Geokon GK-604D User manual

GK-604D
Inclinometer Readout
Application
User’s Manual
No part of this instruction manual may be reproduced, by any means, without the written consent of Geokon, Inc.
The information contained herein is believed to be accurate and reliable. However, Geokon, Inc. assumes no responsibility
for errors, omissions or misinterpretation. The information herein is subject to change without notification.
Copyright © 2014 by Geokon, Inc.
(Doc Rev H, 11/2014)

Warranty Statement
Geokon, Inc. warrants its products to be free of defects in materials and workmanship, under normal
use and service for a period of 13 months from date of purchase. If the unit should malfunction, it
must be returned to the factory for evaluation, freight prepaid. Upon examination by Geokon, if the
unit is found to be defective, it will be repaired or replaced at no charge. However, the WARRANTY
is VOID if the unit shows evidence of having been tampered with or shows evidence of being
damaged as a result of excessive corrosion or current, heat, moisture or vibration, improper
specification, misapplication, misuse or other operating conditions outside of Geokon's control.
Components which wear or which are damaged by misuse are not warranted. This includes fuses and
batteries.
Geokon manufactures scientific instruments whose misuse is potentially dangerous. The instruments
are intended to be installed and used only by qualified personnel. There are no warranties except as
stated herein. There are no other warranties, expressed or implied, including but not limited to the
implied warranties of merchantability and of fitness for a particular purpose. Geokon, Inc. is not
responsible for any damages or losses caused to other equipment, whether direct, indirect, incidental,
special or consequential which the purchaser may experience as a result of the installation or use of
the product. The buyer's sole remedy for any breach of this agreement by Geokon, Inc. or any breach
of any warranty by Geokon, Inc. shall not exceed the purchase price paid by the purchaser to Geokon,
Inc. for the unit or units, or equipment directly affected by such breach. Under no circumstances will
Geokon reimburse the claimant for loss incurred in removing and/or reinstalling equipment.
Every precaution for accuracy has been taken in the preparation of manuals and/or software, however,
Geokon, Inc. neither assumes responsibility for any omissions or errors that may appear nor assumes
liability for any damages or losses that result from the use of the products in accordance with the
information contained in the manual or software.

Table of Contents:
1. Introduction .............................................................................................. 1
1.1 Features...........................................................................................
1
1.2 GK-604D Inclinometer Readout Application...........................................
3
1.2.1 Tiltmeter and Compass Probes...............................................................................5
1.3 Before using the GK-604D Inclinometer Readout..................................
6
2. Installation and Operation......................................................................... 7
2.1 Initial Quick Start Sequence................................................................
7
2.2 Establishing Contact with the Remote Module.....................................
12
2.3 Installing the GK-604D IRA...............................................................
15
2.3.1 Launching the GK-604D Installer........................................................................ 17
2.4 Starting the Inclinometer Readout the first time..................................
21
3. User Interface..........................................................................................26
3.1 Overview........................................................................................
26
3.2 Project Explorer...............................................................................
27
3.2.1 Context Menu.............................................................................................................. 28
3.3 Application Menu .............................................................................
29
3.3.1 Live Readings.............................................................................................................. 29
3.3.2 Edit Settings................................................................................................................ 35
3.3.3 Terminal Window....................................................................................................... 35
3.3.4 About GK-604D.......................................................................................................... 37
3.3.5 System Configuration.............................................................................................. 39
3.4 File Menu........................................................................................
47
3.4.1 Export Menu ................................................................................................................ 47
3.4.2 Import Menu................................................................................................................ 50

