Fritsch ANALYSETTE 22 NeXT User manual

ANALYSETTE 22 NeXT
LASER PARTICLE SIZER
Operang instrucons
Valid starng with: 22.90X0/00001
Read the instrucons prior to performing any task!
Translaon of the original operang instrucons

Version 04/2020 Index 000
Fritsch GmbH
Milling and Sizing
Industriestraße 8
D - 55743 Idar-Oberstein
Telephone: [phone]
Fax: [phone]
Email: inf[email protected]
Internet: www.fritsch-sizing.de

Cercaons and CE conformity
Fritsch GmbH has been cered by the SGS-TÜV Saar GmbH.
An audit cered that Fritsch GmbH conforms to the requirements of the
DIN EN ISO 9001:2015.
The enclosed Conformity Declaraon lists the guidelines the FRITSCH
instrument conforms to, to be able to bear the CE mark.
Cercaon
CE Conformity
Cercaons and CE conformity
- 3 -

Table of contents
1 Safety informaon and use........................................................... 6
1.1 Requirements for the user..................................................... 6
1.2 Scope of applicaon............................................................... 6
1.3 Obligaons of the operator.................................................... 7
1.4 Informaon on hazards and symbols used in this manual..... 7
1.5 Informaon on hazards at the instrument........................... 10
1.6 Device safety informaon.................................................... 10
1.6.1 Laser.................................................................................. 11
1.7 Protecve equipment.......................................................... 12
1.8 Electrical safety.................................................................... 12
2 Technical data.............................................................................. 13
2.1 Dimensions.......................................................................... 13
2.2 Weight.................................................................................. 13
2.3 Operang noise.................................................................... 13
2.4 Voltage................................................................................. 13
2.5 Current consumpon........................................................... 13
2.6 Power consumpon............................................................. 14
2.7 Electrical fuses..................................................................... 14
2.8 Measuring ranges................................................................. 14
3Installaon................................................................................... 15
3.1 Transport.............................................................................. 15
3.2 Unpacking............................................................................ 15
3.3 Ambient condions.............................................................. 17
3.4 Seng up............................................................................. 18
3.5 Removing the transport securing device of the measuring
device................................................................................... 18
3.6 Accessory case..................................................................... 19
3.7 Electrical connecon............................................................ 21
3.7.1 Electrical fuses.................................................................. 21
3.7.2 Adapng to the mains....................................................... 21
4Inial start-up.............................................................................. 22
4.1 Connecons for measuring unit........................................... 22
4.2 Connecons for supply units................................................ 22
4.2.1 Wet dispersion unit........................................................... 22
4.3 Preparaon of the computer............................................... 24
4.4 Checking communicaon..................................................... 26
5 Supply units................................................................................. 27
5.1 Wet dispersion unit.............................................................. 27
5.1.1 Design of wet dispersion unit............................................ 27
5.1.2 Selecng the liquids.......................................................... 27
5.1.3 Filling the measuring circuit.............................................. 29
Table of contents
- 4 -

5.1.4 Sample addion................................................................ 30
6 Using the device........................................................................... 31
6.1 Wet dispersion unit.............................................................. 31
6.1.1 Fritsch test powder F500.................................................. 31
6.1.2 Dispersion of barely weable samples............................. 32
6.1.3 Measurement of hardly soluble samples.......................... 33
7 Accessories................................................................................... 34
7.1 Ultrasonic box...................................................................... 34
7.1.1 Assembly of the ultrasonic box......................................... 35
7.2 Immersion pump set............................................................ 36
8 Cleaning........................................................................................ 37
8.1 Cleaning the devices............................................................ 37
8.2 Cleaning the hoses............................................................... 37
8.3 Cleaning the wet measuring cell.......................................... 38
8.3.1 Emptying the system......................................................... 38
8.3.2 Removal of the wet measuring cell................................... 39
8.3.3 Design of wet measuring cell............................................ 40
8.3.4 Removing the wet measuring cell..................................... 41
8.3.5 Cleaning the measuring cell glasses.................................. 42
8.3.6 Flow plate.......................................................................... 42
8.3.7 Sealing rings...................................................................... 43
8.3.8 Mounng the wet measuring cell..................................... 43
9 Maintenance................................................................................ 44
9.1 Replacing hoses in wet dispersion units.............................. 45
9.2 Removing the measuring cell glasses................................... 45
10 Disposal........................................................................................ 47
11 Guarantee terms.......................................................................... 48
12 Exclusion of liability..................................................................... 50
13 Safety logbook............................................................................. 52
14 Index............................................................................................. 53
Table of contents
- 5 -

