Graco Mini Fire-Ball 225 Series Operation manual

Graco Inc. P.O. Box 1441 Minneapolis, MN 55440-1441
Copyright 2007, Graco Inc. is registered to I.S. EN ISO 9001
309967A
Instructions - Parts List
Mini Fire-Ball®225,
50:1 Grease Pump
Packages
Portable units for dispensing heavy grease.
See page 2 for model numbers.
5000 psi (34 MPa, 345 bar) Maximum Working Pressure
100 psi (0.7 MPa, 7 bar) Maximum Air Working Pressure
Contents
Models . . . . . . . . . . . . . . . . . . . . . . .2
Warnings . . . . . . . . . . . . . . . . . . . . .3
Operation/Service . . . . . . . . . . . . . .4
Installation . . . . . . . . . . . . . . . . . . .5
Operation . . . . . . . . . . . . . . . . . . .11
Parts . . . . . . . . . . . . . . . . . . . . . . .12
Sound Data . . . . . . . . . . . . . . . . . .18
Graco Standard Warranty . . . . . .20
Graco Information . . . . . . . . . . . .20
Important Safety Instructions
Read all warnings and instructions in this manual.
Save these instructions.
253388
Model 253388 shown

Models
2309967A
Models
† These models are CE certified.
Model
No. Size
Dispense
Kit 236058
Hose/Fitting
Kit 222072
Base
Type Cover
Follow
Plate Handle Pail
CE Kit
240979
246910 35-50 lb
(16-23 kg)
✔222059 220653 ✔
253384† 35-50 lb
(16-23 kg)
✔222059 220653 ✔✔
253362 35-50 lb
(16-23 kg)
✔222059 220653
246911 35-50 lb
(16-23 kg)
✔204574 ✔✔
253385† 35-50 lb
(16-23 kg)
✔204574 ✔✔✔
246913 35-50 lb
(16-23 kg)
✔2-wheel
truck
204574 ✔✔
253386† 35-50 lb
(16-23 kg)
✔2-wheel
truck
204574 ✔✔✔
246914 120 lb
(55 kg)
✔204574 220654
253387† 120 lb
(55 kg)
✔204574 220654 ✔
246915 120 lb
(55 kg)
✔portable 204574 220654
253388† 120 lb
55 kg)
✔portable 204574 220654 ✔
246916 120 lb
(55 kg)
✔2-wheel
truck
204574 220654
253389† 120 lb
(55 kg)
✔2-wheel
truck
204574 220654 ✔
246917 400 lb
(180 kg)
✔200326 223845
253390† 400 lb
(180 kg)
✔200326 223845 ✔

Warnings
309967A 3
Warnings
The following general warnings are for the setup, use, grounding, maintenance, and repair of this equipment. Addi-
tional, more specific warnings may be found throughout the body of this manual where applicable. Symbols appear-
ing in the body of the manual refer to these general warnings. When these symbols appear throughout the manual,
refer back to these pages for a description of the specific hazard.
WARNING
EQUIPMENT MISUSE HAZARD
Misuse can cause death or serious injury.
• Do not operate the unit when fatigued or under the influence of drugs or alcohol.
• Do not exceed the maximum working pressure or temperature rating of the lowest rated system
component. See Technical Data in all equipment manuals.
• Use fluids and solvents that are compatible with equipment wetted parts. See Technical Data in all
equipment manuals. Read fluid and solvent manufacturer’s warnings. For complete information
about your material, request MSDS forms from distributor or retailer.
• Check equipment daily. Repair or replace worn or damaged parts immediately with genuine Graco
replacement parts only.
• Do not alter or modify equipment.
• Use equipment only for its intended purpose. Call your Graco distributor for information.
• Route hoses and cables away from traffic areas, sharp edges, moving parts, and hot surfaces.
• Do not kink or over bend hoses or use hoses to pull equipment.
• Keep children and animals away from work area.
• Comply with all applicable safety regulations.
SKIN INJECTION HAZARD
High-pressure fluid from dispense valve, hose leaks, or ruptured components will pierce skin. This may
look like just a cut, but it is a serious injury that can result in amputation. Get immediate surgical
treatment.
• Do not point dispense valve at anyone or at any part of the body.
• Do not put your hand over the end of the dispense nozzle.
• Do not stop or deflect leaks with your hand, body, glove, or rag.
• Follow Pressure Relief Procedure in this manual, when you stop dispensing and before cleaning,
checking, or servicing equipment.
MOVING PARTS HAZARD
Moving parts can pinch or amputate fingers and other body parts.
• Keep clear of moving parts.
• Do not operate equipment with protective guards or covers removed.
• Pressurized equipment can start without warning. Before checking, moving, or servicing equipment,
follow the Pressure Relief Procedure in this manual. Disconnect power or air supply.