3.4.3 View Data......................................................................................................................53
3.4.4 Delete/Restore Menu................................................................................................56
3.4.5 Exit...................................................................................................................................57
4. Configuring Project Explorer Elements ..................................................... 58
4.1 Hole Configuration...........................................................................59
4.2 Probe Configuration.........................................................................60
4.3 Project Configuration .......................................................................62
5. Files, Folders and Transferring Data ......................................................... 63
5.1 File Transfer ...................................................................................64
5.2 Backing up configurations ................................................................64
APPENDIX A. Inclinometer Theory ............................................................... 65
A.1. Inclinometer Theory .......................................................................65
A.2 Conducting the survey....................................................................68
A.3 Checksums and “Face Errors” on Inclinometer Probes.........................69
A.3.1 Effect of “Face Error” on reading accuracy.....................................................70
A.3.2 Measurement of “Face Error” .............................................................................. 71
A.3.3 Setting of the “Face Error” to zero....................................................................71
A.3.4 Conclusion...................................................................................................................72
APPENDIX B. Data File Format ..................................................................... 73
B.1 Hole Data File Format......................................................................73
APPENDIX C. Text Reports ........................................................................... 75
C.1 Raw Data Text Report...................................................................... 75
C.2 A-axis Profile Data Text Report .........................................................76
C.3 B-axis Profile Data Text Report .........................................................77
C.4 A-axis Deflection Data Text Report....................................................78

C.5 B-axis Deflection Data Text Report ....................................................79
APPENDIX D. Remote Module Command Structure......................................81
APPENDIX E. Data Reduction Formulas........................................................83
E.1. Deflection Calculation......................................................................
83
E.2. Profile Calculation...........................................................................
85
E.3. GTILT Users...................................................................................
86
APPENDIX F. Technical Specifications ..........................................................87
F.1. GK-604D Digital System Specifications..............................................
87
F1.1 Compass Sensor Specifications............................................................................. 88
F.2. Analog Probe System Specifications ..................................................
89
F.3. Field PC (FPC-1) Specifications .........................................................
90
APPENDIX G. Tiltmeter Operation (Model 6101) .........................................91
G.1. Tiltmeter Data Format ....................................................................
96
APPENDIX H. Spiral and Compass Probe Operation .....................................97
H.1 Spiral Indicator Probe (6005-3).........................................................
97
H.2 Inclinometer/Compass Probe (6100D-X) ..........................................100
H.2.1 Calibrate Compass.................................................................................................. 103
H.3 Spiral Indicator Data......................................................................105
H.4 Compass Survey Data....................................................................105

Table of Figures:
Figure 1 – Model GK-604D, Digital Inclinometer System .......................................................................1
Figure 2 - Model 6000-2 Control Cable (top) ......................................................................................... 2
Figure 3 – FPC-1 running GK-604D IRA...................................................................................................3
Figure 4 - 6000/6100 type probe............................................................................................................4
Figure 5 - GK-604-4 Interface .................................................................................................................4
Figure 6 - GK-604-3 Reel System (shown with the Archer unit and carrying case)................................ 5
Figure 7 - Probe Settings Mismatch .......................................................................................................9
Figure 8 - Initial Probe Settings ............................................................................................................ 10
Figure 9 - No probe association window..............................................................................................10
Figure 10 - ActiveSync Window showing active connection ................................................................ 15
Figure 11 - Windows Mobile Device Center.........................................................................................16
Figure 12 - Windows Explorer window displaying HHD root folder..................................................... 17
Figure 13 - Hand-held device root folder contents ..............................................................................18
Figure 14 - Installation Folder Contents ...............................................................................................18
Figure 15 - GK-604D Installer at root of HDD .......................................................................................19
Figure 16 - GK-604D Install Screen .......................................................................................................20
Figure 17 - GK-604D IRA Icon in Start->Program.................................................................................. 20
Figure 18 - Select Workspace Name.....................................................................................................21
Figure 19 - Select Workspace Folder....................................................................................................22
Figure 20 - Workspace Exists................................................................................................................22
Figure 21 - Select Probe Library Name .................................................................................................23
Figure 22 - Select Probe Library Folder ................................................................................................24
Figure 23 - Probe Library Exists ............................................................................................................24
Figure 24 - Empty Workspace and Probe Library................................................................................. 25

