Fisher-Price GeoTrax User manual

2 3
www.fisher-price.com
Assembled Parts
Curved Track – 5
Straight Track – 4
Curved Elevation Track
Ramp Track with
Guardrails – 2
Shack
Upper MountainLower Mountain
Short Track – 2Small Trestle – 2
Large Trestle – 1
Easy Rail Station Station Track Piece
1,5V x 6
“AAA” (LR03)
Battery Installation
• Protect the environment by not
disposing of this product with
household waste (2002/96/EC).
Check your local authority for
recycling advice and facilities
(Europe only).
IMPORTANT! Under normal use conditions, the batteries in the vehicle will require
replacement more often than the batteries in the remote controller.
Remote Controller
• Locate the battery compartment on
the bottom of the remote controller.
• Loosen the screw in the battery
compartment door with a Phillips
screwdriver. Remove the battery
compartment door and insert three
“AAA” (LR03) alkaline batteries.
• Replace the battery compartment
door and tighten the screw with
a Phillips screwdriver. Do not
over-tighten.
• If this product begins to operate
erratically, you may need to reset
the electronics. Remove the batteries
and replace them in the toy.
Engine
• Locate the battery compartment on
the back of the engine.
• Loosen the screws in the battery
compartment door with a Phillips
screwdriver. Lower the battery
compartment door and insert three
“AAA” (LR03) alkaline batteries.
• Close the battery compartment door
and tighten the screws with a Phillips
screwdriver. Do not over-tighten.
• If this product begins to operate
erratically, you may need to reset the
electronics. Remove the batteries and
replace them in the toy.
Please keep this instruction sheet for future reference, as it contains important information.
Requires six “AAA” (LR03) alkaline batteries (not included).
Adult assembly is required.
Tool required for battery installation: Phillips screwdriver (not included)

456
Battery Safety Information Assembly and Setup
Shack
Fit the upper mountain and shack into the•
slots on the lower mountain. Push to “snap”
in place.
Track pieces easily snap together.•
“Snap”• the easy rail station onto the station
track piece.
“Snap”• a small trestle into the bottom of
a ramp track with guardrail.
Repeat this procedure to assemble the•
other small trestle to the other ramp track
with guardrail.
Upper
Mountain
Lower
Mountain
Small Trestle
Ramp Track
with Guardrails
BOTTOM VIEW
Easy Rail
Station
Station
Track Piece
Curved Track
Straight Track
Fit any track pieces onto the large trestle for•
added support.
Large Trestle
1
3
4
5
2
Consumer Information
Fisher-Price, Inc., a subsidiary of Mattel, Inc., East Aurora, NY 14052 U.S.A.
©2010 Mattel, Inc. All Right Reserved. ® and ™ designate U.S. trademarks of Mattel, Inc.
PRINTED IN CHINA V0420pr-0920
CO
N
S
UMER
ASS
I
S
T
A
N
C
E
1-800-432-5437 (US & Canada)
1300 135 312 (Australia)
Fisher-Price, Inc., 636 Girard Avenue, East Aurora, NY 14052.
Hearing-impaired consumers: 1-800-382-7470.
Outside the United States:
Canada: Mattel Canada Inc., 6155 Freemont Blvd.,
Mississauga, Ontario L5R 3W2; www.service.mattel.com.
Great Britain: Mattel UK Ltd, Vanwall Business Park,
Maidenhead SL6 4UB. Helpline: 01628 500303.
www.service.mattel.com/uk
Mattel Europa, B.V., Gondel 1, 1186 MJ Amstelveen, Nederland.
Australia: Mattel Australia Pty. Ltd., 658 Church Street,
Locked Bag #870, Richmond, Victoria 3121 Australia.
New Zealand: 16-18 William Pickering Drive,
Albany 1331, Auckland.
FCC Statement (United States Only)
This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide
reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses and can
radiate radio frequency energy and, if not
installed and used in accordance with the
instructions, may cause harmful interference
to radio communications. However, there is
no guarantee that interference will not occur
in a particular installation. If this equipment
does cause harmful interference to radio or
television reception, which can be determined
by turning the equipment off and on, the user
is encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the
equipment and receiver.
• Consult the dealer or an experienced radio/
TV technician for help.
Note: Changes or modifications not expressly
approved by the manufacturer responsible for
compliance could void the user’s authority to
operate the equipment.
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following
two conditions: (1) This device may not cause
harmful interference and (2) this device
must accept any interference received,
including interference that may cause
undesired operation.
ICES-003
This Class B digital apparatus complies with•
Canadian ICES-003.
Operation is subject to the following two•
conditions: (1) this device may not cause
harmful interference and (2) this device
must accept any interference received,
including interference that may cause
undesired operation.
NMB-003
Cet appareil numérique de la classe B est•
conforme à la norme NMB-003 du Canada.
L’utilisation de ce dispositif est autorisée•
seulement aux conditions suivantes :
(1) il ne doit pas produire de brouillage
et (2) l’utilisateur du dispositif doit être prêt
à accepter tout brouillage radioélectrique
reçu, même si ce brouillage est susceptible
de compromettre le fonctionnement
du dispositif.
In exceptional circumstances, batteries may leak fluids that can cause a chemical burn
injury or ruin your toy. To avoid battery leakage:
• Do not mix old and new batteries or batteries of different types: alkaline, standard (carbon-
zinc) or rechargeable (nickel-cadmium).
• Insert batteries as indicated inside the battery compartment.
• Remove batteries during long periods of non-use. Always remove exhausted batteries from the
toy. Dispose of batteries safely. Do not dispose of this product in a fire. The batteries inside may
explode or leak.
• Never short-circuit the battery terminals.
• Use only batteries of the same or equivalent type, as recommended.
• Do not charge non-rechargeable batteries.
• Remove rechargeable batteries from the toy before charging.
• If removable, rechargeable batteries are used, they are only to be charged under
adult supervision.

