Focal Bathys User manual


使用手册 / 사용 설명서 / 取扱説明書 /
Bathys
Manuel d’utilisation / User Manual / Gebrauchsanleitung / Manuale d’uso / Manual de uso /
Manual de utilização / Handleiding / Руководство по эксплуатации /
PLRUZHKOJPAR FRENDEESNL PT IT

3
Bathys
Manuel d’utilisation / User manual
Bathys
Type Closed-back headphones, active, noise cancelling
Bluetooth® 5.1 Multipoint ; range > 15m
Bluetooth® frequency band 2404-2480Mhz
Maximum emission power 4.56dBm (2.86mW)
Audio codecs SBC, AAC, aptX™, aptX™ Adaptive
Autonomy
30h Bluetooth® Noise Cancelling
35h mode jack
42h mode USB DAC
Voice assistants Google Assistant, Amazon Alexa
Drivers 40mm Aluminium-Magnesium
Frequency response 15Hz to 22.1kHz
THD <0.2% @1kHz
Battery type Lithium-ion 1060mAH
Power supply 5V-2000mA (Not supplied)
Microphones 8
Control application Focal & Naim, iOS and Android compatible
Weight 350g
Cables and connectors 1.2m mini-jack
1.2m USB Type-C®
Carrying case 9.5x8.3x2.8" (24x21x7cm)

EN
READ THIS FIRST!
IMPORTANT SAFETY INSTRUCTIONS!
English
Warning symbol. This symbol is designed to warn the user of the presence
of important instructions mentioned in the user manual and relating to the
handling, operation and maintenance of the device.
Before using the product, read the
instructions and keep them carefully
for future reference if required.
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings contained in
these instructions.
4) Follow all the instructions.
5) Listening to high powered
headphones can damage the ears and
lead to hearing problems (temporary
or permanent deafness, ringing in the
ears, tinnitus, hyperacusis).
(CEI 60417-6044)
Exposure to excessive
volumes (over 85 dB) for
more than one hour
can cause irreparable
damage to your hearing.
The headphones must, therefore, be
turned on before wearing them and
we strongly advise against using the
headphones at full volume, nor for
more than one hour a day at medium
volume.
Do not use the headphones
continuously; take regular breaks.
If you experience buzzing or ringing
(tinnitus) in the ears, hearing loss or
a “mued” sensation, stop listening
to the headphones immediately. If
symptoms persist after a few hours,
consult your doctor immediately who
will, if necessary, refer you to an ENT
specialist. In some cases, immediate
treatment can prevent irreversible
damage.
6) Always turn on the headphones
before wearing them, set the listening
device’s volume to the lowest setting
before connecting your headphones
and increasing the volume. Once the
headphones are in place, gradually
increase the volume to a reasonable
and comfortable level.
7) Never use the headphones without
the earpads or protective tips.
8) Be sure to use the headphones
in such a way that you can still hear
sounds around you. In particular, the
product’s active noise cancellation
may make ambient noise inaudible or
significantly change your perception
of warning signals; reducing the
chance of hearing ambient noise is a
risk for yourself and those around you.
Do not use the headphones in
conditions requiring special attention,
such as when outdoors in heavy
trac, near a construction site or a
railway line, etc.
Never drive a vehicle (car, motorcycle,
boat, electric scooter, etc.) or ride
a bicycle, skateboard, roller blades,
hoverboard, etc. while wearing the
headphones.
Any use under these circumstances
is dangerous and, in some countries,
illegal.
9) It is also not recommended to use
the headphones for running, walking
or doing any other activity in crowded
places. If you use the headphones
under these circumstances, set the