Operation/Service
4309967A
Operation/Service
Refer to pump manual 309966 (supplied) for operating and service instructions.
FIRE AND EXPLOSION HAZARD
When flammable fluids are present in the work area, such as gasoline and windshield wiper fluid, be
aware that flammable fumes can ignite or explode. To help prevent fire and explosion:
• Use equipment only in well ventilated area.
• Eliminate all ignition sources, such as cigarettes and portable electric lamps.
• Keep work area free of debris, including rags and spilled or open containers of solvent and gasoline.
• Do not plug or unplug power cords or turn lights on or off when flammable fumes are present.
• Ground all equipment in the work area.
• Use only grounded hoses.
• If there is static sparking or you feel a shock, stop operation immediately. Do not use equipment
until you identify and correct the problem.
• Keep a working fire extinguisher in the work area.
TOXIC FLUID OR FUMES HAZARD
Toxic fluids or fumes can cause serious injury or death if splashed in the eyes or on skin, inhaled, or
swallowed.
• Read MSDS’s to know the specific hazards of the fluids you are using.
• Store hazardous fluid in approved containers, and dispose of it according to applicable guidelines.
PERSONAL PROTECTIVE EQUIPMENT
You must wear appropriate protective equipment when operating, servicing, or when in the operating
area of the equipment to help protect you from serious injury, including eye injury, inhalation of toxic
fumes, burns, and hearing loss. This equipment includes but is not limited to:
• Protective eyewear
• Clothing and respirator as recommended by the fluid and solvent manufacturer
•Gloves
• Hearing protection
WARNING

Installation
309967A 5
Installation
General Information
Air Line Accessories
See page 6 for recommended air accessories and
installation.
Grounding
To reduce the risk of static sparking, ground the pump
and all other components used or located in the
dispensing area. Check your local electrical code for
detailed instructions for your area and type of
equipment.
Ground this equipment:
Pump: remove the ground screw (Z) and insert through
the eye of the ring terminal at end of ground wire (Y).
Fasten the ground screw back onto the pump and
tighten securely. Connect the other end of the ground
wire to a true earth ground. See FIG. 1. To order a
ground wire and clamp, order Part No. 222011.
Air and fluid hoses: use only grounded hoses.
Air compressor: follow manufacturer’s recommenda-
tions.
Dispense valve: ground through connection to a prop-
erly grounded fluid hose and pump.
Fluid supply container: follow local code.
To maintain grounding continuity when flushing or
relieving pressure: hold metal part of the dispense
valve firmly to the side of a grounded metal pail, then
trigger the valve.
Reference numbers and letters in parentheses in
the text refer to the callouts in the figures and parts
drawing.
Always use genuine Graco parts and accessories,
available from your Graco distributor.
FIG. 1
ZY
ti1052

