GEZE TSA 160 Technical manual

1
GEZE
PlanungsunterlageTSA160Datei84338PuTSA160_GB_200999_.p65
TSA 160
GB
Swing Door Drive forAutomatic Doors
Planning document

2
PlanungsunterlageTSA160Datei84338PuTSA160_GB_200999_.p65
MATERIALPRÜFUNGSAMT NORDRHEIN-WESTFALEN
Prüfstelle,ÜberwachungsstelleundZertifizierungsstellegemäߧ28BauONW
CERTIFICATE OF CONFORMITY
Reg.-No. 12 9820 - DO 14.1
This is to certify in accordance with § 22 para.2 No. 2 of the Building Code (Landesbauordnung) for the Land
Baden-Württemberg, that
thebuildingproducts: Swing door drive ‘’GEZE TSA 160 ’’ complies with
the requirements
• set forth by the technical rules in accordance with the Technical Schedule Apart 1 (edition 98/2),
consecutive number 6.14 of DIN 18 263-4
the manufacturer: GEZEGmbH
Postfach 1263
D-71229 Leonberg
the production plant: GEZEGmbH
Reinhold-Vöster-Str. 21-29
D-71229 Leonberg
in accordance with the results of the
• product tests carried through by the MPA NRW
• internal product control carried through by the producer
• foreign control carried through by the MPANRW
The manufacturer is therefore entitled to mark the building products, the packing or the delivery note with the
sign of conformity (Ü-sign) in accordance with the ordinance regulating conformity signs.
Dortmund, 12.12.2000
Marsbruchstraße 186 • Dortmund-Aplerbeck • Postanschrift: 44285 Dortmund • Telefon [phone] • Telefax [phone]

3
GEZE
PlanungsunterlageTSA160Datei84338PuTSA160_GB_200999_.p65
Contents
Fields of application 4
Product features 5
List of product variants 6
Swing door drive for smoke and fire-proof doors TSA 160 F 7
Accessories for TSA 160 F on fire-proof doors 8
TSA160Invers and TSA 160 Z Invers 9
TSA 160 WC-compartments for the handicapped 10
Description of drive 11
System description 14
Technical Features 15
Connection possibilities for actuation elements 16
Safety sensors 17
Side view and installation dimensions TSA 160 18
Side view and installation dimensions TSA 160 and TSA 160 F-IS 20
Side view and installation dimensions TSA 160 pulling 22
Side view and installation dimensions, 1- and 2- leafs
TSA160ZandTSA160Z-IS 24
Cable plan single-leaf door 26
Cable plan single-leaf smoke and fire-proof door,
incl. central smoke control unit 27
Cable plan double-leaf door incl. integrated closer control 28
Cable plan double-leaf door incl. central smoke control unit 29
Cable plan single and double-leaf with door control unit TZ 220 30
Cable plan TSA 160 WC-compartment for the handicapped 31

4
PlanungsunterlageTSA160Datei84338PuTSA160_GB_200999_.p65
Fields of application
Wherehelpisneeded:
Hospitals,rehabilitationcentres
Old-peopleshomes as wellas homesandworkshops fordisabled persons
Publicbuildings,airports,stations
Canteens,waiter’sswingingdoors
Schools,kindergardens
Whereenergyhastobesaved:
Exterior doors, corridor end doors
Draught-proofsystems
Workshops,ateliers,studios
Wherehygieneisrequired:
Foodmanufacturingshops,pharmaceuticalindustry
Hospitals,surgeries
Social rooms, toilets
Wheresafetyisthefirstpriority:
Forsafetylocksand accesscontrol
Forfire preventionpurposes (fireand smokeprevention) typeTSA 160F on
single-leafanddouble-leafdoors
Wherecomfortisthechoice:
Inshops
Inbanks
Inpublicbuildings