1 Safety informaon and use
1.1 Requirements for the user
This operang manual is intended for persons assigned with operang
and monitoring the Fritsch ANALYSETTE 22 NeXT. The operang manual
and especially its safety instrucons are to be observed by all persons
working on or with this device. In addion, the applicable rules and regu-
laons for accident prevenon at the installaon site are to be observed.
Always keep the operang manual at the installaon site of the ANALY-
SETTE 22 NeXT.
People with health problems or under the inuence of medicaon,
drugs, alcohol or exhauson must not operate this device.
The ANALYSETTE 22 NeXT may only be operated by authorised persons
and serviced or repaired by trained specialists. All commissioning, main-
tenance and repair work may only be carried out by technically qualied
personnel. Qualied personnel are persons who, because of their educa-
on, experience and training as well as their knowledge of relevant
standards, regulaons, accident prevenon guidelines and operang
condions, are authorised by those responsible for the safety of the
machine to carry out the required work and are able to recognize and
avoid possible hazards as dened for skilled workers in IEC 364.
In order to prevent hazards to users, follow the instrucons in this
manual.
Malfuncons that impair the safety of persons, the ANALYSETTE 22 NeXT
or other material property must be reced immediately. The following
informaon serves both the personal safety of operang personnel as
well as the safety of the products described and any devices connected
to them: All maintenance and repair work may only be performed by
technically qualied personnel.
This operang manual is not a complete technical descripon. Only the
details required for operaon and maintaining usability are described.
Fritsch has prepared and reviewed this operang manual with the
greatest care. However, no guarantee is made for its completeness or
accuracy.
Subject to technical modicaons.
1.2 Scope of applicaon
The ANALYSETTE 22 NeXT can be universally used as an instrument to
determine the parcle size distribuon of suspensions, emulsions and
solids. It is mainly used in research and development and in quality and
process control.
The ANALYSETTE 22 NeXT makes use of the Reverse Fourier design
invented by FRITSCH.
Safety informaon and use
- 6 -

The laser parcle sizer described here is an operaons resource for use in
industrial environments. This operaons resource possesses hazardous
live components and laser radiaon sources during operaon. Therefore
serious health hazards or material damage can result, e.g., aer the
impermissible removal of the required covers or insucient mainte-
nance.
1.3 Obligaons of the operator
Before using the ANALYSETTE 22 NeXT, this manual is to be carefully read
and understood. The use of the ANALYSETTE 22 NeXT requires technical
knowledge; only commercial use is permied.
The operang personnel must be familiar with the content of the oper-
ang manual. For this reason, it is very important that these persons
actually receive the present operang manual. Ensure that the operang
manual is always near the device.
The ANALYSETTE 22 NeXT may exclusively be used within the scope of
applicaons set down in this manual and within the framework of guide-
lines put forth in this manual. In case of non-compliance or improper
use, the customer assumes full liability for the funconal capability of the
ANALYSETTE 22 and for any damage or injury arising from failure to full
this obligaon.
By using the ANALYSETTE 22 NeXT the customer agrees with this and rec-
ognizes that defects, malfuncons or errors cannot be completely
excluded. To prevent risk of damage to persons or property or of other
direct or indirect damage, resulng from this or other causes, the cus-
tomer must implement sucient and comprehensive safety measures for
working with the ANALYSETTE 22 NeXT.
Neither compliance with this manual nor the condions and methods
used during installaon, operaon, use and maintenance of the ANALY-
SETTE 22 NeXT can be monitored by Fritsch GmbH. Improper execuon
of the installaon can result in property damage and thus endanger per-
sons. Therefore, we assume absolutely no responsibility or liability for
loss, damage or costs that result from errors at installaon, improper
operaon or improper use or improper maintenance or are in any way
connected to these.
The applicable accident prevenon guidelines must be complied with.
Generally applicable legal and other obligatory regulaons regarding
environmental protecon must be observed.
1.4 Informaon on hazards and symbols used in this manual
Safety informaon in this manual is designated by symbols. Safety infor-
maon is introduced by keywords that express the extent of the hazard.
Safety informaon
Safety informaon and use
- 7 -