volume to low so that you can hear
ambient sounds, including horns,
alarms and warning signals.
10) Please ensure that children and
young people under the age of 14 are
not allowed to use the headphones
without supervision. Be particularly
vigilant with regard to children and
adolescents who often use these
devices at excessive volumes.
11) Do not use the headphones for
anything but their original function.
Never use headphones as a form
of noise protection. Do not use
the headphones as an aviation
communications headset.
12) Use compliant adapters to connect
your headphones to aeroplane seat
plugs. Failure to do so may result in
personal injury or property damage
caused by overheating.
13) If you feel heat or lose audio
signal, remove and disconnect the
headphones immediately.
14) Do not place burning objects near
and/or on the headphones, such as lit
candles, lighters, etc.
15) Do not apply any weight or
pressure to the headphones for too
long, including when turned o or
not in use.
16) Do not expose your headphones
to moisture or immerse them in water.
17) The headphones do not require
specific cleaning. If necessary, use a
soft, dry cloth. Do not use cleaning
products containing solvents.
18) Have any repairs or servicing
carried out by a professional. Such
operations are necessary in the event
of damage of any kind, such as liquid
spillage, cable damage, exposure to
rain, dropping the device, etc.
Do not modify the system or
its accessories. Unauthorised
modifications may compromise your
safety, regulatory compliance and
device performance.
If you replace your earpads, be
sure to replace them only with the
specific pad model provided by the
manufacturer so as not to aect
the sound quality and active noise
reduction.
19) This product poses risks of:
• choking;
• fire or electrocution (do not expose
the device to rain or moisture, or any
other liquid).
20) This product contains magnetic
components and generates
magnetic fields which may interfere
with pacemakers and implanted
defibrillators. Before using the
headphones, contact your GP if you
have any questions regarding the
eect of these components on the
functioning of an implanted medical
device.
21) This product
complies with
all applicable
European
regulations and directives. This symbol
means that the product (including its
battery if applicable) must not be
thrown away with household waste
but must be taken to an appropriate
collection centre for recycling. Proper
disposal and recycling helps protect
natural resources, human health and
the environment. For more
information on the disposal and
recycling of this product, contact your
local council, your waste collection
service or the store where you
purchased this product.
22) This product contains
a lithium-ion battery,
which should be
handled with care.
Lithium batteries can be dangerous if
not used and handled properly. In
extreme cases, abnormal use of
lithium batteries can lead to:
• explosion
• fire
• release of heat
• release of smoke or gas.
23) Caution, do not open the device.
It is forbidden to disassemble, open,
pierce, or perform any other action on
the battery on your own.
Caution, there is a danger of explosion
if the battery is incorrectly replaced.
Replacing and/or removing the
battery from your Focal product must
be carried out by a professional. The
battery must be replaced by a battery
identical to the original one and
obtained from a Focal dealer.
Focal cannot guarantee the safety
or compatibility of batteries from
other manufacturers, or that they will
function properly with the device.