5
GEZE
PlanungsunterlageTSA160Datei84338PuTSA160_GB_200999_.p65
Product features
TSA160isanelectronicallycontrolled,electrohydraulicswingdoordrive.
Openingiseffectedbyahydraulicpumpsystem.Theclosingprocessiseffectedbya
closingspringmechanismandadjustablehydraulicvalves.
Smallexterior dimensions,i.e. thedrive canalso beinstalled withlimited space
conditions.
The closing force is infinitely variable from EN size 3 to 6 acc. to EN 1154 for diffe-
rentleafwidths.
Max.leafwidth1400mm
Max. door weight 250 kg
Systemscanbeusedfor eitherpushing orpulling versions(hingesideandopposite
hingeside)
Forsingle-leafdoors
TSA 160
onlyonesystemfordoorDINleftorDINright(retrofittable)andusableforeither
pullingorpushingversion
TSA 160 F
forsmokeandfire-proofdoors,pushing
Fordouble-leafdoors
Intermediate cover possible
TSA 160 - IS
includinginvisibleclosingsequenzcontrol,concealedunderthecover
TSA 160 F - IS
for smoke and fire-proof doors
TSA 160 - IS / TS
automatic2ndclosingleaf,1stclosingleafwithdoorcloserfunction”permanently
open”only.
Themotorisactivatedbyanelectronicsystem:
Start-upasrequiredincl.evaluationofthesensorsandthecontrolunitsintheperiphery.
Samesystemforalldoorsinthehouse(single-leaf,double-leaf,fire-proofdoorsetc.)
reducesmaintenance andinstallation workas wellas stockkeepingof spare partsfor
mechanicalequipment.

6
PlanungsunterlageTSA160Datei84338PuTSA160_GB_200999_.p65
List of product variants
Swing door drive for interior and exterior doors
TSA 160
pulling or pushing
for single-leaf or double-leaf
single-action doors
TSA160pulling + TSA 160pushing
for double-motion, double-leaf doors
TSA 160 - IS
pushingorpullingincl.integratedcloser
controlondouble-leafdoors
TSA 160 / 162
as”master/slave”combinationwithonlyone
combinedcontrolforbothdrivesof
double-leafdoors
TSA 160 - IS / TS
pushingorpullingincl.integratedclosercontrol.
2ndclosingleafincl.automaticfunction,
1stclosingleafincl.doorcloserfunctionand
permanently-openposition
Hinge side, pulling
incl. guide rail
Opposite hinge side, pushing
incl.linkage
Hinge side pulling incl. guide rail
Opposite hinge side pushing incl. linkage
Opposite hinge side pushing
incl.linkage Hinge side, pulling
incl. guide rail

7
GEZE
PlanungsunterlageTSA160Datei84338PuTSA160_GB_200999_.p65
Swing door drive for smoke and fire-proof doors
TSA 160 F
TheTSA160Fis ahold-open mechanisminaccordancewiththe guidelinesfor hold-open
systemsissuedbyDIBt*)
Thedrivesystemisusedtoautomaticallyopenandclosefire-proofdoors.Thesystemcanbe
actuatedviatheusualpulsegenerators.Besidesautomaticopeningandclosing,thedoors
can also be held in an open position.
Inthecaseoffire,theautomaticfunctionorthehold-openfunctionmustbeswitchedoffbya
correspondingfire alarm system.The mains cableis interrupted byamains PCboardfor
powercutoff(F-accessories)andthenormaldoorclosingfunctionthedriveismaintained.
Doorcloserswithautomaticopeningfunction(swingdoordrive)inaccordancewith
DIN18263part4arethereforean integralpartofhold-open mechanismsandrequire
approvalbythebuildingsupervisionauthorities.
TSA 160 F
pushingincl.DIBt-approvalfortheuseon
single-leafsmokeandfire-proofdoors.
TSA 160 F-IS
pushingincl.integratedclosercontrol;
incl.DIBt-approvalfortheuseon
double-leafdoors.
TSA 160 F - IS / TS
pushingincl.integratedclosercontrol;
incl.DIBt-approvalfortheuseondouble-leaf
doors,2ndclosingleafincl.automaticfunction
1stclosingleafincl.doorcloserfunctionand
permanently-openposition.
*) DIBt: German Institute for Structural Engineering (Deutsches Institut für Bautechnik)

