FLIR K 5 Series User manual

User’s manual
FLIR Kx5 series

Important note
Before operating the device, you must read, understand, and follow all instructions, warnings, cautions, and legal disclaimers.
Důležitá poznámka
Před použitím zařízení si přečtěte veškeré pokyny, upozornění, varování a vyvázání se ze záruky, ujistěte se, že jim rozumíte, a řiďte
se jimi.
Vigtig meddelelse
Før du betjener enheden, skal du du læse, forstå og følge alle anvisninger, advarsler, sikkerhedsforanstaltninger og
ansvarsfraskrivelser.
Wichtiger Hinweis
Bevor Sie das Gerät in Betrieb nehmen, lesen, verstehen und befolgen Sie unbedingt alle Anweisungen, Warnungen,
Vorsichtshinweise und Haftungsausschlüsse
Σημαντική σημείωση
Πριν από τη λειτουργία της συσκευής, πρέπει να διαβάσετε, να κατανοήσετε και να ακολουθήσετε όλες τις οδηγίες,
προειδοποιήσεις, προφυλάξεις και νομικές αποποιήσεις.
Nota importante
Antes de usar el dispositivo, debe leer, comprender y seguir toda la información sobre instrucciones, advertencias, precauciones y
renuncias de responsabilidad.
Tärkeä huomautus
Ennen laitteen käyttämistä on luettava ja ymmärrettävä kaikki ohjeet, vakavat varoitukset, varoitukset ja lakitiedotteet sekä
noudatettava niitä.
Remarque importante
Avant d'utiliser l'appareil, vous devez lire, comprendre et suivre l'ensemble des instructions, avertissements, mises en garde et
clauses légales de non-responsabilité.
Fontos megjegyzés
Az eszköz használata előtt figyelmesen olvassa el és tartsa be az összes utasítást, figyelmeztetést, óvintézkedést és jogi
nyilatkozatot.
Nota importante
Prima di utilizzare il dispositivo, è importante leggere, capire e seguire tutte le istruzioni, avvertenze, precauzioni ed esclusioni di
responsabilità legali.
重要な注意
デバイスをご使用になる前に、あらゆる指示、警告、注意事項、および免責条項をお読み頂き、その内容を理解して従ってくだ
さい。
중요한 참고 사항
장치를 작동하기 전에 반드시 다음의 사용 설명서와 경고,주의사항,법적 책임제한을 읽고 이해하며 따라야 합니다.
Viktig
Før du bruker enheten, må du lese, forstå og følge instruksjoner, advarsler og informasjon om ansvarsfraskrivelse.
Belangrijke opmerking
Zorg ervoor dat u, voordat u het apparaat gaat gebruiken, alle instructies, waarschuwingen en juridische informatie hebt
doorgelezen en begrepen, en dat u deze opvolgt en in acht neemt.
Ważna uwaga
Przed rozpoczęciem korzystania z urządzenia należy koniecznie zapoznać się z wszystkimi instrukcjami, ostrzeżeniami,
przestrogami i uwagami prawnymi. Należy zawsze postępować zgodnie z zaleceniami tam zawartymi.
Nota importante
Antes de utilizar o dispositivo, deverá proceder à leitura e compreensão de todos os avisos, precauções, instruções e isenções de
responsabilidade legal e assegurar-se do seu cumprimento.
Важное примечание
До того, как пользоваться устройством, вам необходимо прочитать и понять все предупреждения, предостережения и
юридические ограничения ответственности и следовать им.
Viktig information
Innan du använder enheten måste du läsa, förstå och följa alla anvisningar, varningar, försiktighetsåtgärder och
ansvarsfriskrivningar.
Önemli not
Cihazı çalıştırmadan önce tüm talimatları, uyarıları, ikazları ve yasal açıklamaları okumalı, anlamalı ve bunlara uymalısınız.
重要注意事项
在操作设备之前，您必须阅读、理解并遵循所有说明、警告、注意事项和法律免责声明。
重要注意事項
操作裝置之前，您務必閱讀、了解並遵循所有說明、警告、注意事項與法律免責聲明。

