GLP SCAN OPERATOR FX User manual

SCAN OPERATOR FX
User Manual
For Softwareversion 1.3
email: [email protected]
Internet: http://www.glp.de

SCAN OPERATOR FX
Contents
1View.......................................................................................................................... 7
1.1 Frontal view....................................................................................................... 7
1.2 Back view........................................................................................................ 10
1.3 Install into a 19“ rack........................................................................................ 10
2DMX Basics ............................................................................................................ 11
2.1 Signal transmission........................................................................................... 11
2.2 The cabling...................................................................................................... 11
2.3 The conversion to Light .................................................................................... 12
2.4 Adjusting how to address DMX ......................................................................... 13
3Using the Scanoperator FX...................................................................................... 13
3.1 View............................................................................................................... 13
3.2 Operation mode................................................................................................ 14
3.2.1 Play Mode............................................................................................. 14
3.2.2 Program mode....................................................................................... 14
3.2.3 Setup Mode ........................................................................................... 14
3.2.4 Easy mode............................................................................................. 14
3.3 Switching between Modes................................................................................. 15
3.4 LCD Display informations................................................................................. 15
3.5 Activate programming ...................................................................................... 16
3.6 Programming scenes......................................................................................... 16
3.6.1 Creating a new Scene............................................................................. 16
3.6.2 Editing scenes........................................................................................ 18
3.6.3 Copying a scene..................................................................................... 18
3.6.4 Copying Fixture..................................................................................... 19
3.6.5 Copying complete Bank .......................................................................... 19
3.6.6 Deleting scenes...................................................................................... 20
3.6.7 Deleting banks....................................................................................... 20
3.7 Programming Chasers....................................................................................... 20
3.7.2 Insert a bank into a chaser..................................................................... 21
3.7.3 Change the editing position of a Chaser ................................................. 22
3.7.4 Delete a step in Chaser........................................................................... 23
3.7.5 Delete Chasers ...................................................................................... 24
2(V1.3) GLP German Light Products

SCAN OPERATOR FX
3.7.6 Delete all Chasers...................................................................................24
3.8 Delete entire memory.........................................................................................25
This function clears and initializes the entire memory. After the deletion the....................25
Memory will be in the following condition:..................................................................25
3.9 Blackout configure............................................................................................25
3.9.2 Set back Blackout function.......................................................................27
3.10 3.10 Overlay scenes...........................................................................................28
3.10.1 Providing and editing scenes from overlay ...............................................28
3.10.2 Deleting Overlay scenes..........................................................................29
3.10.3 Using Overlay scenes (Play mode)............................................................30
3.11 Effect Generator...............................................................................................30
3.11.1 The Effect sample ..........................................................................................30
3.11.2 The "Create Wave" function.....................................................................31
3.11.3 The "Randomize" function .......................................................................32
3.11.4 Providing an effect..................................................................................32
3.11.5 Deleting an Effect...................................................................................34
3.11.6 Showing an effect....................................................................................34
3.12 Configuring Fade time function .........................................................................34
3.12.1 Changing and storing Fade Time channels................................................35
3.12.2 To set back Fade Time channels...............................................................36
3.13 Inverting channels.............................................................................................36
3.13.1 Provide and put back invertings ...............................................................36
3.13.2 Reset inverted Channels ..........................................................................37
3.14 Pan and Tilt Encoder .........................................................................................37
3.14.1 Configuring Pan and Tilt Encoder wheel...................................................38
3.14.2 Using Pan and Tilt Encoder wheel............................................................39
3.15 Desklock function .............................................................................................39
3.16 Autostart function..............................................................................................39
3.16.1 Activating Autostart function....................................................................39
3.16.2 Configuring Autostart Desklock ...............................................................40
3.16.3 Storing current playback condition as a autostart condition........................41
3.17 Calling up banks (Play mode).............................................................................41
3.17.1 Calling up a scene manually ....................................................................41
3.17.2 Playing a bank with auto-beat..................................................................42
3.17.3 Playing a bank with music clock ...............................................................43
3.18 Manual overwriting of channels by using the Faders (Play mode)...........................44
GLP •German Light Products (V1.3) 3