8
PlanungsunterlageTSA160Datei84338PuTSA160_GB_200999_.p65
Accessories for TSA 160 F on fire-proof doors
For
TSA 160 F
TSA 160 F - IS
TSA 160 F - IS / TS
thefollowingitemsare requiredfortheuseonfire-proofdoors:
Smokeswitchwithenergysupplye.g.RSZ6
probably additional smoke detectors in accordance with the guidelines for hold-
openmechanisms
break key (manually operated release button) in accordance with the guidelines
for hold-open
electric door opener, approved for fire-proof doors (customer)
MountingplateTSA160
Electric door
opener
Interrupter
button Actuation
button
Emergency
cut-out
RSZ6

9
GEZE
PlanungsunterlageTSA160Datei84338PuTSA160_GB_200999_.p65
TSA 160 Invers and TSA 160 Z Invers
Functional description
Singleordouble-leaf doors are kept close by theescaperoute locking
mechanism. The door is monitored via an emergency exit system
which controls all safety-relevant functions. The doors are electro-
hydraulically closed and opened through spring force. This ensures
that the doors can be reliably opened and kept permanently open in
the case of power failure.
Automaticfunction
The system is released at the emergency exit system via the key-operated switch (or e.g.
card reader), which activates the actuation elements of the automatic door drives. As soon
as the sensors respond, the drives open
the doors through spring force. Upon
lapse of the pre-set hold-open time, the
doors close automatically with all safety
elements being active. This means that
the sensors will stop the movement of the
door if a person is within the swing of the
door and the door will not close until the
obstacle has been removed.
Smoke/heat extracting system – fresh air
If an alarm has been released by the
smoke detector or the fire alarm system
the doors are immediately unlocked and
mechanically opened to allow secure
smoke extraction. The doors remain open
until the alarm has been reset.
Escape way function
If the red emergency button is operated by a
fleeing person, the doors are immediately
unlocked and mechanically opened through
spring force. Thus the escape route is free. The
operation of the emergency button at the same
time releases an alarm which is transmitted to
the control centre.
Smoke/heat extracting system
View of the door: opposite hinge side featuring
TSA 160 Z Invers
BURG
NOTTASTE
NurbeiGefahr betätigen
BURG
NOTTASTE
NurbeiGefahr betätigen

10
PlanungsunterlageTSA160Datei84338PuTSA160_GB_200999_.p65
TSA 160 WC-compartments for the handicapped
Functional description
Afterthepad switchhadbeenoperated,thetoiletdooropensandcloses automaticallyuponlapse
ofapresettablehold-opentime.
Byoperatingthechangeoverswitchinsidethetoiletcabin,theuseractivatestheilluminatedsign
“OCCUPIED“outsidethecompartmentaswellasthecontrollampatthechangeoverswitch.
Simultaneouslytheinteriorandexteriorpadswitchisswitchedoff.Thusthedoorcanneitherbe
openedbyathirdpersonnorbytheuserhimselfbyaccident.
Thelivedooropenerpreventsthatthedoorscanbeopenedmanually.
Toleavethelavatory,theuseragainoperatesthechangeoverswitch;thesign“OCCUPIED“out-
sidethecompartmentaswellasthe
controllampgoout.
Byoperatingthe interiorpadswitch
“DOOROPEN“,thedoorwillimmediately
open.
Inthecaseofpowerfailuretheuserhas
thepossibilitytoopenthedoormanually
bypushingorpullingitopen,theclosed-
circuitopenerisunlocked.
The door can also be opened from inside
byoperatingthedoorhandleevenifthe
systemislive.Inanemergencythedoor
canalsobemanuallyopenedfromout-
side using a key or by operating the
emergencycutout.
TSA160
Illuminatedsign
“OCCUPIED“
Pad switch “DOOR
OPEN“(insideand
outside)
Emergency
cutout
Door
opener
Changeover
switch
locked/unlocked
Illuminatedsign
“OCCUPIED“