DANGER!
This symbol and keyword combinaon points out a
directly hazardous situaon that can result in death or
serious injury if not avoided.
WARNING!
This symbol and keyword combinaon points out a pos-
sibly hazardous situaon that can result in death or
serious injury if not avoided.
CAUTION!
This symbol and keyword combinaon points out a pos-
sibly hazardous situaon that can result in slight or
minor injury if not avoided.
NOTICE!
This symbol and keyword combinaon points out a pos-
sibly hazardous situaon that can result in property
damage if not avoided.
To call aenon to specic hazards, the following symbols are used in the
safety informaon:
DANGER!
This symbol and keyword combinaon points out a
directly hazardous situaon due to electrical current.
Ignoring informaon with this designaon will result in
serious or fatal injury.
DANGER!
This symbol and keyword combinaon designates con-
tents and instrucons for proper use of the machine in
explosive areas or with explosive substances. Ignoring
informaon with this designaon will result in serious
or fatal injury.
DANGER!
This symbol and keyword combinaon designates con-
tents and instrucons for proper use of the machine
with combusble substances. Ignoring informaon with
this designaon will result in serious or fatal injury.
Special safety informaon
Safety informaon and use
- 8 -

WARNING!
This symbol and keyword combinaon points out a
directly hazardous situaon due to movable parts.
Ignoring informaon with this designaon can result in
hand injuries.
WARNING!
This symbol and keyword combinaon points out a
directly hazardous situaon due to hot surfaces.
Ignoring informaon with this designaon can result in
serious burn injuries due to skin contact with hot sur-
faces.
Safety informaon can refer to specic, individual procedure instrucons.
Such safety informaon is embedded in the procedure instrucons so
that the text can be read without interrupon as the procedure is being
carried out. The keywords described above are used.
Example:
1. Loosen screw.
2.
CAUTION!
Risk of entrapment at the lid.
Close the lid carefully.
3. Tighten screw.
This symbol emphasises useful ps and recommenda-
ons as wells as informaon for ecient operaon
without malfuncon.
To emphasise procedure instrucons, results, lists, references and other
elements, the following designaons are used in this manual:
Designaon Explanaon
1., 2., 3. ...
Step-by-step procedure instrucons
ðResults of steps in the procedure
Safety informaon in the procedure
instrucons
Tips and recommendaons
Further designaons
Safety informaon and use
- 9 -

Designaon Explanaon
References to secons in this manual and rele-
vant documentaon
Lists without a specic order
[Buon] Operang elements (e.g. push buon, switch),
display elements (e.g. signal lamps)
‘Display’ Screen elements (e.g. buons, funcon key
assignment)
1.5 Informaon on hazards at the instrument
There is a laser radiaon hazard warning on the back of the device.
It is explained below.
Do not remove the informaon and warning signs.
Cauon! Beware of laser beam
1.6 Device safety informaon
nThe laser parcle sizer has been designed from the viewpoint of
safety to users; nevertheless, residual hazards cannot be ruled out.
nThe device may only be used for the purpose described in
Ä Chapter
1 ‘Safety informaon and use’ on page 6.
nOnly use original accessories and original spare parts. Failure to
observe this instrucon can compromise the funconing of the
machine.
nSafe conduct must be strictly observed during all work.
Safety informaon and use
- 10 -

