FOR-A FocusTemp IR42a User manual

Operating Instructions
Bedienungsanleitung
Mode d’emploi
Istruzioni per l’uso
Instrucciones de funcionamiento
Gebruiksaanwijzing
Instruções de funcionamento
Instrucțiuni de utilizare
0123
-20°C
60°C
85%
ForaCare Suisse AG
Neugasse 55,
9000, St. Gallen,
Switzerland
www.foracare.ch
Forehead Theromometer
Stirn-Thermometer
Thermomètre frontal
Termometro frontale
Termómetro de frente
Voorhoofdthermometer
Termómetro de leitura na testa
Termometru de frunte
FORA IR42a
311-1242100-007

EN-2

EN-3
INTRODUCTION
Thank you for choosing FORA FocusTemp Forehead
Thermometer. Please read this instruction manual first so that
the thermometer can be used safely and correctly. Keep this
instruction manual for future reference. This innovative medical
device uses advanced infrared (IR) technology to measure
temperature instantly and accurately on the forehead/any surface
area. FORA FocusTemp Forehead Thermometer delivers a body
temperature reading from the thermal radiation emitted from the
forehead without any body contact.
INTENDED USE
FORA FocusTemp Forehead Thermometer is intended for
the intermittent measurement and monitoring of human body
temperature from the forehead. The device is intended for
home use by people of all ages who are able to understand the
operating instructions.

EN-4
APPEARANCE AND KEY FUNCTIONS OF THE
THERMOMETER
1. Probe lens
2. Display screen
3. Power/Scan button
4. Protective sensor cap
5. Mode button
6. Memory button
7. Battery Cover
LCD SCREEN
1. Adult body temperature
indicator
2. Child body temperature
indicator
3. Object surface temperature
indicator
4. Error message
5. Memory mode
6. Hold Symbol
7. Battery indicator
8. Temperature display
9. Temperature unit
SCAN
MEMORY SET MORE
1
2
3
5
6
7
4
7
2
1
3
4
5
8
9
6

EN-5
IMPORTANT SAFETY INSTRUCTIONS
READ THIS BEFORE USING AND KEEP THESE
INSTRUCTIONS IN A SAFE PLACE
1. Close supervision is necessary when the thermometer
is used by, on, or near children, handicapped persons or
invalids.
2. Use the thermometer only for the intended use described in
this manual.
3. Do not use the thermometer if it is not working properly, or if
it has sustained any damage.
4. Keep the sensor end clean and free of debris. See
Maintenance section for instructions.
5. Do not use ethylene oxide gas, heat, autoclave, or any other
harsh methods to sterilize the device.
6. Put in place the protective sensor cap on the sensor end
when not in use.
7. Do not use the device shortly after exercise, bathing or
coming indoors.
8. If coming from an environment of warmer or cooler
temperature or after a period of exertion, allow the user and
the thermometer to reach room temperature for 20 minutes
prior to taking a measurement.
9. As the forehead temperature may be affected by sweat, oil
and the surrounding temperature, the reading shall be taken
as a reference only.
10. Do not use in presence of flammable anesthetic mixtures.
11. Do not use accessories which are not supplied or
recommended by the manufacturer.
12. Proper maintenance is essential to the longevity of your
device. If you are concerned about the accuracy of
measurement, please contact the local customer service or
place of purchase for assistance.

EN-6
WARNING AND PRECAUTIONS
► As with any thermometer, proper technique is crucial to
getting accurate temperature readings. Please read this
manual thoroughly and carefully before use.
► Always operate the thermometer in an operating
temperature range 10°C to 40°C, and relative humidity of
less than 85%.
► Always store the thermometer in a cool and dry place:
temperatures between -20°C to 60°C; relative humidity less
than 85%. Avoid direct sunlight.
► Avoid dropping the thermometer.
► Basic safety precautions should always be observed,
especially when the thermometer is used on or near
children and disabled persons.
► This thermometer is not intended to be a substitution for a
consultation with your physician.

EN-7
USING THE DEVICE
Install Battery
1. Remove the battery cover by pressing down at the arrow mark
and slide to the direction of the arrow as shown in the figures
below.
2. Install (2) AAA alkaline batteries and close the battery cover.
3. Remove the batteries if the thermometer is stored and not in
use.
MEASUREMENT MODES
The default measuring mode is for the adult forehead temperature.
Press the MODE button on the side of the thermometer to adjust
the measuring mode.
Adult Forehead Mode: measuring the forehead
temperature of adults
Children Forehead Mode: measuring the forehead
temperature of children (age: 3 ~ 36 months)
Object Surface Mode: measuring the surface
temperature of objects

EN-8
MEASURING TEMPERATURE FOR ADULTS
1. Remove the protective cap. The
forehead should be clear of hair
and perspiration.
2. Aim at the center of the forehead
area 3 to 7cm away from and
perpendicular to the surface of the
skin.
3. Press and release the SCAN
button to take the measurement.
A double “beep” sound indicates
that a reading has been taken and
displayed on the LCD screen.
When a reading is more than 38°C,
a warning symbol will flash with a red
backlight.
4. To take another measurement,
follow steps 2 and 3.
5. The thermometer turns off
automatically after 30 seconds.
Replace the sensory cap when
finished.

