Fritsch PULVERISETTE 1 classic line User manual

LABORATORY - JAW CRUSHER
PULVERISETTE 1 classic line
Operang instrucons
Valid starng with: 01.50XX/2185
Valid starng with: 01.70XX/2180
Read the instrucons prior to performing any task!
Translaon of the original operang instrucons

Version 03/2019 Index 011
Fritsch GmbH
Milling and Sizing
Industriestraße 8
D - 55743 Idar-Oberstein
Telephone: [phone]
Fax: [phone]
Email: inf[email protected]
Internet: www.fritsch.de

Cercaons and CE conformity
Fritsch GmbH has been cered by the SGS-TÜV Saar GmbH.
An audit cered that Fritsch GmbH conforms to the requirements of the
DIN EN ISO 9001:2015.
The enclosed Conformity Declaraon lists the guidelines the FRITSCH
instrument conforms to, to be able to bear the CE mark.
Cercaon
CE Conformity
Cercaons and CE conformity
- 3 -

Table of contents
1Basic structure............................................................................... 6
2 Safety informaon and use........................................................... 7
2.1 Requirements for the user..................................................... 7
2.2 Scope of applicaon............................................................... 8
2.2.1 Operang principle............................................................. 8
2.3 Obligaons of the operator.................................................... 8
2.4 Informaon on hazards and symbols used in this manual..... 9
2.5 Device safety informaon.................................................... 12
2.6 Protecve equipment.......................................................... 13
2.7 Hazardous points................................................................. 13
2.8 Electrical safety.................................................................... 13
2.8.1 General informaon.......................................................... 13
2.8.2 Protecon against restart.................................................. 14
3 Technical data.............................................................................. 15
3.1 Dimensions.......................................................................... 15
3.2 Weight.................................................................................. 15
3.3 Operang noise.................................................................... 15
3.4 Voltage, current consumpon, power consumpon........... 15
3.5 Electrical fuses..................................................................... 15
3.6 Material................................................................................ 16
3.7 Final neness....................................................................... 16
3.8 Protecon class.................................................................... 16
4Installaon................................................................................... 17
4.1 Transport.............................................................................. 17
4.2 Unpacking............................................................................ 17
4.3 Seng up............................................................................. 17
4.4 Ambient condions.............................................................. 19
4.5 Aaching the funnel............................................................ 19
4.6 Electrical connecon............................................................ 20
4.6.1 Adapng to the mains....................................................... 20
4.6.2 Drive motor....................................................................... 20
4.6.3 Rotaon direcon of the drive motor............................... 21
5Inial start-up.............................................................................. 22
5.1 Switching on......................................................................... 22
5.2 Switching o........................................................................ 22
6 Using the device........................................................................... 23
6.1 Comminuon of material to be crushed.............................. 23
6.1.1 Seng the gap width........................................................ 23
6.1.2 Adding material................................................................. 24
6.1.3 Dust extracon.................................................................. 24
Table of contents
- 4 -

6.1.4 Final neness.................................................................... 24
6.1.5 Seng the pressure plate................................................. 25
6.2 Selecng the crushing plates and lateral support walls....... 26
6.3 Replacing the crushing plates and support walls................. 28
6.3.1 Assembling the crushing plates........................................ 29
6.3.2 Checking the gap width..................................................... 30
6.3.3 Aaching the support walls.............................................. 31
7 Accessories................................................................................... 33
7.1 Conversion for use with the dust exhaust system................ 33
7.2 Conversion kit for metal-free pre-crushing.......................... 35
7.2.1 Model I.............................................................................. 35
7.2.2 Model II............................................................................. 35
7.2.3 Converng the funnel....................................................... 36
7.3 Crushing and grinding in combinaon with the Disk Mill
PULVERISETTE 13 classic line................................................ 41
8 Cleaning........................................................................................ 42
8.1 Grinding chamber................................................................ 42
8.2 Intake connector.................................................................. 43
9 Maintenance................................................................................ 44
9.1 Crushing plates..................................................................... 44
9.2 V-belt.................................................................................... 44
9.3 Guide pin.............................................................................. 45
9.4 Lubricang the bearings...................................................... 45
10 Disposal........................................................................................ 46
11 Guarantee terms.......................................................................... 47
12 Exclusion of liability..................................................................... 49
13 Safety logbook............................................................................. 51
14 Index............................................................................................. 53
Table of contents
- 5 -