SCAN OPERATOR FX
3.19 Call up a Chaser (Play mode)............................................................................. 45
3.19.1 Call up a chaser manually ...................................................................... 45
3.19.2 Play a Chaser with a Auto-beat ............................................................... 45
3.19.3 Play a Chaser with a music-beat.............................................................. 46
3.20 Freeze function................................................................................................. 46
3.21 MIDI control..................................................................................................... 47
3.21.1 The Midi key board reservation............................................................... 47
3.21.2 Synthesizer Mode................................................................................... 48
3.21.3 Selecting MIDI channel and Midi reservation........................................... 49
3.22 Easy mode....................................................................................................... 50
3.23 copying the data between Scanoperator 12/PT/FX................................................ 51
3.23.1 Connecting the Controllers ..................................................................... 51
3.23.2 Receiving data....................................................................................... 52
3.23.3 Sending data.......................................................................................... 52
3.24 Reference to copying to a Scanoperator 12 Advanced........................................... 53
3.25 Editing logo..................................................................................................... 53
3.26 Set back logo ................................................................................................... 53
4Technical specifications........................................................................................... 54
4.1 general data...................................................................................................... 54
4.2 DMX Parameter ............................................................................................... 54
4.3 Desklamp connection........................................................................................ 54
4(V1.3) GLP German Light Products

SCAN OPERATOR FX
Marks and features
•192 DMX channels used by 12 fixtures which 16 DMX channels, each. Assignment
can not be changed
•240 scenes that can be programmed (30 Banks with 8 scenes per Bankl)
•Extensive effect generator to create automatic motion processes
•Autostart function inc. Desklock can be versatile inserted
•6 Chasers consisting of a maximum of 250 steps consisting of the programmed
scenes
•Speed and Fade-Time of all programs (scenes and chaser) can be adjusted
•2 Pan/Tilt Encoders, can individiually be assigned for each and every fixture
•Completely configureable Blackout Master
•Manual overwriting of any channel in Play mode inc. Master release key
•Freeze function to “freeze” the current DMX output
•Installed microphone for music controlled operation with digital filter that can be
adjusted
•6 freely programmable and selective Overlay scenes , that can be laid over running
programs and Chaser
•2 different MIDI (Musical Instrument Data Interface) configurations can be selected
(synthesizer operation or optimized for live operation on a 49 key Midi keyboard)
•MIDI-controlling of many Play functions, like banks, chaser, Blackout Master,
Overlays, Freeze, Auto-Beat, Music-Beat, Tapsync etc.
•Possibility to invert any channels
•Fadetime function that can be configured separately for each channel
•„Easy Modus“, which transforms the set into an easy DMX Faderunit with 120 DMX
channels for quicker testing of DMX endproducts or as a Faderuntit for bigger desks
•Copy function to copy the whole memory from one controller to another (compatible
to Scanoperator 12 Advanced and Scanoperator PT Advanced)
•Clearly arranged user interface and an informative LCD display
•12V/5W XLR Desklamp Connection with fuse
•A safe power failure memory
GLP •German Light Products (V1.3) 5

SCAN OPERATOR FX
Note:
Note that knowledge about MIDI and DMX is necessary for secure and complete control
of the desk
6(V1.3) GLP German Light Products

SCAN OPERATOR FX
1View
1.1 Frontal view
GLP •German Light Products (V1.3) 7

SCAN OPERATOR FX
1. Fixture keys (1-12)
12 Fixtures (Lamps) of each 16 DMX channels are to adjust over Fader. The currently
selected fixtures will be shown by their belonging LED.
Fixture DMX channels Fixture selection / LED
1 1-16 OFF/ON
2 17-32 OFF/ON
3 33-48 OFF/ON
4 49-64 OFF/ON
5 65-80 OFF/ON
6 81-96 OFF/ON
7 97-112 OFF/ON
8 113-128 OFF/ON
9 129-144 OFF/ON
10 145-160 OFF/ON
11 161-176 OFF/ON
12 177-192 OFF/ON
Press the Fixtures key, to control the respective lamp over the appropriate Faders. The
LED next to the Fixture keys shows the selected lamps.
2. Scene keys To access or to save scenes – press scenes key
3. Fader Here you can adjust the DMX data of the respective channel.
4. Page Select key Here you can switch the function of the Faders between
channels 1-8 (page A) or 9-16 (Page B).One LED shows the
current state.
5. Desklamp
connection 3 pin XLR connector for 12V Desklamp (max. 500mA).
6. Overlay keys 1-6 Here you access the 6 Overlay scenes.
7. LCD display Shows all current informations.
8. Bank keys
(UP/DOWN) Here you can switch between the banks 1-30. These keys are
also there to change the start angle in the effect editor
8(V1.3) GLP German Light Products