DANGER!
Explosion hazard!
– When measuring oxidisable substances, e.g. metal,
organic material, wood, coal, plascs etc. there is a
risk of spontaneous combuson (dust explosion) if
the proporon of ne parcles exceeds a certain
percentage. Therefore special safety measures (e.g.
measurement in suspension) must be taken and
the work must be supervised by a specialist.
– The device is not explosion-protected and is not
suitable for measuring explosive, ammable or oxi-
dising substances.
– The device must not be used in electrically conduc-
ve, dusty or damp environments.
– Do not use highly ammable and ammable liquids
such as alcohols, ketones and benzines etc.
DANGER!
Mains voltage
– Do not allow any liquids to run inside the device.
WARNING!
The maximum accepted concentraon (MAC) levels of
the valid safety regulaons must be observed. If neces-
sary, venlaon must be provided or the machine must
be operated under an extractor hood.
nUnauthorised alteraon of the device will void Fritsch's declaraon
of conformity to European direcves and void the guarantee.
nIf, aer reading the operang manual, there are sll quesons or
problems, please do not hesitate to contact our specialised per-
sonnel.
1.6.1 Laser
ANALYSETTE 22 NeXT
1 semiconductor laser
Wavelength 532 nm, power < 2 mW
The lasers are classied in Class 3b EN 60825-1/11.2001 and with regard
to the laser emier may only be operated in the valid range of the safety
regulaons of the German Labour Inspectorate in accordance with the
corresponding safety instrucons in EN 60825 Part 1 and 2. The user
must inform himself about the dangers of handling laser beams before
use.
Safety informaon and use
- 11 -

WARNING!
Laser radiaon!
Laser devices of laser class 3B and 4 are dangerous for
the human eye, so that even an exposure me of 0.25
sec is sucient to cause permanent damage to the
rena. Therefore it is mandatory for every person who
is operang the device with the housing open during
repairs or maintenance to wear suitable safety goggles.
The safety goggles must be suitable for the wavelength
of the laser being used.
WARNING!
Laser radiaon!
– Never look directly into the laser beam.
– Always avoid placing any reecve objects in the
laser beam.
– Wear suitable safety goggles during maintenance
and adjustment work on the open laser emier. (<
10 mW, 532 nm).
It is not necessary to appoint a laser safety ocer for the ANALYSETTE 22
as the laser radiaon sources are fully enclosed and not accessible.
The ANALYSETTE 22 is classied in laser protecon class 1 according to
EN 60825.
1.7 Protecve equipment
Protecve equipment, such as covers, must be used as intended and may
not be disabled or removed.
1.8 Electrical safety
Connect the measuring unit and ultrasonic box to a mains line protected
with a residual current circuit breaker.
The measuring unit is connected via a table-top power supply with an
own fuse.
Safety informaon and use
- 12 -

2 Technical data
2.1 Dimensions
Measuring unit:
nNeXT: 66.6 x 31.9 x 29.4 cm (W x D x H)
Supply unit:
nWet dispersion unit: 29 x 27.2 x 29 cm (W x D x H)
Accessories:
nUltrasonic box: 29 x 9 x 27.9 cm (W x D x H)
2.2 Weight
Measuring unit:
nNeXT Micro: 24 kg net
nNeXT Nano: 25 kg net
Supply unit:
nWet dispersion unit: 13 kg
Accessories:
nUltrasonic box: 4.8 kg
2.3 Operang noise
The workplace-specic emission value is LpA<70 dB(A).
2.4 Voltage
Measuring unit:
100 - 240V ± 10%
Ultrasonic box:
100-120 V or 200-240 V ± 10%
2.5 Current consumpon
The maximum current consumpon is 0.25 - 0.5 A for the measuring
unit, 0.4 A for the ultrasonic box 230 V and 0.8 A for the ultrasonic box
115 V.
Technical data
- 13 -

2.6 Power consumpon
The maximum power consumpon is 50 W (measuring unit and ultra-
sonic box).
2.7 Electrical fuses
The measuring unit is connected via a table-top power supply with inte-
grated fuse.
2 x 4 A fuses in the ultrasonic box.
2.8 Measuring ranges
ANALYSETTE 22 NeXT Micro
0.5 - 1500 µm
ANALYSETTE 22 NeXT Nano
0.01 - 3800 µm
Technical data
- 14 -

