Fritsch PULVERISETTE 7 premium line User manual

Operang instrucons
PLANETARY MICRO MILL
PULVERISETTE 7 premium line
Read the instrucons prior to performing any task!
Valid starng with: 07.5000/00100
Translaon of the original operang instrucons

Version 05/2022 Index 032
Fritsch GmbH
Milling and Sizing
Industriestraße 8
D - 55743 Idar-Oberstein
Telephone: [phone]
Email: inf[email protected]
Internet: www.fritsch.de

Cercaons and CE conformity
3
Cercaon
CE Conformity
Cercaons and CE conformity
Fritsch GmbH has been cered by the SGS-TÜV Saar GmbH.
An audit cered that Fritsch GmbH conforms to the requirements of the DIN EN
ISO 9001:2015.
The enclosed Conformity Declaraon lists the guidelines the FRITSCH instrument
conforms to, to be able to bear the CE mark.

Table of contents
4
Table of contents
1 Safety informaon and use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.1 Requirements for the user. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.2 Scope of applicaon. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.2.1 Operang principle. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.2.2 Drive motor and speed regulaon. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.3 Obligaons of the operator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.4 Informaon on hazards and symbols used in this manual. . . . . . . . . . . . 10
1.5 Informaon on hazards at the device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
1.6 Device safety informaon. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
1.7 Protecve equipment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
1.8 Hazardous points. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
1.9 Electrical safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
1.9.1 General informaon. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
1.9.2 Protecon against restart. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
1.9.3 Overload protecon. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
1.9.4 Imbalance detecon. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2Technical data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.1 Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.2 Weight. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.3 Operang noise. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.4 Voltage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.5 Current consumpon. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.6 Protecon class. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.7 Power consumpon. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.8 Electrical fuses. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.9 Material. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
2.10 Final neness. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
3Installaon. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
3.1 Transport. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
3.2 Unpacking. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
3.3 Seng up. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
3.4 Ambient condions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
3.5 Electrical connecon. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Table of contents
5
4Inial start-up. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
4.1 Switching on. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
4.2 Funcon check. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
4.3 Switching o. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
5 Using the device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
5.1 Safety informaon. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
5.1.1 General informaon. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
5.1.2 Overpressure relief of the grinding bowls. . . . . . . . . . . . . . . . . . . . . . . 26
5.1.3 Grinding bowl lid. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
5.2 Choice of grinding bowls and grinding balls. . . . . . . . . . . . . . . . . . . . . . . . 29
5.2.1 Size of the grinding balls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
5.2.2 Number of balls per grinding bowl (independent of the material
quanty). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
5.2.3 Calculated weight of a ball. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
5.3 Impact of the ball size and the material during grinding. . . . . . . . . . . . . 32
5.4 Filling quanes of grinding bowls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
5.5 Filling the grinding bowl. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
5.6 Factors with an impact on grinding. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
