FRO­NIUS TransTig 1600 Guide

TransTig 1600
TransTig 1700
42,0426,0023,EN 012006
Operating Instructions
Spare Parts List
TIG power source
GB
42,0426,0023,EN 003-08112013

ud_fr_st_et_00493 012004
Dear Reader
Thank you for choosing Fronius - and congratulations on your new, technically high-
grade Fronius product! This instruction manual will help you get to know your new
machine. Read the manual carefully and you will soon be familiar with all the many
great features of your new Fronius product. This really is the best way to get the most
out of all the advantages that your machine has to offer.
Please also take special note of the safety rules - and observe them! In this way, you
will help to ensure more safety at your product location. And of course, if you treat your
product carefully, this definitely helps to prolong its enduring quality and reliability - things
which are both essential prerequisites for getting outstanding results.
Introduction

ud_fr_st_sv_00467 022013
I
EN
Safety rules
DANGER!
WARNING!
CAUTION!
“NOTE!” indicates a situation which implies a risk of impaired welding result
and damage to the equipment.
NOTE!
This equipment has been made in accordance with the state of the art and
all recognised safety rules. Nevertheless, incorrect operation or misuse may
still lead to danger for
- the life and well-being of the operator or of third parties,
- the equipment and other tangible assets belonging to the owner/
operator,
- efficient working with the equipment.
All persons involved in any way with starting up, operating, servicing and
maintaining the equipment must
- be suitably qualified
- know about welding and
- read and follow exactly the instructions given in this manual.
The instruction manual must be kept at the machine location at all times. In
addition to the instruction manual, copies of both the generally applicable
and the local accident prevention and environmental protection rules must
be kept on hand, and of course observed in practice.
All the safety instructions and danger warnings on the machine itself:
- must be kept in a legible condition
- must not be damaged, must not be removed
- must not be covered, pasted or painted over
For information about where the safety instructions and danger warnings
are located on the machine, please see the section of your machine’s
instruction manual headed “General remarks”.
General remarks
Important!
“DANGER!” indicates an imminently hazardous situation which, if not
avoided, will result in death or serious injury. This signal word is to be
limited to the most extreme situations. This signal word is not used for
property damage hazards unless personal injury risk appropriate to this
level is also involved.
“WARNING!” indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury. This signal word is not used
for property damage hazards unless personal injury risk appropriate to this
level is also involved.
“CAUTION!” indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury. It may also be used to
alert against unsafe practices that may cause property damage.
“Important!” indicates practical hints and other useful special-information. It is no
signal word for a harmful or dangerous situation.
Whenever you see any of the symbols shown above, you must pay even closer
attention to the contents of the manual!

ud_fr_st_sv_00467 022013 II
Operation or storage of the power source outside the stipulated range is
deemed to be “not in accordance with the intended use”. The manufacturer
shall not be liable for any damage resulting herefrom.
Temperature range of ambient air:
- when operating: - 10 °C to + 40 °C (14 °F to 104 °F)
- when being transported or stored: - 20 °C to + 55 °C (-4 °F to 131 °F)
Relative atmospheric humidity:
- up to 50 % at 40 °C (104 °F)
- up to 90 % at 20 °C (68 °F)
Ambient air: Free of dust, acids, corrosive gases or substances etc.
Elevation above sea level: Up to 2000 m (6500 ft)
Ambient
conditions
The machine may only be used for jobs as defined by the “Intended purpose”.
The machine may ONLY be used for the welding processes stated on the
rating plate.
Utilisation for any other purpose, or in any other manner, shall be deemed to
be "not in accordance with the intended purpose". The manufacturer shall
not be liable for any damage resulting from such improper use.
Utilisation in accordance with the “intended purpose” also comprises
- complete reading and following of all the instructions given in this manual
- complete reading and following of all the safety instructions and danger
warnings
- performing all stipulated inspection and servicing work.
The appliance must never be used for the following:
- Thawing pipes
- Charging batteries/accumulators
- Starting engines
The machine is designed to be used in industrial and workshop
environments. The manufacturer shall not be liable for any damage resulting
from use of the machine in residential premises.
ikewise the manufacturer will accept no liability for defective or faulty work
results.
Utilisation for
intended purpose
only
Any malfunctions which might impair machine safety must be eliminated
immediately - meaning before the equipment is next switched on.
It’s your safety that’s at stake!
The owner/operator undertakes to ensure that the only persons allowed to
work with the machine are persons who
- are familiar with the basic regulations on workplace safety and accident
prevention and who have been instructed in how to operate the machine
- have read and understood this operating manual particulary the sections
on “Safety rules”, and have confirmed as much with their signatures
- be trained in such a way that meets with the requirements of the work
results
Regular checks must be performed to ensure that personnel are still working
in a safety-conscious manner.
Obligations of
owner/operator
General remarks
(continued)

