GEZE Slimdrive EMD User manual

Slimdrive EMD
Valid for variants:
Slimdrive EMD (1-leaf/2-leaf)
Slimdrive EMD-F (1-leaf/2-leaf)
Slimdrive EMD Invers (1-leaf/2-leaf)
Slimdrive EMD-F-IS
Slimdrive EMD-F/R
Slimdrive EMD-F/R-IS
Original operating instructions
EN User manual
118176 - 07

Slimdrive EMD/EMD-F
2
Contents
1 Introduction...............................................................................................................................................................3
1.1 Symbols and illustrations ..............................................................................................................................................................................3
1.2 Product liability .................................................................................................................................................................................................3
1.3 Special cases.......................................................................................................................................................................................................3
1.4 More detailed information............................................................................................................................................................................3
1.5 Terms .....................................................................................................................................................................................................................4
2 Fundamental safety precautions .......................................................................................................................6
3 Description.................................................................................................................................................................7
3.1 Types of installation and versions ..............................................................................................................................................................7
3.2 Structure ..............................................................................................................................................................................................................7
3.3 Overview of the modes of operation........................................................................................................................................................8
3.4 Operating elements.........................................................................................................................................................................................8
3.4.1 Internal programme switch..........................................................................................................................................................................8
3.4.2 Mechanical programme switch MPS (optional)....................................................................................................................................9
3.4.3 Display programme switch DPS (option).................................................................................................................................................9
3.4.4 Keypad programme switch TPS (optional) .......................................................................................................................................... 10
3.5 Door in normal operation .......................................................................................................................................................................... 10
4 Operation .................................................................................................................................................................12
4.1 Selecting the mode of operation .............................................................................................................................................................12
4.1.1 Selecting the mode of operation at the mechanical programme switch.................................................................................12
4.1.2 Selecting the mode of operation at the mechanical programme switch MPS.......................................................................12
4.1.3 Selecting the mode of operation using the display programme switch...................................................................................13
4.1.4 Selecting the mode of operation using the keypad programme switch..................................................................................14
5 Troubleshooting.....................................................................................................................................................15
6 Cleaning and maintenance ................................................................................................................................17
6.1 Cleaning .............................................................................................................................................................................................................17
6.2 Maintenance.....................................................................................................................................................................................................17
6.3 Inspection by an expert ...............................................................................................................................................................................17
7 Technical data.........................................................................................................................................................18

Slimdrive EMD/EMD-F
3
Introduction
1 Introduction
1.1 Symbols and illustrations
Warning notices
In these instructions, warning notices are used to warn against material damage and injuries.
XAlways read and observe these warning notices.
XObserve all measures marked with the warning symbol and warning word.
Warning
symbol
Warning
word
Meaning
CAUTION Danger to persons.
Non-compliance can result in minor injuries.
More symbols and illustrations
Important information and technical notes are highlighted to explain correct operation.
Symbol Meaning
means “important note”;
Information on avoiding material damage, improved understanding or optimising the workows
means “additional Information”;
The user's attention should be drawn to important addition information. There is no danger to persons
or property, but it is particularly useful to read the additional information carefully
XSymbol for an action: This means you have to do something.
XIf there are several actions to be taken, keep to the given order.
1.2 Product liability
In compliance with the liability of the manufacturer for his products as dened in the German “Product Liability Act”,
compliance with the information contained in this brochure (product information and intended use, misuse, product
performance, product maintenance, obligations to provide information and instructions) must be ensured. Failure
to comply releases the manufacturer from his statutory liability.
1.3 Special cases
In certain cases, such as with
àSpecial wiring
àspecial function settings (parameters)
àSpecial software
dierences from the information given in this user manual may occur.
XIf this is the case, please ask the service technician responsible.
1.4 More detailed information
Information about commissioning and service can be found on the following diagrams:
àWiring diagram Slimdrive EMD
àInstallation instructions Slimdrive EMD