Figure 25 - User Interface .................................................................................................................... 26
Figure 26 – Context Menu ................................................................................................................... 28
Figure 27 - Application Menu............................................................................................................... 29
Figure 28 - Remote Module Connection Problem ............................................................................... 30
Figure 29 - Live Readings Screen.......................................................................................................... 30
Figure 30 - Unsaved Data prompt........................................................................................................ 31
Figure 31 - Auto Increment Save ......................................................................................................... 31
Figure 32 - Save File Screen ................................................................................................................. 32
Figure 33- Menu option (Live Readings screen) .................................................................................. 32
Figure 34 - Viewing Inclinometer Data ................................................................................................ 33
Figure 35 - Viewing Compass Data....................................................................................................... 34
Figure 36 - Terminal Window .............................................................................................................. 35
Figure 37 - About GK-604D IRA............................................................................................................ 37
Figure 38 - Ready for Connection?....................................................................................................... 37
Figure 39 - Remote Module/Probe Status........................................................................................... 38
Figure 40 - System Configuration......................................................................................................... 39
Figure 41 - Stable Indication ................................................................................................................ 40
Figure 42 - Unstable Indication............................................................................................................ 40
Figure 43 – Auto Record Enabled ........................................................................................................ 42
Figure 44 - Auto Record Active ............................................................................................................ 42
Figure 45 - Auto record paused, Dataset 2 selected............................................................................ 44
Figure 46 - File Menu Figure 47 - Export Menu ................................................................................ 47
Figure 48- Export Data Window Figure 49 - Save Data File ............................................................. 48
Figure 50 - Export Path Selection Figure 51 - Probe Selection Window.......................................... 49
Figure 52 - Import Menu Figure 53 - Select Hole Export File............................................................ 50
Figure 54 - Select Project Export File Figure 55 - Select Probe Export File....................................... 51

Figure 56 - Select Probe Library Export File Figure 57 - Probe Library Switch after Import .............52
Figure 58 - Select View Options Window Figure 59 - View Option List...........................................53
Figure 60 - Menu Options for Reports Figure 61 - Raw Data Report ...............................................54
Figure 62 - Axis Profile Report Figure 63 - Axis Deflection Report....................................................54
Figure 64 - Profile Plot Figure 65 - Profile Plot - Marker On.............................................................55
Figure 66 - Deflection Plot....................................................................................................................56
Figure 67 - Delete / Restore Window Figure 68 - Hole Delete / Restore Window...........................57
Figure 69 - Hole General Settings.........................................................................................................59
Figure 70 - Hole Parameters.................................................................................................................59
Figure 71 - Probe General Settings....................................................................................................... 60
Figure 72 - Probe Coefficients ..............................................................................................................60
Figure 73 - Project Settings...................................................................................................................62
Figure 74 - Inclinometer Casing (end view) .......................................................................................... 65
Figure 75 - Inclinometer Probe.............................................................................................................66
Figure 76 - Inclinometer Survey Description ........................................................................................ 67
Figure 77 - Plot of Borehole Deflection ................................................................................................67
Figure 78 - Model 6101 Tiltmeter with 6201-3 Interface Cable...........................................................91
Figure 79 - Tiltplates: 6201-1C (ceramic), 6201-1A (Copper plated Aluminum), 6201-1S (stainless)..92
Figure 80 - Live Readings (Tiltmeter).................................................................................................... 94
Figure 81 - Saving data query ...............................................................................................................94
Figure 82 - Save File Dialog...................................................................................................................95
Figure 83 - File Exists Dialog .................................................................................................................95
Figure 84 - Spiral Indicator Probe (6005-3) ..........................................................................................97
Figure 85 - Live Readings for Spiral Data..............................................................................................98
Figure 86 - Saving Compass Survey Data.............................................................................................. 99
Figure 87 – Digital Inclinometer/Compass Probe (6100D-X) .............................................................100