7 8 9
Track Layout All Aboard
Hook the cars together and place them on the track. Make sure the engine is in front.•
Press the power button on top of the engine. The ready light turns on.•
Hold the remote controller with the stick facing you. Point the remote controller toward the•
vehicle and push the stick forward 1. The vehicle moves forward around the track.
Pull the stick back a little to stop the vehicle• 3.
Pull the stick all the way back and the vehicle travels in reverse• 4. Release the stick to stop 3.
4-Position Remote Controller
1234
1
2
3
4
FORWARD
(WITH SOUND EFFECTS)
FORWARD
OFF
REVERSE
POWER
BUTTON
READY LIGHT
Hints:
If you do not operate the remote controller for a few minutes, the vehicle shuts off and the ready•
light turns off. Press the vehicle power button and operate the remote controller to restart.
This toy works best if you have a clear path between the remote controller and the vehicle.•
Point the remote controller at the vehicle. The maximum range of the remote controller is•
about 12 feet (3,66 m).
Wipe the toy with a clean, damp cloth. Do not immerse.•
Hint: We do not recommend using the engine on carpets. For best performance, use on the
track provided or hard, flat surfaces.

10 11 12
Use the crane to lift and load cargo.•
All Aboard
Drop your train into the station, and all the•
wheels align on the track!
Try these other
fun layouts!
Troubleshooting
PROBLEM SOLUTION
Vehicle drives slowly Battery power in the vehicle may be weak. Replace all three
batteries in the vehicle with fresh, alkaline batteries.
The wheels on the vehicle may be dirty. Wipe them with
a clean cloth.
Vehicle does not
respond to the
remote controller
Battery power in the remote controller may be weak.
Replace all three batteries in the remote controller with
fresh, alkaline batteries.
You may be beyond the maximum range of the remote
controller, which is about 12 feet (3,66 m).
You may not have a clear path between the remote controller
and the vehicle. This toy works best when there are no
obstructions between the vehicle and the remote controller.
Bright sunlight or fluorescent lights may affect the range of the
remote controller. Try dimming the room you are playing in.
The vehicle may have shut off. If you do not operate the remote
controller for a few minutes, the vehicle shuts off automatically
and the ready light turns off. Press the power button on the
vehicle, and operate the remote controller to restart.
