Gazebo penguin 41218MR-12 User manual

ZZZ-184.41218MR.0312-21.GP.EN.doc WEB VERSION 1
41218MR-12 SAND
41218MR-32 SLATE
12 X 18 SOLARIUM
ASSEMBLY INSTRUCTIONS
DO NOT DESTROY THE BOXES UNTIL COMPLETELY ASSEMBLED
PLEASE VERIFY THE CONTENT OF EACH BOX AGAINST THE LIST OF PARTS
Three adults required for assembly
Base Dimensions 12’ ½”x18’11”
Largest Dimensions 12’10”x19’9”
Overall Height 110’’
APPROX.

ZZZ-184.41218MR.0312-21.GP.EN.doc WEB VERSION 2
DO NOT DESTROY THE BOXES UNTIL COMPLETELY ASSEMBLED
PLEASE VERIFY THE CONTENT OF EACH BOX AGAINST THE LIST OF PARTS
12ft x 18ft / 3.66m x 5.49m Solarium
Instruction Manual
IMPORTANT: RETAIN FOR FUTURE REFERENCE, READ CAREFULLY
For assistance with assembly, installation, parts, or customer service, contact Gazebo Penguin Customer
Service Department at the numbers listed below (English & French, Mon-Fri 8:00AM to 4:00 PM EST):
Montreal: [phone] Elsewhere in Canada and the US: 1-800-737-7174
Consult with your local governing authority / local municipal codes regarding installation of temporary structures before
purchase or assembly. Some jurisdictions may require permits for, or otherwise regulate, installation and use.
WARNING:
For outdoor use.
Snow should be regularly cleared from the roof and not allowed to accumulate.
Retain your proof of purchase for warranty purposes. Also keep the original boxes
until the installation is complete and correct.
The unit may take more than 4 hours and 3 people are required for this assembly.
PRIOR TO ASSEMBLY:
Please don't destroy boxes until completely assembled.
The foundation must be level, flat, and solid, such as concrete or asphalt.
Keep away from overhead utility lines, tree branches, and other structures.
Check for underground pipes or wires if digging or drilling is required.
Do not install near roof lines or other structures that could shed snow, ice, or excessive rain run-off onto the roof top.
Assemble the structure as close to its final location as possible.
It is recommended to wear safety gloves, safety glasses, and hard hats for installation.
Do not hang from, climb on, or stand on the structure or roof.
Before assembly, read instructions and check that all parts are present in the boxes. If any parts are missing, refer to warranty
information.
A 6ft (1.8m) stepladder, Phillips screwdriver, tape measure, level, mallet, and a tarp to place parts on will be required for
assembly (not included).
Remove top protective film from roof panels prior to assembly; DO NOT remove bottom protective film until ready to insert roof
panels, so as to identify which side is on top.
ANCHORING INSTRUCTIONS:
Proper anchoring of the frame to the base and the wall is required for safety.
Any structure not anchored securely has the potential to fly away during high wind causing damage and safety hazard.
How the item is anchored, and the hardware and tools required, will vary based upon the set up location and are not provided.
Please check with your local hardware store if for the appropriate anchors for your surface.
Do not anchor to pavers / pavement slabs because they are not a solid foundation.
Periodically check the anchors to ensure they remain secure
CARE AND MAINTENANCE:
In case of a defective or damaged part, or for any other questions concerning the product, please contact the manufacturer
directly.
Please have the parts list and part numbers on hand when ordering or requesting replacement parts.
ROOF PANELS:
Gently clean with an environmentally-friendly soap solution and water using a sponge or washcloth.
Do not use abrasive materials, wire brushes, chemicals, harsh cleaners, or bleach.
Rinse using a garden hose and air dry. If removed, ensure thoroughly dry prior to storage.
Do not use pressure washer.
STRUCTURE:
Gently clean with an environmentally-friendly soap solution and water using a sponge or washcloth.
Do not use abrasive materials, wire brushes, chemicals, harsh cleaners, or bleach.
Rinse using a garden hose and air dry.
Do not use pressure washer.
If there are nicks, chips, and/or scratches see the part # of the paint in the parts list to obtain a matching touch-up paint.