3 Installaon
3.1 Transport
DANGER!
Do not step under the transport pallet during transport.
WARNING!
Improper liing can lead to personal injury or property
damage. The machine is only to be lied with suitable
equipment and by qualied personnel.
Fritsch laser parcle sizers are delivered in wooden cases on pallets. Do
not lt or stack these crates. The laser parcle sizers must be transported
and stored in their packaging and protected from weather and outside
inuences.
Transport over larger distances only in the original Fritsch packaging.
The guarantee excludes all claims for damage due to improper transport.
3.2 Unpacking
Please check the delivery against your order! If the delivery is incomplete
or damaged, inform the shipping agent immediately and inform FRITSCH
GmbH within 24 hours. Any claims received later cannot be considered.
1. Only open the box with the arrows poinng upwards! Remove the
transport packaging as shown in the following illustraons.
2. Pull out the nails that fasten the upper lid and then remove the lid.
3. Remove the rst foam layer from under the lid.
Installaon
- 15 -

4. Next remove the sample bath, the ultrasonic box (if ordered), the
two accessories cases and the cardboard box with the hoses.
5. Remove the next foam layer.
6. Aerwards, take out the screen, the keyboard and the cardboard
box with the connecon kit of the measuring unit.
7. Li the wooden frame carefully away over the measuring unit.
Installaon
- 16 -

8. Li the measuring unit out of the foam mouldings.
Thanks to the grooves in the foam mouldings you
can hold the device by the base plate and li it
out.
3.3 Ambient condions
WARNING!
Mains voltage
– The device may only be operated indoors.
– The surrounding air must not contain any electri-
cally conducve parcles.
– Maximum relave humidity 80% for temperatures
up to 31 °C, linearly decreasing down to 50% rela-
ve humidity at 40 °C.
nThe room temperature should be between 5 and 40 °C.
nStorage and transport is possible between 1 and 40 °C.
nIf stored or transported below -10 °C, you have to wait unl the
instrument has warmed up to ambient temperature before switching
it on. The formaon of condensaon inside the instrument can cause
malfuncons and damage.
Installaon
- 17 -

3.4 Seng up
Necessary connecons:
n1 x power socket
n1 x liquids inlet
n1 x liquids outlet
Locaon requirements:
nLevel, stable and non-vibrang base. It does not have to be fastened
to the surface.
nMake sure when seng up the instrument that it is easily accessible
so that it is easy to operate.
nProtect against strong heat or light sources.
nMake sure there is enough venlaon.
3.5 Removing the transport securing device of the measuring device
The measuring unit is secured with a transport securing device. For disas-
sembling, li the measuring unit up and screw out the securing device.
It is necessary to screw in the transport securing device every me the
measuring unit is transported. Posion the main detector in the
intended posion for that. (See MaScontrol manual)
Installaon
- 18 -

3.6 Accessory case
The following parts for connecng the measuring unit are packed in a
cardboard box:
nPower supply
nUSB cable
nMulple socket outlet
nSpring ring
nPC with operang system and MaScontrol
nMouse
The following parts for connecng the wet dispersion unit are packed in a
cardboard box:
nOutlet hose with 25 mm inner diameter
nPVC mesh wire hose for the inlet
nConnecng cable, measuring unit
If the ultrasonic box has been ordered:
nHose to connect the US box with the wet dispersion unit incl. kink
protecon
nPower cable
nConnecng cable, measuring unit
The measuring cell is packed, with aached hoses, in a further hard-top
case.
Connecon kit, measuring unit
Connecon kit, wet dispersion unit
Accessories case, measuring cell
Installaon
- 19 -

1 Powder spatula
2 Screwdriver
3 Round jars with various bits, hose clamps, hose con-
nectors and screws
4 Transport securing device deposit
5 USB sck with soware and documentaon
6 Dusazin
7 Precision wipes
8 Cleaning sand
9 Standard test powder F 500
Service kit
Installaon
- 20 -