Table of contents
1 Disclaimers ......................................................................................1
1.1 Legal disclaimer ....................................................................... 1
1.2 U.S. Government Regulations......................................................1
1.3 Patents...................................................................................1
1.4 Quality assurance ..................................................................... 1
1.5 Third-party licenses...................................................................1
1.6 Usage statistics ........................................................................ 1
1.7 Copyright ................................................................................1
2 Safety information .............................................................................2
2.1 Label affixed to the camera ......................................................... 5
2.1.1 FLIR K45 and FLIR K55...................................................5
2.1.2 FLIR K65......................................................................5
2.2 Marking recommendations and restrictions..................................... 5
3 Notice to user ...................................................................................6
3.1 Online documentation................................................................6
3.2 Register your camera.................................................................6
3.3 Disposal of electronic waste ........................................................ 6
3.4 Training ..................................................................................7
3.5 Important note about this manual.................................................. 7
3.6 Note about authoritative versions.................................................. 7
4 Customer help ..................................................................................8
4.1 General ..................................................................................8
4.2 Submitting a question ................................................................ 8
4.3 Downloads ..............................................................................8
5 Important information about FLIR Kx5 series service.............................9
6 Starting the camera for the first time (FLIR K65).................................. 10
7 Quick start guide ............................................................................. 12
8 Accessories and services................................................................. 13
9 System configuration overview ......................................................... 14
10 System parts...................................................................................15
10.1 Camera (FLIR K45, FLIR K55) ................................................... 15
10.2 Camera (FLIR K65) ................................................................. 16
10.3 Lanyard strap and retractable lanyard.......................................... 17
10.4 Handle strap and retractable lanyard........................................... 17
10.5 Neck strap............................................................................. 18
11 Screen elements ............................................................................. 19
11.1 Battery condition indicator ........................................................ 20
11.2 Settings menu icons ................................................................ 20
12 Operation .......................................................................................21
12.1 Removing the battery (FLIR K45, FLIR K55) ................................. 21
12.2 Removing the battery (FLIR K65) ............................................... 22
12.3 Charging the battery ................................................................ 22
12.4 Turning on and turning off the camera.......................................... 22
12.5 Selecting camera modes .......................................................... 23
12.5.1 Automatic temperature range selection ............................. 23
12.5.2 Explanation of the different camera modes ........................ 24
12.6 Saving an image ..................................................................... 28
12.7 Recording a video clip (FLIR K55 and FLIR K65) ........................... 28
12.8 Continuous video recording (FLIR K55 and FLIR K65) .................... 29
12.9 Freezing the image.................................................................. 29
12.10 Connecting the camera to a computer ......................................... 29
12.10.1 Procedure (FLIR K45, FLIR K55) ..................................... 30
12.10.2 Procedure (FLIR K65) ................................................... 31
#T559946; r. BG/87484/87484; en-US iii

Table of contents
12.11 Viewing saved images ............................................................. 33
12.12 Viewing saved video clips ......................................................... 34
12.13 Changing settings (in the camera) .............................................. 35
12.13.1 General...................................................................... 35
12.13.2 Restore factory default settings ....................................... 36
12.14 Configuring the camera ............................................................ 37
12.14.1 Installation .................................................................. 37
12.14.2 Configure the camera.................................................... 37
12.14.3 The General settings tab................................................ 37
12.14.4 The User interface tab................................................... 38
13 In-truck charger (optional accessory) ................................................ 40
13.1 Introduction ........................................................................... 40
13.2 Parts and functions.................................................................. 40
13.3 Choosing a suitable position...................................................... 41
13.4 Recommended cable area and fuse............................................ 41
13.5 Mounting instructions............................................................... 41
13.6 Charging the camera ............................................................... 42
13.7 Charging a battery separately .................................................... 42
13.8 Cleaning ............................................................................... 42
13.9 Customer support ................................................................... 42
14 Mechanical drawings ....................................................................... 43
15 CE Declaration of conformity ............................................................ 47
16 Cleaning, decontamination and disinfection ....................................... 48
16.1 Cleaning ............................................................................... 48
16.1.1 Camera housing, cables, and other items .......................... 48
16.1.2 Infrared lens................................................................ 48
16.2 Decontamination and disinfection ............................................... 48
17 Maintenance, inspection, and service ................................................ 50
17.1 Maintenance.......................................................................... 50
17.2 Inspection ............................................................................. 50
17.3 Service................................................................................. 50
18 About FLIR Systems ........................................................................ 51
18.1 More than just an infrared camera .............................................. 52
18.2 Sharing our knowledge ............................................................ 52
18.3 Supporting our customers......................................................... 53
#T559946; r. BG/87484/87484; en-US iv