ZZZ-184.41218MR.0312-21.GP.EN.doc WEB VERSION 3
MAINTENANCE NOTES
1. In case of a defective or damaged part, or for any other questions concerning the product, please contact
the manufacturer directly.
2. Please have the parts list and part numbers on hand when ordering or requesting replacement parts.
3. The product should not be installed adjacent to trees or a sloped roof. Snow and ice may slide onto the
roof and cause it to collapse.
4. While the product is designed to stay assembled year long, the roof must be kept free of accumulation of
snow.
ONE YEAR LIMITED WARRANTY
This product has been designed and manufactured to meet the highest standards of quality and durability.
Subject to the Conditions for Exercising the Warranty and the Limitations on the Warranty set forth below, it
is warranted to be free of material and manufacturing defects for a period of one year from the date of
purchase. Missing and damage due to transportation is not covered by the manufacture warranty. Should
the product become damaged, or the warranty period has expired, please contact Gazebo Penguin
Customer Service Department for a complete schedule of replacement parts and prices.
CONDITIONS FOR EXERCISING THE WARRANTY
The warranty only applies to the original purchaser with the bill.
In order to properly exercise your warranty, please comply with the following:
Carefully inspect the contents of the carton for missing or damaged components. Should you
discover damaged or missing parts, do not return the product to the place of purchase, but
contact Gazebo Penguin Customer Service Department at the numbers listed below:
Montreal: [phone]
Elsewhere: 1-800-737-7174
You can also find a claim form to fill out online:
https://abrispenguin.com/assemblyinstructions/
NOTE: Damages/missing parts must be reported within 30 days of delivery. If claimed after your
request might be rejected.
LIMITATIONS ON THE WARRANTY
1. The product is not warranted against damages due to vandalism, abuse, falling or thrown objects, or
accumulation of snow.
2. The product is not warranted against damages due to extreme weather conditions, such as thunderstorms,
hail, strong wind or snow storms, or any other acts of God.
3. Leaking due to heavy rain may happen, please refer to the instruction manual for window positions and
information on how to evacuate the water.
4. The product is only warranted in the event it is installed in accordance with the Gazebo Penguin’s written
instructions enclosed with the product.
5. The product is not warranted in the event it has been improperly anchored.
6. We reserve the right to replace or repair any defective product or parts at our discretion.
7. No change to the unit is allowed. This will void your warranty.

ZZZ-184.41218MR.0312-21.GP.EN.doc WEB VERSION 4
DESCRIPTION
PACKED
IN BOX
QTY
DRAWING
DESCRIPTION
PACKED
IN BOX
QTY
DRAWING
08-129-12
REGULAR
FRAME
A
2
4
08-160-12
SLIDING
DOOR WITH
RECEIVER
CHANNEL
D
2
1
3
8
17-054-12
ROOF
PANEL
Aa
6
4
08-133-12
CONNECTING
PIECE 78.9’’
E
4
14
08-130-12
FRAME
NEXT TO
DOORS
(extra holes)
B
2
2
08-167-12
SCREW
M6*63.5
Ee
1
28
08-158-12
SCREW
M6*16
Bb
1
140
08-162-12
TOP DOOR
RAIL LEFT
81.9’’
F
4
1
08-159-12
SLIDING
DOOR -
REGULAR
C
2
1
08-221-12
TOP DOOR
RAIL RIGHT
81.9’’
F1
4
1
08-161-12
SCREW
M6X70
Cc
1
12
08-163-12
BOTTOM DOOR
RAIL LEFT
81.9”
G
4
1
12-037-12
CAPNUT
M5X60
Cc-2
1
12
08-220-12
BOTTOM DOOR
RAIL RIGHT
81.9”
G1
4
1
41218 SAND
(See page 8 for Slate parts)

ZZZ-184.41218MR.0312-21.GP.EN.doc WEB VERSION 5
DESCRIPTION
PACKED
IN BOX
QTY
DRAWING
DESCRIPTION
PACKED
IN BOX
QTY
DRAWING
08-187-12
WASHER
Gg
1
45
17-061-12
ROOF PANEL
Kk
5
4
08-138-12
DOOR
STOPPER
H
1
2
17-044-12
RAFTER
78.9’’
L
4
7
08-189-12
ACORN NUT
Hh
1
5
17-057-12
ROOF PANEL
Ll
6
4
08-139-12
CONNECTING
PIECE 78.9’’
I
4
8
08-164-12
TOP CAP
M
4
1
08-193-12
PLASTIC
PLUG
Ii
1
28
17-058-12
ROOF PANEL
Mm
5
4
08-140-12
CONNECTING
PIECE 78.9’’
J
4
8
08-166-12
CENTRAL
HUB
N
4
1
17-055-12
ROOF PANEL
Jj
5
4
08-134-12
UPPER
DOOR RAIL
END CAP
Nn
1
2
17-043-12
RAFTER
89.9’’
K
4
8
17-049-12
COVER FOR
RAFTER
88.9’’
O
4
8