Slimdrive EMD/EMD-F
4
Introduction
1.5 Terms
Term Explanation
Hinge side
The side of the door where the hinges from which the door leaf is suspended are located.
Usually that side of the door located in the opening direction.
Opposite hinge side The side of the door facing the hinge side. Usually that side of the door located in the
direction of closing movement.
Active leaf The active leaf of a double leaf door. When the door is used, the active leaf must open
as the rst door leaf and close as the last door leaf.
Passive leaf The secondary leaf of a double leaf door. When the door is used, the passive leaf may
not open until the active leaf has left the closing position and must close again as the
rst door leaf.
Activation device inside (KI) Push button, switch or movement detector for activating the drive unit.
The activation device is located within the room enclosed by the door.
Activation function in the AUTOMATIC and EXIT ONLY modes of operation.
The activation device does not have any function in the NIGHT/OFF mode of operation.
Activation device outside (KA) Push button, switch or movement detector for activating the drive unit.
The activation device is located outside the room enclosed by the door.
Activation function in the AUTOMATIC mode of operation. The activation device does
not have any function in the EXIT ONLY and NIGHT/OFF modes of operation.
Activation device
authorised (KB)
Access control function (for example key switch or card reader) used by authorised
persons to activate the drive unit.
The activation function is active in the AUTOMATIC, EXIT ONLY and NIGHT/OFF modes
of operation.
Activation device with current
impulse function
Push button for opening and closing the door. Activation function only in the AUTO-
MATIC and EXIT ONLY modes of operation. The door is opened automatically when
the button is rst pressed and closed again automatically when the button is pressed
the second time. The function can be activated during commissioning by parameter
setting using the display programme switch, ST 220 or GEZEconnects. If the activation
device is connected to the passive leaf control unit by means of the “current impulse”
function, both door leaves open when activated, even when the passive leaf control
system is deactivated.
Push&Go When the door is pressed manually out of the closing position with an activated Push
& Go function in the AUTOMATIC mode of operation, the door opens automatically
as soon as a specic adjustable opening angle is exceeded.
Opening safety sensor (SIO) Presence detector (e.g. active infrared light sensor) for protecting the swivelling range
of the door in the opening direction. As a rule the sensor is located on the hinge side
of the door on the door leaf.
Closing safety sensor (SIS) Presence detector (for example active infrared light sensor) for protecting the swiv-
elling range of the door in the closing direction. As a rule the sensor is located on the
opposite hinge side of the door leaf.
Emergency stop button Self-locking switch with which immediate stopping of the drive unit can be triggered
in case of danger. The drive unit remains in its current position until the user unlocks
the emergency stop switch again, thus terminating the emergency stop situation.
Low-energy function The Slimdrive EMD can be used as a low-energy drive.
In low-energy function the force needed for opening and closing the door is reduced
to 67N and the opening and closing time is reduced. This lowers the danger of a per-
son bumping into the moving leaf.
If people who are particularly vulnerable pass through the door, special measures must
be taken to eliminate the contact hazard (e.g. use of open/closing safety sensors).