1 Basic structure
1 Funnel
2 Fixed crushing plate
3 Fixed crushing plate guide pin
4 Cam sha grinding gap (crank)
5 Cover safety switch
6 Grinding stock container
7 Belt guard
8 Link pin
9 Motor
10 Main switch
Basic structure
- 6 -

2 Safety informaon and use
2.1 Requirements for the user
This operang manual is intended for persons assigned with operang
and monitoring the Fritsch of the PULVERISETTE 1 classic line. The oper-
ang manual and especially its safety instrucons are to be observed by
all persons working on or with this device. In addion, the applicable
rules and regulaons for accident prevenon at the installaon site are
to be observed. Always keep the operang manual at the installaon site
of the of the PULVERISETTE 1 classic line.
People with health problems or under the inuence of medicaon,
drugs, alcohol or exhauson must not operate this device.
The of the PULVERISETTE 1 classic line may only be operated by author-
ised persons and serviced or repaired by trained specialists. All commis-
sioning, maintenance and repair work may only be carried out by techni-
cally qualied personnel. Qualied personnel are persons who, because
of their educaon, experience and training as well as their knowledge of
relevant standards, regulaons, accident prevenon guidelines and oper-
ang condions, are authorised by those responsible for the safety of the
machine to carry out the required work and are able to recognize and
avoid possible hazards as dened for skilled workers in IEC 364.
In order to prevent hazards to users, follow the instrucons in this
manual.
Malfuncons that impair the safety of persons, the of the PULVERISETTE
1 classic line or other material property must be reced immediately.
The following informaon serves both the personal safety of operang
personnel as well as the safety of the products described and any devices
connected to them: All maintenance and repair work may only be per-
formed by technically qualied personnel.
This operang manual is not a complete technical descripon. Only the
details required for operaon and maintaining usability are described.
Fritsch has prepared and reviewed this operang manual with the
greatest care. However, no guarantee is made for its completeness or
accuracy.
Subject to technical modicaons.
Safety informaon and use
- 7 -

2.2 Scope of applicaon
The PULVERISETTE 1 classic line is a Laboratory - jaw crusher for pre-
crushing of hard and brile sample material from the elds of mining
and metallurgy, geology and mineralogy, chemical industry, as well as the
glass and ceramics industry.
The maximum feed size is
nModel I 65 mm
nModel II 100 mm
The achievable nal neness is between approx. 15 mm and 2 mm
depending on the seng.
The jaw crusher described here is producon equipment for use in indus-
trial environments. The device may be used for these purposes only.
2.2.1 Operang principle
The materials are comminuted in a crushing chamber which is formed by
two support walls, an adjustable, xed crushing plate, and an oscillang,
movable crushing plate. The oscillang crushing jaw is driven by a y‐
wheel and a robust cam. Its special sequence of movements draws the
material to be comminuted into the crushing chamber and prevents the
crushed material from geng jammed. Crushed material exits the
crushing chamber though the adjustable output gap and is collected in
the grinding stock container.
2.3 Obligaons of the operator
Before using the of the PULVERISETTE 1 classic line, this manual is to be
carefully read and understood. The use of the of the PULVERISETTE 1
classic line requires technical knowledge; only commercial use is per-
mied.
The operang personnel must be familiar with the content of the oper-
ang manual. For this reason, it is very important that these persons
actually receive the present operang manual. Ensure that the operang
manual is always near the device.
The of the PULVERISETTE 1 classic line may exclusively be used within the
scope of applicaons set down in this manual and within the framework
of guidelines put forth in this manual. In case of non-compliance or
improper use, the customer assumes full liability for the funconal capa-
bility of the PULVERISETTE 1 classic line and for any damage or injury
arising from failure to full this obligaon.
By using the of the PULVERISETTE 1 classic line the customer agrees with
this and recognizes that defects, malfuncons or errors cannot be com-
pletely excluded. To prevent risk of damage to persons or property or of
other direct or indirect damage, resulng from this or other causes, the
customer must implement sucient and comprehensive safety measures
for working with the of the PULVERISETTE 1 classic line.
Safety informaon and use
- 8 -