Installation
6309967A
Typical Installation
The installation shown below is only a guide for selecting and installing system components and accessories. Con-
tact your Graco distributor for assistance in designing a system to suit your particular needs.
Air Line and Accessories
• Install a pump runaway valve (G) to shut off the air
to the pump if the pump accelerates beyond the pre-
adjusted setting. A pump that runs too fast can be
seriously damaged.
• Install an air line lubricator (F) for automatic air
motor lubrication.
• Install a bleed-type master air valve (H) to relieve air
trapped between the valve and the motor when the
valve is closed.
• Install the air regulator (C) to control pump speed
and pressure.
• On the main air supply line from the compressor,
install an air line filter (E) to remove harmful dirt and
contaminants fro the compressed air supply.
• For models 253384 through 253390, install the pro-
vided air regulator/safety valve (K) at the pump air
inlet with the nipple (9a, also included).
Key:
A Fluid dispense line
B Pump ground wire (required)
C Air regulator
D Main air supply line
EAirfilter
F Pump lubricator
G Pump runaway valve
H Bleed-type master air valve (required)
J Quick-disconnect couple and nipple
K Air regulator (9b) with safety valve (9c) and gauge (not shown)
Included with models 253384 through 253390 A
C
D
FG H
J
E
01519
B
Install air line accessories in the order shown in the
Typical Installation illustration. Trapped air can cause the air motor to cycle unex-
pectedly, causing serious injury if you are adjusting or
repairing the pump. Be sure to follow the Pressure
Relief Procedure on page 11.
Avoid hanging air accessories directly on the pump
air inlet. The fittings are not strong enough to sup-
port the accessories and may cause one or more to
break. If accessories must be installed directly on
the pump, provide a bracket on which to mount
them.

Installation
309967A 7
Models 246910, 253362, and 253384 (FIG. 2)
1. Remove the cover from the pail, and scoop the
lubricant from the center to the sides of the pail to
make its surface concave.
2. Center the follow plate (5) in the pail opening. Press
the plate firmly downward and rotate it over the
lubricant surface to eliminate air pockets and pre-
vent channeling.
3. Insert the pump through the cover (4a) and slide the
cover up far enough to let the pump pass easily
through the follow plate grommet. The pump stop
plate(4b) will secure the pump in place.
4. Place the cover (4a) on the pail, and tighten the
thumbscrews (4f).
5. Assemble the gun (2b) and hose (2a), and connect
the hose to the pump fluid outlet.
6. Connect the nipple (2d) to the pump air inlet or air
regulator (9b) inlet, whichever is applicable. Con-
nect the quick–disconnect coupler (2c) to the air
supply hose.
FIG. 2
9b
2c, 2d
4f
5
4a
2b
2a
Model 253384 shown 01517
4b

Installation
8309967A
Models 246911, 246913, 253385 and 253386
(FIG. 3)
1. Remove the fluid outlet adapter included with the
pump, and screw the holster (6) into the pump outlet
using thread sealant.
2. Models 246913 and 253386: Assemble the truck (7)
as shown in the parts drawing on page 17. Secure
the truck pail (10) to the truck base with the pointed
clamps (7d) and thumbnuts (7c).
3. Remove the cover from the pail of lubricant. Place
the pail of lubricant into the truck pail.
4. Secure the cover (4) on the pail with the three
thumbscrews (A).
5. Insert the pump riser tube through the top of the
cover (4). Lower the pump until it rests on the cover.
6. Assemble the gun (2b) and hose (2a), and connect
the hose to the pump fluid outlet.
7. Connect the nipple (2d) to the pump air inlet or air
regulator (9b) inlet, whichever is applicable. Con-
nect the quick-disconnect coupler (2c) to the air
supply hose.
FIG. 3
Model 253386 shown
01514
2a
4
A
7c, 7d
10
6
2c
9b
2b
2d
7

Installation
309967A 9
Models 246914, 246917, 253387 and 253390
(FIG. 4 and FIG. 5)
1. Remove the cover from the pail, and scoop the
lubricant from the center to the sides of the pail to
make its surface concave.
2. Center the follow plate (5) in the pail opening. Press
the follow plate firmly downward and rotate it over
the lubricant surface to eliminate air pockets and
prevent channeling.
3. Place the cover (4) on the pail ant tighten the
thumbscrews (A).
4. Connect the swivel adapter to the pump fluid outlet.
Connect fluid hose (3c) to the swivel adapter. Con-
nect a suitable dispense valve.
5. Connect the swivel adapter to the pump air inlet or
air regulator (9b), whichever is applicable. Connect
the air hose (3a) to the swivel. Connect the air hose
to the air accessories.
FIG. 4
8729
Model 253387 shown
5
A
4
9b
3a
3c
FIG. 5
8726
Model 253390 shown
3a
5
4
9b 3c

