Grandstream Networks GVC3200 Installation and operating instructions

Grandstream Networks, Inc.
GVC3200 Video Conferencing System for AndroidTM
FacebookTM Messenger Application Note

GVC3200 FacebookTM Messenger Application Note
Page 1 of 14
GVC3200 FacebookTM Messenger Application Note
Index
DOWNLOAD AND INSTALL FACEBOOKTM MESSENGER......................3
USE FACEBOOKTM MESSENGER ON GVC3200 .....................................6
SIGN IN AND SIGN OUT.......................................................................................................................6
MAIN INTERFACE.................................................................................................................................8
MAKE A CALL........................................................................................................................................9
ANSWER A CALL ................................................................................................................................10
OPTIONS DURING CALL ...................................................................................................................11
CHAT....................................................................................................................................................12
GROUP................................................................................................................................................14

GVC3200 FacebookTM Messenger Application Note
Page 2 of 14
Table of Figures
GVC3200 FacebookTM Messenger Application Note
Figure 1: GVC3200 Main Screen..................................................................................................................3
Figure 2: GVC3200 Applications...................................................................................................................3
Figure 3: GVC3200 Applications->Download Google Play...........................................................................4
Figure 4: Sign In Google Account in Google Play.........................................................................................4
Figure 5: Install FacebookTM Messenger from Google Play .........................................................................4
Figure 6: Sign In FacebookTM Messenger with FacebookTM Account...........................................................6
Figure 7: Sign In FacebookTM Messenger with Phone Number....................................................................7
Figure 8: Settings->System->Apps->Messenger..........................................................................................7
Figure 9: Clear Data to Sign Out from Messenger........................................................................................8
Figure 10: Main Interface..............................................................................................................................9
Figure 11: Make a Call ..................................................................................................................................9
Figure 12: Incoming Video Call...................................................................................................................10
Figure 13: Incoming Audio Call...................................................................................................................11
Figure 14: Chat Options..............................................................................................................................13
Figure 15: Messenger Chat Icon on GVC3200 Main Screen .....................................................................13
Figure 16: Group in FacebookTM Messenger..............................................................................................14

GVC3200 FacebookTM Messenger Application Note
Page 3 of 14
DOWNLOAD AND INSTALL FACEBOOKTM MESSENGER
The latest FacebookTM Messengerapplication can be downloaded from Google Play Store. Here are the
application downloading steps on GVC3200:
1. On the GVC3200 main screen, select “Applications”.
Figure 1: GVC3200 Main Screen
2. Select “GS Market”.
Figure 2: GVC3200 Applications

GVC3200 FacebookTM Messenger Application Note
Page 4 of 14
3. Select “Google Play”to download, and it will be installed on the GVC3200.
Figure 3: GVC3200 Applications->Download Google Play
4. Open Google Play and sign in with your Google account.
Figure 4: Sign In Google Account in Google Play
5. In Google Play, search for FacebookTM Messenger, and install the application.
Figure 5: Install FacebookTM Messenger from Google Play

GVC3200 FacebookTM Messenger Application Note
Page 5 of 14
Note:
When there is an updated version of FacebookTM Messenger in Google Play, users could go to GVC3200
main menu->Applications to open Google Play->Messenger, and then select “Update”to update the app
on the GVC3200.

GVC3200 FacebookTM Messenger Application Note
Page 6 of 14
USE FACEBOOKTM MESSENGER ON GVC3200
On GVC3200, FacebookTM Messenger works similarly as on other AndroidTM platform devices. This
section describes the main functions such as making call, receiving calls and other behaviors when
Messenger app is used on GVC3200.
SIGN IN AND SIGN OUT
Open FacebookTM Messenger from GVC3200 main screen->Applications. The user must have a
FacebookTM account, or have a phone number ready for signing in.
In the following sign-in interface, use the GVC3200 remote control trackpad to tap on the “Email or phone”
and “Password”fields to activate the onscreen keyboard and enter login credentials. Then tap on
“Continue”.
Figure 6: Sign In FacebookTM Messenger with FacebookTM Account
In the following sign-in interface, use the GVC3200 remote control trackpad to tap on the “Phone Number”
field and enter phone number for signing in. Then, users need to tap on “Continue”.