Slimdrive EMD/EMD-F
5
Introduction
Term Explanation
Closing sequence control Electrical closing sequence control
In normal operation of double leaf drive units, the closing sequence of the door leaves
is controlled by the control units of the drive units, with the passive leaf being closed
rst. The active leaf remains in the open position until the passive leaf has reached the
closed position, then the active leaf begins to close.
Integrated closing sequence control (-IS)
In the event of a power failure, the closing sequence is controlled mechanically on double
leaf door systems with Slimdrive EMD-F-IS. The door leaves are closed by means of the
power storage device of the drives, with the active leaf being kept open by the integrat-
ed mechanical closing sequence control. When the passive leaf has reached the closing
position, it releases the active leaf by means of the mechanical elements of the integrated
closing sequence control so that it can also close completely.
Electric strike Fail-secure electric strike
Available as AC or DC electric strike version. When the drive unit is activated, the elec-
tric strike is switched on by the control unit of the drive unit provided the door
is in the closing position. The electric strike remains activated until the door has left
the closing position.
Fail-safe electric strike
DC electric strike version. The electric strike is switched o when the drive unit is acti-
vated provided the door is in the closing position. The electric strike remains switched
o until the door has left the closing position.
Bolt feedback The bolt feedback function is a contact integrated in the lock latch that is activated
when the door is locked mechanically by the tie bolt of the door lock. It signals to the
control unit that the door is locked mechanically and can therefore not be opened
by the drive unit. In this case the control unit ignores the control commands of all the
activation devices.
Reset Push button for restarting the drive after the operating voltage has been switched
on or after a re alarm has been terminated. When the push button is pressed, the
latching integrated in the drive is activated, causing the drive to be switched on.
Latching function When the door is closed in a de-energised state, the door leaf is impeded by the lock
latch of the electric strike. To make sure the door can pass the lock latch safely during
closing, an integrated limit switch is activated in the drive once a specic opening an-
gle has been reached, reducing the braking strength. The door accelerates and closes
into the lock at increased speed. In an energised state, this function is regulated by the
drive control unit.
Door closer mode In automatic mode (normal operation) the automatic swing door drive can behave like
a door closer. This means that closing is torque-controlled. This closing torque can
be adjusted and adapted to the respective passage situation.
Servo operation If servo operation is used, the swing door drive supports manual opening through
moment of force. The support torque and the support period can be set for this support.

Slimdrive EMD/EMD-F
6
Fundamental safety precautions
2 Fundamental safety precautions
For the user
Carefully read and abide by this user manual before commissioning the door. Always observe the following
safety instructions:
àOperating, maintenance and repair conditions specied by GEZE must be observed.
àThe commissioning, mandatory installation, maintenance and repair work must be performed by experts
authorised by GEZE.
àThe connection to the mains voltage must be made by a professional electrician.
àNo changes may be made to the system without prior agreement from GEZE.
àGEZE shall assume no liability for damage caused by unauthorised changes to the system.
àThe owner is responsible for safe operation of the system.
àHave a service technician check the safe operation of the system at regular intervals.
àShould safety devices be misaligned, thus preventing them from fullling their intended purpose, further
operation is not permissible. The service technician must be informed without delay.
àMake sure that the safety stickers are attached visibly to any glass leaves and are in a legible state.
àProtect the programme switch against unauthorised access.
àDanger of injury by sharp edges on the drive when removing the weather hood
àDanger of injury by parts hanging down
àThis appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory
or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards involved.
àChildren shall not play with the appliance.
àCleaning and user maintenance shall not be made by children without supervision.
For the service technician
àGEZE does not accept any warranty for combinations with third-party products.
àOnly combine third-party products with original parts following agreement by GEZE. Furthermore, only origi-
nal GEZE parts may be used for repair and maintenance work.
àThe power connection and protective earth conductor test must be carried out in accordance DIN VDE 0100-610.
àUse an on-site automatic cut-out as the line-side disconnecting device, the dimensioning of which is matched
to the type, cross-section, type of routing and ambient conditions of the on-site power supply circuit. The
automatic cut-out must have at least 4A and max. 16A.

Slimdrive EMD/EMD-F
7
Description
3 Description
3.1 Types of installation and versions
àThe drive unit can be mounted in transom installation on the lintel or in door leaf in door leaf installation.
àThe drive unit is available as 1-leaf or 2-leaf version.
3.2 Structure
The door system shown is only a schematic diagram.
For technical reasons, we cannot show all of the possibilities here.
The operating elements can be arranged individually.
Example: Drive unit Slimdrive EMD-F, 1-leaf, transom installation
1 Drive unit
2 Link arm or lever
3 Smoke switch control unit 1)
4 Outside contact sensor (KA) (optional)
5 Mechanical contact (KB) (optional)
6 Smoke switch 1)
7 Contact sensor inside (KI) (optional)
8 Display programme switch (optional)
9 Key switch for enabling the
display programme switch (optional)
10 Emergency stop switch (optional)
11 Manual trigger switch “CLOSE DOOR” 1)
12 Electric strike (optional)
13 Door handle with door lock (on site)
14 inside
15 outside
16 Closing safety sensor (SIS) (optional)
17 Door transmission cable (optional)
18 Opening safety sensor (SIO) (optional)
19 Reset button
20 Internal programme switch
1) optional, in conjunction with Slimdrive EMD-F