Installation
10 309967A
Models 246915, 246916, 253388 and 253389
(FIG. 6)
1. For Models 246915 and 253388: Assemble the por-
table base (8) as shown in the parts drawing on
page 17
For Models 246916 and 253389: Assemble the
truck (7) as shown in the parts drawing on page 17.
2. Remove the fluid outlet adapter included with the
pump, and screw the holster (6) into the pump out-
let, using thread sealant.
3. Place an open 120–lb drum of grease on the mount-
ing base or truck, and secure it with hold-down
clamps (7d or 8d).
For Models 246915 and 253388: Use pointed end of
clamps (8d) for steel drums only. Position the clamp
above the drum bead. Tighten bolts (8b). Reverse
clamps (8d) to use the flat end for fiber drums.
For Models 246916 and 253389: Use pointed end of
clamps (7d) for steel drums only. Position the clamp
above the drum bead. Tighten the thumbnuts (7c).
4. Press the follow plate (5) down firmly onto the
grease, and rotate it to eliminate air pockets and
reduce channeling. Insert the pump through the
cover (4). Slide the cover up far enough to let the
pump pass easily through the follow plate grommet.
5. Secure the cover on the drum with the thumbscrews
(A). It is not necessary to bolt the pump to the
cover.
6. Assemble the gun (2b) and hose (2a), and connect
the hose to the pump fluid outlet.
7. Connect the nipple (2d) to the pump air inlet or air
regulator (9b) inlet, whichever is applicable. Con-
nect the quick–disconnect coupler (2c) to the air
supply hose.
FIG. 6
Model 253389 shown
246916
4
5
8d
7d7c
A
2b
2a
6
7
06790
8b
2c, 2d
9b
8

Operation
309967A 11
Operation
Pressure Relief Procedure
1. Shut off the air to the pump.
2. Bleed off the air pressure by closing the air regulator
(self–relieving type), or closing the bleed–type mas-
ter air valve installed upstream of the air regulator,
or disconnecting the air supply hose at the
quick–disconnect.
3. Hold a metal part of the gun or valve firmly to the
side of a grounded metal waster container and trig-
ger to relieve fluid pressure.
Start–up: Single or Multiple Pump Systems
1. Close the air regulators and bleed–type master air
valves to all but one pump.
2. Open the master air valve from the compressor.
3. For the pump which is connected, trigger the dis-
pensing valve into a grounded metal waste con-
tainer, making firm metal–to–metal contact between
the container and valve. Open the bleed–type mas-
ter air valve, and open the pump air regulator slowly
until the pump is running. When the pump is primed
and all air has been pushed out of the lines, release
the trigger.
4. If you have more than one pump, repeat this proce-
dure for each pump.
5. Set the air pressure to each pump at the lowest
pressure needed to get the desired results.
6. Read and follow the instructions supplied with each
component in the system.
7. When shutting off the system, always follow the
Pressure Relief Procedure.
When the pump is primed, and with sufficient air
supplied, the pump starts when the dispensing
valve is opened and shuts off when it is closed.
A pump runaway valve can be installed on the air
line to automatically shut off the pump if it starts to
run too fast.
Never allow the pump to run dry of the fluid being
pumped. A dry pump will quickly accelerate to a
high speed, possibly damaging itself. If the pump
accelerates quickly or is running too fast, stop it
immediately and check the fluid supply. If the sup-
ply container is empty and air has been pumped
into the lines, prime the pump and lines with fluid,
or flush it and leave it filled with a compatible sol-
vent. Be sure to eliminate all air from the fluid sys-
tem
The maximum working pressure of each pump in your
system may not be the same. To reduce the risk of
over–pressurizing any part of your system, be sure you
know the maximum working pressure rating of each
pump and its connected components. Never exceed
the maximum working pressure of the lowest rated
component connected to a particular pump.
To determine the fluid output pressure using the air
regulator reading, multiply the ratio of the pump by the
air pressure shown on the regulator gauge. For exam-
ple:
50:(1) ratio x 100 psi air = 5000 psi fluid output
50:(1) ratio x 0.7 MPa air = 35 MPa fluid output
50:(1) ratio x 7 bar air = 350 bar fluid output
Limit the air to the pump so that no air line or fluid line
component or accessory is overpressurized.