SCAN OPERATOR FX
9. Record + Delete
key
function-keys to record and delete
10. PROGRAM +
Setup key With these two keys you change the operation mode of the
ScanoperatorFX
11. Speed/Sensitivity
Fader/FX Speed
Fader
Here you can adjust the automatic … (0,12s – 12m 30s). This
Fader is also used to regulate the sensitivity of the microphone
(slow – fast) and the effect speed.
12. Fade Time/FX
Size Fader Here you adjust the Fade time (0 – 32s). The Fade time sets
the time it takes to crossfade between two different scenes or
of a chaser. This Fader is also there to change the size of a
chosen effect.
13. Pan/Tilt Encoder
+ Fine key With the two encoders, you can directly adjust the Pan and Tilt
values of the selected fixtures. The Fine key allows you to work
accurate.
14. FREEZE key Turns on the DMX Freeze function.
15. Music/BankCopy
key Activates the music-beat or copies the whole Bank
16. Auto key Activates the Auto-Beat.
17. Tap Sync /
Manual Go key Allows you to manually trigger the chaser when in Auto-Beat
and learns the timing. The LCD Display then changes between
chaser steps and the current bank.
18. Blackout key With the Blackout key you can overwrite the DMX-Output with
self defined data you configured before. For example all
Shutter channels with data “0”.
19. Release key The release key clears all manual changes
20. FX Editor key This key activates the Effect editor in program mode.
21. FX Clear key This key deletes the adjusted effects.
22. Create Wave key This key changes the starting angle of all selected fixtures
automaticly, so that the fixtures will run the current effects like
a wave.
23. Randomize key This key randomly changes the first angle of all selected
GLP •German Light Products (V1.3) 9

SCAN OPERATOR FX
fixtures and generates randomized samples.
24. Chaser keys Here you access the 6 chasers.
1.2 Back view
1. Audio IN Cinch-socket to connect to an audio source.
2. MIDI IN Socket to receive MIDI data
3. DMX Out 3 pol. DMX- exit.
4. DMX In 3 pol. DMX- entry .
5. DC Input DC +12V, 500mA min. (please pay attention to ...).
6. Power On/Off Switch
1.3 Install into a 19“ rack
The unit is easy to install in a 19“ rack - you only need to remove the plastic border, that
is attached to the Scanoperator in delivery condition. To do this, you have to remove the
10 screws from the plastic parts. Afterwarts you can pull away the single plastic
peelings up, down and to the side. Then use the mounting brackets which have been
shippied with the controller, to install it into the 19” rack.
10 (V1.3) GLP German Light Products

SCAN OPERATOR FX
2DMX Basics
To operate the Scanoperator FX, a basic knowledge about the DMX signal
transmission, is necessary. This chapter offers a short introduction to the world of DMX
data transmission and addresses to beginners and those who have no, or just a little
experience with DMX.
2.1 Signal transmission
Up to 512 DMX channels can be transferred over a so called DMX cable during a DMX
signal transmission. Every DMX channel equals a value of numbers between 0 and 255.
A lightcontroller generates the DMX channels and constantly continues them with
current values. The Scanoperator FX sends 192 channels with a rate of repeatition of
36Hz. That means, that every one of the192 channels is sent 36 times per second.
2.2 The cabling
DMX fixtures are being cabled in series. There is only one transmitter but several
receivers. The order of receivers on a cable does not matter, because all units receive
all data and filter the relevant data. The cabling starts at the transmitter (the lightdesk)
and leads to the first DMX set. Beginning at the first DMX Fixture, there’s a cable
leading to the second and so on, until the last set is reached. According to the standard
you need to plug in a DMX terminator into the last fixture. You can do without this plug if
you have smaller cable lengths (20m-30m length of the cable). But please keep in mind,
that without that plug, errors might show up in the DMX cabling. The maximum length of
the cable is 300m. You can overcome longer distances by a DMX Signal Booster.
Reference:
A DMX Terminator plug is the same as an ordinary XLR plug, where both DMX data
pins (data+ and data-) are connected over a 120Ohm resistor. This minimizes the
reflections at the end of the cable, which clearly raises the signal quality.
The DMX cables normally consist of one cable according to AES/EBU standard with 5
pin XLR plugs. Instead of using AES/EBU standard cables, often normal microphone
cable is being used. This should be considered like not using a Terminator plug: in case
of shorter distances it usually works – but might show errors in the DMX cabling as well.
GLP •German Light Products (V1.3) 11

