Hanil Component R12 User manual

Operation Manual
Component R12
Large Capacity Centrifuge
Product Model Name :
Date of Purchase :

Component R12
Research Use Only
© 2018 Hanil Scienti󽗉c Inc.
If you have any questions, contact our Technical Support Center.
[phone] / [email protected]om
www.ihanil.com
The appearance or speci󽗉cations of the device is subject to partial change for improvement.

INDEX
1. General Considerations ----------------------------------------------------- 4
1.1 Safety -4
1.2 Transport & Storage - 5
1.3 Safety label on the Device - 5
1.4 Electric safety - 5
2. Product Description ---------------------------------------------------------- 6
2.1 Structure - 6
2.2 Delivery package - 6
2.3 Technical Speci󽗉cations - 7
3. Installation ---------------------------------------------------------------------- 8
3.1 Packing Inspection- 8
3.2 Installation - 8
3.3 Power Connection - 10
3.4 Opening/Closing the Lid - 10
3.5 Using the Rotor - 11
3.6 Loading the Blood Bags - 12
4. Operation ----------------------------------------------------------------------- 13
4.1 Control Panel - 13
4.2 Setting Speed - 14
4.3 Setting Run Time - 15
4.4 Setting Temperature - 15
4.5 Setting Temperature Limit - 15
4.6 Setting Acceleration/Deceleration - 16
4.7 Saving/Calling up a Program - 16
4.8 Start/Stop a Run - 17
4.9 Verifying the Setting value - 17
5. Maintenance ------------------------------------------------------------------- 18
5.1 Care Instructions - 18
5.2 Cleaning - 18
5.3 Care Instructions for Refrigerated device - 19
6. Troubleshooting -------------------------------------------------------------- 20
6.1 Possible Problems - 20
6.2 Error Messages - 21
6.3 Emergency Lid Open - 22
7. Rotor ----------------------------------------------------------------------------- 23
The appearance or speci󽗉cations of the device is subject to partial change for improvement.

www.ihanil.com
4/23
1. General Considerations
Follow precautions and all the safety requirements described on this user manual
to prevent any damage and failure of device and loss of lives.
1. The device should be installed on a 󽗊at surface to maintain level.
2. Check the voltage to be used, before connecting the device to the power source.
3. Only use rotors, parts, and accessories provided by Hanil Scienti󽗉c Inc.
Hanil Scienti󽗉c Inc. is not responsible for damages of the device and accidents caused by
using parts and accessories not recommended.
4. Do not exceed the maximum rated speed of the rotor or buckets in use.
5. Make sure to prepare necessary safety measures before using samples that are toxic or
radioactive samples or pathogenic or samples or infectious blood.
6. Substances that may generate volatile or explosive vapor can not be deviced.
7. The balancing work of samples should done in advance before operation.
8. To ensure safe use of the device, do not expose the device to strong acids, strong bases,
cesium, salt, or alkaline detergents.
8. If the device is contaminated by toxic or radioactive samples or infectious blood
samples, remove contaminants completely and take needful actions such as ventilation
or isolation of device.
9. Before operation, rotor and chamber should be dry.
10. Do not attempt to slow or stop the spinning rotor by hand.
11. Do not block vents.
12. When serving the device, be sure to remove contaminants in advance.
13. Please contact the place of purchase or Hanil Scienti󽗉c Inc. for product repairs.
14. According to IEC61010-2-020 maintain a 30cm “clearance envelope” around the
device while the rotor is spinning.
15. Turn the power switch o󽗈 after using the device.
16. Unplug the power plug before cleaning or left unused for a long period of time.
17. Don't lean against the device
1.1 Safety

