Furuno 1824C-BB User manual

PRINTED IN JAPAN
MODEL 1824C-BB MARINE RADAR
MODEL 1834C-BB MARINE RADAR
MODEL 1934C-BB MARINE RADAR
MODEL 1944C-BB MARINE RADAR
MODEL 1954C-BB MARINE RADAR
GD-1920C-BB COLOR VIDEO PLOTTER
VX2

The paper used in this manual
is elemental chlorine free.
Your Local Agent/DealerYour Local Agent/Dealer
9-52 Ashihara-cho,9-52 Ashihara-cho,
Nishinomi
y
a 662-8580, JAPANNishinomi
y
a 662-8580, JAPAN
Tele
p
hone :Tele
p
hone : 0798-65-21110798-65-2111
FaxFax 0798-65-42000798-65-4200
::
F
IRST EDITION :
F
IRST EDITION : FEBFEB.. 20052005
Printed in JapanPrinted in Japan
A
ll ri
g
hts reserved.
A
ll ri
g
hts reserved.
Pub. No.Pub. No. IME-35490-AIME-35490-A
*
00015180600
*
*
00015180600
*
*
00015180600
*
*
00015180600
*
(( DAMIDAMI )) M1804C-BB_GD1920C-BBM1804C-BB_GD1920C-BB * 0 0 0 1 5 1 8 0 6 0 0 ** 0 0 0 1 5 1 8 0 6 0 0 *
*
IME
35490
A
00
*
*
IME
35490
A
00
*
*
IME
35490
A
00
*
*
IME
35490
A
00
*
* I M E 3 5 4 9 0 A 0 0 ** I M E 3 5 4 9 0 A 0 0 *

i
WARNING
Radio Frequency
Radiation Hazard
The radar antenna emits electromagnetic
radio frequency (RF) energy which can be
harmful, particularly to your eyes. Never
look directly into the antenna aperture from
a close distance while the radar is in
operation or expose yourself to the trans-
mitting antenna at a close distance.
Distances at which RF radiation levels of
100 and 10 W/m
2
exist are given in the
table below.
Note: If the antenna unit is installed at a
close distance in front of the wheel house,
your administration may require halt of
transmission within a certain sector of
antenna revolution. This is possible - Ask
your FURUNO representative or dealer to
provide this feature.
MODEL Distance to
100 W/m
2
point
Distance to
10 W/m
2
point
MODEL
1834C-BB Nil
Worst case
0.20 m
Worst case
1.80 m
SAFETY INSTRUCTIONS
Do not open the equipment
unless totally familiar with
electrical circuits and
service manual.
Only qualified personnel
should work inside the
equipment.
Wear a safety belt and hard
hat when working on the
antenna unit.
Serious injury or death can
result if someone falls from
the radar mast.
WARNING
Construct a suitable service platform
from which to install the antenna unit.
Serious injury or death can result if some-
one falls from the radar mast.
Turn off the power at the mains switch-
board before beginning the installation.
Fire, electrical shock or serious injury can
result if the power is left on or is applied
while the equipment is being installed.
ELECTRICAL
SHOCK
HAZARD
MODEL
1934C-BB
MODEL
1944C-BB
Worst case
3.00 m
Nil Worst case
2.50 m
Observe the following compass safe
distances to prevent deviation of a
magnetic compass.
Standard Steering
Processor unit
MODEL1834C-BB antenna unit
MODEL1934C-BB antenna unit
MODEL1944C-BB antenna unit
1.40 m 0.90 m
0.45 m 0.30 m
Control unit
0.90 m 0.70 m
1.00 m
1.00 m 0.80 m
0.80 m
CAUTION
MODEL1954C-BB antenna unit
1.00 m 0.75 m
MODEL
1954C-
BB
XN12A
XN13A
Nil
Worst case
2.50 m
Worst case
2.30 m
Power supply unit (1954C-BB)
1.40 m 0.95 m
MODEL1824C-BB antenna unit
1.25 m 0.85 m
MODEL
1824C-BB Nil Worst case
0.50 m