11
GEZE
PlanungsunterlageTSA160Datei84338PuTSA160_GB_200999_.p65
Description of drive
Field of application:
Forsingle-leafordouble-leafswingdoorsmadeofmetal,timber,all-glass
or PVC u
Type-testedfortheuseonsingle-leafanddouble-leafsmokeandfire-proofdoors,
pushingversion
Outsidedimensionsofdrive: W x H X D = 690 x 100 x 120 mm
Max.leafwidth 1400 mm
Min.hingecentre TSA 160 F - IS 1470 mm
TSA 160 F- IS / TS 1260 mm
Max.weightofleaf 250 kg
Max.soffitdepth pushingfunction(TSA160) 350mm
pullingfunction(TSA160Z) 200 mm
Fordryroomsonly,ambienttemperature -10° to +60°C
Adjustablefunctions:
Openingspeed: viahydraulicvalve
Closing speed: withinrange75°...0°
Openingandclosingdamping: viahydraulicvalve
Latchingaction: viahydraulicvalve
Closingforce,infinitely: EN size 3...6 (DIN 2 ...5)
Approachdelay: 0 – 5 seconds
Adjustablehold-opentime: 0 ... 60 s
(viajumper0...10;10...60s)
Dooropeningangle: max.115°
*notrequiredforTSA160Invers,theclosingforceisgeneratedelectrically

12
PlanungsunterlageTSA160Datei84338PuTSA160_GB_200999_.p65
1400
1200
1000
100 130 160 190 220 250
Leaf width [mm]
Leaf weight [kg]
Leaf width
Hinge centre [mm]
Leaf width
pushing function pulling function
minimum spring
pre-tension maximum spring
pre-tension minimum spring
pre-tension maximum spring
pre-tension
Closer size acc. to
EN 1154
moment exerted by the
closing spring when door
is opened automatically
moment exerted by the
closing spring when door
is closed
moment that has to be
exerted manually to open
the door
Size 3 . . . . . . . . Size 6
20 Nm . . . . . . > 60 Nm 8 Nm . . . . . . . 30 Nm
150 Nm . . . . . . . 90 Nm 70 Nm . . . . . . 40 Nm
35 Nm . . . . . . . 110 Nm 13 Nm . . . . . . 45 Nm
Closing moments:
Opening moments:
Hint:
The doors have to be equipped with hinges suitable for automatic function.
A door stopper is recommended in any case.
TSA 160 maximum leaf width as a function of leaf weight

13
GEZE
PlanungsunterlageTSA160Datei84338PuTSA160_GB_200999_.p65
TSA 160 minimum and maximum leaf widths, hinge sizes
Single-leaf doors minimum maximum
door width door width
(mm) (mm)
TSA160pushing 690 1400
TSA160pulling 950 bei AV = 0 mm *1) 1400
890 bei AV = 60 mm *1) 1400
TSA160Z 690 1400
*1) AV ... drive unit position
Double-leaf doors minimum maximum minimum minimum maximum
hinge size hinge size leaf width leaf width leaf width
2nd closing leaf 1st closing leaf
(mm) (mm) (mm)*2) (mm)*2) (mm)
TSA160 IS 1470 2800 690 400 1400
pushing
TSA160Z-IS 1470 2800 690 650 1400
pulling
TSA160IS/TS 1260 2800 690 400 1400
pushing
TSA160Z-IS/TS 1360 2800 690 650 1400
pulling
On smoke and fire-proof doors:
Single-leaf doors minimum maximum
door width door width
(mm) (mm)
TSA160Fpushing 690 1400
Double-leaf doors minimum maximum minimum minimum maximum
hinge size hinge size leaf width leaf width leaf width
2nd closing leaf 1st closing leaf
(mm) (mm) (mm) *2) (mm) *2) (mm)
TSA160F-IS 1470 2800 690 400 1400
pushing
TSA160F-IS/TS 1260 2800 690 400 1400
pushing
*2) The minimum hinge size must be observed!