Technical Support :[phone] / [email protected]om 5/23
1. General Considerations
1. It is recommended that switchgear or circuit breaker and overcurrent protection devices
should be installed near the device.
2. Use a power cord only provided with the device.
3. Do not use an extension cord.
4. Do not place anything on the powercable.
5. If you have the following emergencies, shut o󽗈 the power supply and unplug the
powercord from outlet and contact your place of purchase or Hanil Scienti󽗉c Inc.
- Unusual noises or smell from the equipment.
- Damage or wear of a power cord.
- Breakdown of circuit breaker, fuse or safety device.
- If you spill liquid on the equipment.
- If the equipment has been damaged.
1.2 Transport & Storage
1.3 Safety label on the Device
1.4 Electric safety
Insert the rotor and tubes symmetrically.
Firmly tighten the rotor door.
Watch your 󽗉gers when close the lid.
- The device and the accessories must only be stored in dry rooms.
- Only lift and transport the device with su󽗋cient number of helpers.
-Storage- -Transport-
Ambient temperature 5℃~40℃
Maximum relative humidity 30%~85%
Air pressure 500~1060hpa
Ambient temperature -10℃~40℃
Maximum relative humidity 10%~90%
Air pressure 500~1060hpa
Mark indicating danger
and warning.
Mark indicating a place in
danger of electric shock.
Mark indicating earth
grounding

www.ihanil.com
6/23
2. Product Description
2.1 Structure
- Component R12
- Operating manual
- T-wrench
- Leveler tool
- Rotors & Accessories on request
2.2 Delivery package
① Lid
② RPM measuring window
③ Control panel
④ Power switch key
⑤ Emergency Open Hole
①
③
④
⑤
②

Technical Support :[phone] / [email protected]om 7/23
2. Product Description
2.3 Technical Speci󽗉cations
Max. RPM
(Swing-out rotor) 4,500 rpm
Max. RCF
(Swing-out rotor) 6,491 xg
Time < 100 hr, continuous
Max. Capacity
(Swing-out rotor) 6 x 2,400 mL
Temperature range -10℃ to 40℃
ACC/DEC steps 10/10 steps
Program memory 100
Rotor Identi󽗉cation Automatic
Imbalance cuto󽗈 / tracking Yes
Noise level < 65 dB
Dimension (W x D x H, mm) 840 x 980 x 970
Weight without rotor 480 kg
Power requirement 3.0 kVA
Power input (V, Hz) 210~240V
50/60 Hz (110V, 50 Hz optional)
Cat. No. CP-R12

www.ihanil.com
8/23
3. Installation
3.1 Packing Inspection
3.2 Installation
3.2.1 Selecting the Location
▶ You can get contact details on the packing box or manual.
• Check packing conditions carefully, before unpacking.
• Contact Hanil Scienti󽗉c Inc. immediately if damages found.
• Check the delivery for completeness.
Installation on hard and 󽗊at ground.
• Centrifuge should be installed on hard and 󽗊at place.
• If the centrifuge is installed in an inclined place, the shaft may be bent
due to the weight of the rotor.
Good ventailation.
• For air circulation and safety, maintain a 30cm“clearance envelope”
around the centrifuge while the rotor is spinning.
Constant temperature/humidity
• Centrifuge equipped with the sensitive electronic software which is
fragile with humidity and temperature.
• Must avoid direct ray or heater and be put in the ambience of controlled
temp.and air.
Avoid the corrosive gas
• Install the centrifuge in a place where corrosive gas is not generated.
• Sulfur dioxide gas and chlorine gas may cause corrosion.
Leveling
• The device should be operated on a 󽗊at surface.
Use a leveler tool to check the device is level.

