Getinge LUCEA 10 User manual

Maintenance Manual
LUCEA 10-40
01700EN 22-07-18

Copyright
All rights reserved. This document may not be copied, adapted or translated without prior written permission,
except as permitted under copyright law.
© Copyright 2021 Maquet SAS
Subject to technical changes.
The illustrations and technical specifications provided in this manual may, on account of future product devel-
opments, differ slightly from the actual product supplied.
V 01 18.07.22
LUCEA 10-40
01700 EN

Contents
LUCEA 10-40
01700 EN 3 / 40
Contents
1 Introduction .............................................................................................................. 5
1.1 Preface ................................................................................................................................................. 5
1.2 Other documents relating to this product.............................................................................................. 5
1.3 Information about this document .......................................................................................................... 5
1.3.1 Symbols used in this manual ................................................................................................. 5
1.3.1.1 Cross-references................................................................................................. 5
1.3.1.2 Actions and results .............................................................................................. 5
1.3.1.3 Menus and buttons.............................................................................................. 5
1.3.2 Definitions .............................................................................................................................. 6
1.3.2.1 Hazard levels....................................................................................................... 6
1.3.2.2 Indications ........................................................................................................... 6
2 Safety-related information....................................................................................... 7
2.1 Safety instructions ................................................................................................................................ 7
2.1.1 Technician safety ................................................................................................................... 7
2.1.2 Product integrity ..................................................................................................................... 8
3 Technical specifications.......................................................................................... 9
3.1 Electrical characteristics ....................................................................................................................... 9
3.2 Mechanical specifications..................................................................................................................... 10
3.3 Diagrams .............................................................................................................................................. 11
3.3.1 Lucea 10 circuit diagrams ...................................................................................................... 11
3.3.2 Lucea 40 circuit diagrams ...................................................................................................... 14
4 Maintenance and inspection procedures .............................................................. 17
4.1 Tools required for maintenance............................................................................................................ 17
4.2 Periodic replacements .......................................................................................................................... 17
4.2.1 Periodic replacement cycles .................................................................................................. 17
4.3 Adjustments.......................................................................................................................................... 18
4.3.1 On LUCEA 10 ........................................................................................................................ 18
4.3.2 On Lucea 40 .......................................................................................................................... 20
4.3.2.1 Adjusting the brake and lighthead fork ................................................................ 20
4.3.2.2 Adjusting the ceiling and wall-mounted spring arm ............................................. 22
4.3.2.3 Adjusting the mobile spring arm .......................................................................... 22
4.4 Mechanical inspections ........................................................................................................................ 23
4.4.1 Visual inspections on LUCEA 10 ........................................................................................... 23
4.4.2 Visual inspections on LUCEA 40 ........................................................................................... 26
4.4.2.1 Checking the position of the circlip...................................................................... 29
4.5 Electrical inspection.............................................................................................................................. 29
4.5.1 Functional tests...................................................................................................................... 30
4.5.2 Visual inspections .................................................................................................................. 30
4.6 Optical inspections ............................................................................................................................... 31
4.6.1 Visual inspections .................................................................................................................. 31
4.7 Electrical safety tests............................................................................................................................ 32
5 Recording the inspection ........................................................................................ 34

Contents
4 / 40 LUCEA 10-40
01700 EN

Introduction
Preface 1
LUCEA 10-40
01700 EN 5 / 40
1 Introduction
1.1 Preface
Your hospital has chosen Getinge's innovative medical technology. We thank you for the confid-
ence you have shown in us.
Getinge is one of the world’s leading suppliers of medical equipment for operating rooms, hybrid
rooms, induction rooms, intensive care units and patient transport. Getinge always puts the
needs of healthcare staff and patients first during the development of its products. Getinge
provides solutions that respond to the safety, efficiency and economic constraints faced by hos-
pitals.
Building on its experience in surgical lights, ceiling-mounted equipment management systems
and multimedia solutions, Getinge focuses on quality and innovation to ensure that its solutions
best meet the needs of patients and healthcare staff. Getinge surgical lights are world-renowned
for their design and innovative features.
1.2 Other documents relating to this product
• Instructions for use (Ref. ARD01701)
• Installation manual (Ref. ARD01704)
• Repair instructions (Ref. ARD01702)
• Decommissioning instructions (Ref. ARD01705)
1.3 Information about this document
1.3.1 Symbols used in this manual
1.3.1.1 Cross-references
References to other pages of the manual are identified by the “ ” symbol.
1.3.1.2 Actions and results
Actions to be performed by the user are listed with sequence numbers; the “ ” symbol is used to
show the result of an action.
Example:
Prerequisites:
• The sterilisable handle must be compatible with the product.
1. Fit the handle to the mount.
ØA click is heard.
2. Turn the handle until it locks into place with a second click.
1.3.1.3 Menus and buttons
Menu and button names are shown in bold.
Example:
1. Press the Save button.
ØThe changes are saved and the Favourites menu is displayed.