Disclaimers
1
1.1 Legal disclaimer
For warranty terms, refer to https://www.flir.com/warranty.
1.2 U.S. Government Regulations
This product may be subject to U.S. Export Regulations. Send any inquiries to export-
[e-mail].
1.3 Patents
This product is protected by patents, design patents, patents pending, or design patents
pending. Refer to the FLIR Systems’ patent registry:
https://www.flir.com/patentnotices
1.4 Quality assurance
The Quality Management System under which these products are developed and manu-
factured has been certified in accordance with the ISO 9001 standard.
FLIR Systems is committed to a policy of continuous development; therefore we reserve
the right to make changes and improvements on any of the products without prior notice.
1.5 Third-party licenses
Information about third-party licenses is available in the user interface of the product.
1.6 Usage statistics
FLIR Systems reserves the right to gather anonymous usage statistics to help maintain
and improve the quality of our software and services.
1.7 Copyright
© 2022 FLIR Systems, Inc. All rights reserved worldwide. No parts of the software in-
cluding source code may be reproduced, transmitted, transcribed or translated into any
language or computer language in any form or by any means, electronic, magnetic, opti-
cal, manual or otherwise, without the prior written permission of FLIR Systems.
The documentation must not, in whole or part, be copied, photocopied, reproduced,
translated or transmitted to any electronic medium or machine readable form without pri-
or consent, in writing, from FLIR Systems.
Names and marks appearing on the products herein are either registered trademarks or
trademarks of FLIR Systems and/or its subsidiaries. All other trademarks, trade names
or company names referenced herein are used for identification only and are the prop-
erty of their respective owners.
#T559946; r. BG/87484/87484; en-US 1

Safety information
2
WARNING
Applicability: Cameras with one or more batteries.
Do not disassemble or do a modification to the battery. The battery contains safety and protection devi-
ces which, if damage occurs, can cause the battery to become hot, or cause an explosion or an ignition.
WARNING
Applicability: Cameras with one or more batteries.
If there is a leak from the battery and you get the fluid in your eyes, do not rub your eyes. Flush well with
water and immediately get medical care. The battery fluid can cause injury to your eyes if you do not do
this.
WARNING
Applicability: Cameras with one or more batteries.
Do not continue to charge the battery if it does not become charged in the specified charging time. If
you continue to charge the battery, it can become hot and cause an explosion or ignition. Injury to per-
sons can occur.
WARNING
Applicability: Cameras with one or more batteries.
Only use the correct equipment to remove the electrical power from the battery. If you do not use the
correct equipment, you can decrease the performance or the life cycle of the battery. If you do not use
the correct equipment, an incorrect flow of current to the battery can occur. This can cause the battery
to become hot, or cause an explosion. Injury to persons can occur.
WARNING
Make sure that you read all applicable MSDS (Material Safety Data Sheets) and warning labels on con-
tainers before you use a liquid. The liquids can be dangerous. Injury to persons can occur.
CAUTION
Do not point the infrared camera (with or without the lens cover) at strong energy sources, for example,
devices that cause laser radiation, or the sun. This can have an unwanted effect on the accuracy of the
camera. It can also cause damage to the detector in the camera.
CAUTION
Applicability: Cameras with one or more batteries.
Do not attach the batteries directly to a car’s cigarette lighter socket, unless FLIR Systems supplies a
specific adapter to connect the batteries to a cigarette lighter socket. Damage to the batteries can
occur.
CAUTION
Applicability: Cameras with one or more batteries.
Do not connect the positive terminal and the negative terminal of the battery to each other with a metal
object (such as wire). Damage to the batteries can occur.
CAUTION
Applicability: Cameras with one or more batteries.
Do not get water or salt water on the battery, or permit the battery to become wet. Damage to the bat-
teries can occur.
CAUTION
Applicability: Cameras with one or more batteries.
Do not make holes in the battery with objects. Damage to the battery can occur.
#T559946; r. BG/87484/87484; en-US 2