SCAN OPERATOR FX
2.3 The conversion to Light
Every DMX Fixture has its own committed amount of operating channels for its
functions(like movement, brightness, selecting colors and so on), given by the
manufacturer. Since every unit receives all DMX channels of the controller, you have to
set every fixture to the right start address.
At this start address the set interprets the coming values (per channel a value between
0 and 255) for its functions. You will find Information about which channels exist and
what each channel does at a specific value in the User-Manual of the Fixture.
Example:
We have a fixture with 6 DMX channels. Our lighting controller is sending 192 channels
and the data for our DMX fixture is on the channels 100 to 105. Therefore we have to
set the start channel to 100 on our fixture, so that it will receive the correct values .
The second of 6 channels is, according to the fixtures instruction manual, a dimmer
channel. At an adjusted startadress of 100, the set will use the data from DMX channel
101 for its dimmer (channel 100=first channel, 101=second Channel and so on).
Dimmer channels often use a value of 0 = Dimmer at 0% and DMX value at 255 =
Dimmer at 100% - but it does not always have to be that way. For more exact
information’s, read the instructions of use for the belonging set .
Caution:
Some DMX Units start counting at 0, not at 1. Then you set the start channel between 0
to 511 instead of 1 to 512. You will find informations about how the fixture counts in the
instructions for use of the belonging fixture, as well.
Reference:
You can set more than one DMX Unit of the same type on the same start address,
without any problems. These fixtures will run exactly synchronized, because they are
receiving the same data. This way you can connect more than 12 fixtures to the Scan
Operator FX.
12 (V1.3) GLP German Light Products

SCAN OPERATOR FX
2.4 Adjusting how to address DMX
Like already has been said, the Scan Operator FX sends 192 channels, which are
12 fixtures with each 16 DMX channels (12*16=192). Therefore there are 12
different DMX addresses you need to set your fixtures to:
Fixture DMX startaddress if you start
to count at 0 DMX startaddress, if you start to count at 1
1 0 1
2 16 17
3 32 33
4 48 49
5 64 65
6 80 81
7 96 97
8 112 113
9 128 129
10 144 145
11 160 161
12 176 177
3Using the Scanoperator FX
3.1 View
This DMX controller allows to control up to 12 Fixtures with up to 16 DMX channels
each. There are 30 Banks with 8 Scenes per Bank.. Out of these 240 scenes you can
build up to 6 chasers with each up to 250 steps. The chasers and Banks can be played
in different ways:
•manual
•music-tap
•already given tap (auto-beat), that is given over the „Tapsync“-key or speed-fader
•MIDI command
GLP •German Light Products (V1.3) 13

