GABBY CAROLINE User manual

CAROLINE CHEST LARGE
ASSEMBLY INSTRUCTION
PARTS :
HARDWARE : TOOLS NOT REQUIRED:
Date: 30-07-2018 Page 1 of 3
F
5 PCS
Feet
1 PC
E
Body
HARDWARE INCLUDE :
1. 2 Anti Tip Kit
A. 4 -Small Screw
B. 4- Large Screw
C. 4-Bracket
D. 2-Retention Belt
PARTS INCLUDE :
E. 1 –Body
F. 5 –Feet
1 Anti Tip Kit
2 Set
Screwdriver

CAROLINE CHEST LARGE
ASSEMBLY INSTRUCTION
- Place the chest on its back . Insert each Feet (F) into the given female receiving slots and
turn the Bun Feet clockwise into place.
-If the floor is uneven adjust the levelers located at the underside of the Feet, to do this lift Up
the side that need to be elevated to provide access to the levelers, turn the leveler until
adequate contact with the floor.
Page 2 of 3
STEP 1
Body
Feet
Leveler
STEP 2

CAROLINE CHEST LARGE
ASSEMBLY INSTRUCTION
Attach the Brackets (C) horizontally to the top of the back of the Chest using the Small Screws (A).
Screw the remaining Brackets (C) vertically 1 inch below the brackets attached to the Chest
using the large screws (B).The Large Screws (B) should be screwed into a stud in the wall. Align the
Brackets vertically and string in the Retention Belt (D). Confirm Strap is securely laced and locked.
Page 3 of 3
B
D
A
C
Wall