ii
TABLE OF CONTENTS
EQUIPMENT LISTS.............................................................................................iii
SYSTEM CONFIGURATIONS .............................................................................. v
1. MOUNTING ...................................................................................................1-1
1.1 Mounting the Control Unit.......................................................................................... 1-1
1.2 Mounting the Processor Unit ..................................................................................... 1-4
1.3 Mounting the Antenna Unit of MODEL1824C-BB ...................................................... 1-5
1.4 Mounting the Antenna Unit of MODEL1834C-BB .....................................................1-13
1.5 Mounting the Antenna Unit of MODEL1934C-BB/1944C-BB/1954C-BB...................1-18
1.6 Mounting the Power Supply Unit for MODEL1954C-BB ...........................................1-27
2. WIRING..........................................................................................................2-1
2.1 Standard Wiring......................................................................................................... 2-1
2.2 Wiring the Power Supply Unit for MODEL 1954C-BB ................................................ 2-4
3. SETTING UP THE EQUIPMENT...................................................................3-1
3.1 Setting up with the Installation Wizard....................................................................... 3-1
3.2 Checking Magnetron Heater Voltage........................................................................3-13
4. OPTIONAL EQUIPMENT..............................................................................4-1
4.1 External Buzzer......................................................................................................... 4-1
4.2 ARP Kit ARP-11......................................................................................................... 4-2
PACKING LISTS ............................................................................................... A-1
OUTLINE DRAWINGS...................................................................................... D-1
INTERCONNECTION DIAGRAMS....................................................................S-1

iii
EQUIPMENT LISTS
Standard supply
Name Type Code No. Qty Remarks
Control unit RCU-017 - 1
Processor unit RPU-015 - 1
RSB-0094-0075 - MODEL1824C-BB
RSB-0071-057 - MODEL1834C-BB
XN10A-RSB-0070-064 - MODEL1934C-BB, 24 rpm
XN10A-RSB-0073-064 - MODEL1934C-BB, 48 rpm
XN12A-RSB-0070-059 - MODEL1944C-BB, 24 rpm
XN12A-RSB-0073-059 - MODEL1944C-BB, 48 rpm
XN12A-RSB-0072-060 - MODEL1954C-BB, 4ft, 24 rpm
XN12A-RSB-0073-060 - MODEL1954C-BB, 4ft, 48 rpm
Antenna unit
XN13A-RSB-0072-060 -
1
MODEL1954C-BB, 6ft, 24 rpm
Power supply unit PSU-005 - 1 For MODEL 1954C-BB
CP03-26000 000-080-049 MJ-A7SPF0006-050
CP03-26100 000-080-536
1set
MJ-A7SPF0006-100
For control
unit
CP03-25900 000-080-542 1
For Processor unit:
MJ-A3SPF0018-050Z,
CP03-25901
CP03-21800 000-080-014
For MODEL1824C-BB/1834C-BB
10 m signal cable
CP03-21810 000-080-015
For MODEL1824C-BB/1834C-BB
15 m signal cable
CP03-21820 000-080-016
For MODEL1824C-BB/1834C-BB
20 m signal cable
CP03-21830 000-080-017
1
For MODEL1824C-BB/1834C-BB
30 m signal cable
CP03-22000 000-080-021
For 1934C-BB/1944C-BB/1954C-BB
10 m signal cable
CP03-22010 000-080-022
For 1934C-BB/1944C-BB/1954C-BB
15 m signal cable
CP03-22020 000-080-023
For 1934C-BB/1944C-BB/1954C-BB
20 m signal cable
CP03-22030 000-080-024
1
For 1934C-BB/1944C-BB/1954C-BB
30 m signal cable
Installation
materials
CP03-24501 000-080-191 1 For 1954C, power supply unit
Accessories FP03-09301 000-852-297 1 For RCU-017
SP03-14501 000-844-420 1set Fuses for processor unit
Spare parts SP03-14001 000-080-018 1set Fuses for 1954C-BB’s power
supply unit

