1. Summary
GD32130C-START-V1.1 board uses GD32F130C8T6 as the main controller. As a complete
development platform of GD32F1x0 powered by ARM® Cortex™-M3 core, the board
supports full range of peripherals. It uses mini-USB interface to supply 3.3V power. SWD,
Reset, Boot, User button key, LED and Extension Pin are also included. This document
details its hardware schematic and the relevant applications.
2. Function Pin Assign
Table 2-1 Pin assignment
Function
Pin
Description
LED
PF6
LED1
PF7
LED2
KEY
PA0
K1-User Key
RESET
K2-Reset
3. Getting started
The START Board uses mini-USB connecter to get power, the hardware system power is
+3.3V. A mini-USB cable are necessary to down programs. Select the correct boot mode and
then power on, the LED3 will turn on, which indicates the power supply is ready.
There are Keil version and IAR version of all projects. Keil version of the projects are created
based on Keil MDK-ARM 4.74 uVision4. IAR version of the projects are created based on
IAR Embedded Workbench for ARM 7.40.2. During use, the following points should be
noted:
1. If you use Keil uVision4 to open the project, install the GD32F1x0_AddOn.3.2.0.exe to
load the associated files.
2. If you use Keil uVision5 to open the project, there are two ways to solve the "Device
Missing (s)" problem. One is to install GigaDevice.GD32F1x0_DFP.3.2.0.pack. In Project
menu, select the Manage sub menu, click on the “Version Migrate 5 Format...” menu, the Keil
uVision4 project will be converted to Keil uVision5 project. Then add “C:\Keil_v5\ARM\Pack
\ARM\CMSIS\4.2.0\CMSIS\Include” to C/C++ in Option for Target. The other is to install
Addon directly. Select the installation directory of Keil uVision5 software, such as C:\Keil_v5,
in Destination Folder of Folder Selection. Select the corresponding device in Device of
Option for Target and add “C:\Keil_v5\ARM\Pack\ARM\CMSIS\4.2.0\CMSIS\Include” to
C/C++ in Option for Target.
3. If you use IAR to open the project, install IAR_GD32F1x0_ADDON.3.2.0.exe to load the
associated files.

User Guide
GD32130C-START
5 /11
4. Hardware layout overview
4.1. Power supply
Figure 4-1 Schematic diagram of power supply
G
1
Vout 2
Vin
34
U2 LM1117-3.3
E1
16V/10uF,AVX
E2
16V/10uF,AVX
GND
C11
50V/0.1uF
+3V3
LED3
LED0603
R9
470Ω
1
TP1
TP +3V3
+U5V P1
SMD1210P005TF
4.2. Boot option
Figure 4-2 Schematic diagram of boot option
R7
10KΩ
1
2
3
JP4
BOOT0
GND BOOT0
+3V3
Table 4-1 Boot configuration
BOOT1
BOOT0
Boot Mode
Default
2-3
User memory
1-2
System memory
Changed by ISP
1-2
SRAM memory
4.3. LED
Figure 4-3 Schematic diagram of LED function
PF6LED1
LED0603
LED
R2
680ΩGND
PF7LED2
LED0603
R3
680ΩGND

User Guide
GD32130C-START
6 /11
4.4. KEY
Figure 4-4 Schematic diagram of Key function
PA0
R1
10KΩ
+3V3
GND
C1
50V/0.1uF
KEY
K1
K-1102B
4.5. GD-Link
Figure 4-5 Schematic diagram of GD-Link function
L_USB_Ctr
C100
50V/20pF
C102
50V/20pF
Y101
HC-49S-8MHz
GND
L_NRST
+3V3
GND
R102
10KΩ
C103
50V/0.1uF
R104
10KΩ
GND
C105
50V/0.1uF
C106
50V/0.1uF
C107
50V/0.1uF
C108
50V/0.1uF
R101
1MΩ
L_OSC_IN
L_OSC_OUT
L_OSC_IN
L_OSC_OUT
L_NRST
GND
+3V3
GND
1
2
3
4
JP100
4×1P2.54
+3V3
GND
MCU SWD
Reset
L_TMS/IO
L_TDI
L_TDO/SWO
L_TCK/CLK
L_USB_DP
L_SWDIO
L_SWDCK
L_SWDIO
L_SWDCK
+3V3
L_USB_DM
BOOT0
44
NRST
7
OSC_IN/PD0
5
OSC_OUT/PD1
6
PA0-WKUP
10
PA1
11
PA2
12
PA3
13
PA4
14
PA5
15
PA6
16
PA7
17
PA8
29
PA9
30
PA10
31
PA11
32
PA12
33
PA13/JTMS/SWDIO
34
PA14/JTCK/SWCLK
37
PA15/JTDI
38
PB018
PB119
PB2/BOOT1 20
PB3/JTDO 39
PB4/JNTRST 40
PB541
PB642
PB743
PB845
PB946
PB10 21
PB11 22
PB12 25
PB13 26
PB14 27
PB15 28
PC13-TAMPER-RTC 2
PC14-OSC32_IN 3
PC15-OSC32_OUT 4
VBAT
1
VDD_1
24
VDD_2
36
VDD_3
48
VDDA
9
VSS_1 23
VSS_2 35
VSS_3 47
VSSA 8
U0
GD32F103C8T6
L_TReset
L_LED1
L_LED2
L_LED1 LED0603
L_LED2 LED0603
R103
10KΩGND
R109 1KΩ
R110 1KΩGND
GND
R105 22R
R106 22R
R108
1MΩC104
50V/4700pF
L_USB_DM
L_USB_DP
GND
R107 1.5KΩL_USB_Ctr
VCC 1
D- 2
D+ 3
ID 4
GND 5
SHELL 6
CN100
Mini_USB
+U5VC10
50V/0.1uF