14
PlanungsunterlageTSA160Datei84338PuTSA160_GB_200999_.p65
Control with
potentiometer for
hold-openperiod,
actuationdelay
System description
Theproductisamodularsystem,consistingof:
Drive unit
Guide rail or standard linkage
Thepossible usedependsonthetype ofapplication. Apushing-version linkageis requiredfor
smoke and fire-proof doors with TSA 160 drive (DIN 18263 part 4).
Intermediate cover and add-on cover set
All necessary connections and ancilliary parts are aesthetically covered
Intermediate cover
for optical and functional connection
of two drives.
Add-on cover set
for single-leaf systems to extend to
full door width
Motor shaft Motor
Side elements
Hydraulic pump
Connecting
cable
Guide rail for
hinge side
pulling function
Linkage for opposite
hinge side
pushing function
Valve adjusting device for closing
damping, latching adjustment, opening
speed, opening damping
Linkagefor revealdepth
- 0 ... 100 mm
- 100 ... 200 mm
- 200 ... 350 mm

15
GEZE
PlanungsunterlageTSA160Datei84338PuTSA160_GB_200999_.p65
Max.leafwidth: 1400 mm
ENsize: EN 3 to EN 6 (DIN size 2 ... 5)
Max.leafweight: 250 kg
Dimensions: Length690mm
Height100mm(withoutspindleandlever)
Depth120mm(mountingplateplus8mm)
Closed position of door: Closingpressureby springaction
Powersupply: 230 V AC, +10%/-14%, 50/60 Hz
Powerconsumption: 200 VA with 230 V AC
The motor is switched off as soon as the preset open position of the door is reached or
uponlapseofthepresetmotorrunningtime.
Motortemperaturecontrolbyintegratedthermoswitch.
Powerfailure manualdoorcloserfunction
hydraulicallycontrolledclosing
Integratedprogramme positionII=automaticfunction
position I=permanentlyopen
position 0 = off
Supplyvoltagefor
peripheralappliances: 24 V DC, 800 mA
Weightofdrive: ca. 13 kg
Technical Features

16
PlanungsunterlageTSA160Datei84338PuTSA160_GB_200999_.p65
43
81
81
Connection possibilities for actuation elements
all known approach monitor elements can be connected, e.g.:
Radarmovementdetectorfortemperature-independentresponse,
evendirectionsensing
Infra-redmovementdetector
Passiveinfra-redmovementdetector
Pushbuttonsofallkind,suchasCode-cardreader,key-operatedswitch,radiocontrol
unitetc.
Dooropener:
24 V DC open-circuit or closed-circuit principle *)
24 V AC open-circuit principle
Lockswitchcontact:
Mustbeinstalledinstrikeplateifthedooris lockedmanually
Internalprogrammeswitch
(externalasanoption)alsoavailableas
key-operatedprogrammeswitch,with
3 positions:
-Off
-Automaticoperation
-Permanentlyopen
*)Explanation:
Open-circuit principle
Typicalapplication:entrancedoor,compulsoryforfire-proofdoors
The locking process is made by the open-circuit principle, i.e. the door remains closed as long as the
lock is not live or actuated. The door is unlocked either by short-term actuation or permanent contact
(permanently open). In the case of power failure the door remains locked and can only be opened
mechanically via the cylinder or the door handle.
Closed-circuit principle
Typical application: RWS system
The door is locked as long as the system or the door opener is live. To open the door the circuit is
closed for a short time by willingly breaking the contact. The holding magnet of the door opener falls
off and the door is released.
Breaking of circuit means permanently open.
In the case of power failure the door is forcibly unlocked.
Available as flush or surface-mounted version