Parts
12 309967A
Parts
.
Models 246910, 253362, and 253384
35-50 lb (16-23 kg) pail size
Models 246911 and 253385
35-50 lb (16-23 kg) pail size
Ref.
No. Part No.Description Qty.
1 246909 PUMP, Mini Fire-Ball 225 50:1
(with handle)
See manual 309966 for parts.
1
253361 PUMP, Mini Fire-Ball 225 50:1
(without handle) Model 253362
See manual 309966 for parts.
1
2 236058 DISPENSE KIT; 12 ft (3.7 m) hose;
See parts list on page 16.
1
4 222059 COVER; includes items 4a-4h 1
4a 207617 • COVER, pail 1
4b 168102 • PLATE, stop, pump
4c 158048 • BUMPER, button, rubber 1
4d 159608 • RIVET 1
4e 150868 • HOLDER, gun 1
4f 100220 • SCREW, thumb 3
4g 100025 • NUT, 1/4 npsm thd 1
4h 100579 • PIN, cotter; 1/8” x 1” 1
5 220653 FOLLOW PLATE
See manual 306345 for parts.
1
9 240979 CE Kit for 253384
See parts on page 17.
1
01517
1
4d
2
9
4a
4b
4e
4h
4g
5
4f
4c
Ref.
No. Part No.Description Qty.
1 246909 PUMP, Mini Fire-Ball 225 50:1
See manual 309966 for parts.
1
2 236058 DISPENSE KIT; 12 ft (3.7 m) hose;
See parts list on page 16.
1
4 204574 COVER
See manual 306345 for parts.
1
6 203976 HOLSTER 1
9 240979 CE Kit for 253385
See parts on page 17.
1
10 204134 PAIL 1
Model 253384 shown
Model 253385 shown
01521
1
6
2
10
4
9

Parts
309967A 13
Models 246913 and 253386
35-50 lb (16-23 kg) pail size
Models 246914 and 253387
120 lb (55 kg) drum size
Ref.
No. Part No.Description Qty.
1 246909 PUMP, Mini Fire-Ball 225 50:1
See manual 309966 for parts.
1
2 236058 DISPENSE KIT; 12 ft (3.7 m) hose;
See parts list on page 16.
1
4 204574 COVER
See manual 306345 for parts.
1
6 203976 HOLSTER 1
7 203650 TRUCK, 2-wheel;
See parts list on page 17.
1
9 240979 CE Kit for 253386
See parts on page 17.
1
10 204134 PAIL 1
10
1
6
2
Model 253386 shown 01514
4
9
7
Ref.
No. Part No.Description Qty.
1 246780 PUMP, Mini Fire-Ball 225 50:1
See manual 309966 for parts.
1
3 222072 Hose and Fitting Kit; 6 ft (1.8 m)
hose; See parts list on page 16.
1
4 204574 COVER
See manual 306345 for parts.
1
5 220654 FOLLOW PLATE
See manual 306345 for parts.
1
9 240979 CE Kit for 253387
See parts on page 17.
1
3
9
1
4
Model 253387 shown
8729
5