GVC3200 FacebookTM Messenger Application Note
Page 7 of 14
Figure 7: Sign In FacebookTM Messenger with Phone Number
There is no Sign Out option in FacebookTM Messenger app. If the user would like to log off while keeping
the app on the GVC3200, go to the GVC3200 main screen->Settings->System->Apps. Locate the
Messenger app and tap on “Clear Data”. The account in FacebookTM Messenger will be signed out.
Figure 8: Settings->System->Apps->Messenger

GVC3200 FacebookTM Messenger Application Note
Page 8 of 14
Figure 9: Clear Data to Sign Out from Messenger
Note:
If the user has already signed in FacebookTM Messenger on the GVC3200, by default it will always
automatically signed in after the GVC3200 reboots.
MAIN INTERFACE
Open FacebookTM Messenger on the GVC3200, and the user could use the GVC3200 remote control
keypad and trackpad to navigate the functions.

GVC3200 FacebookTM Messenger Application Note
Page 9 of 14
Figure 10: Main Interface
Note:
When using the app, the user will need use both navigation keys and trackpad of the GVC3200 remote
control for the functions.
MAKE A CALL
1. Select a contact in the messege list. Click on OK on the remote control to open it.
2. Click on the video call icon, or the audio call icon to make a call to the contact.
Figure 11: Make a Call
Message
List
Group
Directory
Settings
Search for
People/Group
Make a call
Chat

GVC3200 FacebookTM Messenger Application Note
Page 10 of 14
Note:
Video calling is available between FacebookTM Messenger apps on mobile devices. The call between
mobile device and desktop client is audio only at the moment, which relies on the capability of FacebookTM
Messenger app/client.
ANSWER A CALL
When there is an incoming call, the caller’s profile picture and name will be displayed in the notification
screen.
Figure 12: Incoming Video Call
Reject Call
Video Answer

GVC3200 FacebookTM Messenger Application Note
Page 11 of 14
Figure 13: Incoming Audio Call
OPTIONS DURING CALL
During the call with FacebookTM Messenger, users have the following options.
Mute
Video ON / Video OFF
PTZ Control
To adjust PTZ for GVC3200 camera during Messenger call,
1. Press the CAMERA button on the GVC3200 remote control. A UP/DOWN/LEFT/RIGHT panel will be
shown up in the middle of the screen.
2. Press UP/DOWN/LEFT/RIGHT on GVC3200 remote control to adjust position, and press ZOOM
IN/ZOOM OUT buttons on GVC3200 remote control trackpad to adjust zoom.
3. Press BACK button on the GVC3200 remote control trackpad to exit PTZ mode.
4. Go to GVC3200 Applications and open Messenger again to return to the call.
Reject Call
Audio Answer

GVC3200 FacebookTM Messenger Application Note
Page 12 of 14
Note:
1. Besides the above options, users could also use the BACK function key on GVC3200 remote
control trackpad to go back to the previous interface within FacebookTM Messenger app.
2. Function keys on GVC3200 remote control such as MUTE, End Call, PIP, and Presentation will
not work during calls using FacebookTM Messenger. Users need to use the trackpad to navigate
and select options/icons in FacebookTM Messenger, in order to use the supported functions by
FacebookTM Messenger.
3. During an ongoing call, if another user tries to call the Messenger user, it will show the user is
currently in another call.
4. Bridging SIP call with FacebookTM Messenger call is currently not supported on the GVC3200.
CHAT
On GVC3200, users can use Messenger to chat with other individuals or in groups. An external keyboard
connected via USB or Bluetooth to the GVC3200 is recommended for chat.
The following functions can be used by the Messenger app installed on GVC3200.
Send text
Send Emoji
Send photo
Take a photo or video clip to send
Record voice to send
The options are located on the bottom of the chat window.

GVC3200 FacebookTM Messenger Application Note
Page 13 of 14
Figure 14: Chat Options
If the FacebookTM Messenger is running in the background of the GVC3200, the user will get a notification
icon on the GVC3200 screen when there is a new message from chat. It’s a small round floating icon with
the profile picture of the message sender. The user could use the GVC3200 remote control trackpad to
drag it to other location of the screen. Tapping on that icon will open the chat to retrieve the message.
Figure 15: Messenger Chat Icon on GVC3200 Main Screen

GVC3200 FacebookTM Messenger Application Note
Page 14 of 14
GROUP
On the Messenger app, use the GVC3200 remote control to navigate to “Group”tab. Users could view the
current groups with the members’names listed, create new group, and select a group to initiate
conversation.
Figure 16: Group in FacebookTM Messenger
*Android is a Registered Trademark of Google, Inc.
*FacebookTM is a registered trademark Facebook Inc.