Safety information
2
CAUTION
Applicability: Cameras with one or more batteries.
Do not hit the battery with a hammer. Damage to the battery can occur.
CAUTION
Applicability: Cameras with one or more batteries.
Do not put your foot on the battery, hit it or cause shocks to it. Damage to the battery can occur.
CAUTION
Applicability: Cameras with one or more batteries.
Do not put the batteries in or near a fire, or into direct sunlight. When the battery becomes hot, the built-
in safety equipment becomes energized and can stop the battery charging procedure. If the battery be-
comes hot, damage can occur to the safety equipment and this can cause more heat, damage or igni-
tion of the battery.
CAUTION
Applicability: Cameras with one or more batteries.
Do not put the battery on a fire or increase the temperature of the battery with heat. Damage to the bat-
tery and injury to persons can occur.
CAUTION
Applicability: Cameras with one or more batteries.
Do not put the battery on or near fires, stoves, or other high-temperature locations. Damage to the bat-
tery and injury to persons can occur.
CAUTION
Applicability: Cameras with one or more batteries.
Do not solder directly onto the battery. Damage to the battery can occur.
CAUTION
Applicability: Cameras with one or more batteries.
Do not use the battery if, when you use, charge, or put the battery in storage, there is an unusual smell
from the battery, the battery feels hot, changes color, changes shape, or is in an unusual condition.
Speak with your sales office if one or more of these problems occurs. Damage to the battery and injury
to persons can occur.
CAUTION
Applicability: Cameras with one or more batteries.
Only use a specified battery charger when you charge the battery. Damage to the battery can occur if
you do not do this.
CAUTION
Applicability: Cameras with one or more batteries.
Only use a specified battery for the camera. Damage to the camera and the battery can occur if you do
not do this.
CAUTION
Applicability: Cameras with one or more batteries.
The temperature range through which you can charge the battery is 0°C to +45°C (+32°F to +113°F). If
you charge the battery at temperatures out of this range, it can cause the battery to become hot or to
break. It can also decrease the performance or the life cycle of the battery.
#T559946; r. BG/87484/87484; en-US 3

Safety information
2
CAUTION
Applicability: Cameras with one or more batteries.
The temperature range through which you can remove the electrical power from the battery is -15°C to
+50°C (+5°F to +122°F), unless other information is specified in the user documentation or technical
data. If you operate the battery out of this temperature range, it can decrease the performance or the life
cycle of the battery.
CAUTION
Applicability: Cameras with one or more batteries.
When the battery is worn, apply insulation to the terminals with adhesive tape or equivalent materials
before you discard it. Damage to the battery and injury to persons can occur if you do not do this.
CAUTION
Applicability: Cameras with one or more batteries.
Remove any water or moisture on the battery before you install it. Damage to the battery can occur if
you do not do this.
CAUTION
Do not apply solvents or equivalent liquids to the camera, the cables, or other items. Damage to the bat-
tery and injury to persons can occur.
CAUTION
Be careful when you clean the infrared lens. The lens has an anti-reflective coating which is easily dam-
aged. Damage to the infrared lens can occur.
CAUTION
Do not use too much force to clean the infrared lens. This can cause damage to the anti-reflective
coating.
CAUTION
Do not change the standard fire-fighting procedures when you use a FLIR K series camera. The FLIR K
series camera is not a replacement technology.
CAUTION
Do not use the FLIR K series camera without the correct training. If the persons that operate the camera
do not have the correct training, an incorrect analysis of the infrared images can occur. Thus, incorrect
decisions during the firefighting can be made.
The training must include:
• How a thermal camera operates and its limits
• How to interpret an image
• How to work safely with the camera.
CAUTION
Make sure that you do not use a torque value that is more than 80 Ncm on the Torx T20 screw. Damage
to the camera can occur if you do not obey this.
CAUTION
Only use the equipment as given in the applicable manufacturer’s instructions. If you do not obey this,
the protection that the equipment gives can become unsatisfactory. Damage to the equipment can
occur.
#T559946; r. BG/87484/87484; en-US 4