EN-9
WARNING AND PRECAUTIONS
► If the reading is < 31.9°C, “Lo” will be displayed.
► If the reading is ≥ 32.0°C and ≤ 37.9 °C, it will be displayed
with a green backlight.
► If the reading is ≥ 38°C and ≥ 43°C, it will be displayed with
a red backlight.
► If the reading is ≥ 43.1°C, “Hi” will be displayed.

EN-10
MEASURING TEMPERATURE FOR CHILDREN
1. Press the SCAN button to turn on
the thermometer.
2. Press and hold the MODE button
for 1 second before releasing.
An adult facial profile should be
flashing, indicating that the preset
mode is for adults.
3. Press the MODE key to switch to
Child mode which is indicated by
a smiley face icon.
4. Aim the scanner at the center
of the child’s forehead or
temple 3 to 7cm away from and
perpendicular to the surface
of the skin. Press and release
the SCAN button to take the
measurement.
A red backlight with a warning
symbol indicates a reading more
than 37.6 °C.
5. The thermometer will be switched off automatically when left
idle for 30 seconds.
6. Replace the sensor cap when finished.
Note:
● If the reading is ≤ 31.9°C, “Lo” will be displayed.
● If the reading is ≥ 32°C and ≤ 37.6 °C, it will be displayed
with a green backlight.
● If the reading is ≥ 37.7 °C and ≤ 43°C, it will be displayed
with a red backlight.
● If the reading is ≥ 43.1°C, “Hi” will be displayed.
● Parents should not rely only on temperature readings. If
you have concerns, please seek medical advice.

EN-11
MEASURING SURFACE TEMPERATURE
1. Press the SCAN button to turn on the thermometer.
2. Press and hold the MODE button for 1 second before releasing.
An adult facial profile should be flashing, indicating that the
preset mode is for adults.
3. Press the MODE key to switch to Surface mode which is
indicated by a thermometer icon.
4. Make sure the probe is flat and close to the surface of the
object and not at an angle. The measurement should be taken
within a distance of 5 cm. Press and hold the SCAN button
as you move the meter along the surface. The HOLD symbol
flashes.
Note:
● If the reading is ≤ 0°C, “Lo” will be displayed.
● If the reading is ≥ 100.1°C, “Hi” will be displayed.
5. Release the button and read the result. If the reading is ≥ 0°C
and ≤ 100.1°C, it will be displayed with a green backlight.

EN-12
Note:
When the memory is full, the oldest result deleted as the new
ones are added. While recalling previous readings, you may
take a measurement by pressing the SCAN button.
RECALLING PAST READINGS
FORA FocusTemp stores 30 of the most recent readings.
1. Press and release the SCAN button to turn on the thermometer.
2. Press and hold the MEMORY button for 1 second to enter the
memory mode which is indicated by a flashing " " symbol.
The most recent reading which is stored will be displayed.
3. Press and release the MEMORY button to scroll through older
readings.
4. When left idle for 30 seconds, the thermometer will be switched
off automatically.

EN-13
ABOUT NORMAL BODY TEMPERATURE &
FEVER
Body temperature can vary from one individual person to the
next. It also varies according to the location on the body and time
of day. Fever indicates that the body temperature is higher than
normal. This symptom may be caused by infection, overdressing
or immunization. Some people may not experience fever even
when they are ill. These include, but are not limited to, infants
younger than 3 months old, persons with compromised immune
systems, persons taking antibiotics, steroids or antipyretics
(aspirin, ibuprofen, acetaminophen), or persons with certain
chronic illnesses. Please consult your physician if you are
concerned about your body temperature readings.
MAINTENANCE
● FORA FocusTemp has no user serviceable internal parts except
battery replacement.
● Always replace Sensor Cap (or place in cradle) when not in use.
● Store in a dry location free of dust and away from direct sunlight.
CLEANING AND DISINFECTION
● Use a soft dry cloth to clean the plastic casing or a cloth
dampened with a solution of water and mild detergent.
Occasionally, 70% isopropanol solution may be used. Never
submerge in liquid.
● The sensor window is recessed to assist in keeping it clean
and free of debris. Inspect the lens and remove any debris.
Smudges may be cleaned by gently wiping the window with
a small foam-tipped swab (non-linting) moistened with 70%
alcohol. Wait 10 minutes prior to taking your temperature.