Slimdrive EMD/EMD-F
8
Description
3.3 Overview of the modes of operation
The following modes of operation can be set on the Slimdrive EMD:
àAutomatic
àExit only
àHold open
àNight mode
àOFF
Mode of operation MPS/MPS-ST/
TPS*
DPS** Explanatory notes
Key Display
Automatic aU Door opens and closes again.
The inside and outside activation devices are active.
Refer also to Chapter 3.5.
àOpening of 2 leaves
When the keys are pressed simultaneously, the mode
of operation changes between 1-leaf opening and
2-leaf opening.
àOpening of 1 leaf On the DPS the LED is lit in 1-leaf operation.
Exit only ls Door only opens and closes if someone exits.
Only the inside activation devices are active.
Hold open DO Door remains open.
Night mode Na Door opens and closes only when activated using
the key switch The inside and outside activation
devices are inactive.
OFF OFF OFF Of Door is enabled and can be moved by hand. The
inside and outside activation devices are inactive.
* Mechanical programme switch MPS/mechanical programme switch with integrated key switch MPS-ST/keypad
programme switch TPS
** Display programme switch
3.4 Operating elements
The modes of operation can be set using the following operating elements:
àInternal programme switch (20) on the drive unit (see chapter 3.4.1)
àMechanical programme switch MPS with/without integrated key switch (optional) (see chapter 3.4.2)
àDisplay programme switch (optional) (see chapter 3.4.3)
àKeypad programme switch (optional) (see chapter 3.4.4)
3.4.1 Internal programme switch
The mode of operation on the drive unit can be selected using the internal
programme switch (20). The switch position indicates the current mode
of operation:
àSetting II aU Automatic
àSetting 0Na Night/O
àSetting IDO Hold open


Slimdrive EMD/EMD-F
9
Description
3.4.2 Mechanical programme switch MPS (optional)
àCan be connected additionally to the internal programme switch (20).
At the mechanical programme switch MPS, the mode of operation for
the system is selected and the corresponding programme is displayed.
The mechanical programme switch is accessible for everyone without
a key switch.
Mechanical programme switch MPS
With the mechanical programme switch MPS-ST, selection of the
modes of operation is disabled if the key provided has been removed.
Mechanical programme switch MPS-ST
with integrated key switch
3.4.3 Display programme switch DPS (option)
àCan be connected additionally to the internal programme switch (20).
If a dot appears on the bottom right-hand part of the display,
maintenance is due.
OFF
Display programme switch DPS
If a dot appears in the middle of the display, the door has not
yet been fully initialised after the mains voltage has been
switched on.
Initialisation is carried out automatically when the drive opens
and closes the door.
As an option, operation of the display programme switch can
be restricted by a key switch SCT.