17
GEZE
PlanungsunterlageTSA160Datei84338PuTSA160_GB_200999_.p65
Field of application
Safety sensors are used to monitor the swiveling area of
automatic doors. The door stops moving as soon as one or
several persons step within the detection range of the sensor.
If the safety sensor “OPEN“ (SA) is used, the door
movement stops as soon as the sensor detects an obstable.
Wall recognition possible.
The safety sensor “CLOSE“ (SZ) actuates the drive of the
closing door and opens them again.
Incl. radar, on both sides and
SA=Safetysensor“OPEN“
SZ=Safetysensor“CLOSE“ Incl. radar on both sides
Radar
Sensor
SA
Sensor
SZ Radar
safety sensors
AIR16
Radar
Radar
FB = Width of the leaf
B = Width of the system
(possibly double-leaf)
Safety sensors

18
PlanungsunterlageTSA160Datei84338PuTSA160_GB_200999_.p65
31
33
51
AUT
AUS
DO
8 120
23
39
54
100
A*
Dimensions for direct mounting of drive
Further details see installation drawing No 70423-9-9920
(Swing door drive TSA 160 size 2-5 incl. safety and actuation sensor)
Side view and installation dimensions TSA 160
Oppositehingeside,pushing,incl.Mountingplate
For door widths 690 – 1400 mm
TobeusedvorTSA160ZInversaswell
*A
Spindleextension
optional 24, 30, 45 mm
not illustrated above
Linkage,pushing
Actuation sensor AIR 16
Mounting plate L= 690 mm
SafetysensorAIR16
(without scales)

19
GEZE
PlanungsunterlageTSA160Datei84338PuTSA160_GB_200999_.p65
14
14
260
690
[M5]
M6
M6
335 44
625
50
27
54
23
260
[]
125
[]
[ø11]
[a]
34 420
[M5]
M6
M8
335
44
650
487.5
325
162.5
50
20
11
51
39
[125]
[260]
[ø11]
[a]
*)
*)
(50)
(200)
(400)
(600)
(800)
(114)
(Ø10)
[M5] [ø11]
[200]
[260]
[125]
Safety sensor hinge side
Mounting dimensions drive door DIN right pushing
Dimensions for actuation sensor in [brackets]
Hinge centre
Mounting dimensions for direct mounting Mountingdimensions
when mounting plate is used
Blind rivet nut
*) If cable entry is from the
rear make boring Ø 20
Mounting dimensions safety sensor (DIN right door)
For door widths > 900
mm make further
tappered boreholes at
intervals of 200 mm
Dimensions of drive and sensors door DIN right pushing
Hinge centre
Drive and actuation sensor
opposite hinge side
Actuation sensor, dimensions in [brackets] Safety sensor, dimensions in [brackets]
Doorwidth, [mm]
< 900
900 - 1400
Overalldimensions a [mm]
doorwidth - 700 (amin= 25)
200
Door hinge
axis
Door hinge
axis

20
PlanungsunterlageTSA160Datei84338PuTSA160_GB_200999_.p65
DO
AUS
AUT
X (max.350mm)
8120
H
61
90
39
Y=31+A
10
54
23
100
-
24
30
45
4
28
34
49
H
max
[mm]
[mm]
Y
[mm]
31
55
61
76
2nd closing leaf = drive TSA 160 F-IS
1st closing leaf = drive TSA 160 or 1st closing leaf closer TS 160
2nd and 1st closing leaf incl. drive TSA 160 F
Side view and installation dimensions TSA 160 and TSA 160 F-IS
Fordouble-leafdoorswithintegratedclosingsequencecontrol
Oppositehingeside,pushing,incl.mountingplateandsteelframe
Door widths 690 – 1400 mm
Mounting plate L= 690 mm
min. 5 fixing points,
dowelS10
SpindleextensionA*)
Reset button
Linkagepushing
forsoffit depthA
X=0-100
100-200
200-350
(without scale)
Dimensions for direct mounting of drive
FurtherdetailsseeinstallationdrawingNo70437-9-9910(SwingdoordriveTSA160F/F-IS)
*)Spindle
extension A