Safety information
2
CAUTION
Only use with batteries that have the part number T199368 on them (that FLIR Systems AB supplies).
Damage to the equipment can occur if you do not obey this.
WARNING
Make sure that you only change the batteries in a known safe area. If you do not obey this, an explosion
can occur. An explosion can cause death or injury to persons and damage to the equipment.
CAUTION
Do not open unless you are sure that there are no flammable materials in the area. A fire or an explosion
can occur. This can cause injury or death to persons and damage to the equipment.
CAUTION
Do not use the connection port while it is in a classified (danger) area. Injury to persons and damage to
the equipment can occur.
Note The encapsulation rating is only applicable when all the openings on the camera
are sealed with their correct covers, hatches, or caps. This includes the compartments
for data storage, batteries, and connectors.
2.1 Label affixed to the camera
2.1.1 FLIR K45 and FLIR K55
2.1.2 FLIR K65
2.2 Marking recommendations and restrictions
Applicability: FLIR K65
The camera body may not be physically marked. Such markings include labels, engrav-
ings, printing, melting, etc. If the camera needs to be identified or tracked, such identifi-
cation shall be carried out by adding a custom boot image in the camera firmware, see
section 12.14 Configuring the camera.
#T559946; r. BG/87484/87484; en-US 5

Notice to user
3
3.1 Online documentation
Our manuals are continuously updated and published online.
To access the FLIR Kx5 user manual and other product documentation, go to
http://support.flir.com/resources/v362.
To access the manuals for our other products, as well as manuals for our discontinued
products, go to https://support.flir.com/resources/app.
3.2 Register your camera
Register your camera to receive an extended warranty and other related benefits.
To register the camera, go to www.flir.com/register.
To access the registration form, you must log in to your FLIR account or sign up for a new
account.
You will also need the serial number of your camera. You can find the serial number by
doing the following:
• Power on the camera. The serial number is temporarily displayed on the screen.
• When the camera is on, push the Mode and Zoom buttons at the same time. This dis-
plays the main menu, with the serial number at the top of the screen.
• A label with the serial number is available under the rubber cover at the top of the
camera.
3.3 Disposal of electronic waste
Electrical and electronic equipment (EEE) contains materials, components and substan-
ces that may be hazardous and present a risk to human health and the environment
when waste electrical and electronic equipment (WEEE) is not handled correctly.
Equipment marked with the below crossed-out wheeled bin is electrical and electronic
equipment. The crossed-out wheeled bin symbol indicates that waste electrical and elec-
tronic equipment should not be discarded together with unseparated household waste,
but must be collected separately.
For this purpose all local authorities have established collection schemes under which
residents can dispose waste electrical and electronic equipment at a recycling centre or
other collection points, or WEEE will be collected directly from households. More de-
tailed information is available from the technical administration of the relevant local
authority.
#T559946; r. BG/87484/87484; en-US 6

Notice to user3
3.4 Training
For training resources and courses, go to https://www.flir.com/support-center/training.
3.5 Important note about this manual
FLIR Systems issues generic manuals that cover several cameras within a model line.
This means that this manual may contain descriptions and explanations that do not apply
to your particular camera model.
3.6 Note about authoritative versions
The authoritative version of this publication is English. In the event of divergences due to
translation errors, the English text has precedence. Any late changes are first imple-
mented in English.
#T559946; r. BG/87484/87484; en-US 7