5.6.1 Running me (grinding duraon). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
5.6.2 Speed. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
5.6.3 Reverse mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
5.6.4 Number and size of the balls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
5.6.5 Weight of the balls (type of material). . . . . . . . . . . . . . . . . . . . . . . . . . 35
5.7 Dry grinding. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
5.8 Wet grinding (grinding in a suspension). . . . . . . . . . . . . . . . . . . . . . . . . . . 36
5.8.1 The eect of high temperature. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
5.8.2 Safety measures against an excessively high pressure. . . . . . . . . . . . . 37
5.9 Handling the grinding bowl. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
5.9.1 Design. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
5.9.2 Opening the grinding bowl aer a grinding operaon. . . . . . . . . . . . . 38
5.9.3 Closing the grinding bowl. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
5.9.4 Inserng the grinding bowl in the grinding bowl holder. . . . . . . . . . . 42
5.9.5 Removing the grinding bowl. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
5.10 Mass balance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
5.11 Grinding duraon. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
5.12 Conducng a grinding operaon. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
5.12.1 Program sequence aer switching on. . . . . . . . . . . . . . . . . . . . . . . . . . 46
5.12.2 Starng grinding at high speed. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Table of contents
6
5.12.3 Overload. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
5.12.4 "Program" menu item. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
5.12.5 Saving the current data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
5.12.6 Loading the program. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
5.12.7 Seng the me control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
5.12.8 Imbalance check. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
5.12.9 Switching o. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
5.12.10 Cooling the grinding bowl. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
6Accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
6.1 Standard gassing lid for grinding with inert gas. . . . . . . . . . . . . . . . . . . . . 56
6.1.1 Scope of delivery. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
6.1.2 Fing the gassing lid on the grinding bowl. . . . . . . . . . . . . . . . . . . . . . 57
6.1.3 Hose adapter for grinding bowl gassing. . . . . . . . . . . . . . . . . . . . . . . . . 59
6.1.4 Removing the gassing lid in individual steps. . . . . . . . . . . . . . . . . . . . . 60
6.2 Gassing lid with stainless steel, swagelok hose couplings. . . . . . . . . . . . . 62
6.2.1 Scope of delivery / lid design. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
6.2.2 Fing the gassing lid on the grinding bowl. . . . . . . . . . . . . . . . . . . . . . 63
6.2.3 Hose adapter for grinding bowl gassing. . . . . . . . . . . . . . . . . . . . . . . . . 65
6.2.4 Removing the gassing lid in individual steps. . . . . . . . . . . . . . . . . . . . . 66
6.3 EASY GTM Gas Pressure and Temperature Measuring System. . . . . . . . . 67
6.3.1 Case contents and system design. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
6.3.2 Inserng / changing the baery. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
6.3.3 Conguraon of transmier ID and data transmission frequency. . . 70
6.3.4 Installaon of the transmission unit on the EASY GTM bowl. . . . . . . . 71
6.3.5 Installaon of the receiver board in the P-7 premium line. . . . . . . . . . 73
6.3.6 Acvang EASY GTM. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
6.3.7 Entering the temperature limit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
6.3.8 Entering the pressure limit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
6.3.9 Selecng the operang mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
6.3.10 Deacvang EASY GTM. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
6.3.11 Cleaning the EASY GTM system. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
6.3.12 Baery arrangement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
6.4 Special emptying device for grinding bowls. . . . . . . . . . . . . . . . . . . . . . . . 80
6.4.1 Design. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
6.4.2 Handling. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
6.4.3 Cleaning the special emptying device. . . . . . . . . . . . . . . . . . . . . . . . . . 84