EN-14
SYMBOL INFORMATION
Symbol Referent
Model number
Consult instructions for use
Caution, consult accompanying
documents
Temperature limitation
Humidity limitation
Keep away from sunlight
Type BF Equipment
Ingress protection rating
Serial number
CE Mark
Manufacturer
Disposal of waste equipment

EN-15
TROUBLESHOOTING
Message What it means What to do
The ambient
temperature
is outside of
the operating
temperature range.
Only operate the
thermometer within an
ambient temperature range
of 10°C to 40°C.
Measured
temperature below
the measurement
range (below 32°C).
Review instructions and
repeat the measurement.
Make sure the distance
from the forehead is not
further than 5cm, and that
the forehead is clear.
Gemeten
temperatuur hoger
dan meetbereik
(boven 43°C).
Review instructions and
repeat the measurement.
Consult a physician if the
problem persists.
Low or no power. New batteries should be
replaced.
Surface temperature
measured outside
of the measurement
range (0°C ~
100°C).
Review the instructions and
re-start the measurement
procedure.

EN-16
SPECIFICATIONS
Model No.: FORA IR42a
Dimension & Weight 155.46 (L) x 40.14 (W) x 39.45 (H) mm,
61.8g (without battery)
Power Source 2 x 1.5V AAA alkaline batteries
Battery Life With new batteries, approx. 3,000
measurements.
Displayed Temperature
range
• Forehead: 32°C to 43°C
• Object Surface: 0°C to 100°C
Display Resolution 0.1°C
Accuracy The accuracy requirements specified in
ASTM E1965-98 is met
• Forehead: ±0.2°C for the range of
35.0°C to 42.0°C / ±0.3°C for the
range of <35.0°C or >42.0°C
• Object surface: ±1°C
Reference to Standards ASTM E1965-98; IEC 60601-1; IEC
60601-1-2 (EMC)
Temperature Unit °C
Operating Temperature
Range
10°C to 40°C
Operating Humidity 85% RH or less
Storage / Transportation
Temperature Range
-20°C to 60°C
Storage / Transportation
Humidity
85% RH or less
Memory Capacity 30 measurements
Expected Service Life 3 years
The specifications may be changed without prior notice.

EN-17
SPECIFICATIONS
Model No.: FORA IR42a
Dimension & Weight 155.46 (L) x 40.14 (W) x 39.45 (H) mm,
61.8g (without battery)
Power Source 2 x 1.5V AAA alkaline batteries
Battery Life With new batteries, approx. 3,000
measurements.
Displayed Temperature
range
• Forehead: 32°C to 43°C
• Object Surface: 0°C to 100°C
Display Resolution 0.1°C
Accuracy The accuracy requirements specified in
ASTM E1965-98 is met
• Forehead: ±0.2°C for the range of
35.0°C to 42.0°C / ±0.3°C for the
range of <35.0°C or >42.0°C
• Object surface: ±1°C
Reference to Standards ASTM E1965-98; IEC 60601-1; IEC
60601-1-2 (EMC)
Temperature Unit °C
Operating Temperature
Range
10°C to 40°C
Operating Humidity 85% RH or less
Storage / Transportation
Temperature Range
-20°C to 60°C
Storage / Transportation
Humidity
85% RH or less
Memory Capacity 30 measurements
Expected Service Life 3 years
The specifications may be changed without prior notice.
WARRANTY TERMS AND CONDITIONS
With respect to disposable products, ForaCare Suisse warrants
to the original purchaser that, at time of delivery, each standard
product manufactured by ForaCare Suisse shall be free from
defects in material and workmanship and, when used for the
purposes and indications described on the labeling, is fit for the
purposes and indications described on the labeling. All warranties
for a product shall expire as of the product expiration date, or if
none, after two (2) years from the original date of purchase, as
long as it has not been modified, altered, or misused. ForaCare
Suisse warranty hereunder shall not apply if:
(i) a product is not used in accordance with its instructions or if it
is used for a purpose not indicated on the labeling; (ii) any repairs,
alterations or other work has been performed by the buyer or
others on such item, other than work performed with ForaCare
Suisse’s authorisation and according to its approved procedures;
or (iii) the alleged defect is a result of abuse, misuse, improper
maintenance, accident or the negligence of any party other than
ForaCare Suisse. The warranty set forth herein is conditioned
upon proper storage, installation, use and maintenance in
accordance with applicable written recommendations from
ForaCare Suisse.
The warranty furnished hereunder does not extend to damaged
items purchased hereunder resulting in whole or in part from the
use of components, accessories, parts or supplies not furnished
by ForaCare Suisse.