User Guide
GD32130C-START
7 /11
4.6. Extension
Figure 4-6 Schematic diagram of Extension Pin
Extension Pin
PA4
PA5PA6
PA7
PB12 PB13
PB14 PB15
PB10 PB11
PA1
PB1PB0
PA3PA2
PC13
PB5PB6
PB7
PA9
PA10
PB8
PB9
PA15
PB3
PA13
PA14 PB4
PA8PA0
PB2
PF6PF7
1 2
3 4
5 6
7 8
910
11 12
13 14
15 16
17 18
19 20
JP1
10×2P2.54
1 2
3 4
5 6
7 8
910
11 12
13 14
15 16
17 18
19 20
JP2
10×2P2.54
GND +3V3 +3V3 GND
PA11
PA12
4.7. MCU
Figure 4-7 Schematic diagram of MCU Pin
PA4
PA5
PA6
PA7
PA0
PA1
PA3
PA2
PA11
PA12
PA9
PA10
PA8
PB5
PB6
PB7
PB1
PB0
PB12
PB13
PB14
PB15
PB10
PB11
PB8
PB9
PC13
BOOT0
OSC32_IN
OSC32_OUT
OSC_IN
OSC_OUT
GND
NRST
PA13
PA14
PA15
PB2
PB3
PB4
+3V3
SWCLK
SWDAT
PF6
PF7
SP1
Short
BOOT0
44
NRST
7
OSC_IN/PF0
5
OSC_OUT/PF1
6
PA0-WKUP
10
PA1
11
PA2
12
PA3
13
PA4
14
PA5
15
PA6
16
PA7
17
PA8
29
PA9
30
PA10
31
PA11
32
PA12
33
PA13/SWDAT
34
PA14/SWCLK
37
PA15
38
PB018
PB119
PB220
PB339
PB440
PB541
PB642
PB743
PB845
PB946
PB10 21
PB11 22
PB12 25
PB13 26
PB14 27
PB15 28
PC13-TAMPER-RTC 2
PC14-OSC32_IN 3
PC15-OSC32_OUT 4
VBAT
1
VDD_1
24
PF736
VDD_2
48
VDDA
9
VSS_1 23
PF635
VSS_2 47
VSSA 8
U1
GD32F130C8T6

User Guide
GD32130C-START
8 /11
5. Routine use guide
5.1. GPIO_Running_LED
5.1.1. DEMO purpose
This Demo includes the following functions of GD32 MCU:
Learn to use GPIO for controlling the LED
Learn to use SysTick to generate 1ms delay
GD32130C-START-V1.1 board has two LEDs. The LED1 and LED2 are controlled by GPIO.
This demo will show how to light the LED.
5.1.2. DEMO running Result
Download the program <01_GPIO_Running_LED> to the board, the states of LED1 and
LED2 are toggled every 200ms.
5.2. GPIO_Key_Polling_mode
5.2.1. DEMO purpose
This Demo includes the following functions of GD32 MCU:
Learn to use GPIO control the LED and the KEY
Learn to use SysTick to generate 1ms delay
GD32130C-START-V1.1 board has two keys and two LEDs. The two keys are Reset key and
User key. The LED1 and LED2 are controlled by GPIO.
This demo will show how to use the User key to control the LED2. When press down the
User Key, it will check the input value of the IO port. If the value is 0, wait for 100ms. Then
check the input value of the IO port again. If the value is still 0, indicates that the button is
pressed down successfully, and light the LED2.
5.2.2. DEMO running Result
Download the program <02_GPIO_Key_Polling_mode> to the board, first of all, all the LEDs
will be flashed once for test. Then press down the User Key, LED1 will be turned on. Press
down the User Key again, LED1 will be turned off.

