•
Lightning McQueen and push the stick forward. Lightning McQueen moves forward around
the track.
Pull the stick back a little to stop Lightning McQueen.
•
Pull the stick all the way back and Lightning McQueen travels in reverse. Release the stick•
to stop.
POWER BUTTONREADY LIGHT
LIGHTNING MCQUEEN

10
Troubleshooting
Lightning
McQueen
does not
respond to
the remote
controller
Vehicle drives
slowly
PROBLEM SOLUTION
Battery Safety Information
In exceptional circumstances, batteries may leak fluids that can cause a chemical burn injury
or ruin your toy. To avoid battery leakage:
Do not mix old and new batteries or batteries of different types: alkaline, standard
•
(carbon-zinc) or rechargeable (nickel-cadmium).
Insert batteries as indicated inside the battery compartment.
•
Remove batteries during long periods of non-use. Always remove exhausted batteries from•
the toy. Dispose of batteries safely. Do not dispose of the product in a fire. The batteries
inside may explode or leak.
Never short-circuit the battery terminals.
•
Use only batteries of the same or equivalent type, as recommended.•
Do not charge non-rechargeable batteries.•
Remove rechargeable batteries from the toy before charging.•
If removable, rechargeable batteries are used, they are only to be charged under•
adult supervision.
Battery power in the vehicle may be weak. Replace all three batteries
in the vehicle with fresh, alkaline batteries.
The wheels on the vehicle may be dirty. Wipe them with a clean cloth.
Battery power in the remote controller may be weak. Replace all
three batteries in the remote controller with fresh, alkaline batteries.
You may be beyond the maximum range of the remote controller,
which is about 12 feet (3.7 m).
You may not have a clear path between the remote controller and
the vehicle. This toy works best when there are no obstructions
between the vehicle and the remote controller.
Bright sunlight or fluorescent lights may affect the range of the
remote controller. Try dimming the room you are playing in.
The vehicle may have shut off. If you do not operate the remote
controller for a few minutes, the vehicle shuts off automatically and
the ready light turns off. Press the power button on the vehicle, and
operate the remote controller to restart.