Table of contents
7
6.5 Compl. counterweight. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
6.5.1 Design. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
6.5.2 Handling. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
6.6 Planetary mills - "MillControl" soware. . . . . . . . . . . . . . . . . . . . . . . . . . . 86
6.7 Single-use grinding containers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
7 General and oponal sengs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
7.1 Standard Operaon Procedure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
7.1.1 Acvang SOP mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
7.1.2 Deacvang SOP mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
7.1.3 Deleng SOP mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
7.2 RFID. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
7.3 Language change. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
7.4 Screen brightness. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
7.5 Informaon. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
7.6 Interfaces. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
7.7 Firmware update. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
8 Cleaning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
8.1 Grinding elements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
8.2 Mill. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
8.2.1 Removing the grinding chamber cover. . . . . . . . . . . . . . . . . . . . . . . . . 97
9 Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
10 Guarantee terms. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
11 Exclusion of liability. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
12 Safety logbook. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
13 Index. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105

Safety informaon and use
8
1 Safety informaon and use
1.1 Requirements for the user
This operang manual is intended for persons assigned with operang and mon-
itoring the Fritsch PULVERISETTE 7 premium line. The operang manual and
especially its safety instrucons are to be observed by all persons working on
or with this device. In addion, the applicable rules and regulaons for accident
prevenon at the installaon site are to be observed. Always keep the operang
manual at the installaon site of the PULVERISETTE 7 premium line.
People with health problems or under the inuence of medicaon, drugs, alcohol
or exhauson must not operate this device.
The PULVERISETTE 7 premium line may only be operated by authorised persons
and serviced or repaired by trained specialists. All commissioning, maintenance
and repair work may only be carried out by technically qualied personnel.
Qualied personnel are persons who, because of their educaon, experience and
training as well as their knowledge of relevant standards, regulaons, accident
prevenon guidelines and operang condions, are authorised by those respon-
sible for the safety of the machine to carry out the required work and are able to
recognize and avoid possible hazards as dened for skilled workers in IEC 364.
In order to prevent hazards to users, follow the instrucons in this manual.
Malfuncons that impair the safety of persons, the PULVERISETTE 7 premium
line or other material property must be reced immediately. The following
informaon serves both the personal safety of operang personnel as well as
the safety of the products described and any devices connected to them: All
maintenance and repair work may only be performed by technically qualied
personnel.
This operang manual is not a complete technical descripon. Only the details
required for operaon and maintaining usability are described.
Fritsch has prepared and reviewed this operang manual with the greatest care.
However, no guarantee is made for its completeness or accuracy.
Subject to technical modicaons.
1.2 Scope of applicaon
NOTICE
This laboratory instrument is designed for an 8-hour shi oper-
aon at 30 % duty cycle and not for connuous operaon.
The duty cycle is dened as the rao of load duraon to run
me. The run me is dened as load duraon plus pause me.
According to DIN EN 60034-1 (VDE 0530, IEC34-1) a connuous
operaon already takes place aer a standardised run me of
10 minutes. At 30 % duty cycle (DC = rao of load duraon to
run me) a load duraon of 3 minutes and a pause me of 7
minutes would be within standard.
If the standardised run me of 10 minutes is exceeded, then,
by denion, there would be a connuous operaon and
disproporonate temperature increases may occur, possibly
involving increased wear.

Safety informaon and use
9
The planetary micro mill, "PULVERISETTE 7 premium line", can be applied univer-
sally for the fast dry or wet grinding of inorganic and organic samples for analysis,
quality inspecon or material tesng.
During synthesis, the planetary micro mill is used for mixing and homogenizaon
of dry samples, emulsions or suspensions.
The planetary micro mill, premium line , described here is an equipment item for
use in industrial environments.
The device may be used for these purposes only.
1.2.1 Operang principle
aRotaon of the grinding bowl
b Centrifugal force
cRotaon of the support disc
The source material is crushed and ground by grinding balls in a grinding bowl.
The centrifugal forces from the rotaon of the grinding bowls around their own
axis and from the rotang support disc have an eect on the contents of the
grinding bowl, consisng of material to be ground and grinding balls.
The grinding bowl and the support disc have opposite direcons of rotaon,
in order that the centrifugal forces alternate in the same direcon and in the
opposite direcon.
The result is that the grinding balls run down the inside of the bowl's wall with
a fricon eect and the grinding balls hit the opposite wall of the grinding bowl
with an impact eect.
1.2.2 Drive motor and speed regulaon
A maintenance-free electric motor operated via frequency converter is used as
the drive.
1.3 Obligaons of the operator
Before using the PULVERISETTE 7 premium line, this manual is to be carefully
read and understood. The use of the PULVERISETTE 7 premium line requires
technical knowledge; only commercial use is permied.
The operang personnel must be familiar with the content of the operang
manual. For this reason, it is very important that these persons actually receive
the present operang manual. Ensure that the operang manual is always near
the device.
The PULVERISETTE 7 premium line may exclusively be used within the scope of
applicaons set down in this manual and within the framework of guidelines put
forth in this manual. In case of non-compliance or improper use, the customer
assumes full liability for the funconal capability of the PULVERISETTE 7 premium
line and for any damage or injury arising from failure to full this obligaon.
By using the PULVERISETTE 7 premium line the customer agrees with this and
recognizes that defects, malfuncons or errors cannot be completely excluded.
To prevent risk of damage to persons or property or of other direct or indirect
damage, resulng from this or other causes, the customer must implement su‐
cient and comprehensive safety measures for working with the PULVERISETTE 7
premium line.