iv
Optional supply
Name Type Code No. Qty Remarks
000-013-484 For GD-1920C-BB, 100 VAC
000-013-485 For GD-1920C-BB, 110 VAC
000-013-486 For GD-1920C-BB, 220 VAC
PR-62
000-013-487
1
For GD-1920C-BB, 230 VAC
Rectifier
RU-3423 000-030-443 1 For MODEL series
External buzzer XH3-BZ-L970 000-146-422 1
MJ-A6SPF0014-010 000-144-421 1 For NavNet, 1 m
MJ-A6SPF0014-050 000-144-422 1 For NavNet, 5 m
MJ-A6SPF0014-100 000-144-423 1 For NavNet, 10 m
MJ-A6SPF0014-200 000-144-424 1 For NavNet, 20 m
MJ-A6SPF0014-300 000-144-425 1 For NavNet, 30 m
MJ-A6SPF0012-050 000-134-424 1 For navaid, 5 m, 6P-6P cross
MJ-A6SPF0012-100 000-133-817 1 For navaid, 10 m, 6P-6P cross
MJ-A6SPF0003-050 000-117-603 1 w/6P connector, 5 m
MJ-A6SPF0009-100 000-125-236 1 w/6P connector, 10 m
MJ-A6SPF0007-100 000-125-237 1 For compass, 10 m, 6P-6P straight
MJ-A7SPF0007-050 000-144-418 1 w/7P connector, 5 m
MJ-A6SRMD/TM11AP8-0
05
000-144-463 1 Adapter cable for HUB
3COX-2P-6C 5M 000-146-500 1
3COX-2P-6C 10M 000-146-501 1 For monitor D-sub 15
MJ-B24LPF0010-100 000-147-880 1 For remote display, 10 m
MJ-B24LPF0010-200 000-147-881 1 For remote display, 20 m
Cable assy.
MJ-B24LPF0010-300 000-147-882 1 For remote display, 30 m
ARP kit ARP-11 008-523-050 1 ARP Board, for radar
Mounting bracket
(1) OP03-92 008-445-070 1 For MODEL1834C-BB
Mounting bracket
(2) OP03-93 008-445-080 1 For MODEL1824C-BB
Chart card - -- Specify when ordering.
EMI core CP03-24801 008-481-410 1 For remote display cable
connection
Ring unit MU3721 000-144-645 1 For trackball of control unit
Desktop mounting
kit
FP03-09901 008-443-540 1 For control unit RCU-017
MJA7SPF0006-050 000-147-879 1 Cable between processor unit and
control unit
Cable assy.
MJA7SPF0006-100 000-147-578 Cable between processor unit and
control unit
RCU-017-E-5-CS 000-080-533 1 w/5 m cableControl unit
RCU-017-E-5-CS 000-080-534 1 w/10 m cable

v
SYSTEM CONFIGURATIONS
All NavNet products incorporate a "network circuit board" to integrate each NavNet product
on board through an optional LAN cable (Ethernet 10BASE-T). Each NavNet product is
assigned an IP address to enable transfer of images between other NavNet products. For
example, video plotter pictures can be transferred to a radar and vice versa. Pictures
received via the NavNet may be adjusted at the receiving end.
The number of processor units which may be installed depends on the number of network
sounders connected. For a system incorporating three or more NavNet products, a "hub" is
required to process data.
For one network sounder: one radar and three plotters, or four plotters
For two network sounders: one radar and two plotters, or four plotters
Heading sensor
Navigator
Echo sounder
Rectifier
RU-3423
GPS receiver
GP-310B/320B
12 - 24 VDC*
Network
Sounder
ETR-6/10N
ETR-30N
Other NavNet
system
(GD-1920C-BB, etc.)
Antenna Unit
MODEL
1834C-BB
MODEL
1934C-BB MODEL
1944C-BB
Processor unit
RPU-015
100/110/115/220/230 VAC
1φ, 50/60 Hz*
Monitor
(Local supply)
(See next page)
MODEL
1954C-BB
Control unit
RCU-017
Power Supply
Unit PSU-005
*:The power for the power supply unit
and display unit must be drawn from
the same power source.
Facsimile
Receiver
FAX-30
MODEL1824C-BB
PUSHTO ENTERPUSHTO ENTER
DEFDEF
MNOMNO
VWXVWX
_'#_'#
POWERPOWER
RANGERANGE
TXTX
00
JKLJKL
44
77
STUSTU
55
88
ABCABC 2211
BB
GAINGAIN
ALARMALARM
EBLEBL
VRMVRM
PQRPQR
YZ&YZ&
66
99
DISPDISP
EE
MENUMENU
CC
DD
CLEARCLEAR
GHIGHI
33
SAVESAVE
MOBMOB HIDEHIDE SHOWSHOW
AA
POWER
DATA 3 NETWORK CONT DATA 1DATA 2
DJ-1
SLAVE DISPLAY
RGB OUT
NTSC/PAL
2
GND
3
INPUT
12-24 VDC
1
CARD SLOT
3
2
1
GND
F.G.
12 VDC
OUTPUT
OPTION
ARPA
ARP-11
: Standard
: Option
: Local supply
NavNet system: Model 1824C-BB/1834C-BB/1934C-BB/1944C-BB/1954C-BB