User Guide
GD32130C-START
9 /11
5.3. EXTI_Key_Interrupt_mode
5.3.1. DEMO purpose
This Demo includes the following functions of GD32 MCU:
Learn to use GPIO to control the LED and the KEY
Learn to use EXTI to generate external interrupt
GD32130C-START-V1.1 board has two keys and two LEDs. The two keys are Reset key and
User key. The LED1 and LED2 are controlled by GPIO.
This demo will show how to use EXTI interrupt line to control the LED2. When press down
the User Key, it will produce an interrupt. In the interrupt service function, the demo will
toggle LED2
5.3.2. DEMO running Result
Download the program <03_EXTI_Key_Interrupt_mode> to the board, first of all, all the
LEDs will be flashed once for test. Then press down the User Key, LED1 will be turned on.
Press down the User Key again, LED1 will be turned off.
5.4. TIMER_Key_EXTI
5.4.1. DEMO purpose
This demo includes the following functions of GD32 MCU:
Learn to use GPIO control the LED and the KEY
Learn to use EXTI to generate external interrupt
Learn to use TIMER to generate PWM
GD32130C-START-V1.1 board has two keys and two LEDs. The two keys are Reset key and
User key. The LED1 and LED2 are controlled by GPIO.
This demo will show how to use the TIMER PWM to trigger EXTI interrupt to toggle the state
of LED2 and EXTI interrupt line to control the LED1. When press down the User Key, it will
produce an interrupt. In the interrupt service function, the demo will toggle LED1.
5.4.2. DEMO running result
Download the program < 04_TIMER_Key_EXTI > to the START board, all the LEDs are
flashed once for test, press down the User Key, LED1 will be turned on. Press down the User
Key again, LED1 will be turned off. Connect PA6 (TIMER2_CH0) and PF7 with DuPont line.
The LED2 will be toggled every 500ms.

User Guide
GD32130C-START
10 /11
6. Revision history
Table 6-1 Revision history
Revision No.
Description
Date
1.0
Initial Release
Jun.28, 2017
2.0
Updated format across the whole document
Jun.1, 2019
3.0
Updated format across the whole document
Nov.20, 2019

User Guide
GD32130C-START
11 /11
Important Notice
This document is the property of GigaDevice Semiconductor Inc. and its subsidiaries (the "Company"). This document, including any
product of the Company described in this document (the “Product”), is owned by the Company under the intellectual property laws and
treaties of the People’s Republic of China and other jurisdictions worldwide. The Company reserves all rights under such laws and
treaties and does not grant any license under its patents, copyrights, trademarks, or other intellectual property rights. The names and
brands of third party referred thereto (if any) are the property of their respective owner and referred to for identification purposes only.
The Company makes no warranty of any kind, express or implied, with regard to this document or any Product, including, but not
limited to, the implied warranties of merchantability and fitness for a particular purpose. The Company does not assume any liability
arising out of the application or use of any Product described in this document. Any information provided in this document is provided
only for reference purposes. It is the responsibility of the user of this document to properly design, program, and test the functionality
and safety of any application made of this information and any resulting product. Except for customized products which has been
expressly identified in the applicable agreement, the Products are designed, developed, and/or manufactured for ordinary business,
industrial, personal, and/or household applications only. The Products are not designed, intended, or authorized for use as
components in systems designed or intended for the operation of weapons, weapons systems, nuclear installations, atomic energy
control instruments, combustion control instruments, airplane or spaceship instruments, transportation instruments, traffic signal
instruments, life-support devices or systems, other medical devices or systems (including resuscitation equipment and surgical
implants), pollution control or hazardous substances management, or other uses where the failure of the device or Product could
cause personal injury, death, property or environmental damage ("Unintended Uses"). Customers shall take any and all actions to
ensure using and selling the Products in accordance with the applicable laws and regulations. The Company is not liable, in whole or
in part, and customers shall and hereby do release the Company as well as it’s suppliers and/or distributors from any claim, damage,
or other liability arising from or related to all Unintended Uses of the Products. Customers shall indemnify and hold the Company as
well as it’s suppliers and/or distributors harmless from and against all claims, costs, damages, and other liabilities, including claims for
personal injury or death, arising from or related to any Unintended Uses of the Products.
Information in this document is provided solely in connection with the Products. The Company reserves the right to make changes,
corrections, modifications or improvements to this document and Products and services described herein at any time, without notice.
© 2019 GigaDevice –All rights reserved