ud_fr_st_sv_00467 022013
III
EN
Before starting work, all persons to be entrusted with carrying out work with
(or on) the machine shall undertake
- to observe the basic regulations on workplace safety and accident
prevention
- to read this operating manual particulary the sections on “Safety rules”
and to sign to confirm that they have understood these and will comply
with them.
Before leaving the workplace, personnel must ensure that there is no risk of
injury or damage being caused during their absence.
Obligations of
personnel
Protection for
yourself and
other persons
When welding, you are exposed to many different hazards such as:
- flying sparks and hot metal particles
- arc radiation which could damage your eyes and skin
- harmful electromagnetic fields which may put the lives of cardiac pace-
maker users at risk
- electrical hazards from mains and welding current
- increased exposure to noise
Mains connec-
tion
High-performance devices can affect the quality of the mains power due to
their current-input.
This may affect a number of types of device in terms of:
- connection restrictions
- criteria with regard to maximum permissible mains impedance *)
- criteria with regard to minimum short-circuit power requirement *)
*) at the interface with the public mains network
see Technical Data
In this case, the plant operator or the person using the device should check
whether or not the device is allowed to be connected, where appropriate
through discussion with the power supply company.
- noxious welding fumes and gases.
Anybody working on the workpiece during welding must wear suitable
protective clothing with the following characteristics:
- flame-retardant
- isolating and dry
- must cover whole body, be undamaged and in good condition
- protective helmet
- trousers with no turn-ups
NOTE! Ensure that the mains connection is earthed properly.

ud_fr_st_sv_00467 022013 IV
The fumes given off during welding contain gases and vapors that are
harmful to health.
Welding fumes contain substances which may cause birth defects and
cancers.
Keep your head away from discharges of welding fumes and gases.
Do not inhale any fumes or noxious gases that are given off.
Extract all fumes and gases away from the workplace, using suitable
means.
Ensure a sufficient supply of fresh air.
Where insufficient ventilation is available, use a respirator mask with an
independent air supply.
If you are not sure whether your fume-extraction system is sufficiently
powerful, compare the measured pollutant emission values with the
permitted threshold limit values.
Close the shielding gas cylinder valve or central gas supply if no welding is
taking place.
Hazards from
noxious gases
and vapours
Keep other people - especially children - well away from the equipment and
the welding operation while this is in progress. If there are still any other
persons nearby during welding, you must
- draw their attention to all the dangers (risk of being dazzled by the arc or
injured by flying sparks, harmful welding fumes, high noise immission
levels, possible hazards from mains or welding current ...)
- provide them with suitable protective equipment and/or
- erect suitable protective partitions or curtains.
Protection for
yourself and
other persons
(continued)
“Protective clothing” also includes:
- protecting your eyes and face from UV rays, heat and flying sparks with
an appropriate safety shield containing appropriate regulation filter glass
- wearing a pair of appropriate regulation goggles (with sideguards)
behind the safety shield
- wearing stout footwear that will also insulate even in wet conditions
- protecting your hands by wearing appropriate gloves (electrically insula-
ting, heat-proof)
- To lessen your exposure to noise and to protect your hearing against
injury, wear ear-protectors!
Information on
noise emission
values
The device generates a maximum sound power level of <80 dB(A) (ref. 1pW)
when idling and in the cooling phase following operation at the maximum
permissible operating point under maximum rated load conditions according
to EN 60974-1.
It is not possible to provide a workplace-related emission value during wel-
ding (or cutting) as this is influenced by both the process and the environ-
ment. All manner of different welding parameters come into play, including the
welding process (MIG/MAG, TIG welding), the type of power selected (DC or
AC), the power range, the type of weld metal, the resonance characteristics
of the workpiece, the workplace environment, etc.