1Introduction
Information about this document
6 / 40 LUCEA 10-40
01700 EN
1.3.2 Definitions
1.3.2.1 Hazard levels
The text in safety instructions describes types of risk and how to avoid them. Safety instructions
are classified into the following three levels:
Symbol Hazard level Meaning
DANGER! Indicates a direct and immediate risk that may be
fatal or cause very serious injuries potentially lead-
ing to death.
WARNING! Indicates a potential risk that may cause injuries,
health hazards or serious material damage leading
to injuries.
CAUTION! Indicates a potential risk that may cause material
damage.
Tab.1: Hazard levels of safety instructions
1.3.2.2 Indications
Symbol Indication type Meaning
NOTICE Additional assistance or useful information not relat-
ing to risks of injuries or risks of material damage.
ENVIRONMENT Information relating to recycling or to appropriate
disposal of waste.
Tab.2: Types of indication in the document

Safety-related information
Safety instructions 2
LUCEA 10-40
01700 EN 7 / 40
2 Safety-related information
2.1 Safety instructions
2.1.1 Technician safety
WARNING!
Risk of electric shock
Anyone not trained in installation, maintenance or decommissioning opera-
tions is exposed to the risk of injury or electric shock.
Installation, maintenance and decommissioning of the device or components
of the device must be performed by a Getinge technician or a Getinge-trained
service technician.
WARNING!
Risk of burns
During maintenance operations, certain accessible parts may be hot immedi-
ately after use of the device.
Allow the device to cool down before performing any service.
WARNING!
Risk of infection
If no decontamination is carried out on the device before servicing work,
there is a risk of infection for anyone handling the device or any of its com-
ponents.
Make sure that the device is fully decontaminated before any servicing work
is conducted.
WARNING!
Risk of infection
A maintenance or cleaning operation may result in contamination of the sur-
gical site.
Do not perform maintenance or cleaning operations when the patient is
present.
WARNING!
Risk of injury
Parts (e.g. tools, screws and colts) are liable to fall during a technical proced-
ure.
Please limit your presence under the device during technical procedures,
and use the appropriate safety equipment (e.g. safety hat, safety glasses).

2Safety-related information
Safety instructions
8 / 40 LUCEA 10-40
01700 EN
2.1.2 Product integrity
WARNING!
Risk of electric shock or injury
The use of screws or spare parts other than those supplied by the manufac-
turer may damage the device.
Use only screws and spare parts supplied by the manufacturer.
WARNING!
Risk of infection
Lightweight parts from the device may fall onto the surgical site.
Check that all fastenings, covers, cover plates and bumpers on the device
are properly in place.