ZZZ-184.41218MR.0312-21.GP.EN.doc WEB VERSION 6
DESCRIPTION
PACKED
IN BOX
QTY
DRAWING
DESCRIPTION
PACKED
IN BOX
QTY
DRAWING
17-050-12
COVER FOR
RAFTER
78.5’’
O1
4
8
17-046-12
FINISHING
BAR 45.3”
S
1
4
08-135-12
SCREW
Oo
1
4
17-068-12
FINISHING
BAR 42.6’’
Ss
1
4
16-118-12
SCREW
M6 X 36
Oo1
1
64
17-048-12
SOLIDIFYING
BAR 20.8”
T
1
4
17-051-12
GAP COVER
BAR 39.7”
P
1
16
17-069-12
SOLIDIFYING
BAR 39.4”
Tt
1
4
18-067-12
SOLIDIFYING
BAR
BRACKET
Pp
1
16
17-045-12
FINISHING
BAR 45.2”
U
1
4
17-075-12
ROOF PANEL
Qq
7
4
17-071-12
FINISHING
BAR 45.2”
U1
1
4
17-053-12
END CAP
R
1
16
17-047-12
SOLIDIFYING
BAR 20.8”
V
1
4
17-076-12
ROOF PANEL
Rr
7
4
17-070-32
SOLIDIFYING
BAR 20.8”
V1
1
4

ZZZ-184.41218MR.0312-21.GP.EN.doc WEB VERSION 7
DESCRIPTION
PACKED
IN BOX
QTY
DRAWING
DESCRIPTION
PACKED
IN BOX
QTY
DRAWING
11-599-12
CORNER
KEY
Vv
(Installed in
Yy)
2
4
08-156-12
SCREW
M4 X 16
Z
1
64
12-047-12
SCREW
M5 X 15
Ww
1
12
11-598-12
HORIZONTAL
BAR FOR
DOOR
FRAME 81.1”
Zz
2
2
17-072-12
MIDDLE
DOOR ROOF
RAFTER
78.9”
Xx
4
1
15-124-12
STEEL
ANGLE
Z1
(assembled
on rafter K)
4
8
17-060-12
ROOF PANEL
Y
6
4
15-125-12
STEEL
ANGLE
Z2
(assembled
on rafter L)
4
7
11-597-12
VERTICAL
BAR DOOR
FRAME
78.7”
Yy
2
2
19-102-12
STEEL
ANGLE
Z3
(assembled
on rafter Xx)
4
1
*NOT INCLUDED IN THE BOX
DESCRIPTION
COLOUR
PART #
SPRAY PAINT
SAND
11-699
PAINT PEN
18-245

ZZZ-184.41218MR.0312-21.GP.EN.doc WEB VERSION 8
DESCRIPTION
PACKED
IN BOX
QTY
DRAWING
DESCRIPTION
PACKED
IN BOX
QTY
DRAWING
08-129-32
REGULAR
FRAME
A
2
4
08-160-32
SLIDING
DOOR WITH
RECEIVER
CHANNEL
D
2
1
3
8
17-054-32
ROOF
PANEL
Aa
6
4
08-133-32
CONNECTING
PIECE 78.9’’
E
4
14
08-130-32
FRAME
NEXT TO
DOORS
(extra holes)
B
2
2
08-167-32
SCREW
M6*63.5
Ee
1
28
08-158-32
SCREW
M6*16
Bb
1
140
08-162-32
TOP DOOR
RAIL LEFT
81.9’’
F
4
1
08-159-32
SLIDING
DOOR-
REGULAR
C
2
1
08-221-32
TOP DOOR
RAIL RIGHT
81.9’’
F1
4
1
08-161-32
SCREW
M6X70
Cc
1
12
08-163-32
BOTTOM DOOR
RAIL LEFT
81.9”
G
4
1
12-037-32
CAPNUT
M5X60
Cc-2
1
12
08-220-32
BOTTOM DOOR
RAIL RIGHT
81.9”
G1
4
1
41218 SLATE