Neither compliance with this manual nor the condions and methods
used during installaon, operaon, use and maintenance of the of the
PULVERISETTE 1 classic line can be monitored by Fritsch GmbH. Improper
execuon of the installaon can result in property damage and thus
endanger persons. Therefore, we assume absolutely no responsibility or
liability for loss, damage or costs that result from errors at installaon,
improper operaon or improper use or improper maintenance or are in
any way connected to these.
The applicable accident prevenon guidelines must be complied with.
Generally applicable legal and other obligatory regulaons regarding
environmental protecon must be observed.
2.4 Informaon on hazards and symbols used in this manual
Safety informaon in this manual is designated by symbols. Safety infor-
maon is introduced by keywords that express the extent of the hazard.
DANGER!
This symbol and keyword combinaon points out a
directly hazardous situaon that can result in death or
serious injury if not avoided.
WARNING!
This symbol and keyword combinaon points out a pos-
sibly hazardous situaon that can result in death or
serious injury if not avoided.
CAUTION!
This symbol and keyword combinaon points out a pos-
sibly hazardous situaon that can result in slight or
minor injury if not avoided.
NOTICE!
This symbol and keyword combinaon points out a pos-
sibly hazardous situaon that can result in property
damage if not avoided.
Safety informaon
Safety informaon and use
- 9 -

ENVIRONMENT!
This symbol and keyword combinaon points out a pos-
sibly hazardous situaon that can result in environ-
mental damage if not avoided.
To call aenon to specic hazards, the following symbols are used in the
safety informaon:
DANGER!
This symbol and keyword combinaon points out a
directly hazardous situaon due to electrical current.
Ignoring informaon with this designaon will result in
serious or fatal injury.
DANGER!
This symbol and keyword combinaon designates con-
tents and instrucons for proper use of the machine in
explosive areas or with explosive substances. Ignoring
informaon with this designaon will result in serious
or fatal injury.
DANGER!
This symbol and keyword combinaon designates con-
tents and instrucons for proper use of the machine
with combusble substances. Ignoring informaon with
this designaon will result in serious or fatal injury.
WARNING!
This symbol and keyword combinaon points out a
directly hazardous situaon due to movable parts.
Ignoring informaon with this designaon can result in
hand injuries.
WARNING!
This symbol and keyword combinaon points out a
directly hazardous situaon due to hot surfaces.
Ignoring informaon with this designaon can result in
serious burn injuries due to skin contact with hot sur-
faces.
Special safety informaon
Safety informaon and use
- 10 -

Safety informaon can refer to specic, individual procedure instrucons.
Such safety informaon is embedded in the procedure instrucons so
that the text can be read without interrupon as the procedure is being
carried out. The keywords described above are used.
Example:
1. Loosen screw.
2.
CAUTION!
Risk of entrapment at the lid.
Close the lid carefully.
3. Tighten screw.
This symbol emphasises useful ps and recommenda-
ons as wells as informaon for ecient operaon
without malfuncon.
To emphasise procedure instrucons, results, lists, references and other
elements, the following designaons are used in this manual:
Designaon Explanaon
1., 2., 3. ...
Step-by-step procedure instrucons
ðResults of steps in the procedure
References to secons in this manual and rele-
vant documentaon
Lists without a specic order
[Buon] Operang elements (e.g. push buon, switch),
display elements (e.g. signal lamps)
‘Display’ Screen elements (e.g. buons, funcon key
assignment)
Safety informaon in the procedure
instrucons
Tips and recommendaons
Further designaons
Safety informaon and use
- 11 -

2.5 Device safety informaon
nOnly use original accessories and original spare parts. Failure to
observe this instrucon can compromise the safety of the machine.
nAccident-proof conduct is to be strictly followed during all work.
nComply with all currently applicable naonal and internaonal acci-
dent prevenon guidelines.
CAUTION!
Wear hearing protecon!
If a noise level of 85 dB(A) is reached or exceeded, ear
protecon should be worn to prevent hearing damage.
WARNING!
The maximum accepted concentraon (MAC) levels of
the relevant safety guidelines must be observed; if nec-
essary, venlaon must be provided or the machine
must be operated under an extractor hood.
DANGER!
Explosion hazard!
– When Grinding oxidizable substances, e.g. metals
or coal, there is a risk of spontaneous combuson
(dust explosion) if the share of ne parcles
exceeds a certain percentage. When Grinding these
kinds of substances, special safety measures must
be taken and the work must be supervised from a
specialist.
– The PULVERISETTE 1 classic line is not explosion
protected and is not designed to grind explosive
materials.
nDo not remove the informaon signs.
NOTICE!
Immediately replace damaged or illegible informaon
signs.
Please observe!
Safety informaon and use
- 12 -

