Gilson CENTRY 103 Minicentrifuge User manual

Quick Guide
EN
3
1
2
DESCRIPTION PART NUMBER
CENTRY 103 Minicentrifuge F110736
8
10
4
567
9
12
14
13
11
15
1Lid
2Chamber
3Motor shaft boss
4Power indicator light
5Main power switch
6AC adapter connector
7Battery compartment
4 AA size / LR6, alkaline
batteries (1.5V)
8Rotor for microtubes:
2.0 mL x 8 microtubes or 1.5 mL x 8 microtubes
9Rotor for Tube–strips:
2 lines of 0.2 mL x 8 connected microtubes
10 AC adapter
Input voltage: AC 100–240V, 50/60 Hz
11 Type C (EU)
12 Type A (Japan/USA)
13 Type A (China)
14 Type G (UK)
15 Type I (Australia)
Parts Checklist
Figure 1
CENTRYTM 103 Minicentrifuge components
CENTRY™ 103 Minicentrifug
e

2QUICK GUIDE | CENTRYTM 103 MINICENTRIFUGE
Operation
Installing
• Place the Minicentrifuge on a flat and level surface such as a laboratory bench.
• The place must be well ventilated and free of direct sunlight.
• Avoid installing the Minicentrifuge on a slippery surface or surface prone to vibration.
Do not install the instrument in facilities that store chemicals which could generate
flammable gases or fumes.
Connecting to the Power Source and Turning On
1. Connect the type of plug 11 , 12 , 13 , 14 , or 15 compatible with the local power socket to the
AC adapter 10 (Refer to Figure 1).
Only use the AC adapter provided with this product. It may cause fire or electrical shock.
2. Insert the other end of the AC adapter 10 into the connector 6on the back of the
Minicentrifuge and connect the plug to the power source.
3. To open the lid, lightly push down on the lid to release the lock.
CAUTION
If the power switch is turned on while the lid is closed, the rotor will start spinning
immediately, which may cause damage to the Minicentrifuge.
4. Press the main power switch 5to its ON position (“I” side) to turn the unit on. The power
indicator red light turns on.
Installing the Rotor
Before the initial use, turn the rotor slowly by hand, five to six revolutions.
1. Install the rotor 8or 9onto the motor shaft boss 3.
2. Push down until it clicks (Refer to Figure 2). Make sure that the tabs of the boss are blocked
inside the hole of the rotor.
For dismounting the rotor, hold it by both hands and push the tabs inward with two thumbs to
disconnect them from the rotor, then pull the rotor out from the motor shaft boss.
Do not use any damaged, deformed, or corroded rotors. It may break the rotor while
spinning and cause unexpected accidents or injury.
Figure 4
Balanced rotor with
2 Tube-strips
Figure 3
Balanced sample microtubes setting
Figure 2
Install the rotor onto the motor shaft boss
3
8
9

3
CENTRYTM 103 MINICENTRIFUGE |QUICK GUIDE
Preparing the Microtubes
• Prepare the microtubes that are compatible with the rotor in use.
Do not use the instrument to centrifuge explosive or flamable samples. It may cause
fatal or serious accidents. The instrument does not provide adequate protection against
explosion or ignition.
Do not use the instrument to centrifuge infectious samples. It may cause a serious hazard
to laboratory personnel. The instrument is not a biohazard safety model. If there is the need
of handling any potentially infectious or radioactive samples, or other hazardous materials,
implement appropriate safety measures.
• Load the microtubes in the rotor symmetrically. Always ensure that the microtubes are
appropriately balanced, as described in Figures 3 and 4 on page 2 (black circles indicate
dierent possible tube placement).
NOTICE
Imbalanced loads will significantly reduce the life of the motor and Minicentrifuge.
In severe cases, imbalances may damage the Minicentrifuge and injure the operator.
CAUTION
Do not overfill microtubes. The sample volume should not exceed 70% of the maximum allowable
volume of the tube in use. The sample may spill during run and damage the Minicentrifuge.
Always use cap centrifuge microtubes. The sample may spill during run.
Starting and Ending Operation
• By closing the lid 1, the rotor instantly starts spinning. After six minutes of spinning,
the rotor will automatically decelerate to a stop.
Ensure that there is no foreign material in the rotor or in the chamber before operating
the instrument. It may break a sample during spinning and the broken pieces may scatter,
resulting in a serious accident.
• For ending the operation, lightly press down on the lid 1. The rotor will start decelerating
and the lid will lift automatically.
• The operation ends when the rotor is completely stopped, and the sample tubes can be
unloaded.
Never open the lid while the rotor is spinning. Accidental contact with the spinning rotor
may cause a serious injury.
Using Batteries
The instrument can be operated using battery power when there is no power supply available.
• Install four AA (LR6, 1.5V) alkaline batteries from the same brand in the battery
compartment 7(Refer to Figure 1 on the first page).
• The AC adapter is given first priority if connected.
Do not mix batteries by age or by brand type. The battery may cause heating, leakage, or
explosion and could result in damage to the instrument or personal injury. When leaving the
instrument out of use for a long period of time, be sure to remove the batteries for safety.
The battery may cause leakage and could result in damage to the instrument or personal injury.
Do not attempt to replace the batteries immediately after use, touching them could result in burns.

Specifications subject to change without notification — errors excepted. Reproduction,
adaptation, or translation without prior written permission is prohibited, except as
allowed under copyright laws.
www.gilson.com/contactus
LT801605/A | ©2018 Gilson, Inc. All rights reserved.
Routine Maintenance
For routine maintenance, please refer to the User’s Guide CENTRY
TM
103 Minicentrifuge
LT801606, which can be consulted and downloaded from our website www.gilson.com
Unplug the instrument before performing maintenance procedures. It may cause a
serious electrical shock.
Cleaning and Disinfecting
For cleaning the Minicentrifuge, wipe the unit with a soft cloth moistened with a neutral
detergent. The unit can be disinfected with ethanol.
Inspecting and Maintening
• Check the rotor, main body, and lid for damage, deformation, and corrosion.
• Check the lid to make sure it opens and closes smoothly. Press down on the lid to
make sure it is locked into place.
• Slowly rotate the rotor by hand to make sure it rotates smoothly and does not contact
any other component.
• Operate the centrifuge with no microtubes in the rotor and make sure it is running
safely without excessive vibration.
• Check the brake for wear. Verify if it takes an abnormally long time for the rotor to
come to a complete stop or if it takes longer to stop than it used to.
• Check the AC adapter for damage, cracks, or broken cable.
Inspection is recommended to be performed on a monthly basis.
Ordering Information
Spare parts
Warranty
Gilson warrants the CENTRY 103 Minicentrifuge against defects in material under normal
use and service for 12 months from the date of purchase. This warranty is valid only if the
instrument is used in the manner described in this guide and for the purpose for which it is
designed. Gilson is not responsible for consequential damages resulting from the misuse or
bad cleaning or decontamination of this instrument. Should warranty service be required,
repair or replacement will be provided by your local Gilson service center. Freight shipping
the unit to Gilson will be the responsibility of the purchaser.
DESCRIPTION PART NUMBER
CENTRY 103 ROTOR 8 TUBES 1.5-2.0 mL F1077310
CENTRY 103 ROTOR 2 TUBE-STRIPS 8 X 0.2 mL F1077311
CENTRY 103 MOTOR SHAFT BOSS F1077312
CENTRY 103 AC ADAPTER WITH 5 PLUGS F1077313
DESCRIPTION PART NUMBER
CENTRY 103 Minicentrifuge F110736