Safety informaon and use
10
Special safety informaon
Neither compliance with this manual nor the condions and methods used
during installaon, operaon, use and maintenance of the PULVERISETTE 7
premium line can be monitored by Fritsch GmbH. Improper execuon of the
installaon can result in property damage and thus endanger persons. Therefore,
we assume absolutely no responsibility or liability for loss, damage or costs
that result from errors at installaon, improper operaon or improper use or
improper maintenance or are in any way connected to these.
The applicable accident prevenon guidelines must be complied with.
Generally applicable legal and other obligatory regulaons regarding environ-
mental protecon must be observed.
1.4 Informaon on hazards and symbols used in this manual
Safety informaon
Safety informaon in this manual is designated by symbols. Safety informaon is
introduced by keywords that express the extent of the hazard.
DANGER
This symbol and keyword combinaon points out a directly
hazardous situaon that can result in death or serious injury if
not avoided.
WARNING
This symbol and keyword combinaon points out a possibly
hazardous situaon that can result in death or serious injury if
not avoided.
CAUTION
This symbol and keyword combinaon points out a possibly
hazardous situaon that can result in slight or minor injury if
not avoided.
NOTICE
This symbol and keyword combinaon points out a possibly
hazardous situaon that can result in property damage if not
avoided.
To call aenon to specic hazards, the following symbols are used in the safety
informaon:
DANGER
This symbol and keyword combinaon points out a directly haz-
ardous situaon due to electrical current. Ignoring informaon
with this designaon will result in serious or fatal injury.

Safety informaon and use
11
Safety informaon in the procedure instrucons
Tips and recommendaons
DANGER
This symbol and keyword combinaon designates contents and
instrucons for proper use of the machine in explosive areas
or with explosive substances. Ignoring informaon with this
designaon will result in serious or fatal injury.
DANGER
This symbol and keyword combinaon designates contents
and instrucons for proper use of the machine with combus-
ble substances. Ignoring informaon with this designaon will
result in serious or fatal injury.
WARNING
This symbol and keyword combinaon points out a directly
hazardous situaon due to movable parts. Ignoring informaon
with this designaon can result in hand injuries.
WARNING
This symbol and keyword combinaon points out a directly
hazardous situaon due to hot surfaces. Ignoring informaon
with this designaon can result in serious burn injuries due to
skin contact with hot surfaces.
Safety informaon can refer to specic, individual procedure instrucons. Such
safety informaon is embedded in the procedure instrucons so that the text can
be read without interrupon as the procedure is being carried out. The keywords
described above are used.
Example:
1. Loosen screw.
2. CAUTION
Risk of entrapment at the lid.
Close the lid carefully.
3. Tighten screw.
This symbol emphasises useful ps and recommendaons as
wells as informaon for ecient operaon without malfunc-
on.

Safety informaon and use
12
Further designaons To emphasise procedure instrucons, results, lists, references and other ele-
ments, the following designaons are used in this manual:
Designaon Explanaon
1., 2., 3. ...
Step-by-step procedure instrucons
ðResults of steps in the procedure
References to secons in this manual and relevant
documentaon
Lists without a specic order
[Buon] Operang elements (e.g. push buon, switch), dis-
play elements (e.g. signal lamps)
‘Display’ Screen elements (e.g. buons, funcon key assign-
ment)
1.5 Informaon on hazards at the device
There is a laser radiaon hazard warning on the back of the device.
It is explained below.
Do not remove the informaon and warning signs.
Cauon! Hot surface
Cauon! Crushing hazard
1.6 Device safety informaon
■Only use genuine accessories and genuine spare parts. Failure to observe this
instrucon can compromise the safety of the machine.
■Accident-proof conduct is to be strictly followed during all work.

Safety informaon and use
13
DANGER
Explosion hazard!
−Wear safety goggles. The high temperature or chemical
reacons during the grinding process may result in over-
pressure in the grinding bowl. Splashing hazard! Explosion
hazard! Do not fail to observe ⮫ Chapter 5.1 ‘Safety infor-
maon’ on page 25 and ⮫ Chapter 5.8.2 ‘Safety measures
against an excessively high pressure’ on page 37 .
−Never use brute force to open the grinding bowl. Open
the grinding bowl only if you are sure that the internal
pressure has been released completely. Observe the
opening instrucons in ⮫
Chapter 5.9.2 ‘Opening the
grinding bowl aer a grinding operaon’ on page 38
and
⮫ Chapter 5.8.2 ‘Safety measures against an excessively
high pressure’ on page 37 .
−The device may only be operated indoors. The surrounding
air must not contain any electrically conducve dust.
−When grinding oxidisable substances (e.g. metal or coal),
there is a risk of spontaneous combuson (dust explosion)
if the proporon of ne parcles exceeds a certain per-
centage. Chemical reacons are also possible during wet
grinding. When grinding these kinds of substances, special
safety measures (e.g. wet grinding) must be taken and the
work must be supervised by a specialist.
−The device is not explosion-protected and is not suitable
for grinding explosive materials.
DANGER
−Do not reuse damaged accessories.
−If the planetary micro mill or its components are damaged
or if its operaon is not as described in the operang
manual, the device may not be put into service. In such a
case, consult your Fritsch GmbH representave or distrib-
utor.
WARNING
The maximum accepted concentraon (MAC) levels of the valid
safety regulaons must be observed. If necessary, venlaon
must be provided or the machine must be operated under an
extractor hood.