vi
Network
Sounder
ETR-6/10N
ETR-30N
GPS receiver
GP-310B/320B
12 - 24 VDC 100/110/115/220/230 VAC
1φ, 50/60 Hz
Rectifier
PR-62
Navigator
Echo sounder
Monitor
(Local supply)
Facsimile
Receiver
FAX-30
Other NavNet
system
(Model 1834C-BB, etc.)
Processor unit
RPU-015
Control unit
RCU-017
PUSHTO ENTERPUSHTO ENTER
DEFDEF
MNOMNO
VWXVWX
_'#_'#
POWERPOWER
RANGERANGE
TXTX
00
JKLJKL
44
77
STUSTU
55
88
ABCABC 2211
BB
GAINGAIN
ALARMALARM
EBLEBL
VRMVRM
PQRPQR
YZ&YZ&
66
99
DISPDISP
EE
MENUMENU
CC
DD
CLEARCLEAR
GHIGHI
33
SAVESAVE
MOBMOB HIDEHIDE SHOWSHOW
AA
POWER
DATA 3 NETWORK CONT DATA 1DATA 2
DJ-1
SLAVE DISPLAY
RGB OUT
NTSC/PAL
2
GND
3
INPUT
12-24 VDC
1
CARD SLOT
3
2
1
GND
F.G.
12 VDC
OUTPUT
OPTION
ARPA
ARP-11
: Standard
: Option
: Local supply
Heading sensor
NavNet system: GD-1920C-BB
Note: The output signal from the processor unit for a monitor is as follows.
RGB signal: Analog 0.7 Vpp, Output impedance 75 Ω
Synchro signal: H 31.5 kHz, V 60Hz (Separate), TLL level
(VGA signal)
Choose a monitor whose aspect ratio is 4:3, for example, VGA, SVGA, XGA, SXGAX,
VXGA, QXGA, etc

vii
Three-or-more-unit NavNet system
HUB
Network Sounder
ETR-6/10N
ETR-30N
(option)
Radar Antenna Unit
OR
GPS Receiver GP-310B/320B
Radar Antenna Unit
OR
GPS Receiver GP-310B/320B
Sounder data
Radar data Plotter data
Network Sounder
ETR-6/10N
ETR-30N
(option)
Facsimile
Receiver
FAX-30
(option)
Sounder data
Facsimile data
RADAR
or
PLOTTER
RADAR
or
PLOTTER
Three-or-more-unit NavNet system
Two-unit NavNet system
Radar Antenna Unit
OR
GPS Receiver GP-310B/320B
Radar, plotter data
Radar, plotter data
Radar Antenna Unit
OR
GPS Receiver GP-310B/320B
RADAR
or
PLOTTER
RADAR
or
PLOTTER
Two-unit NavNet system

viii
This page intentionally left blank.

1-1
1. MOUNTING
1.1 Mounting the Control Unit
1.1.1 Mounting considerations
The control unit can be mounted on a desktop or flush mounted in a console or panel. For
flush mounting, the optional flush mount kit is required.
When selecting a mounting location for the control unit keep the following in mind:
• Keep the control unit out of direct sunlight.
• The temperature and humidity at the mounting location should be moderate and stable.
• Locate the unit away from exhaust pipes and vents.
• The mounting location should be well ventilated.
• Mount the unit where shock and vibration are minimal.
• Keep the unit away from electromagnetic field generating equipment such as motors
and generators.
• For maintenance and checking purposes, leave sufficient space at the sides and rear of
the unit and leave slack in cables. Minimum recommended space is shown in the outline
drawing for the control unit.
• A magnetic compass will be affected if the control unit is placed too close to it. Observe
the compass safe distances shown in the SAFETY INSTRUCTIONS to prevent
disturbance to the magnetic compass.