Technical specifications
Electrical characteristics 3
LUCEA 10-40
01700 EN 9 / 40
3 Technical specifications
3.1 Electrical characteristics
Specifications LUCEA10 LUCEA40
Supply voltage 100-240 VAC / 50-60 Hz 100-240 VAC / 50-60 Hz
Nominal voltage 40 V 45 V
Rated power 14 VA 40 VA
Tab.3: LUCEA 10-40 electrical specifications
Item Description Part number Length
POWER CORD C7
EUR
Power cord for Europe 5 686 02 901 4 metres
POWER CORD C7
GBR
Power cord for the UK 5 686 02 904 4 metres
POWER CORD C7
US
Power cord for the US 5 686 02 900 4 metres
POWER CORD C7
BRA
Power cord for Brazil 5 686 02 902 4 metres
POWER CORD C7
JPN
Power cord for Japan 5 686 02 903 4 metres
POWER CORD C7
AUS
Power cord for Australia 5 686 02 905 4 metres
Tab.4: Power cord reference table for Lucea10
Item Description Part number Length
POWER CORD EUR Power cord for Europe 5 686 04 960 4 metres
POWER CORD GBR Power cord for the UK 5 686 04 961 4 metres
POWER CORD US Power cord for the US 5 686 04 967 4 metres
POWER CORD BRA Power cord for Brazil 5 686 04 963 4 metres
POWER CORD JPN Power cord for Japan 5 686 04 966 4 metres
POWER CORD CHE Power cord for Switzerland 5 686 04 965 4 metres
POWER CORD AUS Power cord for Australia 5 686 04 964 4 metres
POWER CORD ITA Power cord for Italy 5 686 04 962 4 metres
POWER CORD ARG Power cord for Argentina 5 686 04 968 2 metres
Tab.5: Power cord reference table for Lucea40

3Technical specifications
Mechanical specifications
10 / 40 LUCEA 10-40
01700 EN
3.2 Mechanical specifications
Specifications LUCEA 10 LUCEA 40
Lighthead weight 0.8 kg 1.85 kg
Lighthead dimensions 223 × 175 mm 337 × 214 mm
Sterilisation and disinfection methods Not applicable
Operating mode Continuous operation
Tab.6: LUCEA 10-40 mechanical characteristics

Technical specifications
Diagrams 3
LUCEA 10-40
01700 EN 11 / 40
3.3 Diagrams
3.3.1 Lucea 10 circuit diagrams
LUCEA 10 simplified circuit diagram: wall-mounted, mobile, desktop and rail-mounted (old
version)
Power supply
red
red red
black
black
Regulator board
Fig.1: LUCEA 10 simplified circuit diagram: wall-mounted, mobile, desktop and rail-mounted

3Technical specifications
Diagrams
12 / 40 LUCEA 10-40
01700 EN
LUCEA 10 circuit diagram: wall-mounted, mobile, desktop and rail-mounted (new version)
ARD568602518
ARD669606029
ARD568602520ARD568602519
D1 D2
D10
Circuit Leds
ARD568602524
Regulator circuit
LCA 10 soldered IEC cable
HBU32-110 power supply
PCB connection cable LED board
Flexible conduit board LUCEA 10 head subassembly
Switch
Structure
Handle mount
red
red
red
black
black
Fig.2: LUCEA 10 circuit diagram: wall-mounted, mobile, desktop and rail-mounted

Technical specifications
Diagrams 3
LUCEA 10-40
01700 EN 13 / 40
Ceiling-mounted Lucea10 circuit diagram
ARD 5 686 02 511ARD 6 696 060 29ARD 5 686 02 512 ARD 5 686 02 520ARD 5 686 02 515
D1 D2
D10
Power cable HBU32-110 power supply Suspension cable Adapter cable LED board
LED circuit
Regulator circuit
LUCEA 10 head subassemblySuspension arm
Handle mount Structure
Switch
AC/DC power supply red
black black
red red
red
black
red
black
green/yellow
Fig.3: Ceiling-mounted Lucea10 circuit diagram

3Technical specifications
Diagrams
14 / 40 LUCEA 10-40
01700 EN
3.3.2 Lucea 40 circuit diagrams
Circuit diagram for ceiling-mounted version




ARD568601506 ARD699600549 ARD568601511 ARD568601510
ARD568601505
ARD568601525 ARD569003014 ARD568601563 ARD569003014
Cable for wall-mounted LCA 40
Anchor point Anchor tube and shaft Main arm
Lighthead Fork Spring arm
Cable for wall-mounted LCA 40 XP ECM60US48 power supply Ceiling-mounted LCA 40 power supply cable kitSuspension shaft cable
LCA 40
LED board Fork cable kit
Blue 30
Spring arm cable Extension cable
Blue 30-80
AC/DC power supply
Switch
Handle mount
Structure
LED circuit
ARD699600554
Fig.4: Circuit diagram for ceiling-mounted version
Circuit diagram for wall-mounted version