Parts
14 309967A
Models 246915 and 235388
120 lb 55 kg) drum size
Models 246916 and 253389
120 lb 55 kg) drum size
Ref.
No. Part No.Description Qty.
1 246780 PUMP, Mini Fire-Ball 225 50:1
See manual 309966 for parts.
1
2 236058 DISPENSE KIT; 12 ft (3.7 m) hose;
See parts list on page 16.
1
4 204574 COVER
See manual 306345 for parts.
1
5 220654 FOLLOW PLATE
See manual 306345 for parts.
1
6 203976 HOLSTER 1
8 203622 PORTABLE BASE;
See parts list on page 17.
1
9 240979 CE Kit for 235388
See parts on page 17.
1
2
4
1
9
5
Model 253388 shown 253388
8
6
Ref.
No. Part No.Description Qty.
1 246780 PUMP, Mini Fire-Ball 225 50:1
See manual 309966 for parts.
1
2 236058 DISPENSE KIT; 12 ft (3.7 m) hose;
See parts list on page 16.
1
4 204574 COVER
See manual 306345 for parts.
1
5 220654 FOLLOW PLATE
See manual 306345 for parts.
1
6 203976 HOLSTER 1
7 203650 TRUCK, 2-wheel;
See parts list on page 17.
1
9 240979 CE Kit for 253389
See parts on page 17.
1
1
4
5
6
2
Model 253389 shown
01522
7
9

Parts
309967A 15
Models 246917 and 253390
400 lb (180 kg) drum size
Ref.
No. Part No.Description Qty.
1 246781 PUMP, Mini Fire-Ball 225 50:1
See manual 309966 for parts.
1
3 222072 Hose and Fitting Kit; 6 ft (1.8 m)
hose; See parts list on page 16.
1
4 200326 COVER
See manual 306345 for parts.
1
5 223845 FOLLOW PLATE
See manual 306345 for parts.
1
9 240979 CE Kit for 253389
See parts on page 17.
1
5
1
4
Model 253390 shown 8726
9
3
3

Parts
16 309967A
Ref. No. 2, Dispense Kit 236058
Ref. No. 3, Hose and Fitting Kit 222072
Ref.
No. Part No.Description Qty.
2a 109151 HOSE; 1/4 npt(mbe) x 12 ft (3.7 m) 1
2b 242056 VALVE, grease dispense
See manual 309032
1
2c 114558 COUPLER, quick-disconnect 1
2d 169971 NIPPLE, quick-disconnect 1
2e 202577 Z-SWIVEL 1
2c
236058
2a
2d
2b
2e
Ref.
No. Part No.Description Qty.
3a 203320 HOSE; air, buna-N; 3/8 npt(mbe) x 6
ft (1.8 m)
1
3b 155494 UNION, 90°; 3/8 npt(m) x 3/8
npsm(f) swivel
1
3c 109150 HOSE; fluid, buna-N; 1/4 npt(mbe) x
6 ft (1.8 m)
1
3d 155541 UNION, 90°; 1/4 npt(m) x 1/4
npsm(f) swivel
1
3d
3c
3b
3a
222072

Parts
309967A 17
Ref. No. 7, Truck 203650
Ref. No. 8, Portable Base 203622
Ref. No. 9, CE Kit 240979
Ref.
No. Part No.Description Qty.
7a 203651 BASE, truck; bare 1
7b 101251 WHEEL 2
7c 159912 NUT, thumb, 5/16-18 2
7d 159913 CLAMP, hold down;
(for steel drums only)
2
7e 154636 WASHER, 5/8”, 16 GA 4
7f 100609 SCREW, machine, panhead; 1/4-20
x 0.375”
2
7g 101242 RING, retaining 2
7h 159924 HANDLE, truck 1
7h
7d 7c
7f
7e
7b
7g 7e
7a
203650
Ref.
No. Part No.Description Qty.
8a 191750 BASE, drum 1
8b 102547 BOLT, hex head; 5/16”-18 x 1.5” 2
8c 100214 WASHER, lock 2
8d 191747 BRACKET 2
8e 100132 WASHER, flat 2
8f 113660 RIVET 16
8g 113646 CASTER; polyurethane 4
8b
8c
8e
8d
8a
8f
8g
203622
† Attention: To comply with CE directives, the CE iden-
tification label must be affixed to the back of the cart or
to the top of the drum cover. Permanently mark the date
of assembly on the label.
Ref.
No. Part No.Description Qty.
9a 156849 NIPPLE 1
9b 109075 REGULATOR, air, with gauge 1
9c 103347 VALVE, safety 1
9d 222011 CLAMP, grounding 1
9e † CE Label (not shown) 1
9c
9d
9a
9b
240979