nUnauthorised alteraon of the of the PULVERISETTE 1 classic line will
void Fritsch's declaraon of conformity to European direcves and
void the guarantee.
nOnly use the of the PULVERISETTE 1 classic line when it is in proper
working order, as intended and in a safety- and hazard-conscious
manner adhering to the operang manual. In parcular, immediately
recfy any malfuncons that could pose a safety hazard.
nIf, aer reading the operang manual, there are sll quesons or
problems, please do not hesitate to contact our specialised per-
sonnel.
2.6 Protecve equipment
Protecve equipment is to be used as intended and may
not be disabled or removed.
All protecve equipment is to be regularly checked for
integrity and proper funconing.
The Laboratory - jaw crusher has a comprehensive safety system:
1. The funnel is protected against being reached into by a zig-zag
shaped material guide.
2. A safety switch monitors the closing of the front cover during oper-
aon and prevents the Laboratory - jaw crusher from starng up
when the cover is open.
nThe switch fulls the direcves concerning personal protecve
equipment.
nThe Laboratory - jaw crusher will not start when the front
cover is open.
nThe Laboratory - jaw crusher stops when the front cover is
opened.
2.7 Hazardous points
nCrushing hazard when closing the front cover!
2.8 Electrical safety
2.8.1 General informaon
nThe main switch disconnects the device from the mains on all poles.
nIf the Laboratory - jaw crusher is not operated for a longer period of
me (e.g. overnight), disconnect the device from the mains by
pulling the mains plug.
Safety informaon and use
- 13 -

nThe Laboratory - jaw crusher is equipped with a motor protecon
switch that is adapted to the mains voltage (according to the type
plate).
The motor protecon switch automacally cuts o the current
supply in the event of an overload or a defecve motor or cable.
Aer the malfuncon has been reced, the device can be switched
on again by means of the main switch.
nThe Laboratory - jaw crusher is switched on and o using the main
switch.
– When the main switch is turned to the Start posion "I" ®, the
Laboratory - jaw crusher starts up.
– When the main switch is turned to the Stop posion "0" ®, the
Laboratory - jaw crusher comes to a standsll aer approx. 3
seconds.
– The front cover can be opened.
2.8.2 Protecon against restart
The Laboratory - jaw crusher comes to a standsll if there is a power
outage during operaon: The Jaw Crusher comes to a standsll aer
approx. 3 seconds.
When electrical power returns, the Laboratory - jaw crusher does not
start up.
nThe jaw crusher is secured against restarng.
nWhen the main switch is turned to the Start posion "I": The Labora-
tory - jaw crusher starts up.
Safety informaon and use
- 14 -

3 Technical data
3.1 Dimensions
Models I + II: 72 x 41 x 83 (height x width x depth)
3.2 Weight
Model I:
177 kg net
202 kg gross
Model II:
205 kg net
230 kg gross
3.3 Operang noise
Emissions value of workplace according to DIN EN ISO 3746:2005 LPa = 93
dB(A).
3.4 Voltage, current consumpon, power consumpon
The device can be operated in the following voltage ranges:
Model I:
nSingle-phase alternang current 115 V +/- 10 %, 21 A, 1.9 kW
nSingle-phase alternang current 230 V +/- 10 %, 9 A, 1.57 kW
nThree-phase alternang current 200 V +/- 10 %, 5.3 A, 1.1 kW
nThree-phase alternang current 400 V +/- 10 %, 2.62 A, 1.45 kW
Model II:
nThree-phase alternang current 230 V +/- 10 %, 9 A, 2.78 kW
nThree-phase alternang current 400 V +/- 10 %, 4.95 A, 2.2 kW
nThree-phase alternang current 500 V +/- 10 %, 5.15 A, 3 kW
nSingle-phase alternang current 230 V +/- 10 %, 13.5 A, 2.36 kW
Transient overvoltages in accordance with overvoltage category II are
permied. (See also
Ä Chapter 4.6 ‘Electrical connecon’ on page 20)
3.5 Electrical fuses
The electrical fuse is a motor protecon switch, which is integrated in the
main switch.
Technical data
- 15 -