Safety informaon and use
14
CAUTION
−Wear hearing protecon! Above a sound level of 90dB(A)
−Wear safety gloves! The grinding bowls may get very
hot. See ⮫ Chapter 1.8 ‘Hazardous points’ on page 15 ,
⮫
Chapter 5.8.1 ‘The eect of high temperature’
on page 37 and ⮫ Chapter 5.12.10 ‘Cooling the grinding
bowl’ on page 55 .
−Do not grind with the device for several hours in succes-
sion without cooling phases. Risk of overheang!
−The device may not be run without supervision. In certain
operang states, the vibraons may result in a shiing
eect on the surface.
■Do not remove the informaon signs.
■Unauthorised alteraon of the device will void Fritsch's declaraon of con-
formity to European direcves and void the guarantee.
■If, aer reading the operang manual, there are sll quesons or problems,
please do not hesitate to contact our specialists.
1.7 Protecve equipment
Protecve equipment is to be used as intended and may not
be disabled or removed.
All protecve equipment is to be regularly checked for integ-
rity and proper funconing.
DANGER
−The valves on the grinding bowls may not be repaired.
■Each me before using the planetary micro mill, check that the protecve
equipment is not damaged or contaminated (see ⮫ Chapter 1.8 ‘Hazardous
points’ on page 15
, ⮫ Chapter 1.9 ‘Electrical safety’ on page 15 and
⮫ Chapter 5.1 ‘Safety informaon’ on page 25 ).
■Do not make any changes to the protecve equipment, apart from the main-
tenance tasks listed in the operang manual.
■The device's grinding chamber cover can only be opened and closed by a
motor and therefore not without a connecon to the power supply. See
⮫ Chapter 1.9.2 ‘Protecon against restart’ on page 15 .
■It can only be opened when the mill comes to a stop.
■The grinding chamber cover must always be closed during grinding.
■When the grinding chamber cover is open, the mill's mechanical unit is
locked mechanically to prevent it from starng.

Safety informaon and use
15
1.8 Hazardous points
■Crushing hazard when opening and closing the grinding chamber cover (the
closing force can be adjusted, consult Fritsch GmbH).
■Crushing hazard when adjusng the control display.
■Crushing hazard when using the locking lever.
CAUTION
Fire hazard at the grinding bowl aer grinding and during the
grinding pauses. See ⮫
Chapter 5.3 ‘Impact of the ball size and
the material during grinding’ on page 32
, ⮫ Chapter 5.8.1 ‘The
eect of high temperature’ on page 37 and ⮫ Chapter 5.12.10
‘Cooling the grinding bowl’ on page 55 .
DANGER
The grinding bowl may open extremely suddenly if the internal
pressure is too high. Never use brute force to open the bowl.
Do not fail to observe ⮫ Chapter 5.8.1 ‘The eect of high tem-
perature’ on page 37 and ⮫ Chapter 5.8.2 ‘Safety measures
against an excessively high pressure’ on page 37 .
1.9 Electrical safety
1.9.1 General informaon
■The main switch separates the device from the power supply with two poles.
■Turn o the main switch if the planetary micro mill is "out of service" for
prolonged periods (e.g. overnight).
1.9.2 Protecon against restart
In the case of a power failure during operaon or aer turning the device o at
the main switch, the grinding chamber cover is locked. When the power supply is
restored, the grinding chamber is not opened unl the soware detects that the
drive is staonary. For safety reasons, however, the planetary micro mill does not
restart.