Sound Data
18 309967A
Sound Data
See the pump instruction manual for technical data including wetted parts, port sizes, maximum air consumption,
maximum delivery, and so on. Sound data for the air motors of the pumps on these portable units is as follows:
Tested at 140 psi (1.0 MPa, 10 bar) at 100 cycles per minute
Sound Pressure Level, measured at 1 meter from unit 77.8 dB(A)
Sound Power Level, tested in accordance with ISO 9614-2 85.6 dB(A)

309967A 19

All written and visual data contained in this document reflects the latest product information available at the time of publication.
Graco reserves the right to make changes at any time without notice.
This manual contains English. MM 309967
Graco Headquarters: Minneapolis
International Offices: Belgium, China, Japan, Korea
GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440-1441
www.graco.com
8/2007
Graco Standard Warranty
Graco warrants all equipment referenced in this document which is manufactured by Graco and bearing its name to be free from defects in
material and workmanship on the date of sale to the original purchaser for use. With the exception of any special, extended, or limited warranty
published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by
Graco to be defective. This warranty applies only when the equipment is installed, operated and maintained in accordance with Graco’s written
recommendations.
This warranty does not cover, and Graco shall not be liable for general wear and tear, or any malfunction, damage or wear caused by faulty
installation, misapplication, abrasion, corrosion, inadequate or improper maintenance, negligence, accident, tampering, or substitution of
non-Graco component parts. Nor shall Graco be liable for malfunction, damage or wear caused by the incompatibility of Graco equipment with
structures, accessories, equipment or materials not supplied by Graco, or the improper design, manufacture, installation, operation or
maintenance of structures, accessories, equipment or materials not supplied by Graco.
This warranty is conditioned upon the prepaid return of the equipment claimed to be defective to an authorized Graco distributor for verification of
the claimed defect. If the claimed defect is verified, Graco will repair or replace free of charge any defective parts. The equipment will be returned
to the original purchaser transportation prepaid. If inspection of the equipment does not disclose any defect in material or workmanship, repairs will
be made at a reasonable charge, which charges may include the costs of parts, labor, and transportation.
THIS WARRANTY IS EXCLUSIVE, AND IS IN LIEU OF ANY OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED
TO WARRANTY OF MERCHANTABILITY OR WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE.
Graco’s sole obligation and buyer’s sole remedy for any breach of warranty shall be as set forth above. The buyer agrees that no other remedy
(including, but not limited to, incidental or consequential damages for lost profits, lost sales, injury to person or property, or any other incidental or
consequential loss) shall be available. Any action for breach of warranty must be brought within two (2) years of the date of sale.
GRACO MAKES NO WARRANTY, AND DISCLAIMS ALL IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, IN CONNECTION WITH ACCESSORIES, EQUIPMENT, MATERIALS OR COMPONENTS SOLD BUT NOT
MANUFACTURED BY GRACO. These items sold, but not manufactured by Graco (such as electric motors, switches, hose, etc.), are subject to
the warranty, if any, of their manufacturer. Graco will provide purchaser with reasonable assistance in making any claim for breach of these
warranties.
In no event will Graco be liable for indirect, incidental, special or consequential damages resulting from Graco supplying equipment hereunder, or
the furnishing, performance, or use of any products or other goods sold hereto, whether due to a breach of contract, breach of warranty, the
negligence of Graco, or otherwise.
FOR GRACO CANADA CUSTOMERS
The Parties acknowledge that they have required that the present document, as well as all documents, notices and legal proceedings entered into,
given or instituted pursuant hereto or relating directly or indirectly hereto, be drawn up in English. Les parties reconnaissent avoir convenu que la
rédaction du présente document sera en Anglais, ainsi que tous documents, avis et procédures judiciaires exécutés, donnés ou intentés, à la suite
de ou en rapport, directement ou indirectement, avec les procédures concernées.
Graco Information
TO PLACE AN ORDER, contact your Graco distributor or call to identify the nearest distributor.
Phone: [phone] or Toll Free: 1-800-533-9655, Fax: [phone]