Customer help
4
4.1 General
Do not hesitate to contact our Customer Support Center if you experience problems or
have any questions.
For customer help, go to http://support.flir.com.
4.2 Submitting a question
To submit a question to the customer help team, you must be a registered user. It only
takes a few minutes to register online. If you only want to search the knowledgebase for
existing questions and answers, you do not need to be a registered user.
When you want to submit a question, make sure that you have the following information
to hand:
• The camera model.
• The camera serial number.
• The communication protocol, or method, between the camera and your device (e.g.,
SD card reader, HDMI, Ethernet, USB, or FireWire).
• Device type (PC/Mac/iPhone/iPad/Android device, etc.).
• Version of any programs from FLIR Systems.
• Full name, publication number, and revision number of the manual.
4.3 Downloads
On the customer help site you can also download the following, when applicable for the
product:
• Firmware updates for your infrared camera.
• Program updates for your PC/Mac software.
• Freeware and evaluation versions of PC/Mac software.
• User documentation for current, obsolete, and historical products.
• Mechanical drawings (in *.dxf and *.pdf format).
• CAD data models (in *.stp format).
• Application examples.
• Technical datasheets.
#T559946; r. BG/87484/87484; en-US 8

Important information about
FLIR Kx5 series service
5
• Contact the service department before shipping the camera. Many problems can be
resolved on the phone—if so, the camera does not need to be shipped.
• The camera must be thoroughly cleaned, decontaminated and disinfected before
shipping to our service department. No hazardous residues are allowed on cameras.
Such residues include—but are not limited to—chemical fire-extinguishing com-
pounds, radioactivity, biohazardous materials, and residues from chemical fires.
• FLIR Systems reserves the right to charge the full cost for the decontamination and
disinfection of contaminated cameras that are shipped to our service department.
#T559946; r. BG/87484/87484; en-US 9

Starting the camera for the first
time (FLIR K65)
6
Applicability: FLIR K65
The first time you start the camera, you need to unlock the camera by entering a camera
unique code. The code is based on the serial number of the camera. To get the camera
unique code, you must log in using a FLIR Customer Support account and register the
camera. If you already have an existing FLIR Customer Support account, you can use
the same login credentials.
Follow this procedure:
1. Charge the battery for 4 hours before starting the camera for the first time, or until the
blue battery condition LED glows continuously.
2. Push the on/off button to turn on the camera. This displays the following dialog box:
3. To register the camera, use a computer or other device with internet access and go
to: http://support.flir.com/unlock.
4. To access the registration form, log in to your FLIR account or sign up for a new
account.
5. To find the serial number of your camera, push the Mode button. The serial number
(S/N) is displayed at the top of the screen.
6. To complete the registration and unlock the camera, you must enter an unlock code
into the camera. The code is available in your FLIR account, under My Products.
#T559946; r. BG/87484/87484; en-US 10

Starting the camera for the first time (FLIR K65)
6
7. On the camera, do the following to enter the code:
• Push the Mode button repeatedly to change a digit.
• Push the Zoom button to navigate to the next digit.
• When all of the digits have been entered, push the Zoom button to select . Push
the Zoom button again to confirm.
8. Depending on the entered code, one of the following will happen:
• If the entered code is correct, is momentarily displayed. Then the unlock dialog
box closes.
• If the entered code is incorrect, is momentarily displayed. Then the unlock dia-
log is zeroed and you can enter the code again.
9. The camera is now fully operational and an infrared image is displayed.
10. To turn off the camera, push and hold the on/off button for more than 10 seconds.
Note The next time you turn on the camera, it will be fully operational from its start-up.
You do not have to go through the unlock procedure again.
#T559946; r. BG/87484/87484; en-US 11