ARD568601506 ARD699600549 ARD568601505
ARD568601525 ARD568602519 ARD569003014 ARD568601563 ARD569003038
LCA 40 wall power cord XP ECM60US48 power supply LCA 40 wall power cord
LED board PCB connection cable Fork cables kit
Blue 30
Blue 30 spring arm cable Extension cable
Blue S80/30 850
Structure Switch
Handle
mount
Lighthead Fork Spring arm
Main arm
Anchor point
ARD699600554
Fig.5: Circuit diagram for wall-mounted version

Technical specifications
Diagrams 3
LUCEA 10-40
01700 EN 15 / 40
Circuit diagram for mobile version
ARD568601525 ARD568602519 ARD569003014
ARD699600549
ARD568601564
ARD568601504
ARD568601503
Fork
Lighthead Spring arm
Structure
LED board PCB connection cable Fork cables kit
Blue 30
Mobile spring arm cable Lucea 40
XP ECM60US48 power supply
Power supply cover
Power supply AC/DC
110V UL power cord
220V CE power cord
ARD699600552
Fig.6: Circuit diagram for mobile version

3Technical specifications
Diagrams
16 / 40 LUCEA 10-40
01700 EN
Integration of earth wires in the mobile unit
5 682 04 540-A 5 682 04 020
5 686 04 521-B
Spring arm Connect
the flat terminal
Power supply cover
IEC
Power supply board
Ferrite bead
Connect to the double terminal / male terminal
Fig.7: Integration of earth wires in the mobile unit

Maintenance and inspection procedures
Tools required for maintenance 4
LUCEA 10-40
01700 EN 17 / 40
4 Maintenance and inspection procedures
CAUTION!
Risk of equipment damage
If adjustments are made incorrectly or not at all, the lighthead or installed
equipment may drift.
Make all adjustments (balance, stop and brakes) during installation and then
after all maintenance operations.
NOTICE
After-sales service kits are available on the spare parts platform
.
The LinkOne platform is accessible on the GetingeOnline portal:
getingeonline.com/SIS/external-links
4.1 Tools required for maintenance
Description Qty Part number
OPM 039 Photometer 1 5 720 34 999
OPM 059 Multimeter M 54 RMS 1 5 720 59 999
OPM085 Angled, insulated pliers (for regulation board fuse) 1 6 870 00 011
Grease 1 6 590 00 011
4.2 Periodic replacements
4.2.1 Periodic replacement cycles
To ensure safety and performance, please follow the recommendations below.
Items Frequency
Suspension mounting screws on Lucea40
(tighten the screws with a torque of 16N.m)
Every six years

4Maintenance and inspection procedures
Adjustments
18 / 40 LUCEA 10-40
01700 EN
4.3 Adjustments
4.3.1 On LUCEA 10
Fig.8: Unscrewing the Torx screws
• Remove the three Torx screws.
Fig.9: Removing the transparent housing
• Remove the transparent housing and
cover plate assembly.
Fig.10: Unscrewing the Torx screws
• Loosen the two Torx screws by a few
turns.

Maintenance and inspection procedures
Adjustments 4
LUCEA 10-40
01700 EN 19 / 40
1
2
Fig.11: Removing the collimator subassembly
• Remove the faceted structure:
1 - Push the structure to one side.
2 - Pull on the assembly.
Fig.12: Unplugging the connector
• Unplug the two-pin connector.
Fig.13: Adjusting the brake
• Adjust the braking with an appropriate tool
(hex socket)
– upwards for firmer braking
– downwards for more flexible braking
NOTICE
Take particular care when removing the lighthead to avoid pulling off the
connector.
NOTICE
To reinstall the faceted structure and the cover subassembly, follow the
above instructions in reverse order. The transparent housing mounting
screw must be tightened to a torque of 0.9N.m.
NOTICE
Check that the two-pin connector is properly connected.

4Maintenance and inspection procedures
Adjustments
20 / 40 LUCEA 10-40
01700 EN
4.3.2 On Lucea 40
4.3.2.1 Adjusting the brake and lighthead fork
Fig.14: Unscrew the Torx screws
• Unscrew the three Torx screws holding the
housing to the fork subassembly.
Fig.15: Remove the cover
• Remove the transparent housing and
cover plate assembly.
Fig.16: Unscrew the Torx screws
• Loosen the two Torx screws by a few
turns.
