Gecko In.k175 aeware Operating instructions

in.k175™

wired remote control

Specifications & installation

Owner's manual

Giving full control

to wet fingers!

FAILURE TO COMPLY WITH THE FOLLOWING WARNINGS MAY SIGNIFICANTLY SHORTEN

THE PRODUCT’S LIFE TIME, AND LEAD TO FAILURES AS WELL AS HAZARDOUS

CONDITIONS*. COMMON SENSE MUST ALWAYS PREVAIL WHEN EVALUATING THE

INSTALLATION AND/OR USE OF ANY ELECTRONIC CONTROL IN A FINAL APPLICATION.

The maximum ambient conditions this PRODUCT is subjected to (temperature, humidity,

etc.) are not to be exceeded.

This PRODUCT must be installed by a qualified personnel.

Only qualified personnel are to service this PRODUCT. There are no user serviceable

parts inside.

This PRODUCT is only compatible with Aeware's® in.tune™ products.

This PRODUCT should be installed on a clean flat surface.

The gasket on the back of the unit will prevent water infiltration inside, behind the

mounted surface. If the gasket is damaged, the user must seal the back of the unit with

silicone to avoid any leakage behind the mounted surface.

* HAZARDOUS CONDITION: A condition that is potentially damaging and/or dangerous to

its operator or surroundings. This includes, but is not limited to: fire, flooding or other

water damage, dielectric breakdowns (presence of high voltage), etc.

Warnings:

in.K175™AEWAREAUDIO/VIDEO KEYPAD 





Radio models supported by in.k175™ are:

Aeware® in.tune™ / in.tune.110™

receiver model.

Aeware® in.pix™ audio/video model.

Compatibility: 3.58 (Length) by 2.15’’ (Width) by

0.20’’ (Height).

Soft gasket

Mechanical Specs:

Humidity: Up to 95 %

condensing

Operating temp.: -20 to 50˚C

Storage temp.: -30 to 70˚C

Environmentals: IP rating IPX5

UV resistant

UL 1563

CSA C22.2 No.218.1

Standards: 





User Instructions:

Source: Pressing SRC will allow you to select a source between

the following (in order): Tuner, CD/DVD, CD changer, Aux.

Band: Press Band to select between FM1, FM2, FM3, AM1,

AM2 and WB (Weather Band available with in.tune only)

Track Down:

Radio mode Press Track Down to go to the previous preset station.

Weather band Press Track Down to go to the previous memorized station

(in.tune only).

CD mode Press Track Down to change music track.

MP3 mode Press Track Down to select file Down. If source is CD

or CD changer, press on this key to go back to

the previous song.

DVD mode Press Track Down to go to next lower chapter.

Mute: A 2 seconds press on this key mute the audio output.

Press again during 2 seconds to return to previous

volume level.

User Instructions:

Track Up:

Radio mode Press Track Up to go to the next preset station.

Weather band Press Track Up to go to the next memorized station

(in.tune only).

CD mode Press Track Up to change music track.

MP3 mode Press Track Up to select file up. If source is CD or CD

changer, press on this key to go forward to the next song.

DVD mode Press Track Up to go to next higher chapter.

Volume Up: Press on this key to increase volume.

Volume Down: Press on this key to decrease volume.

Wiring Diagram:

Male to male 8-pin mini din cable

(supplied with wired remote)

Wired remote

in.k175™

in.tune

in.pix

ToInstallation: 





Drilling template:

""

"

"