SCAN OPERATOR FX
3.2 Operation mode
All together there are 4 different operation modes in which different functions are
available. When you turn on the unit, you start directly in the play mode.
The current mode is always shown in the first line in the display!
3.2.1 Play Mode
This mode is there to play the scenes, banks and chasers you have programmed
before. There are different ways to let the banks and chasers tap automatically. The
Desk also reacts to given MIDI commands.
3.2.2 Program mode
It is possible to program the whole scenes, effects, banks, chasers, overlays and
blackouts in this mode.
3.2.3 Setup Mode
The Setup mode is used to configure the scanoperator. You can configure the midi
channel, the midi control mode (between synthesizer and keyboard), reverse DMX
channels, turn on the Fade-time function for each channel and alter the assignment of
the Pan/Tilt wheels.
The Pan/Tilt wheels can be assigned per fixture to one channel (1 to 16), each and can
be an alternative Pan/Tilt adjustment opportunity besides of the appropriate
channelfaders.
3.2.4 Easy mode
The easy mode is Therefore quick testing of DMX controllable units or to extend bigger
DMX desks , where a extra DMX fader unit would be useful. Here there are 12 fixtures
with 10 channels each that are manualyl given (over the 10 faders). The scene keys
respond as flash keys for the first 8 channels of each set. The Blackout function turns all
120 DMX channels to 0. Other functions (except Desklock function) are deactivated.
Technical reference:
14 (V1.3) GLP German Light Products

SCAN OPERATOR FX
In easy mode as well as in play mode,192 DMX channels are being sent. The channels
1-120 can be, as written above, controlled by the user. The channels 121-192 will be
constantly transferred with value „0“.
3.3 Switching between Modes
To activate the different modes, press the belonging key for 3 seconds:
•Program mode: PROGRAM key
•Setup mode: SETUP key
•Easy mode: PROGRAM+SETUP key simultaneous
Switching between all modes can be done by pressing the belonging key. The Play
mode can be reached by pressing the key, which brought you into the current mode
again for 3 seconds.
Example:
If you are in setup mode and want to change to program mode, press the program key
for 3 seconds.
If you are in program mode and want to go back to play mode, just press the program
key again for 3 seconds.
3.4 LCD Display informations
The LCD display consists of 2 lines of each 8 signs. The display is intensivly used to
show the current condition. In a normal condition it always shows the current mode in
the first line. In the line below you can find informations to the belonging mode.
In Play Mode you have the current bank and the current scene shown in the second
line. If a chaser is activated, it will be shown at the end oft he first line.
In Program mode you can also see the current bank and scene in second line. Besides
that there is a extra „Overlay Bank“ that should be marked with „Overlay“.
In Setup Mode you can see the belonging menu point in second line, which you can
configure now. The following menu points can be chosen:
•“Midi” to configure the MIDI channel and MIDI assignment
•“Invert” to reverse channels
•“Fadetime” to configure Fadetime channels
•“Tilt” to configure the Tilt Encoder wheel
•“Pan” to configure the Pan Encoder wheel
GLP •German Light Products (V1.3) 15

SCAN OPERATOR FX
•„Autostart“ to configure the Autostart options
In Easy Mode the second line is blank.
Besides that the display also shows a short confirmation or an error report. These
overwrite the current informations of the display for a few seconds. Afterwards the
display turns back to its normal condition. Examples fur such short reports are „Memory
Reset“, „Scene Saved“, „Midi Set / Keyboard“, „Fader xy / Value abc“ ...
3.5 Activate programming
After turning the unit on you are in PLAY Mode.
By pressing the Program key for 3 seconds you change to program mode. Here
scenes, effects and chasers can be created and the Blackout functions as well as
the Overlay scenes can be configured. After pressing the program key again for 3
seconds, you return to play mode.
3.6 Programming scenes
3.6.1 Creating a new Scene
A scene is an adjustment of all 192 DMX values of different DMX sets including a
possible Pan/Tilt effect for each fixture. Up to 240 scenes can be stored. The
scenes are subdivided in 30 banks with each 8 scenes.
16 (V1.3) GLP German Light Products

SCAN OPERATOR FX
1. Activate PROGRAM mode (PROGRAM key).
2. Select desired Fixtures with associated Fixture keys. Thereby several Fixtures
can be selected at the same time.
3. Adjust the desired DMX values (0 to 255) with the Fader.
4. If you need to change to channels 9-16 press the “Page” key. If you’d like to
edit channel 1-8, just press the “Page” key again.
Repeat the steps 2-4 until all DMX values correspond to your desires.
Note:
By pressing the RELEASE key you can set all 192 channels back to the DMX
value "0" at any time and start altering the values again.
For storing continue with step 5:
5. If the current bank does not match the desired bank, then you might select the
desired bank using the BANK keys. 30 banks are available. You can store up to
8 Scenes in each bank.
If the desired scene is created, then you can store it in the scanoperator by
pressing the RECORD key once.
6. Afterwards press the scenes key, which you would like to store the scene to.
As a memory confirmation you’ll receive the message "Scene Saved". After that,
the display will show the current bank and scene.
7. Continue the steps 2-7 until all desired scenes are stored.
8. To leave PROGRAM mode, press the PROGRAM key for 3 seconds.
GLP •German Light Products (V1.3) 17