EN
Warning symbol. This symbol is designed to warn the user of the presence
of important instructions mentioned in the user manual and relating to the
handling, operation and maintenance of the device.
Do not short-circuit the (+) and
(-) terminals of the battery with
conductive elements (in contact with
metallic objects in particular), or by
any other means.
Do not reverse the polarities.
Do not place burning objects near
and/or on the headphones’ built-in
battery. In general, the battery should
not be exposed to excessive heat
such as sunshine, fire or similar (above
70°C) and/or humidity above 90%.
Do not expose the battery and
charger to water (do not immerse,
pour liquid on them, expose to
condensation or get wet). Do not
expose to rain.
Never use a damaged battery.
Do not subject the battery to impacts
or vibrations. In the event of a severe
impact, stop using the battery.
Do not destroy or incinerate the
battery.
Exposure to internal battery
components or the products released
when burned can be hazardous. If you
have been exposed, contact your GP.
If, during use, the battery gives o an
unusual odour or becomes abnormally
hot or warped, switch o the device
immediately and contact your Focal
dealer.
Only use this product with a certified
Limited Power Supply (LPS) that
meets local regulatory requirements
(e.g. UL, CSA, VDE, CCC & CE).
Only charge the battery at an ambient
temperature between 0°C and 45°C.
Never charge a swollen, leaking or
otherwise damaged battery.
Never use a modified or damaged
charger. Only charge the battery
on non-flammable surfaces (do not
charge it on a flammable surface
such as carpet or wooden floors)
and do not charge it near flammable
materials. Charge the battery on a
non-conductive surface to prevent any
damage associated in particular with a
short circuit.
Keep the battery and charger out of
the reach of children under 14 years
old.
Do not use the headphones while the
battery is charging.
Any battery (original or replacement)
should not be exposed to heat such as
sunshine, fire or similar.
OPTIMAL CONDITIONS FOR
BATTERY USE
For your headphones’ battery to
retain optimal autonomy, and in the
event of prolonged non-use, recharge
it regularly and at least once every
three months or so.
Turn o battery-powered products
when not in use.
For optimal use, do not use
headphones with a battery in places
subject to excessive heat (above
40°C) or excessive cold (below -5°C).
In the event of a problem, contact
your specialist dealer.
- The replacement of a battery with an
incorrect type can defeat a safeguard
(for example, in the case of some
lithium battery types);
- the disposal of a battery into fire or
a hot oven, or mechanically crushing
or cutting of a battery can result in an
explosion;
- leaving a battery in an extremely
high temperature surrouding
environment can result in an explosion
or the leakage of flammable liquid
or gas;
- a battery subjected to extremely low
air pressure may result in an explosion
or the leakage of flammable liquid
or gas.
FCC Regulatory Compliance
This device complies with Part 15 of
the FCC Rules. Operation is subject
to the following two conditions: (1)
this device may not cause harmful
interference, and (2) this device must
accept any interference received,
including interference that may cause
undesired operation.
changes or modifications not
expressly approved by the party
responsible for compliance could void
the user’s authority to operate the
equipment.
This equipment has been tested and
found to comply with the limits for
a Class B digital device, pursuant
to Part 15 of the FCC Rules. These
limits are designed to provide
reasonable protection against
harmful interference in a residential
installation. This equipment generates,
uses and can radiate radio frequency
energy and, if not installed and used in
accordance with the instructions, may
cause harmful interference to radio
communications. However, there is no
guarantee that interference will not
occur in a particular installation.
If this equipment does cause harmful
interference to radio or television
reception, which can be determined
by turning the equipment o and
on, the user is encouraged to try to
correct the interference by one or
more of the following measures:
- Reorient or relocate the receiving
antenna.
- Increase the separation between the
equipment and receiver.
- Connect the equipment into an
outlet on a circuit dierent from that
to which the receiver is connected.
- Consult the dealer or an experienced
radio/TV technician for help.
This equipment complies with FCC
radiation exposure limits set forth for
an uncontrolled environment. This
transmitter must not be co-located
or operating in conjunction with any
other antenna or transmitter.
ISED Regulatory Compliance
This device contains licence-exempt
transmitter(s)/receiver(s) that
comply with Innovation, Science and
Economic Development Canada’s
licence-exempt RSS(s). Operation
is subject to the following two
conditions: (1)This device may not
cause interference.(2)This device
must accept any interference,
including interference that may cause
undesired operation of the device.This
equipment complies with IC RSS-102
radiation exposure limits set forth for
an uncontrolled environment.

16
Bathys
EN
User manual
Thank you for purchasing a Focal product. Welcome to our High-Fidelity world. Innovation, tradition,
excellence and pleasure are our values; our one and only aim is to bring you a sound that is rich, pure and
true. To get the most out of your product, we recommend that you read the instructions in this booklet,
then store it in a safe place to refer to in the future.
1. Package contents
• 1 x Bathys headphones
• 1 x carrying case
• 1 x Jack cable
• 1 x USB-C® cable
• 1 x Quick Start
• 1 x Brand content
2. Application
The Focal app allows you to configure and control the headphones from your mobile device, including
via your smartphone.
Using the app, you can manage Bluetooth® connections, headphones settings and access any new features
added through updates (EQ).
For development purposes, FOCAL-JMLab reserves the right to modify the technical specifications of its products without prior notice.
Non-contractual images.
- Download the app
App Store
Google Store
- Follow the instructions in the app
To facilitate the Focal-JMlab warranty, it is now possible to register
your product online, at www.focal.com/warranty