Slimdrive EMD/EMD-F
10
Description
3.4.4 Keypad programme switch TPS (optional)
àCan be connected additionally to the internal programme switch (20).
àSetting of the mode of operation using the keypad programme switch is only possible when the internal pro-
gramme switch (20) is set to the 0position.
The system operating status is selected and the corresponding programme
is displayed at the keypad programme switch.
The keypad programme switch is accessible for everyone without a key
switch. If desired, an additional key switch can be used for blocking.
Keypad programme switch TPS
3.5 Door in normal operation
In normal operation, the door is automatically opened and closed.
What happens? What does the door do?
An activation device (push button, switch or movement
detector) is triggered.
Door opens, waits the hold-open time and then closes.
Closing safety sensor (SIS) is triggered when the door
is open (e.g. light switch).
Door remains open.
Closing safety sensor (SIS) is triggered while the door
is closing.
The door immediately opens again or stops depending on
the parameter setting.
Opening safety sensor (SIO) is triggered while door
is opening.
The door stops and remains in position until the end of
activation (door opens) or until the end of the hold-open
time (door closes).
Opening safety sensor (SIO) is triggered when the door
is closed.
Door remains closed.
A person moves toward the opened door and a move-
ment detector is activated.
Door remains open.
A person moves toward the closing door and a movement
detector is activated.
Door reopens immediately.
Door contacts an obstruction when opening. The opening
safety sensor has not been activated.
Door stops, waits and attempts again to move to the open
position at a reduced speed.
Then the door closes again.
Door contacts an obstruction when closing. The closing
safety sensor has not been activated.
Door reopens immediately, waits the hold-open time and
then closes at a reduced speed.
When door closer mode is used with the closing safety
sensor deactivated, the drive presses against the obstacle
with the force set.

Slimdrive EMD/EMD-F
11
Description
Additional door functions
Which switch/push button? What does the switch/push button do?
Emergency stop switch The door stops immediately (in every mode of operation)
and holds the position until the emergency stop switch
is unlocked.
Key switch of the display programme switch If a key switch is connected to the display programme
switch, the operation of the display programme switch
can be locked or released with it.
Activation device authorised (KB) (e.g. outside key switch) Door opens once and closes after the hold-open time. The
set mode of operation is retained.
Switch function The automated door can be activated using the switch
function.
Normal switch function:
àSwitch contact opens the door and the door remains
in the open position.
àSwitch contact closes the door.
Switch function with hold-open time:
àSwitch contact opens the door.
àSwitch contact closes the door or the door starts to close
after the hold-open time.
Double push button In the case of 2-leaf drives, a button with a double func-
tion can be connected via a push button for which param-
eters can be set. This means that 1-leaf or 2-leaf opening
is possible by pressing the push button.
If the push button is pressed once, only the active leaf
opens and closes after the hold-open time has expired.
If the button is pressed twice within 1.5 s, both leaves open
and close after the double leaf hold-open time has expired.
Emergency lock When the emergency lock is used, a switch can close the
1- or 2-leaf system immediately. The doors close with the
set force and without safety sensors and obstacle detec-
tion. There is an increased risk of injury.
WC control The door opens after the elbow switch on the outside
of the toilet has been pressed, and closes automatically
after the set hold-open time has passed.
When the push button is activated inside the toilet cabin,
the system is switched to the exit only mode of operation,
which means the outer push button no longer opens the
door. At the same time, the lights indicate that the toilet
is occupied.
The electric strike is supplied with current, preventing
manual opening of the door from outside.
Activating the “inner” push button again or through man-
ual opening from inside, the WC function (exit only mode
of operation) is cancelled and the drive switched back
to the automatic mode of operation.
The ‘occupied’ displays and lights go out.

Slimdrive EMD/EMD-F
12
Operation
4 Operation
The set parameters of the drive functions may only be modied by a service technician.
4.1 Selecting the mode of operation
4.1.1 Selecting the mode of operation at the mechanical programme switch
àThe internal programme switch (20) can be deactivated by a service technician.
àIn the 0programme switch setting the mode of operation can be changed using a connected display pro-
gramme switch (optional).
àIn the programme settings Iand II the display programme switch (optional) is used to display the mode
of operation set and to output fault messages.
XSet the internal programme switch (20) to the required position
(II, 0or I).