EN-18
Warning:
Medical electrical equipment needs special precautions
regarding EMC and needs to be installed according to the EMC
information provided. Careful consideration of this information
is essential when stacking or collocating equipment and when
routing cables and accessories.
Warning:
RF mobile communications equipment can affect medical
electrical equipment.
Recommended separation distance between
portable and mobile RF communications equipment and the FocusTemp
The FocusTemp is intended for use in an electromagnetic environment
(for home healthcare and professional healthcare) in which radiated RF
disturbances are controlled. The customer or the user of the FocusTemp can
help prevent electromagnetic interference by maintaining a minimum distance
between the portable and mobile RF communications equipment (transmitters)
and the FocusTemp as recommended below, depending on the maximum
output power of the communications equipment.
Rated maximum
output power of
transmitter
W
Separation distance according to frequency of
transmitter
m
150 kHz to 80 MHz
d =1,2√P
80 MHz to 800 MHz
d =1,2√P
800 MHz to 2,7
GHz
d =2,3√P
0,01 N/A 0,12 0,23
0,1 N/A 0,38 0,73
1 N/A 1,2 2,3
10 N/A 3,8 7,3
100 N/A 12 23
For transmitters rated at a maximum output power not listed above, the
recommended separation distance d in meters (m) can be estimated using
the equation applicable to the frequency of the transmitter, where p is the
maximum output power rating of the transmitter in watts (W) depending on
the transmitter manufacturer.
Note 1 At 80 MHz and 800 MHz, the separation distance for the higher
frequency range applies.
Note 2 These guidelines may not apply to all situations. Electromagnetic
propagation is a󰀨ected by absorption and reection from structures,
objects and people.

EN-19
Manufacturer’s declaration-electromagnetic emissions
The FocusTemp is intended for use in the electromagnetic environment (for
home healthcare and professional healthcare) specied below.
The customer or the user of the FocusTemp should assure that it is used in
such an environment.
Emission test Compliance Electromagnetic
environment-guidance
(for home healthcare and
professional healthcare)
RF-emissies CISPR 11 Group 1 The FocusTemp uses RF
energy only for internal use.
Therefore, its RF emissions
are very low and are not likely
to cause any interference
from nearby electronic
equipment.
RF-emissies CISPR 11 Class B The FocusTemp is suitable
for use in all establishments,
including domestic
establishments and those
directly connected to the
public low-voltage power
supply network that supplies
buildings used for domestic
purposes.
Harmonic emissions
IEC 61000-3-2
Not applicable
Voltage uctuations
/icker emissions IEC 61000-
3-3
Not applicable
Manufacturer’s declaration-electromagnetic immunity
The FocusTemp is intended for use in the electromagnetic environment (for
home healthcare and professional healthcare) specied below.
The customer or the user of the FocusTemp should assure that it is used in
the environment specied below.
Immunity test IEC 60601
test level
Compliance
level
Electromagnetic
environment-
guidance (for
home healthcare
and professional
healthcare
environment)
Electrostatic
discharge(ESD)
IEC 61000-4-2
Contact:±8 kV
Air±2 kV,±4 kV,±8
kV,±15 kV
Contact:±8 kV
Air±2 kV,±4 kV,±8
kV,±15 kV
Floors should be
wood, concrete
or ceramic tile. If
oors are covered
with synthetic
material, the
relative humidity
should be at least
30%.

EN-20
Electrical fast
transient/burst
IEC 61000-4-4
± 2kV for power
supply lines
± 1kV for input/
output lines
Not applicable
Not applicable
Mains power
quality should be
that of a typical
home healthcare
and professional
healthcare
environment.
Surge IEC 61000-
4-5
± 0.5kV, ±1kV
line(s) to line(s)
± 0.5kV, ±1kV,± 2kV
line(s) to earth
Not applicable
Not applicable
Mains power
quality should be
that of a typical
home healthcare
and professional
healthcare
environment.
Voltage Dips,
short interruptions
and voltage
variations on
power supply
input lines IEC
61000-4-11
Voltage dips:
0 % UT; 0,5 cycle 0
% UT; 1 cycle
70 % UT; 25/30
cycles
Voltage
interruptions:
0 % UT; 250/300
cycle
Voltage dips:
Not applicable
Not applicable
Not applicable
Voltage
interruptions:
Not applicable
Mains power
quality should be
that of a typical
home healthcare
and professional
healthcare
environment.
If the user of
the FocusTemp
requires
continued
operation during
power mains
interruptions, it
is recommended
that the
FocusTemp be
powered from an
uninterruptible
power supply or a
battery.
Power
frequency(50, 60
Hz) magnetic eld
IEC 61000-4-8
30 A/m
50 Hz or 60 Hz
30 A/m
50 Hz and 60 Hz
The FocusTemp
power frequency
magnetic
elds should
be at levels
characteristic of
a typical location
in a typical home
healthcare and
professional
healthcare
environment.
NOTE: UT is the a.c. mains voltage prior to application of the test level.