Technical Support :[phone] / [email protected]om 9/23
3. Installation
3.2 Installation
3.2.1 Leveling the Device
1. Place the device on a hard and 󽗊ate place.
· If the device is not installed horizontally, it may cause vibration, noise or
malfunction.
2. Put the leveler tool on the device.
2. Turn the leveling foot on the botton of the device to level the device.
▶ Adjust the leveling foot so that the bubble in the leveler tool is at the center of the line.
Leveling Foot
Bubble in the leveler tool is
at the center of the line.

www.ihanil.com
10/23
3. Installation
3.3 Power Connection
3.4 Opening/Closing the Lid
• Connect the device to voltage sources which correspond to the
electrical requirements on the label attached to the device.
• Only use a socket proviced Hanil Scienti󽗉c Inc.
• If the lid is not closed, the device does not operate.
1. You can choose a embedded socket or a movable socket
2. Switch the centrifuge on using the power switch key on the right side of the device.
Opening the lid
1. Press the Lid button
Closing the lid
1. Put both hands on the lid and close it with light force.

Technical Support :[phone] / [email protected]om 11/23
• Connect the device to voltage sources which correspond to the
electrical requirements on the label attached to the device.
• Only use a socket proviced Hanil Scienti󽗉c Inc.
This device dose not necessary to remove the rotor after use.
Do not disassemble the rotor by the user.
3. Installation
3.5 Using the Rotor
• Do not disassemble the rotor by user.

www.ihanil.com
12/23
3. Installation
3.6 Loading the Blood Bags
· This device is only for blood bag centrifugation.
· Only use accessories provided by Hanil Scienti󽗉c Inc.
1. Load the blood bags into the adaptors with no folds at the top or corners.
2. There are two holes in the each adaptor. Load one blood bag into each hole.
3. Make sure the loaded blood bag adaptors opposite each other on the
rotor are the same weight/volume.

Technical Support :[phone] / [email protected]om 13/23
4. Operation
4.1 Control Panel
Button Description
① Display - Indicate Speed/Time/Temperature/Acc.Dec.
② Speed - Press once : Setting the RPM / Press twice: Setting the RCF
③ Time - Setting run time
④ Temp - Setting temperature
⑤ Temp Limit - Setting temperature limit range
⑥ Numeric buttons - Enter a value using the numeric buttons
⑦ View Setting - Verifying the setting parameters during centrifugation
⑧ Enter - Setting acceleration step
⑨ Program Save - Saving a program
⑩ Program Call - Press the enter after setting the parameters
⑪ Rotor ID. - When rotor id is not identi󽗉ed automatically,
enter the rotor ID. manually
⑫ Deceleration(DEC) - Setting deceleration step
⑬ Acceleration(ACC) - Calling up a program-
⑭ Start - Starting centrifugation
⑮ Stop - Stopping centrifugation
⑯ Lid - Openg the lid
①
xg
Pulse
+
-
② ③ ④ ⑤ ⑥
⑥
⑦
①
⑯⑮⑭
⑯
② ③ ④ ⑤
⑧
⑨
⑩
⑪
⑫
⑬
⑪
⑮⑯ ⑰
⑫ ⑬ ⑭
2 31
5 64
8 97
0
View
Settings
xg
+
-

www.ihanil.com
14/23
4. Operation
4.2 Setting Speed
[Setting RPM]
1. Press the Speed button once.
2. Press the numeric buttons to set the desired RPM value.
▶ Up to 4,800 rpm
3. Press the Enter button.
[Setting RCF]
1. Press the Speed button twice.
2. Press the numeric buttons to set the desired RCF value.
▶ Up to 7,470xg
3. Press the Enter button.

Technical Support :[phone] / [email protected]om 15/23
4. Operation
1. Press the Time button.
2. Press the numeric buttons to set the desired run time.
▶ Up to <100hr
▶ Set the run time to 0 for continuous operation.
During continuous operation, the centrifuge will continue running until you stop it
manually.
3. Press the Setup/Enter button.
4.3 Setting Run Time
1. Press the Temp button.
2. Press the numeric buttons to set the desired temperature.
▶ -10℃ ~ 40 ℃
3. Press the Setup/Enter button.
1. Press the Temp limit button.
2. Press the numeric buttons to set the desired temperature limit range.
▶ Default value: ±30℃
3. Press the Setup/Enter button.
Temperature range that stops operation when the temperature is lower or higher than
the set temperature.
4.4 Setting Temperature
4.5 Setting Temperature Limit