ZZZ-184.41218MR.0312-21.GP.EN.doc WEB VERSION 9
DESCRIPTION
PACKED
IN BOX
QTY
DRAWING
DESCRIPTION
PACKED
IN BOX
QTY
DRAWING
08-187-32
WASHER
Gg
1
45
17-061-32
ROOF PANEL
Kk
5
4
08-138-32
DOOR
STOPPER
H
1
2
17-044-32
RAFTER
78.9’’
L
4
7
08-189-32
ACORN NUT
Hh
1
5
17-057-32
ROOF PANEL
Ll
6
4
08-139-32
CONNECTING
PIECE 78.9’’
I
4
8
08-164-32
TOP CAP
M
4
1
08-193
PLASTIC
PLUG
Ii
1
28
17-058-32
ROOF PANEL
Mm
5
4
08-140-32
CONNECTING
PIECE 78.9’’
J
4
8
08-166-32
CENTRAL
HUB
N
4
1
17-055-32
ROOF PANEL
Jj
5
4
08-134-32
UPPER
DOOR RAIL
END CAP
Nn
1
2
17-043-32
RAFTER
89.9’’
K
4
8
17-049-32
COVER FOR
RAFTER
88.9’’
O
4
8

ZZZ-184.41218MR.0312-21.GP.EN.doc WEB VERSION 10
DESCRIPTION
PACKED
IN BOX
QTY
DRAWING
DESCRIPTION
PACKED
IN BOX
QTY
DRAWING
17-050-32
COVER FOR
RAFTER
78.5’’
O1
4
8
17-046-32
FINISHING
BAR 45.3”
S
1
4
08-135-32
SCREW
Oo
1
4
17-068-32
FINISHING
BAR 42.6’’
Ss
1
4
16-118-32
SCREW
M6 X 36
Oo1
1
64
17-048-32
SOLIDIFYING
BAR 20.8”
T
1
4
17-051-32
GAP COVER
BAR 39.7”
P
1
16
17-069-32
SOLIDIFYING
BAR 39.4”
Tt
1
4
18-067-32
SOLIDIFYING
BAR
BRACKET
Pp
1
16
17-045-32
FINISHING
BAR 45.2”
U
1
4
17-075-32
ROOF PANEL
Qq
7
4
17-071-32
FINISHING
BAR 45.2”
U1
1
4
17-053-32
END CAP
R
1
16
17-047-32
SOLIDIFYING
BAR 20.8”
V
1
4
17-076-32
ROOF PANEL
Rr
7
4
17-070-32
SOLIDIFYING
BAR 20.8”
V1
1
4

ZZZ-184.41218MR.0312-21.GP.EN.doc WEB VERSION 11
DESCRIPTION
PACKED
IN BOX
QTY
DRAWING
DESCRIPTION
PACKED
IN BOX
QTY
DRAWING
11-599-32
CORNER
KEY
Vv
(Installed in
Yy)
2
4
08-156-32
SCREW
M4 X 16
Z
1
64
12-047-32
SCREW
M5 X 15
Ww
1
12
11-598-32
HORIZONTAL
BAR FOR
DOOR
FRAME 81.1”
Zz
2
2
17-072-32
MIDDLE
DOOR ROOF
RAFTER
78.9”
Xx
4
1
15-124-32
STEEL
ANGLE
Z1
(assembled
on rafter K)
4
8
17-060-32
ROOF PANEL
Y
6
4
15-125-32
STEEL
ANGLE
Z2
(assembled
on rafter L)
4
7
11-597-32
VERTICAL
BAR DOOR
FRAME
78.7”
Yy
2
2
19-102-32
STEEL
ANGLE
Z3
(assembled
on rafter Xx)
4
1
*NOT INCLUDED IN THE BOX
DESCRIPTION
COLOUR
PART #
SPRAY PAINT
SLATE
18-125
PAINT PEN
18-126

ZZZ-184.41218MR.0312-21.GP.EN.doc WEB VERSION 12
Before you assemble the Solarium
PLEASE DON'T DESTROY BOXES UNTIL COMPLETELY ASSEMBLED
Tools needed:
Step Ladder 6’ – 8’
#2 Phillips Screwdriver, Robertson #2 (not supplied)
Rubber Mallet
Various Files
12” piece of wood
Based on the location, decide where you would like to position the two (2) doors
panels which can slide open to the left or the right, your choice.

ZZZ-184.41218MR.0312-21.GP.EN.doc WEB VERSION 13
Assembly Instructions
12x18 Solarium
Pre-assembled steel angle (Z1, Z2, and Z3) to roof Rafters (K, L, Xx) respectively using
Bolts (Bb)
To Be Assembled Before Packing
4 Steel Angles (Z1) to be attached to the right hole
and remaining 4 to the left hole.

