Grandstream Networks GDS3710 User manual

For Warranty and RMA information, please visit
www.grandstream.com
Grandstream Networks, Inc.
126 Brookline Ave, 3rd Floor
Boston, MA 02215. USA
Tel : [phone] - 9300
Fax: [phone] - 1987
www.grandstream.com In-Wall Mounting Kit
Quick Reference Guide
(GDS3710 NOT Included)

Content
English......................................................1

.1. .2.
EN
PRECAUTIONS
PACKAGE CONTENTS
• Please follow local building code and electrical
code to install the device.
• Suggest to install the device with bottom line
around 50~55 inches above the ground lever.
• Please refer to Grnadstream website for more
updated Online Documents like:
QIG:
www.grandstream.com/sites/default/files/
Resources/GDS3710_QIG.pdf
User Manual:
www.grandstream.com/sites/default/files/
Resources/GDS3710_UserManual.pdf
FAQ:
www.grandstream.com/our-products
1 x Cover Plate
1 x Quick
Reference Guide
1 x Plastic Box 1 x Drill Template
1 x Anti-Tamper
Hex Key
1 x Metal Frame
(For Stud Mount)
In-Wall Mounting Kit
Quick Reference Guide
(GDS3710 NOT Included)

.4.
Solid Wall Installation
Please follow below steps to install the device into solid wall.
Step 1: Use provided Drill Template to mark boundary then
dig a rectangle hole into the wall (drilling or dig
tools not provided) .
The depth of hole is 35 mm (or 1.38 inch), marked
in the template (rotating it to measure if necessary) .
Step 2: Mount the Installation Bracket into the Plastic Box
using supplied Screws(2).
.3.
6 x Screws
(Fix Plastic box
on Meta Frame)
6 x Anti-Tamper
Screws
6 x Screws
(Fix the Bracket
into Plastic Box)
6 x Anchor & Screw
Set (Mount the Plastic
Box into Solid Wall)
6 x Nuts
(Fix Plastic Box on
the Meta Frame)
(1) (2)
(5)(4)
(3)
(4)
6 x Nuts
(Fix Plastic Box on
the Meta Frame)
35mm(or 1.38 inch)
PA3.5*35mm PM3*10mm PM3*12mm
M3 M3 PM3*12mm
193.8mm(or 7.63 inch)
99.8mm(or 3.93 inch)

.5.
Step 3: Use provided Anchor/Screw(1) to mount the
Plastic Box inside the hole just digged.
Step 4: Follow GDS3710 QIG and User Manual to connect
wires to the PoE switch or PoE Injector. Connect the
Electrical Lock acoording to its document.
Step 5: Align the bracket clips, press and push down
the GDS3710 into place.
Step 6: Install the Cover Plate and fix it using the Hex Key
with the Anti-Tamper Screws
(Result after installation.
GDS3710 NOT included)
.6.
(5) provided.

.8. .7.
Stud Installation
Please follow below steps to install the device at the stud of
a new building open wall,or a finished wall.
Step 1: For finished wall,use provided Drill Template to
mark boundary and dig a rectangle hole into the
wall. For open wall, skip and go to next step.
Step 2: Install the Metal Frame with short edge to the stud
using the set of Anchor/Screw(1) provided.
Step 3: Mount the Installation Bracket into the Plastic Box
using supplied Screws(2).
Step 4: Use provided Screws and Nuts(3)(4) to install the
Plastic Box on the long edge of the Metal Frame.
Choose either set of Nuts(4) with convenience.
or
Max: 203.2 mm(or 8 inch)
35mm
(or 1.38 inch)

.9.
Step 5: Follow GDS3710 QIG and User Manual to connect
wires to the PoE switch or PoE Injector. Connect the
Electrical Lock acoording to its document.
Step 6: Align the bracket clips, press and push down the
GDS3710 into place.
Step 7: Install the Cover Plate and fix it using the Hex Key
with the Anti-Tamper Screws(5) provided.
.10.
(Result after installation.
GDS3710 NOT included)

.11. .12.
Step 2: Mount the Installation Bracket into the Plastic Box
using supplied Screws(2).
Step 3: Insert the Plastic Box into the cutted hole properly.
Step 4: Tighten the four clamps alternately in diagonal to
mount the Plastic Box on the wall. Please do NOT
over tighten to avoid damaging the wall or clamp.
Drywall (Hollow Wall) Installation
Please follow below steps to install the device on a drywall or
hollow wall. The thickness of the wall where the clamps can
handle is among 6.2 ~ 24 mm (or 0.24 ~ 0.94 inch)
Step 1: Use provided Drill Template to mark boundary then
cut opening on the dry wall. Do NOT over cut.
(wall cutting tools not provided)
193.8mm(or 7.63 inch)
99.8mm(or 3.93 inch)

Install the Cover Plate and fix it using the Hex Key
with the Anti-Tamper Screws(5) provided.
(Result after installation.
GDS3710 NOT included)
.13.
Step 6: Align the bracket clips, press and push down
the GDS3710 into place.
Step 7:
Step 5: Follow GDS3710 QIG and User Manual to connect
wires to the PoE switch or PoE Injector. Connect the
Electrical Lock acoording to its document.