3.6 Material
Feed size:
Model I approx. 60 mm
Model II approx. 95 mm
Throughput: (depending on the set gap width and the sample material)
Model I - 140 kg / h
Model II - 200 kg / h
3.7 Final neness
The nal neness depends on the set gap width and the sample material.
Example: Approx. 80 % of stone crushed with the smallest gap has a nal
neness of < 4 mm.
3.8 Protecon class
IP 54
Technical data
- 16 -

4 Installaon
4.1 Transport
The device is delivered on a transport pallet with a wooden cover. We
recommend using a forkli or pallet truck for transporng the packed
device.
DANGER!
Do not step under the transport pallet during transport.
WARNING!
Improper liing can lead to personal injury or property
damage. The machine is only to be lied with suitable
equipment and by qualied personnel.
The guarantee excludes all claims for damage due to improper transport.
4.2 Unpacking
nPull out the nails that fasten the cover to the transport pallet. The
cover is the wooden box that has been placed over the transport
pallet.
nLi the cover o of the transport pallet.
CAUTION!
Crushing hazard!
Always li with 2 persons.
nCompare the contents of the delivery with your order.
4.3 Seng up
DANGER!
Do not step under the transport pallet during transport.
Installaon
- 17 -

CAUTION!
The weight of the jaw crusher is
Model I: 177 kg
Model II: 205 kg
NOTICE!
The Laboratory - jaw crusher must be placed on a at,
stable surface. It can be screwed onto it or a base plate.
1. The jaw crusher is screwed to the pallet from below using 4
screws. Unscrew the screws with a 17 mm spanner.
2. Lash the harnesses to a crane or another hoist.
3. Next, lash the harness to the two eyelets provided for this purpose
on the front and back of the device.
4. Li the device o the transport pallet.
5. To avoid movements of the machine during the grinding process,
mount the included feet with the corresponding rubber pads on
the 4 corners of the machine that were previously aached to the
transport pallet.
6. Screw the 4 feet into the correct threads from below and lock
them from the top using the included lock nuts.
7. Using a crane, bring the jaw crusher to the desired posion and
place the an‐slip mats below the 4 feet. When posioning the
device, make sure it does not swing when it is suspended from the
crane.
8. Remove the harnesses.
Installaon
- 18 -

4.4 Ambient condions
WARNING!
Mains voltage!
– The device may only be operated indoors.
– The surrounding air may not carry any electrically
conducve dust.
– Maximum relave humidity 80% for temperatures
up to 31°C, linearly decreasing down to 50% rela-
ve humidity at 40°C.
nThe room temperature has to stay between 5 - 40°C.
nAltudes up to 2000 m
nDegree of polluon 2 according to IEC 664.
4.5 Aaching the funnel
The Laboratory - jaw crusher is delivered with the funnel not aached.
Before operang the device for the rst me, the funnel must be
aached.
1. Take the funnel and the supplied hexagon socket screw key out of
the packaging.
2. Remove the 4 cylinder screws and the washers with the hexagon
socket screw key.
3. Insert the funnel into the funnel opening intended for this purpose
on the top side of the Laboratory - Jaw Crusher.
4. Screw the funnel to the housing using the 4 previously removed
cylinder head screws and the washers.
Installaon
- 19 -

5. The cylinder head screws must be rmly ghtened so that the
rubber seal is compressed and sealed.
4.6 Electrical connecon
DANGER!
Provide short-circuit protecon!
Risk of damage due to short-circuits.
– Make sure that the socket is connected to a mains
line protected with a residual current circuit
breaker.
Before establishing the connecon, compare the voltage and current
values stated on the type plate with the values of the mains system to be
used. (See
Ä Chapter 3 ‘Technical data’ on page 15)
4.6.1 Adapng to the mains
CAUTION!
Mains voltage!
Changes to the connecon voltage, from 230 V 3~ to
400 V 3~, and / or the connecon line may only be
made by an electrician.
4.6.2 Drive motor
Driven by:
1~ 120 V motor,
1~ 230 V motor,
3~115 / 200 V motor or
3~230 / 400 V motor.
The drive motors are single-phase motors. Because of the drive's high
reducon rao, the jaw crusher comes to a standsll very quickly when
switched o.
Installaon
- 20 -