ZZZ-184.41218MR.0312-21.GP.EN.doc WEB VERSION 14
Step 1:
Before starting to assemble, please decide where you would like to position the door panels.
1. Stand up two Regular Frames (A) and affix the panels together at an angle by sliding
two connecting Pieces (I, J) from top to bottom. All Frames should be placed such that
screening face out of the unit.
2. To assemble door frame, firstly assemble 2 vertical bars (Yy) with 2 horizontal bars
(Zz). Make sure the shape of the aluminum matches the other parts to be joined. With
a rubber mallet get them closed at the corners. Make sure to not damage the
aluminum parts. Make a small pilot hole if necessary, under 1/8”and use screws (Z) to
secure 4 corners manually, screwing all screws into frame 4 holes.
3. After assembling door frame, attach to frames (B) on either side, by sliding connecting
piece (E) between the frame and the door frame.
4. When assembling angled panels (A, B), you should put the two panels at 135-degree
angle then use the angled connecting pieces (I) and (J) to affix the panels together.
5. Door frame step down is on the inside of the unit.
Note:
1. When sliding the part I, J and E into the frames shake the frames for it too slide.
Do not apply excess force. Make sure the edges are clean from any extra paint if
necessary, use a fine file.
2. Make sure the floor is level if not use Leveling Shims.
Start Here
Top View
D

ZZZ-184.41218MR.0312-21.GP.EN.doc WEB VERSION 15
Step 2:
1. Affix gap Cover Bars (P) by sliding them on the top of the exterior groove of the Regular
Frames (A, B, D).

ZZZ-184.41218MR.0312-21.GP.EN.doc WEB VERSION 16
Step 3:
1. Slide Top Door Rail (F) into wheels of Sliding Door (C).
2. Slide Lower Door Rail (G) into the plastic guide of the Sliding Door (C).
3. Use Bolts (Bb) to affix the Plastic Stoppers (H) one on each end of Top Door Rail (F).
4. Using a Screw (Oo) affix the upper door rail End Caps (Nn) one on each end of Top Door
Rail (F).
5. Similarly follow the above step to assemble the Sliding Door (D).

ZZZ-184.41218MR.0312-21.GP.EN.doc WEB VERSION 17
Step 4:
Please note the sliding door is suggested to be installed from the inside of the solarium.
1. Place a Bolt (Ww) and Washer (Gg) through the Top of Sliding Door Frame (C) and Top Door
Rail (F), and place a Female Bolt (Cc-2) from the other side. Once all are inserted, tighten them
all securely.
2. Secure the Bottom Door Rail (G), using a Bolt (Cc) with a Washer (Gg).
3. Similarly follow the above step for Sliding Door (D) with Top Door Rail (F1) and Bottom Door
Rail (G1).
Note: Adjust door rail high up, for easy sliding of door.

ZZZ-184.41218MR.0312-21.GP.EN.doc WEB VERSION 18
Step 5:
1. Attach roof rafters (L, Xx) to the Central Hub(N) using bolt (Bb).
2. Use screws (Z) to affix the Rafters (L) onto the top of panels going through the Metal Piece
(Z2) attached to the Rafter (L).
3. Use Bolts (Bb) to affix Rafter (Xx) over the Horizontal Bar For Door Frame (Zz) at the top of
Door opening as shown below.
Note:
1. Rafters must be affixed where panels connect to each other.
2. The Central Hub is a heavy part so it requires support while assembling.

ZZZ-184.41218MR.0312-21.GP.EN.doc WEB VERSION 19
Step 6:
1. Follow the same procedure of Rafter (L) to assemble roof Rafters (K) onto the remaining
panels.
Note:
1. Rafters must be affixed where panels connect to each other.
2. Affix the Rafter (K) such that, the extra hole on the bracket (Z1) are facing each
other as shown below.
3. Do not tighten the bolts right away as you may have to adjust the angle when
inserting the roof panels.

ZZZ-184.41218MR.0312-21.GP.EN.doc WEB VERSION 20
Step 7:
1. Now secure the sides of the roof with Finishing Bar (S, U, Ss and U1) with Bolts (Bb) and
Brackets (R).
2. Place roof Finishing Bars (S, U, Ss and U1) on the right of the Roof Finishing Bar (S, U and
U1) and align the holes in each bar one on top of the other. Place End Caps (R) under the
aligned holes and secure with Bolts (Bb).
3. Repeat process with all Finishing Bars as illustrated.
4. In order to finish the installation of the last Finishing Bar (S, Ss, U, U1) you have to unscrew
the first screw (Bb) at your starting point and place an end cap (R) then re-install the screw
(Bb).
Note: Make sure all screws/ bolts are tight, when finished assembling.