4.1.2 Selecting the mode of operation at the mechanical programme switch MPS
àSetting of the mode of operation using the mechanical programme switch is only possible when the internal
programme switch (20) is set to the 0position.
With the programme switch MPS
XTurn the rotary switch (21) to the required mode of operation.
The mode of operation is set.
21
Mechanical programme switch MPS

Slimdrive EMD/EMD-F
13
Operation
With the programme switch MPS-ST (key switch)
Operation of the mechanical programme switch MPS-ST is only possi-
ble with the supplied key (22).
XInsert the key (22) into the mechanical programme switch MPS-ST.
XTurn the key rotary switch (23) to the required mode of operation.
The mode of operation is set.
XRemove the key.
The mechanical programme switch MPS-ST locked.
 
Mechanical programme switch MPS-ST
with integrated key switch
4.1.3 Selecting the mode of operation using the display programme switch
àSetting of the mode of operation using the display programme switch is only possible when the internal pro-
gramme switch (20) is set to the 0position.
XTouch the required mode of operation on the display pro-
gramme switch.
The mode of operation is set and indicated on the display (24).
OFF
24
Display programme switch DPS
Enabling operation of the display programme switch with key switch SCT (optional)
XPress key switch SCT briey.
Operation of the display programme switch is enabled.
XPress key switch SCT briey again.
Operation of the display programme switch is disabled.
Fault messages on the display
If a fault occurs in the door system, it is displayed on the display programme switch about every 5seconds.
XRead o the number of the fault message, note it down and notify the service technician.

Slimdrive EMD/EMD-F
14
Operation
4.1.4 Selecting the mode of operation using the keypad programme switch
àSetting of the mode of operation using the keypad programme switch is only possible when the internal pro-
gramme switch (20) is set to the 0position.
XThe desired operating status is selected by pressing the
and keys.
The LED of the current operating state lights up.
When using a key switch:
XEnable by operating the key switch once briey.
Disable the operation of the keypad programme switch:
XActivate the key switch briey again.
Keypad programme switch TPS
Fault messages in the keypad programme switch
If a fault occurs in the system, this is indicated by at least 2 LEDs lighting up alternately with the current operating
status.
XRead o the light combination, note this down and inform a service technician.

Slimdrive EMD/EMD-F
15
Troubleshooting
5 Troubleshooting
Problem Cause Remedy
Door only opens and
closes slowly
Obstruction in travel path XRemove obstruction and check door leaf
for ease of movement
XHave the door close completely once;
door moves after obstruction at a safe
speed until the complete closing proce-
dure has been completed
Closing safety sensor (SIS) soiled XClean the closing safety sensor
XHave the door close completely once;
door moves after obstruction at a safe
speed until the complete closing proce-
dure has been completed
Closing safety sensor (SIS) misaligned
or defective
XNotify a service technician
Door opens and closes
constantly
Obstruction in travel path XClear the obstruction
Irradiation or reections, e.g. reective
oor, falling rain
XCheck detection area of movement
detector
Misaligned movement detector XCheck detection area of movement
detector
Door only opens a crack Obstruction in travel path XRemove obstruction and check door leaf
for ease of movement
Door does not open Obstruction in travel path XRemove obstruction and check door leaf
for ease of movement
Movement detector misaligned or defec-
tive (outside)
XCheck the movement detector, notify
a service technician if necessary
Emergency stop button activated XUnlock emergency stop button
“Night” mode of operation XSelect a dierent mode of operation
“Exit only” mode of operation XSelect “Automatic” mode of operation
Door locked mechanically XUnlock the door
Electric strike does not release XNotify a service technician
Fire alarm active (Slimdrive EMD-F only) XActivate reset button (19)
Drive defective XNotify a service technician
Door does not close
(After 4minutes of continu-
ous activation by the safety
sensor, the Slimdrive EMD/
Slimdrive EMD-F automati-
cally closes the door
in low-energy mode)
Closing safety sensor (SIS) soiled XClean the closing safety sensor (SIS)
Closing safety sensor (SIS) misaligned
or defective
XNotify a service technician
Obstruction in travel path XRemove obstruction and check door leaf
for ease of movement
Movement detector triggers constantly XCheck the movement detector, notify
a service technician if necessary
“Hold open” mode of operation XSelect a dierent mode of operation
Current impulse push button function
controls
XTerminate activation by pressing the push
button again
Display programme switch
cannot be operated
Display programme switch is disabled XActivate key switch for release
Display programme switch defective XNotify a service technician
Keypad programme switch
cannot be operated
Keypad programme switch is disabled XActivate key switch for release
Keypad programme switch is faulty XNotify a service technician
Display programme switch
displays 88
Connection between display programme
switch and control unit faulty
XNotify a service technician
Display programme switch or control unit
defective
XNotify a service technician
Display programme switch
without display
Power failure XCheck mains fuse
Connection between display programme
switch and control unit faulty
XNotify a service technician
Display programme switch or control unit
defective
XNotify a service technician