SCAN OPERATOR FX
3.6.2 Editing scenes
1. Activate PROGRAM mode (PROGRAM key).
2. Press BANK UP/DOWN key to call up the desired bank in which the scene,
that shall be edited is on.
3. Load desired scene by pressing the appropriate scenes key. Now you can
change and store again, as in the case of creating.
Caution:
Loading a scene that is not containing any values is not possible! In that case you
receive the error message "Scene Empty".
4. Make the desired changes with the Faders. Select the appropriate Fixtures, for
that, previously.
5. After you made the changes you press the RECORD key.
6. Press the previously selected scenes key again, to store the changes. You will
receive the message "Scene Saved".
Reference:
Of course the now changed scene can be stored in another scene or even on a
different bank. Therefore it is possible to quickly create the appropriate scenes for
chases, where each step of the chase should be based on the same scene, but a
little different.
3.6.3 Copying a scene
1. Activate PROGRAM mode (PROGRAM key).
2. Press the BANK UP/DOWN key to call up the desired bank in which the scene
that shall be copied is on.
3. Load the scene which you would like to copy by pressing the appropriate
scene key once.
Caution:
Loading an empty scene is not possible! In that case you receive the error
message "Scene Empty".
18 (V1.3) GLP German Light Products

SCAN OPERATOR FX
4. Press the BANK UP/DOWN key to call up the desired bank which the scene
shall be copied to.
5. Press the RECORDS key.
6. Press the scenes key which you want to copy the chosen scene to. As
confirmation you will receive the message "Scene Saved".
3.6.4 Copying Fixture
This function allows you to transfer the current DMX values from one fixture to
another in PROGRAM mode (COPY).
1. Keep the Fixture key, which you want to copy, pressed
2. While you keep the first Fixture key pressed, press the desired second Fixture
key on which you want to copy.
3. In the display the signature "COPY" appears short as confirmation.
4. For example you can also press further Fixture keys, without releasing first, in
order to copy the same settings on further Fixtures.
Caution:
These changes take place in the buffer only. If you want to store the new scene,
then proceed as described above (RECORD and then scene key)!
3.6.5 Copying complete Bank
1. Activate PROGRAM mode (PROGRAM Key).
2. Press the BANK UP/DOWN key to call up the desired bank you would like to
copy.
3. Press the RECORD key.
4. Press the BANK UP/DOWN key until you reached the bank you would like to
copy to.
5. Press the MUSIC/BANK COPY key. As memory confirmation you receive the
message "BANK COPY".
GLP •German Light Products (V1.3) 19

SCAN OPERATOR FX
6. Press the PROGRAM key for 3 seconds to leave the PROGRAM mode again.
3.6.6 Deleting scenes
1. Select the bank, in which the scene that shall be deleted is located.
2. Keep the DELETE key pressed and press the scenes key of the scene that
you would like to delete. As confirmation you receive the message "Scene
Deleted".
Attention:
A deleted scene cannot be restored again!
3.6.7 Deleting banks
1. Select the bank, which you would like to delete.
2. Keep the DELETE key pressed and press the MUSIC/BANK key at the same
time.
3. All scenes of this bank were deleted. For confirmation you receive the
message "Bank Deleted".
3.7 Programming Chasers
A Chaser is a program, which calls at maximum of 250 scenes successively. You must
have programmed the scenes, from which you "build up" the Chaser, before.
.
Should you change scenes later, the program of the Chaser changes as well. Should a
scene in which a chaser is used, be deleted afterwards, then the chaser will not load the
scene, since it is empty.
20 (V1.3) GLP German Light Products
