G-Cam/EWPC-3285 4 MP HDR Micro Bullet IP Camera Quick Guide
2 3
This guide is for quick installing and connecting the 4 MP HDR Micro Bullet IP Camera. For more details, please
refer to the User’s Manual.
microSD Card Slot / Default Button
Loosen first the tube screw and then pull the tube away from housing.
Motorized Lens (3)
microSD Card Slot (1)
Insert the microSD card into the card slot to store videos and snapshots. Do not remove the microSD card when the
camera is powered on.
NOTE: It is not recommended to record with the microSD card for 24/7 continuously, as it may not be able to
support long-term continuous data read/write. Please contact the manufacturer of the microSD card for
information regarding the reliability and the life expectancy.
Default Button (2)
Press the button with a proper tool for at least 20 seconds to restore the system.
Function Cable
No. Connector Definition
1 RJ-45 For network and PoE connections
Camera Cabling
Please follow the instructions below for cable connections.
Power & Network Connection
Connect the RJ-45 connector of the camera to a PoE switch. The camera will automatically power up and connect to
the Ethernet.
NOTE: Check the status of the link indicator and the activity indicator LEDs. If the LEDs are unlit, please check
the LAN connection.
Green Link Light indicates good network connection.
Orange Activity Light flashes for network activity indication.
Before Login to the Camera
A client program will be automatically installed to the PC when connecting to the camera. Before logging in to the
camera, ensure downloading the ActiveX control is allowed by either changing the ActiveX controls and plug-ins or
setting Internet’s security level to default. For further details, please refer to the User’s Manual.
ActiveX Controls and Plug-ins Settings Internet Security Level
Step 1: Start the Internet Explorer (IE).
Step 2: Select <Tools> from the main menu of the
browser. Then click on <Internet Options>.
Step 3: Click on the <Security> tab and select
<Internet>, and click on <Custom level> to
change ActiveX settings.
Step 4: Set “ActiveX controls and plug-ins” items to
<Prompt> or <Enable>.
Step 1: Start the Internet Explorer (IE).
Step 2: Select <Tools> from the main menu of the
browser. Then click on <Internet Options>.
Step 3: Click on the <Security> tab and select
<Internet>.
Step 4: Down the page, click <Default Level> and click
on <OK> to confirm the setting. Close the
browser window, and open a new one later for
accessing the IP camera.
Camera Login
The default setting of the camera is DHCP. You can find the camera via the Device Searching Tool, which is on the
CD. If no DHCP server is in netweork, the camera sets itself to IP address 192.168.0.250. If you now want to access
to the camera, please set the IP address of the PC as 192.168.0.XXX; for example:
IP Address: 192.168.0.100
Subnet Mask: 255.255.255.0
Login ID and Password
 Key in the camera’s IP address in the URL bar of the web browser window and hit on “Enter”.
 Enter the default username (root) and password (admin) in the prompt request dialogue. Note that username is
case sensitive.
Install the ActiveX Control
 After connecting to the camera, the request for installing the ActiveX control will appear just below the URL bar.
 Right click on the information bar, and then click on <Install ActiveX Control…> to permit ActiveX control installation.
 In the pop-up security warning window, click on <Install> to start downloading DCViewer software on the PC.
 Click on <Finish> after DCViewer installation is completed.

4
Browser-based Viewer
The main page of the IP camera user interface is shown here. Please note that function buttons will vary depending
on the camera model.
Note: For details about configuring the camera in GEUTEBRÜCK-Software (G-Set and GSC-Setup),
please refer to the Quick Guides, which can be found at the supplied CDRom.
G-Cam/EWPC-3285
4 MP HDR Micro Bullet
IP Camera
Quick Guide
Ver. 1.0
