Grandstream Networks GXP2130 Series User manual

Grandstream Networks, Inc.
126 Brookline Ave, 3rd Floor
Boston, MA 02215
Voice: [phone]
Fax: [phone]
www.grandstream.com
For Warranty and RMA information, please visit www.grandstream.com
GXP2130 Enterprise IP Phone
Quick Installation Guide

English...............................................................................1
简体中文..........................................................................7
Español............................................................................13
Français...........................................................................19
Deutsch............................................................................25
Italiano.............................................................................31
Русскй............................................................................37
Português....................................................................... 43
Polski............................................................................. 49
Content

1 2
The GXP2130 is not pre-congured to support or
carry emergency calls to any type of hospital, law
enorcement agency, medical care unit (“Emergency
Service(s)”) or any other kind oEmergency Service.
You must make additional arrangements to access
Emergency Services. It is Your responsibility to
purchase SIP-compliant Internet telephone service,
properly congure the GXP2130 to use that service,
and periodically test your conguration to conrm
that it works as You expect. IYou do not do so, it
is Your responsibility to purchase traditional wireless
or landline telephone services to access Emergency
Services.
GRANDSTREAM DOES NOT PROVIDE
CONNECTIONS TO EMERGENCY SERVICES VIA
THE GXP2130. NEITHER GRANDSTREAM NOR
ITS OFFICERS, EMPLOYEES OR AFFILIATES MAY
BE HELD LIABLE FOR ANY CLAIM, DAMAGE, OR
LOSS, AND YOU HEREBY WAIVE ANY AND ALL
SUCH CLAIMS OR CAUSES OF ACTION ARISING
FROM OR RELATING TO YOUR INABILITY TO
USE THE GXP2130 TO CONTACT EMERGENCY
SERVICES, AND YOUR FAILURE TO MAKE
ADDITIONAL ARRANGEMENTS TO ACCESS
EMERGENCY SERVICES IN ACCORDANCE WITH
THE IMMEDIATELY PRECEDING PARAGRAPH.
PACKAGE CONTENTS:
OVERVIEW:
EN
WARNING: Please DO NOT power cycle the GXP2130 during system boot
up or rmware upgrade. You may corrupt rmware images and cause the unit to
malunction.
1 x GXP2130 Main Case 1 x Handset
1 x Phone Cord1 x Ethernet Cable 1 x Phone Stand
1 x 12V Power adapter
1 x Quick Installation
Guide / 1 x GPL License 1 x Wall Mount
The GXP2130 is a state-o-the-art enterprise grade IP phone that eatures up to 3
lines, 2.8 inch TFT Color LCD, 4 XML programmable context-sensitive sot keys,
8 programmable BLF extension keys, dual Gigabit network ports, integrated PoE
and Bluetooth (V2 only), 4-way voice conerencing, and Electronic Hook Switch
(EHS). The GXP2130 delivers superior HD audio quality on the handset and
speakerphone, rich and leading edge telephony eatures, personalized inorma-
tion and customizable application service, automated provisioning or easy de-
ployment, advanced security protection or privacy, and broad interoperability with
most 3rd party SIP devices and leading SIP/NGN/IMS platorms.
PRECAUTIONS:
WARNING: Use only the power adapter included in the GXP2130 package.
Using an alternative non-qualied power adapter may possibly damage the unit.
12V
BLF Labels

3 4
CONNECTING THE PHONE
PHONE SETUP:
PC Port LAN Port Power Headset Port Handset Port
Installing the Phone (Phone Stand):
For installing the phone on the table with the phone stand, attach the phone stand
to the bottom othe phone where there is a slot or the phone stand (upper part,
bottom part).
Installing the Phone (Wall Mount):
1. Attach the wall mount to the slot on the back othe phone.
2. Attach the phone to the wall via the wall mount hole.
3. Pull out the tab rom the handset cradle (See gure below).
4. Rotate the tab and plug it back into the slot with the extension up to hold the
handset while the phone is mounted on the wall (See gure below).
Tab with extension up
Handset rest
Tab with extension down
DC12PC LAN HEADSET HANDSET
Slots for the wall
mount and phone
stand
DC12PC LAN HEADSET HANDSET
Installing BLF Paper Label:
1. Install the paper label under the plastic notches on the phone and gently lay the
paper down on the phone surace.
2. Install the plastic cover over the paper label by inserting the cover under the
plastic notches on the phone.
Label
Cover

5 6
Note: For the detailed user manual, please download rom:
http://www.grandstream.com/support
This product is covered by one or more othe U.S. patents (and any oreign patent
counterparts thereto) identied at www.cmspatents.com.
Tips For Using the Keypad:
PHONE CONFIGURATION:
Confgure the GXP2130 using Web Browser:
1. To access the MENU, press the round MENU button.
2. Navigate the menu by using the UP/DOWN and LEFT/RIGHT buttons.
3. Press the round MENU button to conrm a menu selection.
4. The phone automatically exits MENU mode with an incoming call, the phone
goes o-hook or the MENU mode is let idle or 60 seconds.
1. Ensure your phone is powered up and connected to the Internet.
2. Press the UP button to see the IP address.
3. Type the phone’s IP address in your PC browser.
4. The deault administrator username and password are “admin”; the deault end-
user username is “user“ and the password is “123”.
Confgure the GXP2130 using the Keypad:
1. Make sure the phone is idle.
2. Press the MENU button to access the keypad MENU to congure the phone.
3. Select MENU-> Phone-> SIP-> Account to congure settings or SIP Proxy,
Outbound Proxy, SIP User ID, SIP Auth ID and SIP Password.
4. Follow MENU options to congure the basic eatures othe phone. For
example: the IP address iusing a static IP. For details, please check GXP2130
User Manual.
5. Please contact your ITSP (Internet Telephony Service Provider) or additional
settings that may be necessary to congure the phone.
Message Waiting
Indicator
Multi-Purpose keys
Message
Contacts
Transfer
Hold
Headset
Conference
Mute
Standard Keypad
Navigation keys
Send
Line keys
Soft keys
Volume
Speaker
Menu/OK Key
To setup the GXP2130, ollow the steps below:
1. Connect the handset and main phone case with the phone cord.
2. Connect the LAN port othe phone to the RJ-45 socket oa hub/switch or a
router (LAN side othe router) using the Ethernet cable.
3. Connect the 12V DC output plug to the power jack on the phone; plug the power
adapter into an electrical outlet.
4. The LCD will display provisioning or rmware upgrade inormation. Beore con-
tinuing, please wait or the date/time display to show up.
5. Using the phone embedded web server or keypad conguration menu, you can
urther congure the phone using either a static IP or DHCP.
