718
Pressure Calibrator
Pump Rebuild Kit
Service Information
Introduction
Use the following diagrams to rebuild the Fluke 718
Pressure Calibrator pump.
How to Contact Fluke
To order accessories, receive operating assistance, or
get the location of the nearest Fluke distributor or
Service Center, call one of the following telephone
numbers:
USA and Canada: 1-888-99-FLUKE (1-888-993-
5853)
Europe: [phone]
Japan: [phone]
Singapore: [phone]
Anywhere in the world: [phone]
Address correspondence to:
Fluke Corporation Fluke Europe B.V
P.O. Box 9090 P.O. Box 1186,
Fluke Everett, WA 5602 BD Eindhoven
98206-9090 The Netherlands
U.S.A.
Or, visit Fluke’s Web site at www.fluke.com.
LIMITED WARRANTY & LIMITATION OF LIABILITY
This Fluke product will be free from defects in material and
workmanship for 90 days from the date of purchase. This warranty
does not cover fuses, disposable batteries or damage from
accident, neglect, misuse or abnormal conditions of operation or
handling. Resellers are not authorized to extend any other warranty
on Fluke’s behalf. To obtain service during the warranty period,
send your defective tester to the nearest Fluke Authorized Service
Center with a description of the problem.
THIS WARRANTY IS YOUR ONLY REMEDY. NO OTHER
WARRANTIES, SUCH AS FITNESS FOR A PARTICULAR
PURPOSE, ARE EXPRESSED OR IMPLIED. FLUKE IS NOT
LIABLE FOR ANY SPECIAL, INDIRECT, INCIDENTAL OR
CONSEQUENTIAL DAMAGES OR LOSSES, ARISING FROM
ANY CAUSE OR THEORY. Since some states or countries do not
allow the exclusion or limitation of an implied warranty or of
incidental or consequential damages, this limitation of liability may
not apply to you.
Parts List
Reference
Designator Description Part Number
MP11-14 O-ring 146688
MP15 Nylon Spacer 687449
MP16 Piston, Pump -
MP17 Piston, Vernier -
Not Shown 718 Pump Rebuild Kit
Service Information 1270835
MP12
MP11 MP13
MP15
MP14 MP16
MP17
zc01f.eps
Figure 1. Pump Rebuild Kit Parts

718 Pump Rebuild Kit
Service Information
2
Assembly Drawings
See Detail A
Snaps
3
2
1
6
7
4
5
zc02f.eps
Figure 2. Disassembly
MP12
MP11 MP13
MP15
MP14
MP16
MP17
1/16"
8
zc03f.eps
Figure 3. Detail A