Safety informaon and use
16
1.9.3 Overload protecon
■In the event of an overload, the device reduces the speed in a controlled
manner. This special operang state is indicated on the display.
■The device shuts down if the drive motor becomes too hot.
■The device shuts down if the drive is blocked.
1.9.4 Imbalance detecon
The device shuts down if there is excessive imbalance. See ⮫ Chapter 5 ‘Using the
device’ on page 25
.

Technical data
17
2 Technical data
2.1 Dimensions
360 mm x 400 mm x 580 mm
(height x width x depth)
2.2 Weight
Net: approx. 44 kg
Gross: approx. 61 kg
2.3 Operang noise
The sound level is approx. 74 dB (A). This value uctuates signicantly, depending
on the speed and material to be ground and on the type of grinding bowl and
grinding balls.
The device is rated with IP 20.
2.4 Voltage
The device can be operated in two voltage ranges:
■Wide range input 100-240 V ± 10 %.
Transient overvoltage according to overvoltage category II permied.
If the device is to be operated with two dierent voltages,
e.g. 115 V or 230 V, it must be disconnected from the power
supply at least 60 seconds before switching over the voltage.
2.5 Current consumpon
The maximum current consumpon is approx. 10 A (115 V)
or 5 A (230 V).
2.6 Protecon class
IP 21
2.7 Power consumpon
The maximum power consumpon is approx. 1100 W.
2.8 Electrical fuses
■Fuses on the back of device: 2x10 A T

Technical data
18
2.9 Material
■Maximum feed amount in the case of hard material approx. 5 mm
■Maximum feed 1 - 60 ml
2.10 Final neness
■Dry grinding up to d50 < 20 µm (depending on the material)
■Wet grinding up to d50 < 0.1 µm (depending on the material)

Installaon
19
3Installaon
3.1 Transport
The device is delivered on a transport pallet with a wooden cover. We recom-
mend using a forkli or pallet truck for transporng the packed device.
DANGER
Do not step under the transport pallet during transport.
WARNING
Improper liing can lead to personal injury or property
damage. The machine is only to be lied with suitable equip-
ment and by qualied personnel.
The guarantee excludes all claims for damage due to improper transport.
3.2 Unpacking
■Open the straps of the packaging.
■Remove the lid from the crate or open the crate upwards.
■Remove the accessory cardboard pieces and addional padding.
■Li the upper part of the packaging o the transport pallet.
■The device can now be lied o the pallet and out of the foam padding.
CAUTION
Crushing hazard!
Always li with 2 persons.
Hold the boom edge of the housing when liing.
■Compare the contents of the delivery with your order.
Grinding bowls made of hardened steel may have recesses on
the surface caused during producon. They do not have an
impact on grinding or the grinding results and usually disap-
pear aer the rst grinding operaon.
These recesses on the surface, if present, are within the range
of the permissible producon tolerances. Complaints relang
to such grinding bowls therefore cannot be accepted.

Installaon
20
3.3 Seng up
NOTICE
Allow the device to acclimase for two hours before commis-
sioning. High temperature dierences can lead to condensaon
in the device and damage to the electronics aer switching on.
Strong temperature uctuaons can occur during transport or interim storage.
Depending on the temperature dierence between the installaon site and the
transport or storage environment, condensaon can form inside the device. This
can damage the electronics if the devices are switched on too early. Wait for at
least two hours aer setup before switching on the device.
■Set up the planetary micro mill indoors, on a at and rm surface.
NOTICE
Never operate PULVERISETTE 7 premium line while it is
standing on the transport pallet!
■Make sure that:
–all switches / control elements are easy to access;
–the venlaon slots are not covered;
–the interfaces (USB / Ethernet) are easy to access.
CAUTION
Risk of overheang!
The cover on the housing openings may reduce the supply of
air, thus causing the device to overheat.
■Please store the transport packaging in order that it can be reused in case you
need to return the product. Fritsch GmbH denies all liability for any damage
due to improper packaging (non-genuine packaging).
3.4 Ambient condions
WARNING
Mains voltage!
−The device may only be operated indoors.
−The surrounding air may not carry any electrically conduc-
ve dust.
−Maximum relave humidity 80% for temperatures up to
31°C, linearly decreasing down to 50% relave humidity at
40°C.
■The room temperature has to stay between 5 - 40°C.
■Altudes up to 2000 m
■Degree of polluon 2 according to IEC 664.