Slimdrive EMD/EMD-F
16
Troubleshooting
Problem Cause Remedy
Keypad programme switch
without display
Power failure XCheck mains fuse
Connection between keypad programme
switch and control unit faulty
XNotify a service technician
Keypad programme switch or control unit
defective
XNotify a service technician
Display of fault messages
on the display programme
switch
Fault in the door system XNote fault messages. Up to 10 dierent
fault messages can occur in succession. The
display changes about every 10seconds.
XNotify a service technician
Display of fault messages
on the keypad programme
switch
Fault in the door system XNote the LED combination.
XNotify a service technician.

Slimdrive EMD/EMD-F
17
Cleaning and maintenance
6 Cleaning and maintenance
6.1 Cleaning
CAUTION!
Danger of injury due to impact and crushing!
XSet the mode of operation to OFF.
XSecure door leaves against accidental movement before carrying out cleaning work.
What is to be cleaned? How is it to be cleaned?
Closing safety sensor (SIS) (e.g. light switch) XWipe with damp cloth
Glass surfaces XWipe with a cold vinegar/water mixture; then dry.
Stainless surfaces XWipe with soft cloth
Coated surfaces XWipe with water and soap
Anodised surfaces XWipe with non-alkaline potassium soap (pH value 5.5 … 7)
Display programme switch, keypad programme
switch, mechanical programme switch
XWipe with soft cloth. Do not use a cleaning agent
6.2 Maintenance
The owner must ensure that the system is working perfectly. To guarantee perfect operation, the door system
must be serviced regularly by a service technician.
Maintenance must be carried out at least once a year or according to the maintenance display on the display
programme switch.
Installation, maintenance and repair work must be performed by experts authorised by GEZE.
If a dot appears on the bottom right-hand part of the display, maintenance is due.
XNotify a service technician.
The maintenance display lights up after the specied calendar period or number of opening cycles, depending
on what occurs rst:
1 year or 500,000 cycles
GEZE oers maintenance contracts with the following services:
àCheck fastening elements for a rm t
àPerformance of miscellaneous adjustment work
àPerformance of operational checks
àCheck all the safety and control equipment of the door system
àLubricate all moving parts
6.3 Inspection by an expert
In compliance with the “Guidelines for windows, doors and gates” (ASR A1.7 and GUV 16.10) Section 6, power-op-
erated doors must be inspected for safety by an expert before initial commissioning and at least once a year.
GEZE oers the following services:
Inspection and operational checks of all safety and control equipment in compliance with the requirements
in the test log for power-operated windows, doors and gates; Sliding doors and sliding gates ZH 1/580.2 edition.

Slimdrive EMD/EMD-F
18
Technical data
7 Technical data
Opening speed: 0°/s … 33°/s
Closing speed: 0°/s … 33°/s
Electrical connection values: 230 V; 50 Hz pursuant to DIN IEC 38
Connected load: max. 300 W Capacity rating 230 W
Protection: Mains connection 230 V: on site 4 A to 16 A
Current consumption for external devices: 24 V DC connection; max. 1000 mA
Temperature range: –15°C to +50°C; for dry rooms only
IP rating: IP 20