1-2
1.1.2 Mounting procedure
Flush mounting
Follow the procedure below to mount the control unit in a panel, using accessories
FP03-10001.
1. Prepare a cutout in the mounting location, referring to the outline drawing at the end of
this manual.
2. Set the control unit to the cutout.
3. Attach the mounting plate to the control unit with four screws M4 x 10 from the rear side.
4. Screw four wing bolts into wing nuts.
5. Fasten the control unit to the mounting location with four wing bolts and wing nuts
assembled at step 4.
Hanger fixture
19-023-1061
Hex bolt
Hanger fixture 19-023-1062
Flush mounting the control unit
6. Attach hard cover to protect the control unit.
How to remove the hard cover
Place your thumbs at the locations shown with
circles in the illustration at right, and then lift the
cover while pressing it with your thumbs.

1-3
Desktop mounting
Use the optional desktop mount kit FP03-09901 (Code number 008-443-540).
No. Name Type Code No. Qty
1 Hanger fixture 19-023-1061 100-307-941 1
2 Hanger fixture 19-023-1062 100-307-951 1
3 Tapping screw 5 x 20 000-802-081 4
4 Hex bolt M5 x 10 000-802-288 2
1. Fix the hanger fixture 19-023-1062 on a desktop with four tapping screws (5x20).
2. Fix the hanger fixture 19-023-1061 to the rear panel of the control unit with four M4x10
(supplied as accessories).
3. Set the control unit to the hanger fixture 19-023-1062 fixed at step 1 and fit it with two
hex bolts.
Hanger fixture
19-023-1061
Hex bolt
Hanger fixture 19-023-1062
Desktop mounting of display unit
4. Attach hard cover to protect the control unit.

1-4
1.2 Mounting the Processor Unit
The unit can be mounted on the deck, a desktop or on a bulkhead. Select a mounting
location considering the points below.
• Locate the unit out of direct sunlight.
• Select a location where temperature and humidity are moderate and stable.
• Consider the length of the cable connected among the processor unit, antenna unit (or
power supply unit) and control unit.
• For mounting on a bulkhead, be sure the mounting location is strong enough to support
the unit (4.1kg) under the pitching and rolling normally encountered on the vessel.
• Leave sufficient space around the unit for maintenance and servicing. Recommended
maintenance space appears in the outline drawing at the back of this manual.
• A magnetic compass will be affected if the processor unit is placed too close to the
magnetic compass. Observe the compass safe distances in the SAFETY
INSTRUCTIONS to prevent disturbance to the magnetic compass.
Tabletop or deck mounting: Fasten with four tapping screws.
Bulkhead mounting: Mark four fixing hole positions on the bulkhead. Screw in two tapping
screws at lower fixing positions, leaving 5 mm protruding. Set the processor unit to the
screws and screw in two tapping screws at upper positions. Tighten all screws.
POWER
310±0.5
375
235
270
250±0.5
7
2-φ7 fixing holes
2 fixing holes
DATA 3 NETWORK CONT DATA 1DATA 2
DJ-1
REMOTE FMD DISPLAY
RGB OUT
NTSC/PAL
2
GND
3
INPUT
12-24 VDC
1
CARD SLOT
3
2
1
GND
F.G.
12 VDC
OUTPUT
OPTION
0.3 A MAX
Processor unit, mounting dimensions

1-5
1.3 Mounting the Antenna Unit of MODEL1824C-BB
1.3.1 Mounting considerations
When selecting a mounting location for the antenna unit, keep in mind the following points.
• Install the antenna unit on the hardtop, radar arch or on a mast on an appropriate
platform. (For sailboats, a mounting bracket is optionally available.) It should be placed
where there is a good all-round view with, as far as possible, no part of the ship’s
superstructure or rigging intercepting the scanning beam. Any obstruction will cause
shadow and blind sectors. A mast, for instance, with a diameter considerably less than
the width of the antenna unit, will cause only a small blind sector. However, a horizontal
spreader or crosstrees in the same horizontal plane would be a much more serious
obstruction; place the antenna unit well above or below it.
Antenna unit
Antenna unit
Antenna unit
Antenna unit
Typical antenna unit placement on sailboat and powerboat
• In order to minimize the chance of picking up electrical interference, avoid where
possible routing the antenna cable near other electrical equipment onboard. Also avoid
running the cable in parallel with power cables.
• Observe the compass safe distances mentioned in the SAFETY INSTRUCTIONS to
prevent interference to a magnetic compass.