www.ihanil.com
16/23
1. Press the ACC or DEC button.
2. Press the numeric buttons to set the desired ACC or DEC rate.
▶ ACC rate: 0~9 / DEC rate: 0~9
▶ The larger the acceleration rate, the faster the acceleration speed.
The smaller the deceleration, the slower the deceleration speed.
3. Press the Enter button.
4. Operation
[Saving]
1. Set the RPM(or RCF) / Run time / Accel, Decel rate / Temperature
2. Press the Program Save button.
3. Press the numeric buttons to set the desired program number.
▶ Up to 0~99 :100
4. Press the Enter button.
5. When "Do you store? Y/N" message pops up, press ACC(Save,Y) or DEC(Cancel,N)
button.
[Calling up]
1. Press the Program Call button.
2. Press the numeric buttons to set the desired program number.
3. Press the Enter button.
4.6 Setting Acceleration/Deceleration
4.7 Saving/Calling up a Program

Technical Support :[phone] / [email protected]om 17/23
During operation you can verify the setting values by pressing the 'View Setting' button.
4. Operation
4.8 Start/Stop a Run
4.9 Verifying the Setting value
[Start a run]
1. Check all parameters are correct.
2. Press the Start button.
[Stop a run]
1. Press the Stop button.

www.ihanil.com
18/23
5.1 Care Instructions
5.2 Cleaning
5. Maintenance
1. Regularly inspect the rotor chamber for check the motor shaft is normal.
2. Regularly check the rotor and accessories to be sure there is no damage.
3. Rotate the motor shaft with your hand to make sure it turns smoothly.
4. Keep dry inside the chamber after every use.
5. If any parts are contaminated with samples, clean the rotor with soft wet cloth and
keep the rotor dry
[Oustside of the device]
1 Clean the outside of deivice with a soft and dry cloth.
▶ If the device is contaminated, use a mild cleaning 󽗊uid to clean.
2. Do not use aggressive chemicals on the device such as alchol, benzene, acetone or
phenol.
3. Make sure do not scratch the surface of deivice when cleaning it.
▶ Do not use a metal sponge.
▶ If the device is rusted, remove it with a mild detergent and wipe it with a dry cloth.
[Chamber]
1. If the rotor chamber is not dry, wipe moisture from the chamber with a dry cloth.
2. If the rotor chamber is dirty, clean it with a mild 󽗊uid to clean.
[Rotor]
1. If any sample is spilt inside the rotor, clean it and dry well.
[Disposal]
1. In case of product is to be disposed of, the local wastes laws and regulations are to be
observed.
• Before cleaning the centrifuge, be sure to switch o󽗈 the device and
disconnect the power cord.

Technical Support :[phone] / [email protected]om 19/23
5.3 Care Instructions for Refrigerated device
5. Maintenance
[Open the lid after centrifugation]
1. Wipe up the moisture in the chamber with a soft cloth.
2. Leave the centrifuge lid open after centrifugation.
[Remove the condensation water]
1. There is a drain hose at the bottom of the device.
Regularly check and remove the condensation water from the drain hose.
[Remove dust]
1. Remove any dust from the ventilation slits regularly.
Drain Hose
ventilation Slots

www.ihanil.com
20/23
6.1 Possible Problems
6. Troubleshooting
Problems Recommended Action
Power failure - Check the power cord connection.
- Check the power fuse of the device.
Centrifugation
cannot be started - Check the lid is closed completely.
Lid cannot be
opened
- Press the ‘Lid open button’.
- Check the power connection.
Lid cannot be
closed
- Remove the dirt on the door latch and close the lid.
- Check the lid latch is not damaged.
Unusual noise
and vibration
- Check the device is installed on the hard and 󽗊at place
- Reload the blood bags symmetrically.