Figure 88 – Compass Enable Message ............................................................................................... 101
Figure 89 - Live Compass Data ........................................................................................................... 102
Figure 90 - Initial Calibration Screen.................................................................................................. 103
Figure 91 - Calibration Routine .......................................................................................................... 104

1
1. Introduction
The GK-604D is made up of three components:
•the Readout Unit, consisting of a hand-held field PC running the GK-604D
Inclinometer Readout Application (see Figures 1 and 3).
•the GK-604D Remote Module, housed in a weather-proof reel enclosure containing
the cable that directly connects to the inclinometer probe (see Figures 1 and 6)
•The inclinometer probe, either analog or digital. See Figure 1 (digital, 6100D-X) and
Figure 4 (analog, 6100-1X).
Figure 1 – Model GK-604D, Digital Inclinometer System
The Readout Unit and Remote Module components communicate wirelessly using
Bluetooth®, a reliable digital communications solution. This simplifies the handling of the
system in the field as well as simplifying the transfer of data to your PC workstation for
final analysis.
1.1 Features
Rugged, general purpose, reliable readout based on a hand-held PC:
•all the benefits of a Windows Mobile compatible device (Windows file system,
RS-232, USB and wireless connectivity)
•long battery life
•ease of use

2
Lightweight and simple Remote Module:
•lithium battery (8 + hours of continuous use)
•one button operation; automatic power down when Bluetooth connection is
dropped or after several minutes of inactivity
•rugged
•reliable connection to standard inclinometer probes (Figures 1 and 4) is
accomplished via model 6000-2 control cable which features a lightweight,
polyurethane jacket and is less than 7 mm in diameter (see Figure 2). The
control cable contains a central Kevlar®strand with a breaking strength of 150
kg
Figure 2 - Model 6000-2 Control Cable (top)

3
1.2 GK-604D Inclinometer Readout Application
The GK-604D Inclinometer Readout Application (GK-604D IRA) installs and runs on
a ruggedized hand-held PC (FPC-1) (see Figure 3) and is designed to communicate
via Bluetooth with Remote Modules connected to analog or digital probes (see
Figure 4), both MEMS and force-balance type. For digital probes the Remote
Module is fully contained within the reel as depicted by Figure 1.
For analog probes an interface unit, GK-604-4 (see Figure 5), connects directly to
the probe (analog MEMS and force-balance type) and can be purchased as a
separate unit or as part of the GK-604-3 reel system (see Figure 6).
Figure 3 – FPC-1 running GK-604D IRA

4
Figure 4 - 6000/6100 type probe
Figure 5 - GK-604-4 Interface

5
Figure 6 - GK-604-3 Reel System (shown with the Archer unit and carrying case)
Note: The GK-604D Inclinometer Readout Application will also operate on the
Archer Field PC from Juniper Systems (shown in Figure 6) as well as the newer
Archer2.
1.2.1 Tiltmeter and Compass Probes
In addition to standard inclinometer probes, the GK-604D IRA also can be used
with Geokon Tiltmeter and Compass Probes. See Appendices G and H for more
information on these probe types.

6
1.3Before using the GK-604D Inclinometer Readout
The readout software runs as an application under Windows Mobile 6 operating
system installed on a hand-held PC (FPC-1).
•The user should familiarize themselves with the FPC-1 and the Windows Mobile
OS.
•It is assumed in the instructions below that the user can launch applications
from the Start button including File Explorer and the Bluetooth Settings
manager.
•It is assumed that the user can tap the keyboard icon as needed and use the on-
screen keyboard to enter text and numbers.

