Grange 222308B002MMBZ01C1 User manual

CONTEMPORARY ARBOUR
CONTARB 220cm [H] x 150cm [W] x 70cm [D]
222308B002MMBZ01C1
18_06_2020
www.grangefencing.co.uk

BEFORE YOU START
Check the pack/s and make sure that you have all of the parts listed below.
If not, contact your retailer who will be able to help you.
When you are ready to start make sure you have the right tools to hand, plenty of space
with a clean and dry area for assembly.
It is advisable for two people to carry out the work.
Where the wood is screwed we advise to pre-drill the holes (the diameter of the holes
should be 2mm smaller than the diameter of the used screw)
HEALTH AND SAFETY
Do not lean or stand on the roof assembly at any time - the structure is not of a load
bearing design.
Do not overreach when working from the step ladder
In order to reduce the risk of suffocation please keep all plastic bags and small parts
away from children.
[email protected]

Hardware pack
Screws
3,5 cm
x82
Recommended tools ( not included )
[w]
[v]
Wooden Dowels
x8
[y]
Screws
10 cm
x4
[x]
Screws
7,0 cm
x20
ASide Panels x2
BRoof Beams x2
CArbour Seat x1
DSeat Back x1
ERoof Slats x1

1
FOOTPRINT
PLAN
150 cm
70 cm
70 cm 150 cm
220 cm

22
A
A
C

23
45 cm
[x]
x16

22
D
24

25

26
[x]
x4

B
B
27
[v]

28
[w]
x4

E
29

210
x82
[y]

Your item is ready!
211