Slimdrive EMD/EMD-F
19

Germany
GEZE GmbH
Niederlassung Süd-West
Tel. [phone]
E-Mail: [email protected]om
GEZE GmbH
Niederlassung Süd-Ost
Tel. [phone]
E-Mail: [email protected]
GEZE GmbH
Niederlassung Ost
Tel. [phone]
E-Mail: [email protected]
GEZE GmbH
Niederlassung Mitte/Luxemburg
Tel. [phone]
E-Mail: frankfur[email protected]
GEZE GmbH
Niederlassung West
Tel. [phone]
E-Mail: [e-mail]
GEZE GmbH
Niederlassung Nord
Tel. [phone]
E-Mail: [e-mail]
GEZE Service GmbH
Tel. [phone]
E-Mail: [e-mail]
Austria
GEZE Austria
E-Mail: [e-mail]
www.geze.at
Baltic States
Lithuania / Latvia / Estonia
E-Mail: [email protected]
Benelux
GEZE Benelux B.V.
E-Mail: [e-mail]
www.geze.be
www.geze.nl
Bulgaria
GEZE Bulgaria - Trade
E-Mail: o[email protected]om
www.geze.bg
China
GEZE Industries (Tianjin) Co., Ltd.
E-Mail: [e-mail]
www.geze.com.cn
GEZE Industries (Tianjin) Co., Ltd.
Branch Oce Shanghai
E-Mail: [e-mail]
www.geze.com.cn
GEZE Industries (Tianjin) Co., Ltd.
Branch Oce Guangzhou
E-Mail: [e-mail]
www.geze.com.cn
GEZE Industries (Tianjin) Co., Ltd.
Branch Oce Beijing
E-Mail: [e-mail]
www.geze.com.cn
France
GEZE France S.A.R.L.
E-Mail: [e-mail]
www.geze.fr
Hungary
GEZE Hungary Kft.
E-Mail: oce-hungar[email protected]
www.geze.hu
Iberia
GEZE Iberia S.R.L.
E-Mail: [email protected]
www.geze.es
India
GEZE India Private Ltd.
E-Mail: o[e-mail]
www.geze.in
Italy
GEZE Italia S.r.l
E-Mail: [e-mail]
www.geze.it
GEZE Engineering Roma S.r.l
E-Mail: [e-mail]
www.geze.it
Korea
GEZE Korea Ltd.
E-Mail: [e-mail]
www.geze.com
Poland
GEZE Polska Sp.z o.o.
E-Mail: gez[email protected]om
www.geze.pl
Romania
GEZE Romania S.R.L.
E-Mail: o[e-mail]
www.geze.ro
Russia
OOO GEZE RUS
E-Mail: o[e-mail]
www.geze.ru
Scandinavia – Sweden
GEZE Scandinavia AB
E-Mail: [email protected]
www.geze.se
Scandinavia – Norway
GEZE Scandinavia AB avd. Norge
E-Mail: [email protected]om
www.geze.no
Scandinavia – Denmark
GEZE Danmark
E-Mail: [e-mail]
www.geze.dk
Singapore
GEZE (Asia Pacic) Pte, Ltd.
E-Mail: [e-mail]
www.geze.com
South Africa
GEZE South Africa (Pty) Ltd.
E-Mail: [e-mail]
www.geze.co.za
Switzerland
GEZE Schweiz AG
E-Mail: sch[email protected]om
www.geze.ch
Turkey
GEZE Kapı ve Pencere Sistemleri
E-Mail: o[e-mail]
www.geze.com
Ukraine
LLC GEZE Ukraine
E-Mail: o[e-mail]
www.geze.ua
United Arab Emirates/GCC
GEZE Middle East
E-Mail: gez[email protected]om
www.geze.ae
United Kingdom
GEZE UK Ltd.
E-Mail: [email protected]
www.geze.com
GEZE GmbH
Reinhold-Vöster-Straße 21–29
71229 Leonberg
Germany
Tel.: [phone]
Fax.: [phone]
www.geze.com
