Gecko Aeware k-19-in Reference guide

The Quick Reference Card provides a quick overview of your spa’s
main functions and the operations accessible with your digital control pad.
Key 1
Press Key 1 key to turn Pump 1 on at low speed. Press a
second time to turn pump to high speed (with a dual-speed
pump). A third time turns pump off.
A built-in timer automatically turns pump off after 20 minu-
tes, unless pump has been manually deactivated fi rst.
The “Pump 1” indicator lights up when Pump 1 is on.
With dual-speed pump, indicator will fl ash when
Pump 1 is on at low speed.
Spa functions
k-19-in
series of k-19 keypads for in.xe spa systems
Key 2 (2 Pump System)
Press Key 2 key to turn Pump 2 on at low speed. Press
a second time to turn pump to high speed. A third time
turns pump off. A built-in timer automatically turns pump
off after a prede-termined period of time, unless it has been
manually deactivated fi rst.
The “Pump 2” indicator lights up when Pump 2 is on.
The indicator will fl ash when Pump 2 is on at low speed.
series of k-19 keypads
for in.xe spa systems
Key 2 (2-Pump/Blower System)
Press Key 2 to turn Pump 2 on at high speed. Pressing a sec-
ond time turns blower on. A third press turns Pump 2 off but
leaves blower on. A fi nal press turns blower off. A built-in
timer automatically turns Pump 2/blower off after 20 minutes,
unless Pump 2/blower has been manually deactivated fi rst.
The “Pump 2” indicator
lights up when Pump 2 is on.
The “Blower” indicator
lights up when blower is on.

Programming the purge / fi lter cycles
Light key
Press Light key to turn light on. Press a second time to turn
light off. A built-in timer automatically turns light off after
2 hours, unless it has been manually deactivated fi rst.
The “Light” indicator lights up
when light is on.
Up/Down keys
Use Up or Down key to set desired water temperature.
The temperature setting will be displayed for 5 seconds to
confi rm your new selection.
The "Set Point" icon indicates that the display shows the
desired temperature, NOT the current water temperature!
Setting fi lter cycle duration
Press and hold Light key until the display shows dxx, with
"xx" representing the duration in hours. (Default: 2 hours).
Use Up or Down key to change setting.
0 = no fi ltration 24 = continuous fi ltration
Note: it's not recommended to set this to "0".
Programming fi lter cycles
Depending on system confi guration the system performs either purge cycles or fi lter cycles.
To program the fi lter cycles, you must enter these parameters: duration and frequency.
During a fi lter cycle, pumps & blower run at high speed for one minute to purge the
plumbing. Pump 1 or CP then runs at low speed for the remaining of the cycle.
Off Mode
This mode allows you to stop all outputs for 30 minutes to
perform a quick spa maintenance.
Press and hold Key 1 key for 5 secs to activate the Off mode.
Quick press Key 1 key to reactivate the system before the ex-
piration of the 30-minute delay.
While the Off mode is engaged, the display will toggle
between OFF and the water temperature.
Setting the temperature display units
Quick press Light key again. The display will show either°F or °C.
Use Up or Down key to change units.
Press Light key a last time to go back to normal mode.
°F = Fahrenheit - °C = Celsius
OFF
OFF

Filter cycle frequency
Press Light key again. The display will show Fx, with "x"
representing the number of fi lter cycles per day (up to 4).
(Default: twice a day).
Use Up or Down key to change setting.
When the desired setting is displayed, press Light key
to confi rm. A fi lter cycle will start immediately.
The “Filter” indicator lights up
when a fi lter cycle is on.
Purge cycle frequency
Press and hold Light key until the display shows Fx, with "x"
representing the number of purge cycles per day (up to 4).
Use Up or Down key to change setting.
When the desired setting is displayed, press Light
key to confi rm. A purge cycle will start immediately.
The “Filter” indicator lights up
when a purge cycle is on.
Programming purge cycles
To program the purge cycles, you must select the frequency. During a purge cycle, all pumps
and the blower run for one minute. To set purge cycles:
Water temperature regulation
In a regulation cycle, the system fi rst gener-
ates water fl ow through the heater housing
and the plumbing, in order to ensure accu-
rate water temperature readings as well as
avoiding heater activation in dry conditions.
After verifying pump activation and taking a
water temperature reading if required, the
system automatically turns the heater on to
reach and maintain water temperature at
Set Point.
The “Heater” indicator lights up when
the heater is on. It fl ashes when there
is a request for more heat but the
heater has not yet started.
Cooldown
While performing this task, the heater is not
allowed to turn on and its icon fl ashes.
Smart Winter Mode
Our Smart Winter Mode protects your
system from the cold by turning pumps on
several times a day to prevent water from
freezing in pipes.
The “Smart Winter Mode” indicator
lights up when the Smart Winter Mode
is on.

Troubleshooting
Hr
An internal hardware error has been detected in in.xe.
Contact dealer or service supplier.
HL
The system has shut the heater down because the temperature at the
heater has reached 119°F (48°C). Do not enter the water! Remove the spa
cover and allow the water to cool down, then shut power off and power
your spa up again to reset the system.
Prr
A problem is detected with the temperature probe.
Call your dealer or service supplier.
AOH
Temperature inside the spa skirt is too high, causing the internal
temperature in the in.xe to increase above normal limits.
Open skirt and wait until error clears.
OH
The water temperature in the spa has reached 108°F (42°C).
Do not enter the water! Remove the spa cover and allow the water to
cool down to a lower temperature. Call your dealer or service supplier if
problem persists.
FLO
The system does not detect any water fl ow while the primary pump is
running. Check and open water valves. Check for water level.
Clean fi lter. If the problem persists, call your dealer or service supplier.
rLy
The system has detected a stuck relay error in in.xe.
Call your dealer or service supplier.
UPL
No low level confi guration software has been installed into the system.
Call your dealer or service supplier.
9919-100805 www.geckoalliance.com