ud_fr_st_sv_00467 022013
V
EN
Hazards from
mains and weld-
ing current
Flying sparks can cause fires and explosions!
Never perform welding anywhere near combustible materials.
Combustible materials must be at least 11 meters (36 ft. 1.07 in.) away from
the arc, or else must be covered over with approved coverings.
Have a suitable, approved fire extinguisher at the ready.
Sparks and hot metal particles may also get into surrounding areas through
small cracks and openings. Take suitable measures here to ensure that
there is no risk of injury or fire.
Do not perform welding in locations that are at risk from fire and/or
explosion, or in enclosed tanks, barrels or pipes, unless these latter have
been prepared for welding in accordance with the relevant national and
international standards.
Welding must NEVER be performed on containers that have had gases,
fuels, mineral oils etc. stored in them. Even small traces of these
substances left in the containers are a major explosion hazard.
Hazards from
flying sparks
An electric shock is potentially life-threatening, and can be fatal.
Do not touch any live parts, either inside or outside the machine.
In MIG/MAG and TIG welding, the welding wire, the wire spool, the drive
rollers and all metal parts having contact with the welding wire are also live.
Always place the wirefeeder on an adequately insulated floor or base, or
else use a suitable insulating wirefeeder holder.
Ensure sufficient protection for yourself and for other people by means of a
dry base or cover that provides adequate insulation against the ground/
frame potential. The base or cover must completely cover the entire area
between your body and the ground/frame potential.
All cables and other leads must be firmly attached, undamaged, properly
insulated and adequately dimensioned. Immediately replace any loose
connections, scorched, damaged or underdimensioned cables or other
leads.
The harmfulness of the welding fumes will depend on e.g. the following
components:
- the metals used in and for the workpiece
- the electrodes
- coatings
- cleaning and degreasing agents and the like
For this reason, pay attention to the relevant Materials Safety Data Sheets
and the information given by the manufacturer regarding the components
listed above.
Keep all flammable vapors (e.g. from solvents) well away from the arc
radiation.
Hazards from
noxious gases
and vapours
(continued)

ud_fr_st_sv_00467 022013 VI
If the following instructions are ignored, stray welding currents may occur.
These can cause:
- fires
- overheating of components that are connected to the workpiece
- destruction of PE conductors
- damage to the machine and other electrical equipment
Ensure that the workpiece clamp is tightly connected to the workpiece.
Attach the workpiece clamp as close as possible to the area to be welded.
On electrically conductive floors, the machine must be set up in such a way
that it is sufficiently insulated from the floor.
Stray welding
currents
Hazards from
mains and weld-
ing current
(continued)
Do not loop any cables or other leads around your body or any part of your
body.
Never immerse the welding electrode (rod electrode, tungsten electrode,
welding wire, ...) in liquid in order to cool it, and never touch it when the
power source is ON.
Twice the open-circuit voltage of one single welding machine may occur
between the welding electrodes of two welding machines. Touching the
potentials of both electrodes simultaneously may be fatal.
Have the mains and the machine supply leads checked regularly by a
qualified electrician to ensure that the PE (protective earth) conductor is
functioning correctly.
Only run the machine on a mains network with a PE conductor, and plugged
into a power outlet socket with a protective-conductor contact.
If the machine is run on a mains network without a PE conductor and
plugged into a power outlet socket without a protective-conductor contact,
this counts as gross negligence and the manufacturer shall not be liable for
any resulting damage.
Wherever necessary, use suitable measures to ensure that the workpiece is
sufficiently grounded (earthed).
Switch off any appliances that are not in use.
Wear a safety harness if working at height.
Before doing any work on the machine, switch it off and unplug it from the
mains.
Put up a clearly legible and easy-to-understand warning sign to stop
anybody inadvertently plugging the machine back into the mains and
switching it back on again.
After opening up the machine:
- discharge any components that may be storing an electrical charge
- ensure that all machine components are electrically dead.
If work needs to be performed on any live parts, there must be a second
person on hand to immediately switch off the machine at the main switch in
an emergency.
