Genie SSAHD2D User manual

SSAHD2D
AHD 2MP Stainless Steel IR
Vandal Dome Camera
User Manual

SSAHD2D - AHD 2MP Stainless Steel IR Vandal Dome Camera
2
1. Key Features
2. Installation
3. Cable
• 1/2.8” Sony IMX322 CMOS Image Sensor
• Full HD Resolution (1920 x 1080)
• Auto Compensation and Long Range Transmission
• Stainless Steel Body (316 Grade)
• 3.6mm Megapixel Lens
• True Day / Night with ICR Mechanism
• 24 Pcs LED’s
• Low Illumination Performance
• 3D-DNR (Digital Noise Reduction)
• Sens-Up
• D-WDR (Digital Wide Dynamic Range)
• Simple Mode Change by OSD (AHD, CVBS)
• 3-Axis Gimbal Bracket
• DC12V
STEP 1 STEP 2 STEP 3
Tighten up 3 pcs of xed screws using the
L-Wrench after closing the Dome Cover.
CAUTION! Please use regulated Power Supply DC12V, 300mA Reverse Polarity Protection
Wrench
Power Input (DC12V)
AHD Video Output
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER(OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
ISO14001

SSAHD2D - AHD 2MP Stainless Steel IR Vandal Dome Camera
3
4. Technical Specication
5. Dimensions
6. Accessories 7. Mode Change
All Specications and Pictures are subject to change without notice.
88.5
118
Model Number SSAHD2D
Image Sensor 1/2.8” Sony IMX322 CMOS
Resolution 1080P
Lens 3.6mm Megapixel Lens
Scanning System Progressive
Video Output AHD: 1080P, 720P
Analogue: NTSC / PAL CVBS
S/N Ratio More than 50dB (AGC Off)
Minimum Illumination Colour: 1.0 Lux, B&W: 0.5 Lux
Colour DSS: 0.002 Lux, B&W DSS: 0.0008 Lux
D-WDR Off / 0~8
Sens-Up Off / x2 - x30
Backlight Off / BLC / HSBLC
DNR Off / Low / Middle / High
Privacy Mask 4 Masks
Motion Detection Off / On
Power Source DC12V ±10%
Power Consumption Max 2.0W
Operating Temperature -10°C to 50°C
Operating Humidity 10% to 85%
Dimensions (W x H x Ø) 118 x 88.5 x Ø80 mm
Weight 1310g
L-Wrench
Screws
Extra Video Out
CVBS Mode: Push the left OSD Key for 3 seconds
AHD Mode: Push the right OSD key for 3 seconds
Block
Left Right
Up
Down

GENIE CCTV LTD.
CCTV House, City Park, Watchmead, Welwyn Garden City, Hertfordshire, AL7 ILT
Tel: [phone] Fax: [phone]
www.geniecctv.com
Edition. GN-February 2016
