Genie SSAHD2BVAF User manual

SSAHD2BVAF
AHD 2MP Stainless Steel Varifocal
Bullet Camera with Auto Focus
User Manual

2
SSAHD2BVAF - AHD 2MP Stainless Steel Varifocal Bullet Camera with Auto Focus
1. Key Features
2. Installation
3. Cable
• 1/3” Panasonic CMOS Image Sensor
• Full HD Mega Pixel (1080P)
• Auto Compensation and Long Range Transmission
• Low Illumination Performance
• 2 Pcs LED’s
• 2.8 ~ 12mm DC Auto Iris Motorized Megapixel Lens
• True Day / Night with ICR Mechanism
• Sens-Up
• D-WDR (Digital Wide Dynamic)
• External Zoom & Focus Adjustable
• DC12V
STEP 1 STEP 2
Fix Bracket at desired place.
CAUTION! Please use regulated Power Supply DC12V, 500mA Reverse Polarity Protection
Adjust View Angle with 3-Axis Bracket.
Wrench
Power - DC12V
OSD Connection
AHD Video
Analogue Video
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER(OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
ISO14001

SSAHD2BVAF - AHD 2MP Stainless Steel Varifocal Bullet Camera with Auto Focus
3
4. Technical Specication
5. Dimensions
6. Accessories 7. Mode Change
STEP 2
Adjust View Angle with 3-Axis Bracket.
All Specications and Pictures are subject to change without notice.
120
158.5
121.5
72
Model Number SSAHD2BVAF
Image Sensor 1/3” Panasonic CMOS
Resolution 1080P
Lens 2.8 ~ 12mm DC Auto Iris MP Lens (ICR)
Scanning System Progressive
Video Output AHD: 1080P, 720P
Analogue: NTSC / PAL CVBS
S/N Ratio More than 50dB (AGC Off)
Minimum Illumination Colour: 1.0 Lux, B&W: 0.5 Lux
Colour DSS: 0.002 Lux, B&W DSS: 0.0008 Lux
D-WDR Off / 0~8
Sens-Up Off / x2 - x30
Backlight Off / BLC / HSBLC
DNR Off / Low / Middle / High
Privacy Mask 4 Masks
Motion Detection Off / On
Power Source DC12V ±10%
Power Consumption Max 2.0 Watt
Operating Temperature -10°C to 50°C
Operating Humidity 10% to 85%
Dimensions (D x L x H) 72 x 158.5 x 120 mm
Weight 1520g
L-Wrench
Screws
CVBS Mode: Push the left OSD Key for 3 seconds
AHD Mode: Push the right OSD key for 3 seconds
Server Cable
OSD
CVBS AHD

GENIE CCTV LTD.
CCTV House, City Park, Watchmead, Welwyn Garden City, Hertfordshire, AL7 ILT
Tel: [phone] Fax: [phone]
www.geniecctv.com
Edition. GN-February 2016