Quick start guide
7
Follow this procedure to get started right away:
1. Charge the battery for 4 hours before starting the camera for the first time, or until the
blue battery condition LED glows continuously.
2. Push the on/off button to turn on the camera.
3. Aim the camera toward the object of interest.
4. Select a suitable camera mode by pushing the Mode button.
5. Pull the trigger to save an image.
6. To move images to a computer, do the following:
6.1. Connect the camera to a computer, using the USB cable.
6.2. Move the images using a drag-and-drop operation in Microsoft Windows
Explorer.
Note Moving an image using a drag-and-drop operation does not delete the
image in the camera.
Note The function of the trigger is configured by a setting, see section 12.14 Configur-
ing the camera.
#T559946; r. BG/87484/87484; en-US 12

Accessories and services
8
Please check the FLIR Kx5 product page on www.flir.com for offered accessories and
services.
#T559946; r. BG/87484/87484; en-US 13

System configuration overview
9
1. FLIR P/N: 1910423, USB cable Std A <-> Mini-B
2. FLIR P/N: T127724ACC, Neck strap1
3. FLIR P/N: T198416ACC, Strap lanyard1
4. FLIR P/N: T198457ACC, Tripod Adapter, Kxx1
5. FLIR P/N: T198125, Battery charger, incl. power supply with multi plugs
6. FLIR P/N: T198509, Cigarette lighter adapter kit, 12 VDC, 1.2 m/3.9 ft
7. FLIR P/N: T199368ACC, Li-Ion Battery pack 3.6 V 16 Wh
8. FLIR P/N: T130980ACC, Retractable lanyard1
9. FLIR P/N: T198322ACC, In-truck charger
10. FLIR P/N: T198441ACC, Transport case Kxx
#T559946; r. BG/87484/87484; en-US 14
1. The inclusion of this item is dependent on model.

System parts
10
10.1 Camera (FLIR K45, FLIR K55)
1. USB Mini-B connector.
2. Attachment point for the lanyard strap/neck strap (left and right sides).
3. Eccentric latch to secure the battery.
4. On/off button. This button has three functions:
• Push the on/off button to turn on the camera.
• Push and hold the on/off button for more than 3 seconds but less than 10 seconds
to put the camera into standby mode. The camera then automatically turns off
after 6 hours.
• Push and hold the on/off button for more than 10 seconds to turn off the camera.
5. Mode button: Push repeatedly to select camera modes.
6. Access to setup menus and stored images: Push Mode + Zoom button.
7. Zoom button (zoom factor 2×).
8. Connectors for in-truck charger.
9. Trigger.
10. Mount for tripod adapter.
11. Attachment point for the retractable lanyard.
12. Battery.
#T559946; r. BG/87484/87484; en-US 15

System parts
10
10.2 Camera (FLIR K65)
1. USB Mini-B connector. The USB Mini-B connector is protected by a plastic cover that
is fastened with a Torx screw (T20).
CAUTION
Make sure that you do not use a torque value that is more than 80 Ncm on the Torx T20 screw.
Damage to the camera can occur if you do not obey this.
2. Attachment point for lanyard strap/neck strap (left and right sides).
3. Latch to secure the battery. The latch is fastened with a Torx screw (T20).
CAUTION
Make sure that you do not use a torque value that is more than 80 Ncm on the Torx T20 screw.
Damage to the camera can occur if you do not obey this.
4. On/off button. This button has three functions:
• Push the on/off button to turn on the camera.
• Push and hold the on/off button for more than 3 seconds but less than 10 seconds
to put the camera into standby mode. The camera then automatically turns off
after 6 hours.
• Push and hold the on/off button for more than 10 seconds to turn off the camera.
5. Mode button: Push repeatedly to select camera modes.
6. Access to the setup menus and stored images: Push the Mode + Zoom buttons.
7. Zoom button (zoom factor ×2).
8. Connectors for the in-truck charger.
9. Trigger.
10. Mount for the tripod adapter.
11. Attachment point for the retractable lanyard.
12. Battery.
#T559946; r. BG/87484/87484; en-US 16