7
2. Installation and Operation
The steps described in section 2.1 are an attempt to guide the user through the process
of launching the GK-604D IRA, connecting to the probe and taking a survey. If all parts
of the GK-604D are purchased as a system, Geokon makes every effort to ensure that
the system is completely set up and working before it leaves the factory. Other times,
the user may already own the hand-held PC and are setting up their hardware and
software for the very first time. The steps below attempt to cover all cases and refer the
user to the appropriate section when more information is needed.
For those users that have purchased a complete GK-604D system, a workspace with the
name of “GK604D” and a probe library called “ProbeLibrary” will have been pre-defined
and the FPC-1 unit will already be paired with the Remote Module. Note that the
workspace and probe library names can be changed at any time or new ones can be
created (see section 3.2.1). When purchasing a GK-604D system, sections 2.2 through
2.4 can possibly be skipped but a quick review is recommended.
NOTE: Always make sure that the inclinometer probe is attached to the reel before
attempting the quick start sequence below.
2.1 Initial Quick Start Sequence
The following steps are a guide to the typical operation of the GK-604D and, if
followed, should result in a successful “hole” survey being taken:
A) If the Remote Module was purchased separately from the FPC-1 unit or if a new
Bluetooth pairing is needed, see section 2.2 (Establishing Contact with the
Remote Module).
B) Launch the GK-604D IRA by tapping on “Start” from the FPC-1 main
window, tap “Programs”, then tap the GK-604D IRA icon. If the
GK-604D Inclinometer Readout Application has not been installed,
please see section 2.3 (Installing the GK-604D IRA).
C) If the window shown in Figure 18 is displayed instead of the Main Window (see
Figure 25), please refer to section 2.4, “Starting the Inclinometer Readout the
First Time”.
D) If the Inclinometer System is an analog system (probe model numbers 6100-1E
and 6100-1M) then a “probe” must be defined in the Project Explorer Probe
Library (see section 3.2 and 4.2 for more information regarding adding and
configuring a new probe). After adding a new analog probe configuration, skip to
step F.

8
E) If the Inclinometer System is a digital system (probe model numbers 6100D-E
and 6100D-M), any new “probe” will be discovered upon connection to the
Remote Module (covered in later steps).
F) If launching the GK-604 IRA for the first time, a “project” and a “hole” must be
defined before connecting to the Remote Module (see sections 3.2, 4.4 and 4.1
for more information regarding adding and configuring Project Explorer
elements).
NOTE: If preparing to connect to a digital system the first time, please select
“UNKNOWN” for the hole parameter, “Probe Name:”.
G) If it’s not selected already, select the new hole (by tapping on the hole icon in
the Project Explorer) created in step F. Press the button labeled “POWER ON
(BLUETOOTH)” on the Remote Module. A blue light should come on and start to
blink, signifying that the Remote Module is waiting to connect to the FPC-1 unit.
H) To start the connection process, tap on the Application Menu (see section 3.3)
then tap “Live Readings”. By default the application will look for a Bluetooth
connection on “COM5”. If the Remote Module fails to connect with the FPC-1,
then the window shown in Figure 28 will be displayed, indicating that either the
Remote Module is no longer trying to connect (timed out) or that the Bluetooth
pairing is associated with another COM port. Make sure that the proper COM
port is selected and tap “Reconnect”.
If connecting to an analog system, after a few seconds, the blue light on the
Remote Module should change to a steady state blue (lit but not flashing) and
the Live Readings Window will be displayed (see Figure 29). Skip to step I.
If connecting to an digital system, after few seconds, the blue light on the
Remote Module should change to a steady state blue (lit but not flashing) and
one of two windows will be displayed:
a. If the window shown in Figure 7 is displayed, then the probe has not
been previously detected by the GK-604 IRA (digital systems only). In
this case, tap “ok” and the probe will be added to the Probe Library and
the window shown in Figure 8 will be displayed. This allows an
opportunity to give the new newly detected probe a user friendly name
and description. See section 4.2, Probe Configuration for more
information on probe settings. When satisfied with the settings, tap
“Menu->Save Settings” to exit the Probe Settings Window (see Figure 8).
If the probe name was set to “UNKNOWN” in step F, the window in figure
9 will be displayed, allowing the name of the probe just found to be
saved into the current hole configuration.