1-6
1.3.2 Mounting procedure
1. Remove the mounting hardware from the bottom of the antenna unit: four each of hex
bolts (M10X20), spring washers and flat washers. Save the mounting hardware to use it
to fix the antenna unit to the mounting platform later on.
Flat washer
Spring washer
Hex bolt (M10 x 20)
Screws
two screws on other side
Bow
Stern
Antenna unit, showing location of mounting hardware
2. Construct a platform (wood, steel*, or aluminum) of 5-10 mm (recommended dimension)
in thickness referring to the outline drawing at back of this manual. Fasten the platform
to the mounting location. Next, position the mounting base on the platform so the cable
entrance faces the stern direction.
*: For steel platform take appropriate measures to prevent corrosion.
Note: When drilling holes in the platform, be sure they are parallel with the fore and aft
line.
3. Using the hex bolts, flat washers and spring washers removed at step 1, fasten the
mounting base to the platform. The torque should be between 19.6-24.5 N•m.
Note: Longer hex bolts (M10X25) are supplied with the installation materials. Use them
instead of the hex bolts removed earlier if the mounting platform thickness is
5–10 mm.
Flat
washer
Antenna base
assy.
Spring
washer
Platform
Hex bolt Apply silicone sealant.
(M10 x 25
or M10 x 20)
5 mm or under :M10x20
5-10 mm: M10x25
over 10 mm: locally supplied bolts
Effective
thread
length:
12 mm
How to fasten the mounting base to platform

1-7
4. The mounting base is fitted with a snap holder, which may be used to hang the cover
after removal. Use the hole next to a screw hole inside the cover to hang it.
a) Unfasten the snap assy. with the string attached at the holder in the mounting base.
b) Unwind the string.
c) Attach the snap to a screw hole on the inside of the cover.
Note: Do not hang any other objects with the snap.
Remove and discard
the packing material.
Snap holder
Antenna unit, inside view

1-8
5. Unfasten the rotation detector cable from the cable clamps, referring to the figure on
page 1-11.
6. Unfasten 16 screws (c
1, c 2and c 3in the figure below) to dismount the shield plate,
core case and core case cover.
GND
IF
+V
OP
GND
-V
OP
Vt
GND
Pan head screws
M3x10 2 pcs. 2
Shield plate
Pan head screws
M4x8 9 pcs.
Pan head screws
M4x10 5 pcs.
Core case cover
Core case
1
1
1
1
11
1
1
3
3
3
3
3
3
3
3
3
3
2
2
Cable clamps
11Rotation detector cable
Caution: Be careful not to pinch the rotation detector cable when remounting the shield
plate.

1-9
7. Pass the antenna cable with connector through the cable gland, gasket and cable
entrance of the antenna unit, and then tighten cable gland.
Note 1: Be sure the shrink tube on the antenna cable does not contact the gasket.
Note 2: Pinch the gasket tightly and insert it into the cable entrance. Confirm that the slit
in the gasket is completely closed after inserting it into the cable entrance.
Rubber gasket
Gasket
Cable Gland
Sectional view
Mounting base
Rubber gasket
Antenna cable
Gasket
Close the gasket
tightly.
Shrink tube
Do not allow
shrink tube to
contact gasket.
Antenna unit, inside view
8. Twist antenna connector cables at the position between the shrink tube and the cable tie,
and then attach EMI core (supplied) to cables as shown below. After attachment, shift
EMI core slightly to confirm that it does not pinch cables.
Cable tie
Shrink tube
Attach EMI core.
Gasket Mounting base
Twist cables here.
Location of EMI core

1-10
9. Attach connectors of the antenna cable to the locations shown in the figure below, and
then fasten a pan head screw M4x10 to fix shield cable and core case (removed at step
6.)
J801
(9 pin)
J809
(4 pin)
J810
(13 pin)
Pan head screws
M4x10 9 pcs.
Antenna unit, connector location and fixing the shield cable w/core case
10. Put the EMI core on the antenna cable into the core case attached at step 9, with the flat
side of the core facing downward.
EMI core
Core case
EMI core, putting into core case
11. Refasten the shield plate and core case cover with 15 screws. Be sure that the cable
from the rotation detector passes through the notch between the two cable ties.
Notch
How to pass the rotation detector cable
